Decision Making and Reasoning with Uncertain Image and Sensor Data

1
Decision Making and Reasoning with Uncertain
Image and Sensor Data

• Pramod K Varshney
• Kishan G Mehrotra
• Chilukuri K Mohan

2
Main Themes

• Decentralized decision-making
• Multiple uncertain information streams
• Dynamically changing environments
• Algorithms for realistic battlefield scenarios

3
What is the agents current location?
What activities are other agents involved in?
What is the likelihood of damage at various
locations?
What would be the safest paths to a goal/exit
zone?
4
Main Contributions

• Scenario recognition from video sequences
• Improved activity recognition with audiovideo
  information
• Development of new algorithms for path planning
  in a battlefield
• Formulation of path planning as a multi-objective
  optimization problem
• Development of a new multi-objective evolutionary
  algorithm

5
1. Scenario Recognition and Classification

• Event recognition and scene analysis with real
  time visual and audio information

6
Problem Formulation

• Detect moving objects and classify activities
• Identify sounds indicative of specific events
• Quantify uncertainty in activity classification
• Develop an enhanced scene representation by
  integrating audio and visual information
• Related work

7
1.1.Video Component

• Goal To detect and track moving objects and
  classify activity in real time
• Input real time video stream
• Output detected moving object and activity
  classification

8
Video Processing Pipeline (contd.)

• Goal Recognition of a moving objects activities
  from a sequence of images (video)

Low Level Processing -Filtering -Detection -Tracki
ng -Feature Extraction
High Level Processing -Frame Classification -Sce
nario Recognition
Sequence of Frames
Extracted Features
Extracted Scenarios
9
Video Processing Pipeline
Real time Video Acquisition
Detection
Tracking
Scene Description Generator
Feature extraction
Classification
Visualization
10
Features Extracted

• Aspect Ratio (AR) d / (abc)
• Relative Upper Density (RUD) a / (abc)
• Relative Middle Density (RMD) b / (abc)
• Relative Lower Density (RLD) c / (abc)
• Velocity and centroid
•

•

• a
•

•

• b
•

•
  c

11
Video Feature Analysis Example
Feature Walking Bending AR 0.2
0.3 RUD 0.3 0.2 RMD
0.4 0.5 RLD 0.3
0.3
Figure 1
Figure 2
12
Classification Algorithms Used for Activity
Detection

• Multi-module back-propagation neural network
• Inductive Decision Tree Learning (C5) algorithm
• Control Chart Approach
• Bayesian networks

13
Visualization of Activity with Uncertainty Measure

• Example activities
• shown here sitting, bending
• and standing
• Uncertainty is calculated
• from classifier output, for
• each event
• The blue pointer indicates
• the level of certainty in the
• classifier decision

14
Control Chart Approach for Video Activity
Classification

• Control Chart indicates the variation in the
  values of some feature over time, with graphical
  depiction of the upper and lower control limits
  for that feature.
• High level detection with control charts
• Identification of each activity.
• Recognition of when the activity begins and ends.

15
Control Chart Example (with Upper and Lower
Control Limits for each activity)
detail
16
1.2.Why Audio?

17
Role of Audio Component

• Obtain information which may not be acquired
  visually
• Provide additional comprehensive information
  enriching the scene context
• Due to large number of potential sounds to
  identify, the scope of problem is very vast

18
Audio Processing

• Goal To detect and classify sounds indicative of
  specific events
• Input A sample of sound in real time
• Output Detected class of specific sound
• Example sound samples indicate specific
  objects/events such as explosions and vehicles

19
Whats New?

• Fusion of audio and video for surveillance and
  scene analysis
• New audio features - Spectrum shape modeling
  coefficients

20
Audio Processing Pipeline
Audio acquisition
Linear predictive coding /Cepstral
coefficients
Histogram Features
Spectral Features
Relative Band Energies
Choose features
Multi Module back-propagation Neural Networks
21
Audio Features

• Amplitude Histogram Features (width, symmetry,
  skewness and kurtosis calculated on a histogram
  of a 3 second clip)

• Spectral Centroid and Zero Crossing Rate
• Relative Band energies

• Linear Predictive Coding Coefficients
• Cepstral Coefficients

• Spectrum shape modeling coefficients

• What and why?

22
Audio Enhanced Visual Processing
Fusion
Video Processing and Classification
Visualization
Video Acquisition
Uncertainty
Audio Processing and Classification
Description Generation
Sound Acquisition
23
Audio Visual Classes

• 3 classes of video events
• Sitting
• Standing
• Bending
• 4 classes of sound events are considered
• Silence
• Clear Speech
• Babble or Speech in noise
• Alarm sounds (smoke detector class)

24
Prototype Demonstration
25
Experimental Results - Video

• Sub-scenario recognition accuracy of Control
  Chart approach

Video Number of Frames Number of sub-scenarios Number of recognized sub-scenarios
1 823 11 10
2 512 6 6
3 701 12 12
4 514 9 10
26
Experimental Results - Video

• We used 4 different video sequences. Total 2250
  feature vectors, 1072 were used in the training
  and rest of the 1478 vectors were used in the
  testing.
• Classification Accuracy using different methods
• Neural Network (back-propagation) 91.34
• Decision Tree (C5) 92.86
• Naive Bayesian Network 89.61
• Control Chart 95.70

27
Experimental Results - Audio

• In this 4 class problem, we obtain classification
  accuracy of 92 on recorded data (off-line
  classification)
• 75 for real time classification in the
  laboratory acoustic environment
• Acoustics of each environment can be different,
  leading to misclassifications
• Characteristics of the recording equipment

28
1.3.Representation Scheme

• Audio and visual processing yields information
  about scene context
• Need for representation scheme for acquired audio
  video information
• Generation of a document containing audio-visual
  information, which can be further processed

29
XML Based Description

• We chose an XML based representation
• Widely accepted standard for information exchange
• More comprehensive forms such as XML schema will
  be used for representation
• MPEG standards use XML based Audio visual content
  management
• Semi structured, allowing for addition of user
  defined data and information
• An XML based representation allows for
  standardization, flexibility and extendibility
• Automatic generation of XML based description
• Descriptor gives the state of observed scenario
  over a certain time period

30
Example Descriptor
Header
Moving object Features and activity class
Complete descriptor
31
Descriptor Utility

• The combined audio visual descriptor can serve as
  a base for
• Data mining for unusual events or correlation
  between events and activities
• Building case libraries of interesting scenarios
  or for particular cases
• Audio-visual fusion and visualization

32
Discussion

• We have shown the feasibility of activity
  recognition using combined video and audio
  information.
• Future work integration, extension, elaboration
• Next section (path planning) after activity
  recognition, battlefield decision-maker must act.

33
2. Personnel Movement Planning in a Battlefield

• Path computation algorithms for risk minimization

34
2.1 Path Planning in a Battlefield

• Goal To determine (escape) paths for personnel
  in a battlefield
• Input A node weighted graph with each node
  representing a geographical location of a
  battlefield whose weight corresponds to the
  associated risk.
• Quality Measure The quality of an escape path is
  determined by cumulative risk of the path

35
Problem Formulation

• A path P is a non cyclic sequence (L1,L2.Ln)
  where L1 is the initial location of personnel, Ln
  is a target or exit point, and each Li is
  adjacent to Li1 in the graph.
• Determine escape paths which maximize path
  quality Q(P) defined as
• k
• Q(P) ? log(1-risk(Li))
• i1

36
Modeling Risks

• We define risk as the probability of occurrence
  of a high level of damage to personnel traversing
  a path
• Two probabilistic risk models
• Gaussian Distribution - models risks due to
• specific events such as explosion and chemical
  threats
• Beta Distribution - models risks due to
  distribution of events through the entire
  geographical region

37
Modeling Risks with Gaussian Distribution
38
Algorithms for Path Planning

• Uniform Cost Search finds the optimal solution
  (Dijkstras algorithm)
• Simulated Annealing
• Evolution Strategies (ES)
• µ1 ES
• Stochastic ES
• Evolutionary Quenching Strategy (EQS)

39
Evolution Strategies

• Initialize population
• Generate offspring at each iteration from a
  population of size µ
• Replacement Strategy
• µ1 ES Deterministic replacement only
  offspring of higher quality are accepted
• Stochastic ES - Probability of replacement
• is equal to min1,Q(offspring)/Q(parent)

40
Key Principle of EQS

• An evolution strategy which accepts solutions of
  lower quality with a probability that decreases
  with increase in number of iterations (annealing
  principle)
• Ensures escape of local optimum during early
  stages of the algorithm
• Emphasizes convergence to optimal solution at
  later stages of the algorithm

41
Optimal Route Planning for Battlefield Risk
Minimization
Goal






Source
Source
42
Optimal Route Planning for Battlefield Risk
Minimization (Contd.)
Goal






Source

High risk
Moderate risk
Low risk
Risk free
43
Simulation Results

• The algorithms were simulated on a 100x100 grid
  with 15 target nodes on the periphery of the
  grid.
• In all instances of the problem, EQS approximates
  the optimal solution outperforming Simulated
  Annealing and variants of ES.
• EQS and other variants of ES require a relatively
  less computational time of 21 seconds compared to
  uniform cost search (470 seconds)

44
Performance Comparison of Different Algorithms
with a Gaussian Distribution for Risk Values
45
2.2 Multi-Objective Path Planning

• In a battlefield, a path can be evaluated with
  respect to different objectives.
• Some crucial aspects of a path to be considered
  are
• Cumulative Risk
• Length of the Path
• Reward associated with the target node

46
Multi-objective Evolutionary Algorithms

• Goal To discover a set of non dominated
  solutions with significant diversity
• Evolutionary algorithms are best suited for
  multi-objective optimization since they
  simultaneously explore multiple solutions

47
Multi-objective Evolutionary Algorithms (Contd.)

• We have implemented three multi-objective
  evolutionary algorithms for path planning problem
• Pareto Archived Evolution Strategy- J.D. Knowles
  and D.W Corne, On Metrics for comparing non
  dominated sets, in Proc. IEEE Congress on
  Evolutionary Computation (CEC02), pp.711-716,
  2002.
• Non-dominated Sorting Genetic Algorithm - K. Deb
  , S. Agarwal, A. Pratap, and T. Meyarivan, A
  fast and elitist multi-objective genetic
  algorithm NSGA II, in Proc. Parallel Problem
  Solving from Nature VI, pp.849-858, 2000.
• Evolutionary Multi-objective Crowding Algorithm

48
Evolutionary Multi-objective Crowding Algorithm
(EMOCA)

• EMOCA considers crowding density in data space
  for path planning
• Mating opportunities are given to better quality
  as well as substantially different individuals
• Stochastic acceptance criteria is used which
  depends on crowding density difference between
  parent and offspring

EMOCA Main steps
49
Multi-objective Problem Scenario
Goal-1 Goal-2


Goal-3



Source

High risk
Moderate risk
Low risk
Risk free
50
Multi-objective Problem Scenario (contd.)

• Paths are evaluated with respect to three
  different measures risk, path length and reward
• Difficult tradeoffs exist for example, should
  personnel follow a more risky path to increase
  the probability of finding a greater reward?

51
Illustrating Mutually Non Dominating Paths
P1 goal1 P2 goal2


goal3
P3


source

High risk
Moderate risk
Low risk
Risk free
52
Path Quality with respect to Different Measures
Path Risk Path length Reward
P1 0.7 9 0.2
P2 0.2 14 0.5
P3 0.7 12 1
53
Best Choice of Path
W-risk W-path length W-reward Best path
Low High Low P1
High Low Low P2
Low Low High P3
54
Performance Comparison

• We have used a well known metric C metric for
  performance comparison. Smaller values of C
  metric indicates better performance.
• We have also obtained C metric values over
  multiple trials comparing the solutions obtained
  by different algorithms for each trial
•

•


55
Simulation Results

• EMOCA outperforms NSGA II and PAES for results
  obtained over 100 trials
• EMOCA obtains more non-dominated solutions and
  has lower C metric values than other algorithms.
• The results clearly indicate that EMOCA performs
  best for the path planning application

56
C-metrics for Various Pair-wise Algorithm
Comparisons
Algorithm1 Algorithm2 C(Algorithm2, Algorithm1)
EMOCA(without crossover) PAES 0.15
EMOCA(with crossover) PAES 0.00
EMOCA (with crossover) NSGA II 0.06
57
Discussion

• Efficient algorithms for risk minimization
• Near-optimal solutions
• Modeled path planning as a multi-objective
  optimization problem
• Developed a new algorithm (EMOCA) outperforming
  state of the art multi-objective evolutionary
  algorithms

58
Future Work

• Develop multi-objective evolutionary algorithms
  for other battlefield applications such as
  wireless sensor networks employed in surveillance
  systems
• Develop algorithms for dynamic path planning
• Multiple object detection and tracking, and work
  on Multi camera platform
• Develop a comprehensive library of recognizable
  sounds to provide richer context information
• New methodologies for audio visual fusion
• Integration with VGIS

59
Mutation

• The mutation step consists of replacing a
  randomly chosen edge of the path by another sub
  path between the same nodes.
• In mutating the path a? b ? c? d? e,
• a randomly chosen edge of the path,
• say c? d, is replaced by an alternate sub-path
  c? f? h? d, yielding
• a? b? c? f? h? d? e
•

60
Simulated Annealing- main steps

• Initialize population- straight line shortest
  paths from source node to target node
• Mutation of parent to produce offspring
• Stochastic replacement with probability
• 1-e (Q(offspring)-Q(parent))/temperature

61
Mutation

• The mutation step consists of replacing a
  randomly chosen edge of the path by another sub
  path between the same nodes.
• In mutating the path a? b ? c? d? e,
• a randomly chosen edge of the path,
• say c? d, is replaced by an alternate sub-path
  c? f? h? d, yielding
• a? b? c? f? h? d? e
•

62
Multi-objective Optimization- Preliminaries

• The solution to a multi-objective optimization
  problem is a set of non-dominated vectors.
• A solution vector x dominates a solution vector y
  (xgtgty) if and only if
• ? i ? 1,.m fi(x) gt fi(y), and
• ? j ? 1,.m fj(x) gt fj(y)
• Where m is the number of objectives. X andY
  are mutually non-dominating if the above
  conditions do not hold.

63
EMOCA- Main Steps

• Initialize
• Generate mating population
• Generate offspring by crossover , mutation
• Create a new pool consisting of some parents and
  some offspring
• Trim new pool to generate population
• of next iteration

64
Crossover

• Two Point Path Crossover operator (2PTPX) which
  is less disruptive and preserves a major portion
  of the parent paths.
• Consider two parent paths S ? N1 ? N3 ? E1 and
  S ? N2 ? N4 ? E2, where N1 and N2 are at
  least four path lengths away from E1 and E2, and
  nodes N3 and N4 are a few edges away from N1 and
  N2, respectively. The crossover operator then
  generates the offspring S ? N1 ? N4 ? E2
  and S ? N2? N3 ?E1 .

65
Pareto Archived Evolution Strategy (PAES)

• Uses a local search strategy and maintains an
  archive of non-dominated solutions.
• Parent is mutated to produce offspring
• If offspring dominates parent, it is accepted
• If offspring and parent are non-dominated, then
  acceptance decision is based on the squeeze
  factor of the solutions.

66
Non-dominated Sorting Genetic Algorithm(NSGA II)

• Generates offspring population of size N from
  mating population of size N by crossover and
  mutation
• Uses binary tournament to select mating pairs
• A non dominated sorting on combined
  population(parentoffspring) is used to obtain
  mating population for next iteration

67
Crowding density

• Data space crowding density is defined as ?(P)
  L/E where L is the number of paths in the
  current population passing through each edge of
  path P, and E is total number of edges in path P

• A relatively low value of ?(P) indicates that
  path P does not share many edges with other
  paths in the population, giving it a relatively
  high diversity rank.
•

68
Salient features of EQS

• The acceptance probability of EQS depends on ?
  where ?((c(1-c)i)/?)-?, i is the current
  iteration , ? is the maximum number of
  iterations, c and ? are algorithm parameters.
• During initial stages of the algorithm, when i0,
  ?c/?-?, and the probability of acceptance is
  high. During later stages of the algorithm when
  i approaches ? ,
• ?c/?(1-c)-?, and the probability of
  accepting the offspring is relatively low.

69
Trimming New pool

• The new pool is sorted based on the primary
  criterion of non-domination rank and the
  secondary criterion of diversity rank
• The new population will consist of the first N
  elements of the sorted list containing solutions
  grouped into different frontsF1, F2,..Fn where
  elements of Fi1 are dominated only by elements
  in F1,F2 ,..Fi.

70
New Pool Generation

• The offspring is compared with one of the
  parents to form the new pool.There are three
  possible cases
• Case 1 If the offspring dominates the parent,
  then the offspring is added to the new pool.
• Case 2 If dominated by the parent, the offspring
  is added to the new pool with probability
• 1-exp(?(offspring)- ?(parent)).
• Case 3 Otherwise, if the offspring has a lower
  crowding density than the parent, then it is
  added to the new pool, else the parent is added
  to the new pool.

71
Mating Population Generation

• Binary tournament selection is iterated to
  create the mating pool
• In each step, two randomly chosen members of the
  current population are compared
• The tournament to determine who enters the mating
  population is won by the solution with lower
  total rank, the sum of its non-domination rank
  and diversity rank

72
Squeeze factor

• The squeeze factor of a candidate solution is
  the number of archive elements located in the
  same cell of the objective function space,
  assuming that this space is a finite hyper cube
  divided in to (2d)m equal sized non overlapping
  hyper cubes.

73
C-metric

• C metric calculates the fraction of
  solutions in one non-dominated set that are
  dominated by the non-dominated solutions of the
  other set.

74
Significance of audio features

• Histogram features
• Features calculated on histogram
• Width
• Symmetry
• Skewness
• Kurtosis
• Clear voice has a asymmetric
• broad histogram
• Voice in noise has a narrower
• histogram, and is more
• symmetric
• Useful in detecting modulations
• in sound

75
Other sound environments

• We conducted experiments
• To classify the following environments
• Air conditioned rooms
• Construction site
• Factory
• Rail tunnel
• Warehouse
• To distinguish between types of power tools in a
  construction setting
• Drills
• Hammers
• Generators
• Compressor
• Electric motors

76
Significance of audio features (contd)

• Spectral Centroid and Zero Crossing Rate, model
  the spectral distribution and the dominant
  frequency (pitch) of sound
• Band Relative Energies calculate the energy in
  several spectral bands. Speech mostly contains
  energy in the band below 1 khz whereas alarms
  might have a different distribution
• LPC coefficients and Cepstral Coefficients give a
  direct indication of sampled sound in time and
  querfency domain respectively

77
Complete XML descriptor
78
Related Work

• Interpretation system of dynamic scenes INRIA
  France 2003.
• Robust, Online Event Detection and Classification
  for Video Monitoring (Cornell University)
• Video Surveillance and Monitoring (Carnegie
  Mellon University 2000)
• Work dealing with situational context learning
  like Computational Auditory scene analysis,
  Wearable Audio Computing at MIT(2003), Technology
  for Enabling Awareness (TEA) project(2000)

79
Low Level Processing of video

• Moving Object Detection
• Background Subtraction
• Luminance Contrast Method
• Background/Template Updating
• Moving Object Tracking
• Dynamic Template
• Infinite Impulse Response (IIR)
• Feature Extraction
• Bounding box is identified, and useful features
  extracted from it

80
Uncertainty computation
Module 1standing
0.987
0.9063
Module 2 standing
0.01
0.0092
0.092
Module 3 sitting
0.0845
81
Spectral shape coefficients

• Divide the spectrum into 5
• bands
• Do a linear regression,find
• best fit lines for the
• spectral envelope in each
• Band
• Slopes of these lines give
• the coefficients
• Inspired by the Kates
• coefficients
• Indicate shape of spectrum

82
Frame based classification

• The mean values and standard deviations are
  computed for each feature fi and for each class
  ci to be discriminated, using the available
  training data
• For each class ci , the upper and lower bounds
  associated with the control chart are obtained
• upperBound(fk , ci ) mean(fk , ci ) ?
  fk, ci .standard deviation (fk , ci )
• lowerBound(fk , ci ) mean(fk , ci ) ?
  fk, ci . standard deviation (fk , ci )

83
Decision in Classification

• Final classification uses the majority rule.
• For instance, if standing,standing,standing,bend
  ing is the vector representing single-feature
  based classification for each of the four
  features, the final conclusion is standing.
• Ties are broken by giving priority to one
  feature
• A tie between standing and bending is broken in
  favor of Standing if the value of RUD feature
  for the candidate object is closer to
  mean(RUD,Standing) than to mean(RUD,Bending).
• A tie between standing and sitting is broken by
  AR.
• A tie between sitting and bending is broken by
  RLD.

84
Recognition of Sub-Scenario

• If c (gt0) consecutive decisions at times t,
  (t-1), ..
• (t-c1) are all different from the decision
  being made at time (t-c), then we conclude that a
  new sub-scenario had commenced at time (t-c1).
• Otherwise, we attribute the differences to noise
  and image quality, and presume that the
  sub-scenario has not changed.

85
Video features

• Features derived from the moving object used for
  activity detection are
• Aspect ratio
• Velocity
• Relative densities of pixels in upper , lower and
  middle bands of bounding box
• Coordinates of centroid of bounding box
