MOVi: Mobile Opportunistic Videoondemand

1
MOVi Mobile Opportunistic Video-on-demand
IEEE PERCOM 2008
Hayoung Yoon, JongWon Kim, Feiselia Tan, and
Robert Hsieh

• 18th, Mar., 2008
• Ph.D candidate
• Hayoung Yoon
• hyyoon_at_nm.gist.ac.kr

Networked Media Laboratory Dept. of Information
Communications Gwangju Institute of Science
Technology
National ICT Australia University of New
South Wales
Deutsche Telekom Laboratories
2
Agenda

• Background
• MOVi Architecture
• Inter-BSS Direct Link-setup
• MOVi Scheduling
• Simulation Results
• Conclusion

3
Background

• Download-and-play style multimedia P2P file
  dissemination schemes have proposed
  BlueT_at_percom2007
• We propose P2P VoD streaming in mobile wireless
  networks
• Opportunistic contact between mobile nodes
• Direct WiFi comm.
• Enlarge System capacity
• Provide QoS

Pervasive Computing
Personalized Internet Services
File Sharing Dissemination Services
WBAN / WPAN / WLAN Tech.
Location-aware Services
4
Conventional VoD vs MOVi
DR PR
DNR DSR PR
1. Better Channel Quality 2. Lower Power
Consumption 3. Higher data-rate
1. System capacity increased 2. Server load
deceased
5
MOVi Architecture
Video Contents
MOVi Server

• Assumptions
• Mobile WiFi users
• APs in infrastructure mode
• No multi-hop connections
• Segmented Contents
• P2P approach Use client cache!
• Like Bitorrent direct p2p comm.
• Centralized controls and distributed
  communications
• Challenges
• Maximize resource utilization
• Direct Peer-to-Peer Comm.
• Minimize QoS degradation
• Scheduling

- Wired Networks -
- Wireless Access Networks -
- Mobile Opportunistic Networks -
6
Direct Comm. DLS in IEEE 802.11e

• DLS (direct link setup) is optional functionality
  in IEEE 802.11e STD
• Special AP is required
• AP resolves control and relay
• Slow adaptation of DLS in real world
• Can not initiate DL (direct-link) over different
  BSS (basic subset)

Special AP
STA
STA
7
Inter-BSS Direct Link Setup

• We propose iDLS that removes BSS dependency
  initiating DL through application-layer
  end-to-end signaling
• Contribution
• Design of iDLS
• Can initiate DL over different domain of BSSs
• Does not require special hardware support
• Implementation and evaluation over real-testbed
• MADWiFi and normal AP

FA
FA
8
Scheduling Considerations

• Scheduling at MOVi Server?
• Select which pairs of MOVi Clients for P2P Comm.
• Select MOVi Clients download from downlink
  (AP-path)
• Can we minimize the playout quality degradation
• Minimize buffer underflow
• Remaining-buffering time-based scheduling

MOVi Server
Longest Playout buffer
Second Shortest Playout buffer
Shortest Playout buffer
CONTACT Range
need to download from
9
MS Scheduler Design (2)

• Is making multiple number of simultaneous P2P
  sessions beneficial?
• No, it is not resilient to the mobility
• Some sessions share interference range
  increasing session duration
• We schedule P2P sessions to achieve burst P2P
  communications

MOVi Server
need
10
Simulation Configurations

• Topology
• 8APs (all APs are connected to MS through wired
  line)
• 1050 MCs
• Mobility Trace from Crawdad dataset Kim_at_INFOCOM
  2006
• PHY
• Set Same Freq. for all APs
• IEEE 802.11a (8 different bit-rate)
• ARF (Auto-rate Fallback)
• MAC
• EDCA (high priority for controls and the low for
  data TX)
• APP
• Request rate, filesize, video playout rate is
  from YouTube measurement Youtube_at_MOBISYS

1km
1km
11
What to compare?

• Compare the performance of CVoD (Conventional
  VoD) and MOVi
• QoS variation w.r.t the number of users
• Capacity w.r.t the buffering time
• Number of users meet target QoS-level
• Power consumption for communication

12
Performance Metric

• Metric for video quality
• Playout continuity Index

• Expressed over (-inf,1)
• The higher the better quality
• PCI 0.95 is normally regarded as target
  performance

13
Simulation Results
Play Continuity Index MOVi and CVoD Performance
Comparison
14
Simulation Results
of MCs MOVi and CVoD Performance Comparison
15
Simulation Results
PHY-rate Distribution over TX/RX packets MOVi
and CVoD Performance Comparison
54Mbps
48Mbps
54Mbps
36Mbps
48Mbps
36Mbps
24Mbps
24Mbps
MOVi
CVOD
16
Simulation Results
Battery Consumption for TX packets MOVi and
CVoD Performance Comparison
17
Simulation Results
Battery Consumption for RX packets MOVi and
CVoD Performance Comparison
18
Simulation Results
Battery Consumption for RXTX packets MOVi and
CVoD Performance Comparison
19
Conclusion

• MOVi provides P2P-based VoD services in IEEE
  802.11 mobile networks
• Playout quality and number of users MOVi can
  provide is roughly 200 of what CVoD can
• Better wireless channel utilization through
  direct peer-to-peer comm.
• Maintain battery consumption rate
• Validate in real testbed (please see the paper)
• We are now working on extending MOVi in the
  multi-channel environment

20
Experiment Setup

• Implement MOVi using MADWiFi and VLC on Linux
• 10 times of iterations and get average PCI
  performance

21
Experiment Results
Sorted MOVi and CVoD PCI Performance Comparison
22
Experiment Results
Experiment and Simulation Validation
23
Appendix VoD issues

• Video On-Demand (VoD) provides highly flexible
  streaming service to end-users
• Known issues in VoD service are
• Efficiency
• Multiple copies
• Scalability
• Centralized design
• Reliability
• No perfect transport protocol

Contents
T1
T2
24
Appendix Scalability Issues in VoD Service
main Server

• System
• Distributed Servers
• A lot of idea in reducing workload at the server
• Bandwidth
• Too much workload in Core network
• Caching Caching_at_ICN02
• CDN Utube_at_Mobisys07
• P2P Approaches Coolstreaming P2cast

Server
Server
CDN
CDN
T1
T2
25
Appendix VoD in Wireless Networks

• Access networks are infrastructure wireless
  network
• WCore WAccess
• P2P strategy is not good idea
• Double resource consumption problem
• E2E throughput degradations due to multi-hop
  forwarding
• CDN is limited
• Relatively small bandwidth of wireless networks
• Need a novel way to enhance the utilization of
  wireless network regarding VoD application
  characteristics!
