Transforming the Representation of Lexical Knowledge

1
Transforming the Representation of Lexical
Knowledge

• Christopher Manning
• University of Sydney
• http//www.sultry.arts.usyd.edu.au/cmanning/

2
Project Objectives

• Aims of the project
• examining the richness of lexical structure, in
  particular the connotational and figurative use
  of words
• providing innovative ways for representing a
  dictionary, through creative use of the medium of
  computers
• augmenting dictionaries from corpora
• to be able to provide practical educationally
  useful programs as a result (at low labor cost)
• Main initial target an interactive front end for
  exploring or using the Warlpiri dictionary.

3
Acknowledgements

• Ken Hale, Mary Laughren, Jane Simpson, Robert
  Hoogenraad, David Nash, Kay Ross
• Kevin Jansz, Nitin Indurkhya, Katrina Avila
• Susan Poetsch, Miriam Corris, John Henderson
• (and many others)

4
Talk Outline

• The research agendas
• Dictionary usability and usefulness
• Kirrkirr A Warlpiri dictionary browser
• Underlying data
• User interface and visualization
• Corpus enrichment for terminology sets
• User study

5
Research Program Lexicon

• A lexicon is not just words but a vast network of
  associations between words and within and across
  the concepts represented by words
• The aim of this work is to provide people with a
  better understanding of this conceptual map.
• E.g., patterns of figurative extension in a song
  about a stockman driving a car glass is used
  first for the windscreen, and then metaphorically
  for sexual attraction, using a systematic
  pattern of figuration between shining and sex

6
Lexicon (cont)

• Traditional paper dictionaries offer very limited
  ways for making such networks visible
• On a computer, one can imagine all sorts of ways
  of bringing out such relationships

7
Research Computational Lexicography

• Dictionaries on computers are now commonplace
• But there has been little attempt to utilize the
  potential of the new medium
• Goal fun dictionary tools that are effective for
  language learning, browsing, and research
• Special interest dictionaries for minority
  languages. Here economic, motivational, and user
  support reasons all point to an important role
  for computers.

8
MRD Structure

• The internal structures of current Machine
  Readable Dictionaries usually merely mimic the
  structure of the printed form (Boguraev 1990)
• Some work, notably WordNet (Miller 1995) has
  involved a fundamental rethinking of dictionary
  content and organization (here, organization via
  synsets which are related via links of part,
  subkind, opposite)
• But this research hasnt been taken to users.

9
Research Program Education

• Dictionary structure and usability are often
  dictated by professional linguists, while the
  needs of others (speakers, semi-speakers, young
  users, second language learners) are not met
• Weiner (1994) The initial purpose of the OED
• to create a record of vocabulary so that English
  literature could be understood by all. But
  English scholarship grew up and lexicography grew
  with it inevitably parting company with the man
  in the street.
• Challenge is to avoid this.

10
Dictionary usefulness and usability

• Kegl (1995) Machine-Readable Dictionaries and
  Education
• Originally, this paper was intended as a survey
  of educational applications using MRDs. As far as
  I have been able to determine, no such
  applications currently exist
• Standard dictionaries are reference works,
  ill-suited for use as learning tools
• Studies of American dictionary skills training
  show that many tasks achieve little in the way of
  education (but do teach word lookup!)

11
Educational value of dictionaries

• However derived lexical information is useful!
• Think of a high school foreign language textbook
• terminology sets
• pictures with parts named
• vocabulary lists
• word explications
• Major issue
• Not many people sit around reading dictionaries
  need something fun

12
Data on usability evaluating a paper dictionary

• Study of paper dictionary usability by Susan
  Poetsch, tested using Alawa dictionary (draft by
  Margaret Sharpe)
• In community, old people are very concerned to
  keep language strong, and help as volunteers in
  bilingual education. They are keen on dictionary
• However, they lack the literacy skills to use it
• Susan worked with people aged 2550
• Since volunteers, probably better than average
  literacy skills for the community

13
Findings

• Not very literate A big dictionary is
  overwhelming to someone with emerging literacy
  skills
• People knew words are ordered but could not use
  ordering effectively (restart or flick randomly)
• Often around 3 minutes a word lookup
• People lost place in page regularly
• An overcrowding of information is confusing
• One word correspondences are easiest for users,
  but often unrealistic linguistically
• Subentries were confusing part of speech
  puzzling

14
Findings (2)

• Regular dictionary users (especially, compilers!)
  grossly underestimate the time they have spent
  becoming familiar with dictionary structure
• If a dictionary is going to be made for a speech
  community, then the people in that community need
  to feel confident in using it.
• Teachers felt that the draft dictionary is too
  long and detailed for school use
• Conclusion These people need a different
  dictionary (My First Alawa)
• Would probably be used by adults as well as kids

15
Initial focusKirrkirr a Warlpiri browser

• Warlpiri is an Australian Aboriginal language
  spoken in the Tanami desert (NW of Alice)
• A computer interface for browsing the Warlpiri
  dictionary.
• Rich lexical materials have been collected by
  linguists over decades (Hales fieldwork from
  1959 on, MIT Lexicon Project in the 1980s)
• The results still havent been produced in a
  format usable by the community (only printouts)
• Previous computer projects have faltered

16
Past Problems

• At least 15 years have passed during which the
  Warlpiri dictionary could have been tested,
  people trained in dictionary use, and the
  dictionary improved with user input, but all that
  has been produced is one badly formatted raw
  paper printout
• Huge amounts of human labor have been expended
• Information systems 101 need to deliver, and
  provide the kind of process automation to make
  production and revisions easy

17
Our educational goals

• Aim at school kids
• Information seeking is a complex process which
  is often not attended to in K-12 education
  (Wallace et al. 1998)
• Provide learner supports for getting started with
  dictionaries
• Adaptable interface can cater to different needs
• Support for active reading by allowing note
  taking
• An interface where you can see words, but are not
  required to know words

18
Target user community
19
Kirrkirr A Warlpiri dictionary browser

• (Jansz 1998 Jansz, Manning and Indurkhya 1999)
• An environment for the interactive exploration of
  dictionaries.
• The design is general, but our current work has
  just been with Warlpiri (Arrernte coming soon!)
• Attempts to more fully utilize graphical
  interfaces, hypertext, multimedia, and different
  ways of indexing and accessing information
• Written in Java, it can either be run over the
  web high bandwidth or run locally (here Javas
  main advantage is cross-platform support).

20
Specific goals

• An interactive environment that encouraged
  exploration easy and fun to use
• Reduction of the dependence on alphabetical order
• Catering to the needs of different user groups
  (kids, teachers, professionals)
• Flexible enough to display appropriate
  information in appropriate ways depending on user
  level

21
Overview

• Kirrkirr provides various modules
• Graph layout of word relationships
• Formatted dictionary entries
• Semantic domain browsing
• A notes facility for jotting in the margin
• Multimedia audio, pictures
• Advanced searching interfaces
• others in planning colors, figuration patterns
• These attempt to cater to users with different
  competence levels

22
(No Transcript)
23
The lexical database

• Existing materials are stored in an ad hoc format
  of markup using backslash codes with some (rather
  odd) nesting of structural tags
• These were converted to XML using an
  error-correcting stack-based parser (written in
  PERL).
• The inconsistency and flexibility of dictionary
  entries actually made this a surprisingly
  difficult task.
• But parser tries to impose data integrity
• Use of XML gives a clear structure to the data,
  and makes available many (free) tools

24
XML

• XML a descendant of SGML for structured markup
  of text
• XML separates the structure of the data from its
  presentation
• Much of the recent enthusiasm for XML has
  centered around representing simple and rigid
  structures such as database records
• The rich hierarchical and variable structure of
  dictionary entries is really more what something
  like XML excels at!
• Result remains a portable, tangible text file

25
Alternative a database

• The obvious thing for storing a lot of data
• Has clear advantages structure, indexing, query
  language, relationships, integrity.
• Many people have suggested using a database for
  lexical data and some have actually done it
  (IITLEX, Austin and Nathan)
• But in general lexicographers oppose the
  rigidity, and, in practice, standard relational
  databases are quite ill-suited to dictionaries

26
Problems

• Dictionary entries vary enormously
• word cross-reference
• word POS gloss example translation
• word dialects sense-1 POS1 definition gloss
  example translation example translation sense-2
  POS2 dialect definition example translation
  subentry-word gloss synonym etymology

• Data is fragmented
• Same element can appear at many levels (dialect,
  crossreference, )
• Dictionaries are only loosely structured
• Database model is inflexible to extending the
  dictionary structure
• Lessens portability
• Answer an object database

27
XML indexing

• XML is a median between the structure, indexing,
  etc. of a database, and the freedom of a word
  processor.
• To improve speed, an ad hoc index to the XML file
  is built, and can be used for rapid headword and
  gloss lookup and indexing which parts of the XML
  file to process.

28
Visualization of dictionary information

• For applications with simple textual content
  behind them, there is little that can be done but
  an on-line reflection of a printed page
• But we want more than just definitions of words
  we want to know their relationships to other
  words, and the patterning in these relationships
• In a computational approach, can mediate between
  the lexical data and the user
• The interface can select from and choose how to
  present information (according to the users
  preferences) in many different ways

29
Previous work

• Current systems present the search-dominated
  interface of classic Information Retrieval
  systems you type a word in a search box
• Results try to mimic, but are generally inferior
  to, the printed version of the dictionary
• Good feature rapid searching
• These systems do little to utilize the
  captivating qualities of computers
  interactivity, user control and adaptability
  (Brown 1985).

30
Previous work (2)

• Only effective when user has a clearly specified
  information need even here, we are ignoring the
  distinction between information gained and
  knowledge sought (Sharpe 1995)
• Lack browsing, and chances for incidental or
  curiosity driven learning
• Lack tangibility and situatedness of paper
  ineffective for getting an idea of a collection
• We wish to exploit the essence of hypertext,
  which is click to explore browsing

31
Previous work (3)

• Little research work (in corpus linguistics,
  visualization etc.) on dictionary visualization
• WordNet built a rich network of relationships,
  which fundamentally departed from the paper
  dictionary tradition, and has been used in many
  computational projects
• However very little has been done in the way of
  interfaces that make these relationships visible
  and intelligible to users.
• Graphical representations seem particularly
  important given our target users.

32
MRD Interfaces WordNet
33
Graph-based visualization

• There is a little previous work on graphical
  representations of dictionaries
• For instance, the visual-thesaurus by plumbdesign
  derived from WordNet
• But it is also a good demonstration of how
  chaotic and confusing graphical interfaces can
  become.

34
Perils of visualization
35
Graph-based visualization

• (Jansz 1998 Jansz, Manning and Indurkhya 1999)
• Classic graph layout problem
• Adapts work by Eades et al. (1998) and Huang et
  al. (1998) on visualization and navigation of WWW
  document linkages
• Uses the spring algorithm. Big advantage is that
  it is an iterative updating algorithm, and so
  gives an easy interactivity
• it wiggles and people can play with it.
• Clarity and simplicity of graph Software
  maintains a set of focus nodes to prevent
  overcrowding

36
Educational advantages

• Alphabetical order is important, but
• A web of words offers other effective
  opportunities for learning
• A student can opportunistically explore words
  that are related in various ways
• Important semantic relationships can be
  understood

37
Kirrkirr network display
38
Kirrkirr network display
39
Formatted dictionary entries

• Are produced automatically from the XML by using
  XSL (a style language)
• XSL allows easy modeling of some user
  preferences.
• Most trivially, one can leave out information
  such as part of speech, or detailed definitions
• This is useful as many users find information
  overload quite confusing and demotivating
• Can produce bilingual or monolingual dictionary
• Opportunities for various output styles, and
  formats such as RTF or TeX for printing.

40
Formatted dictionary entries
41
Rich typology of link types

• The semantically rich types of linkages present
  in a dictionary (synonym, antonym, hyponym,
  subheadword, variant, coverbs, ) solves one of
  the major problems of the web we have many link
  types with a clear semantic interpretation
• Use consistent color-coded text and edges to show
  these link types
• Gives a richer browsing experience
• Can tell where you are going before clicking

42
Browsing

• Work (at PARC and elsewhere Pirolli et al. 1996)
  has stressed role for browsing as well as
  searching in information access
• It provides a context for learning
• We provide browsing in several ways
• conventional hypertext
• but with rich semantically-interpreted links
• their color-coding matches network edges
• network-based display of words
• browsing through semantic domains

43
Semantic Domains

• Alphabetical order is one indexing strategy, but
  there are many others
• Most requested is ability to find things by
  semantic domains e.g., food, manufactured items.
• Essentially the nouns structure of WordNet, or
  the classical KR ISA hierarchy
• We can exploit the domain info in the dictionary

44
Semantic Domains (Katrina Avila)
45
Other components

• Multimedia (currently pictures and audio)
• Can hear pronunciations / see objects
• Im keen to put in videos of Warlpiri sign
  language
• Advanced search page
• search various fields, regular expressions, etc.
• Notes one can annotate dictionary entries (to
  correct or personalize)

46
Simple features

• Show the alphabet
• The list on the left gives concreteness, and
  tangibility
• people can start with one of those words
• One can just type a few letters and then look at
  the list traditional benefit of paper
  dictionary
• English lookup can be helpful when Warlpiri
  spelling fails

47
Fuzzy spelling

• We expected problems with spelling
• Literacy skills based mainly in English, which
  doesnt transfer well
• Different sounds in Warlpiri
• Software employs fuzzy spelling which allows
  generous matching ignoring many distinctions
• done on the fly with FSMs, rather than using the
  SOUNDEX strategy
• Still not enough e.g., one kid wrote wanapy
  when wanting warnapari dingo, the end part of
  which knocked us out.

48
Adding more links Terminology sets

• Related words often arent in same domain
• Rather, words associated with a topic
• E.g., a dance has an associated set of words
  clearing the ground, decorating with ochres,
  leaves, and feathers, singing, dancing
• A concept useful to native speakers and learners
• Such cultural information is hard to learn, and
  not normally in dictionaries or thesauri
• Question can terminology sets be derived
  automatically from appropriate corpora?

49
Terminology sets

• Approach terminology will be determined as
  medium range collocations
• Corpus collection of Warlpiri stories, letters,
  books, fieldwork notes, etc. I have slightly
  over 1/4 million words of online Warlpiri
• This is a large proportion of Warlpiri available
  in textual form the difference between fieldwork
  corpora and StatNLP corpora.

50
Building and assessing

• I stemmed words (to maximize fuel) Warlpiri
  also has clitics that attach to words
• Using a Kay/Röscheisen-style approximate
  morphological analysis vowel harmony
• Collocational bonds were assessed using Dunning
  (1993)s method of loglikelihood ratios

51
Results

• For some topics (including dances,
  unfortunately), one couldnt get much out (too
  little data). Cf. Church and Hanks on strong
  tea.
• But for others, works well. E.g., karli
  boomerang
• ngurrjumani make, fix, repair
• jarnti carve, trim
• kijirni throw
• karaly(pa) smooth
• kurduju shield
• maparni paint

52
Results cont.

• warrirni seek, search, try to find
• kurdu child, baby, young, youth
• kurrupurda boomerang (a specific type)
• jarntu pet dog
• As often, the evaluation criteria are unclear,
  and susceptible to just-so stories. (Do people
  tend to sit around with their dog while carving
  their boomerang? Im not sure.)

53
Another e.g.

• pangurnu digging scoop
• pangurnu
• pili small coolamon/digging scoop
• rdaku hole in the ground
• kaninjarra downwards
• pangirni dig, produce cavity
• mulju soak in soft earth (dig for water)
• karlaja foot end of sleeping area
• pirrkirni scrape
• yirrarni put down

54
User study problems

• Since at present there is no dictionary available
  except the printed out database complete with
  markup codes, it was hard for many people to
  judge the use of the interface, since there was
  no point of comparison.
• First impressions only It would have been good
  to let people try it out at their leisure, but
  unfortunately not possible (NT Ed all Macintosh,
  MRJ 2.1 shipping deadlines slipped past our study
  date)

55
User study

• Mim Corris (Yuendumu, Willowra)
• User testing with primary and (lower) secondary
  students
• Comments from teachers, other adults etc.
• Purely qualitative observational study of
  dictionary use
• (Doing anything much else would be difficult.)

56
Teachers

• Very enthusiastic
• Role in encouraging kids to learn Warlpiri
• See uses for it in classroom
• Would teach dictionary skills and concepts
• Would also help teachers learn Warlpiri
• theyd browse in it and learn things
• Liked spatial layout
• Could use as a basis for classroom activities
  (better with some further development games and
  puzzles)

57
Elementary school kids

• One major benefit is that it was on computer.
• It maintained interest
• They were enthusiastic about the computer side
  of things and negotiated the interfaces various
  windows easily
• e.g., wanted back button
• Sometimes, working on sense relations and
  definitions was of less interest than moving
  things
• Word list was found helpful (can compensate for
  poor spelling)

58
Older children

• More thoughtful had dictionary experience
• Still really liked whole word list
• Could use and liked synonyms and antonyms
• Promoting subentries to entries appeared very
  effective People enjoyed exploring and
  explaining relation of derived terms to main word
  (even if sometimes folk etymologies?)
• The semantically uninterpreted cf link was still
  confusing
• High school girls wanted to spend time with it!

59
Adult literacy workers

• Less interested in graphical interface
• Mainly interested in looking at definitions
• Started discussing and disagreeing with them
  immediately
• although they had and used paper printout, first
  real chance to see what was there?
• They wanted to, and were able to, annotate the
  definitions with notes

60
Room for improvement

• More colorful!
• Make more interactive theres not enough that
  kids can create
• Some cleaning up of the user interface less
  steps for searches, etc.
• Adding in more views to the dictionary
• e.g., search by color

61
Conclusions

• Kirrkirr is just a prototype of what one can do
  to visualize dictionaries
• Wed like to go beyond that and start visualizing
  patterns of metaphor and sense extensions in
  dictionaries
• But it does show how a lot can be done to provide
  much more in the way of a dictionary interface
  which mediates between well-structured data and
  users needs for searching/browsing and
  presentation

62
(No Transcript)
63

• High quality dictionaries without excessive
  manual labor.
• Terminology sets
• Richer hypertext and multimedia

64

• Traditional dictionaries tend not to capture
  collocational knowledge.
• For a somewhat largish window size, collocations
  seem a good way of getting at the notion of a
  terminology set.

65
Overview

• A project to provide an engaging, interactive
  computer front end for the Warlpiri dictionary.
• Research goals
• Effective innovative use of computer medium
• Especially by dictionary visualization
• Augmenting dictionaries from corpora
• Assessing educational use of dictionaries
• Educational and practical goals
• Deliver it information systems 101
• Incidental learning and regular lookup

66

• Cf. also, Atkins and Varantola (1997) IJLexicog.

67
XML vs. Databases

• Flexible and hierarchical structure is easy
• There are tools for parsing and querying XML, but
  much less developed
• Out of the box, one is basically using grep,
  perhaps with structure sensitivity
• Portable text file

• Both flexible and hierarchical structure are
  difficult and can involve use of many tables
• A standard query language makes information
  access straightforward
• Databases provide a lot of technology for
  indexing to allow fast retrieval
• Less portable/tangible
