QTP: Not just for GUI anymore

1
QTP Not just for GUI anymore

• Prepared by Igor Gershovich
• www.connectedtesting.com

2

• The true beauty of QTP is that the only
  limitation is your imagination and ability to
  code in VBScript.
• Ian Fraser

3
Topics

• Web Services
• Telnet
• FTP
• XML

4
Advantages using APIs

• Accessing non-GUI applications via API directly
• Increases test execution speed
• Reduces synchronization problems related to GUI
  window like Telnet, DOS CMD, PuTTY, Exceed, etc.
• Allows execute scripts on locked boxes
• No need for QTP add-ins

5
Lets talk about Component Object Model (COM)
first

• COM is used by developers to create reusable
  software components, link components together to
  build applications, and take advantage of Windows
  services.
• The family of COM technologies includes
• COM
• Distributed COM (DCOM)
• ActiveX Controls.

6
COM methods and properties

• COM properties and methods
• Properties dont take any arguments and can be
  read/write
• value object.property (read)
• object.property value (write)
• Methods are read only if they returns value
• value object.method() (returns value)
• Set RS Conn.Execute(Select From Tbl")
  (returns object)
• Conn.Close (returns no value)
• tdc.Login username", psw" (method with
  parameters, returns no value)

7
VBScript CreateObject function

• CreateObject function creates and returns a
  reference to an Automation object
• CreateObject(servername.typename , location)
• Example connecting to Quality Center (QC)
• Set tdc CreateObject ("TDApiOle80.TDConnection")

• tdc.InitConnectionEx sServerName 'Connect
• tdc.Login sUser, sPassword
• tdc.Connect sDomain, sProject

8
COM objects in Registry editor
9
Resources

• Microsoft COM Component Object Model
  Technologies www.microsoft.com/com/default.mspx
• COM for ASP ProgrammersBy Wayne Berry
  http//www.15seconds.com/Issue/971214.htm

10
File Transfer Protocol (FTP)
11
Using WinInet API for FTP

• Windows WinINet.DLL enables applications to
  interact with the following protocols
• FTP
• HTTP
• Gopher

12
WinInet FTP hierarchy
13
FTP File download steps

• Open an FTP session with InternetOpen function.
  The function returns a session handle.
• Connect to the host by calling the
  InternetConnect function using session handle. It
  returns a connection handle.
• Call the FtpGetFile function to get the file.
• Close the handles created in Steps 1 and 2, using
  the InternetCloseHandle function

14
FTP File download Script
15
FTP File download is successful
16
ActiveX components (COM) for FTP

• The are numerous ActiveX (COM) components for FTP
  free and not free
• by Chilkat Software www.chilkatsoft.com
• by Easewe Software www.easewe.com
• by X360 Software www.x360soft.com
• by Dart Communications www.dart.com
• etc.

17
FTP Download file using Chilkats ActiveX
component (COM)
18
Resources

• FTP your scripts by Dani Vainstein
• www.advancedqtp.com
• Creating an FTP Component in Visual Basic
• By Jeff Niblack www.15seconds.com

19
Telnet to Unix/Linux using COM objects
20
A little bit of history

• A while back I had to automate a Client/Server
  application and execute quite a few UNIX commands
  on a backend.
• After trying several things, like PuTTY, TE
  Add-in, Exceed, etc.
• Exceed worked decent enough, but it was a
  complicated solution. I had to use "Capture to
  File" feature and then parse the file.
• After working with LoadRunner WinSock protocol
  for Telnet interface I start looking for WinSock
  (ActiveX) COM interface that can be used in QTP
• The goal was to connect to Unix/Linux box
  bypassing external GUI applications and execute
  scripts on locked boxes. Another reason was that
  QTP has problems with GetVisibleText method.

21
ActiveX components (COM) for Telnet

• The are numerous ActiveX (COM) components for
  Telnet free and not free
• by Dimac Development www.dimac.net
• EasyCom 3.1 www.sharewareconnection.com/easycom.ht
  m
• by Dart Communications www.dart.com
• etc.

22
Dimac w3sockets DLL methods and properties

•       COM Object - socket.tcp
•     Buffer StringDoTelnetEmulation
  BooleanHost StringTelnetEmulation
  StringTimeOut IntegerClose() GetLine()
  StringGetText( len ) StringOpen()
  SendLine( Line ) SendText( text ) Wait()
  WaitFor( Substring ) BooleanWaitForDisconnect(
  )

23
Dimac W3Socket API installation

• You need to download W3Socket Dll to your
  location and register it using SocketReg.exe
  included in a zip file.
• Note Readme said that you need to download
  winsock2 also - ignore it.
• The full W3Sockets reference is located
•  http//www.dimac.net/Products/FreeProducts/w3Sock
  ets/Reference/Refstart.htm

24
Example for Unix/Linux

• The function on next slide
• connect to Unix/Linux box via Telnet
• navigates to TestDirectory
• executes grep command
• returns grep results
• You can also find more examples on Web
• http//www.tek-tips.com/viewthread.cfm?qid938038
  page3
• http//www.mediamonkey.com/forum/viewtopic.php?t2
  1124

25
(No Transcript)
26
W3Sockets API limitation

• This API has a problem with SendLine method when
  sending over 80 characters.

27
Web Services and XML
28
Web Services architecture
29
HP/Mercury Solutions for WebServices

• The HP Service Test software is a SOA testing
  solution that simplifies and accelerates the
  automated functional testing of SOA services. HP
  Service Test Management module plugs into Quality
  Center
• QTP Web Services add-in

30
Windows APIs for Web Services

• HP Service Test and QTP Web Services Add-in are
  great solutions for comprehensive Web Services
  testing. However, the lightweight solution using
  Windows APIs works perfect in most cases.

31
WinHTTP DLL

• Microsoft Windows HTTP Services (WinHTTP)
  provides developers with a server-supported,
  high-level interface to the HTTP/1.1 Internet
  protocol.
• WinHTTP WinHttpRequest COM object uses Winhttp.dll

32
WinHttp.WinHttpRequest.5.1 Methods and Properties

• Methods of WinHttp
• Abort Aborts a WinHTTP Send method.
• GetAllResponseHeaders Retrieves all HTTP
  response headers.
• GetResponseHeader Retrieves the HTTP response
  headers.
• Open Opens an HTTP connection to an HTTP
  resource.
• Send Sends an HTTP request to an HTTP server.
• SetAutoLogonPolicy Sets the current Automatic
  Logon Policy.
• SetClientCertificate Selects a client
  certificate to send to a Secure Hypertext
  Transfer Protocol (HTTPS) server.
• SetCredentials Sets credentials to be used with
  an HTTP servereither an origin or a proxy
  server.
• SetProxy Sets proxy server information.
• SetRequestHeader Adds, changes, or deletes an
  HTTP request header.
• SetTimeouts Specifies, in milliseconds, the
  individual time-out components of a send/receive
  operation.
• WaitForResponse Specifies the wait time, in
  seconds, for an asynchronous Send method to
  complete, with optional time-out value.
• Properties of WinHttp
• Option Sets or retrieves a WinHTTP option value.

• ResponseBody Retrieves the response entity body
  as an array of unsigned bytes.
• ResponseStream Retrieves the response entity
  body as an IStream.
• ResponseText Retrieves the response entity body
  as a string.

33
ChangeMetricWeightUnit Web Service
on-linehttp//www.webservicex.net/convertMetricWe
ight.asmx
34
ChangeMetricWeightUnit Web Service WSDL
35
Using Http.WinHttpRequest.5.1 for WebServices
36
WinHttp.WinHttpRequest.5.1 snippet

• ' WinHttp.WinHttpRequest.5.1 Object
• Set oWinHttpReq CreateObject("WinHttp.WinHttpReq
  uest.5.1")
• oWinHttpReq.Open "POST", sWebService_Url, False
• oWinHttpReq.setRequestHeader "Content-Type",
  sContentType
• oWinHttpReq.setRequestHeader "SOAPAction",
  sSOAPAction
• 'Send SOAP request
• oWinHttpReq.Send sSOAP_Request
• 'Get XML Response
• sXMLResponse oWinHttpReq.ResponseText

37
SOAP XML Response
38
Off topic Using WinHTTP for Web pages
39
HTML Response
40
Msxml2.DOMDocument

• A DOM for XML is an object model that exposes the
  contents of an XML document
• We use the XML DOM by creating an instance of an
  XML parser
• CreateObject(Msxml2.DOMDocument ) is the
  method to create an instance of the Parser object

• Msxml2.DOMDocument COM object uses Msxml.dll

41
XML Request file
42
Using Msxml2.DOMDocument to load XML file
43
Msxml2.DOMDocument Code Snippet

• 'lMsxml2.DOMDocument
• Set oInputXmlDoc CreateObject("Msxml2.DOMDocumen
  t")
• 'loadXML from file
• oInputXmlDoc.load("C\XML_Files_Demo\Weight_Conver
  sion.xml")
• 'Send SOAP request
• oWinHttpReq.Send oInputXmlDoc

44
QTP XML Objects

• XMLUtil Object
• XMLAttribute Object
• XMLAttributesColl Object
• XMLData Object
• XMLElement Object
• XMLElementsColl Object
• XMLFile Object
• XMLItemColl Object

45
Example Compare XML files using QTP objects
46
Comparison results
47
Resources

• MSDN http//msdn.microsoft.com/en-us/library/aa384
  109.aspx
• Stefan Thelenius about Software Testing
  http//abouttesting.blogspot.com
• QuickTest Professional Help file

48
Igor Gershovich

• E-Mail igershovich_at_connectedtesting.com
• Phone [phone]
• www.connectedtesting.com
