Suspension

1
Suspension
2
The purpose of the suspension system is to absorb
any uneven bumps in the surface of the road.
3
Our racer is a track vehicle, so therefore should
have reasonably stiff suspension
Image curtsey of www.nascar.com
4
Realising this, Our racing proposition will have
a double wishbone system on the front, and a
modified double wishbone system on the rear.
5
Here is a plan view of the racer
6
Any questions?
