WACCM Meeting 2 June 2005

1
WACCM Meeting2 June 2005
2
State of the WACCM June 2005

• WACCM 3 status
• Summary of current research projects
• Other activities
• Release of WACCM3
• Computing resources
• Some details on current work
• Q A

3
Model Status

• WACCM, version 3 (WACCM3) completed March 2005
• Tests for 1995 conditions show realistic
  climatology
• Issues regarding horizontal resolution will
  impact applications (more on this later)
• Current research projects
• Retrospective (1950-2003) simulation (GHG
  effects, trends, etc.)
• Effects of solar variability (Smax vs. Smin
  fixed conditions)
• Others (Hanli Wu, Andrew Gettelman, Yaga
  Beres, )
• MARS WACCM? Proposal by CU to study atmospheric
  chemistry on Mars (Toon et al.) HAO involvement?

4
Release of WACCM3

• WACCM3 is fully interactive throughout
• Aurora/ion code, EUV, ion drag and Joule
  heating
• More efficient LUT for photolysis calculations
• revised SAD code for heterogeneous chemistry
• extended, improved b.c. datasets
• WACCM3 code has been merged into latest version
  of the Community Atmosphere Model (CAM_3.1x)
• Found error in development version of the model

• (thanks, Byron)
• After further testing, WACCM3 will be released
  for community use (sometime in 2005)

5
Computing Resources

• WACCM3 requires 150 Bluesky GAUs/year (430 CPU
  hours, or 9 wallclock hours on 2x32 processors)
• WACCM allocation is 9000 GAU/mo on CSL 5000
  GAU/mo on ESSL (the latter up for review after
  June will submit proposal)
• Trends simulation requires 3 realizations x 50
  years x 150 GAU/yr 22,500 GAUs gt our CSL
  resource base for 2.5 months!
• It is impractical to run WACCM at gt 4x5
  resolution at NCAR for climate studies. We are
  for resources elsewhere (Earth Simulator,
  NASA/Ames, etc.)
• Will lobby NCAR director for immediate
  augmentation to Bluesky. Need to be involved in
  next generation procurement (2006)

6
Other Activities

• Seminar on FV method by Christiane Jablonowski
  (SCD) (May 31)
• Present results of trends run at IAGA Assembly
  (Toulouse, July) and IAMAP (Beijing, August)
  (Garcia and Kinnison, respectively)
• Present results of Smax/Smin runs at IAGA (Katja
  Matthes, Dan Marsh)
• Present work on 2-day wave forcing (Yaga Beres)
  at AMS Middle Atmosphere meeting (Boston, June)
• Participation in SPARCs CCM Validation project
  (Kinnison)
• Several papers appeared, in press, and in
  preparation
• New, upgraded version of geov viewer available
  (lots of new functionality, bug fixes)
• Need to update WACCM web site!

7
Some details
8
WACCM3 Climatology U and T for Jan and Jul
9
WACCM3 Climatology H2O tape recorder, O3 column
10
WACCM3 Resolution issues
Idealized baroclinic wave test case Coarse
resolution does not capture baroclinic evolution!
From C. Jablonowski (SCD)
http//www.scd.ucar.edu/css/staff/cjablono/amr.htm
lamr_resources
11
Impact on N.H. midwinter sudden warmings?
4x5 run on Bluesky
2x2.5 run on Earth Simulator
1.x1.25 run on Earth Simulator
Temperature_at_ 10 hPa 70N
(From F. Sassi)
gt 4x5 unsuitable for annular mode coupling
studies
12
Trends Run H2O (equator, deseasonalized)
solar cycle influence
impact of CH4 ENSO
impact of ENSO
13
Trends Run T (global mean, deseasonalized)
T at 1 mb
T at 10 mb
1 K
T at 85 mb
14
Trends Run Global energy balance (smoothed,
deseasonalized)
0.006 K/d
50 km
-0.006 K/d
100 km
0.02 K/d
-0.02 K/d
