CoBase: Scalable and Extensible Cooperative Information System

1
CoBase Scalable and Extensible Cooperative
Information System
Wesley W. Chu Computer Science Department Univer
sity of California, Los Angeles

http//www.cobase.cs.ucla.edu
2
Conventional Query Answering

• Need to know the detailed database schema
• Cannot get approximate answers
• Cannot answer conceptual queries
• Cooperative Query Answering
• Derive approximate Answers
• Answer Conceptual Queries

3
Cooperative Queries
4
Generalization and Specialization
5
Type Abstraction Hierarchy (TAH)
Provide multi-level knowledge representations
Chemical-Suit Size TAH (A non-numerical TAH)
All_Sizes
Small_Size
Large_Size
Very_Small
Large_to_Extra_Large
Small_to_Medium
Very_Large
XL
XXL
L
M
S
XXS
XXXS
6
Type Abstraction Hierarchy (TAH)
(Location Example)
7
Relaxation Agent
Use knowledge-based approach (generalization
and specialization via Type Abstraction
Hierarchy)
to relax the followings for matching

• query conditions
• constraints

8
Query Relaxation
9
(No Transcript)
10
Visualization of Relaxation Process
Query Find seaports in the given region.
relaxed region
given region
11
(No Transcript)
12
Relaxation Control Primitives

• not-relaxable
• runway-length
• relaxation-order
• (runway length, location)

• preference-list
• unacceptable-list
• answer-size
• relaxation-level

13
Relaxation Primitives

• (approximate)
• 9 am
• between
• near-to (context-sensitive)
• Airport near-to LAX
• Restaurant near-to UCLA

• similar-to
• Airport similar-to LAX base-on (traffic,runway)
• within

14
Similar-to
Find all airports in Tunisia similar to the
Bizerte airport based on runway length and (more
importantly) runway width.
select aport_name, runway_length, runway_width
from runways, countries where aport_name similar-
to Bizerte based-on ((runway_length 1.0)
(runway_width 2.0)) and
country_state_name Tunisia and
countries.glc_cd runways.glc_cd
15
Similar-to Result
Similar-to module ranks the returned answers
according to mean-squared error.
16
Unacceptable List Operator
Constraint
CoBase Relaxation Manager
Tunisia
Tunisia
Central Tunisia
SW Tunisia
NE Tunisia
Central Tunisia
SW Tunisia
NW Tunisia
...
Gafsa
El Borma
Bizerte
El Borma
Gafsa
Trimmed TAH
Type Abstraction Hierarchy
17
TAH Generation for Numerical Attribute Values

• Relaxation Error
• Difference between the exact value and the
  returned approximate value

• The expected error is weighted by the probability
  of occurrence of each value

• DISC (Distribution Sensitive Clustering) is based
  on the attribute values and frequency
  distribution of the data

18
TAH Generation for Non-numerical Attribute Values

• Pattern Based Knowledge Induction (PBKI)
• Rule-based approach
• Clusters attribute values into TAH based on other
  attributes in the relation (i.e.,
  Inter-Attributes Relationships)

• Provides attribute correlation value (measure how
  well the rules applied to the databases)

19
Type Abstraction Hierarchy (TAH)
Provide multi-level knowledge representations
20
Associative Query Answering
Provide relevant information not explicitly asked
by the user User Query List all airports with r
unway length between 8500 and approximately 10
000 feet
21
CoBase and GLADIntegration
22
CoBase Functionality

• Provide approximate matching
• Find HETs with capacity of approximate 5-ton
• Provide conceptual query answering
• Find Earth Moving Equipment
• Provide content-sensitive spatial queries
• Find storage sites near selected location
• (Integration with MATT map server)
• Provide relaxation control
• Relaxation order
• Not-relaxable
• At-least (answer set, quantity on hand)

23
Cooperative Operations Added to GLAD

• Implicit Query Relaxation
• Explicit Query Relaxation
• Approximate operator
• Similar-to/based-on
• Spatial relaxation
• Relaxation Control
• Relaxation-order
• Not-relaxable
• At-least (answer-set size, quantity on hand)

24
CoBase Features Added to GLAD

• Enhance GLAD queries with cooperative operators
  (similar-to, relaxation-order, etc.)

• Display the query relaxation process
• modified query conditions (value, spatial)
• type abstraction hierarchies
• Rank returned answers with similarity measures
• e.g., spatial relaxation ranks answers according
  to their distance from the selected location

25
CoBase and GLAD TIE
Report Collection
Spatial Area Selection
Filter Editor
Display Generator
Query Collection
NSNs
Object Cache
Report Query Constructor
CoBase Query Editor
CoBase Relaxation Manager
GLAD
Data Cache
CoBase Data Source Manager
Databases
26
GLAD Query
Find NSNs of aircraft with passenger capacity
10, combat type 'I', capacity weight and price capacity_qty, capacity_wt_ston
from nsn_description where (upper(class) '7'
and upper(cbs_category_nomen) 'AIRCRAFT'
and price 10
and upper (combat_type) 'I' and capacity_wt_st
on 27
CoGLAD Query with Relaxation Control Operators
Find NSNs of aircrafts with passenger capacity
10, combat type 'I', capacity weight and price capacity is not relaxable. Relax price first and
then capacity weight. select nsn, price, pax_c
apacity_qty, capacity_wt_ston from nsn_descriptio
n where (upper(class) '7' and upper(cbs_categ
ory_nomen) 'AIRCRAFT' and price pax_capacity_qty 10 and upper (combat_type)
'I' and capacity_wt_ston ax_capacity_qty relaxation-order price capacity_w
t_ston
28
CoGLAD Querywith Similar-to Operator
Find aircraft similar to NSN '0000IB0000961'
based on the attributes price, passenger capacity
and air mileage. Passenger capacity has a weight
of 8 and price and air mileage has a
weight of 1. select nsn from nsn_description
where upper(nsn) similar-to '0000IB0000961' bas
ed-on ((price 1.0) (pax_capacity_qty 8.0)
(air_mileage 1.0)) at-least 4 '0000IB
0000961' is an answer from the previous query
29
CoGLAD Querywith Approximate Operator
Find DLA stock report with NSN like 8340 (FSC
for tents and tarpaulin) and on-hand quantity is
approximate 150. select nsn, ric from dla_sto
ck_report where nsn like 8340 and on_hand_q
uantity 150
30
Adding Constraints to a Query
GLAD query select nsn, ric from dla_stock_report
where nsn like 8340 and nomenclature like
TARP Query with added constraints sele
ct nsn, ric from dla_stock_report where nsn like
8340 and nomenclature like TARP and
on_hand_quantity 150 and
size_in_square_feet 350
31
Example of Spatial Relaxation
32
Spatial Relaxation with Relaxation Control

• relaxation-order size, (latitude, longitude)
• not-relaxable price
• at-least
• value size of the tarpaulin
• quantity on hand relax until enough quantity on
  hand (specified by the user) is obtained

33
Scalable and Extensible CoBase Architecture
34
Mediator Inter-Communications via KQML
CoBase Ontology
Module Objects APIs
Content Language Data Actions
35
(No Transcript)
36
Query Answers Without CoBase
Query find chemical suits
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
Electronic Warfare

• Identify and locate sources of radiated
  electromagnetic energy

• Determine emitter type based on the operating
  parameters of observed signals

• Radio Frequency (RF)
• Pulse Repetition Frequency (PRF)
• Pulse Duration (PD)
• Scan Period (SP)
• other operating parameters
• Determine platform sites near the line of the
  bearing of an emitter

This research is a joint effort between CoBase
and Lockheed Martin Communication Systems (Russ
Frew, et al.), Camden, NJ
44
Performance Improvement by Using CoBase in EW
Conventional DB parameter ranges from emitter
specifications CoBase DB peak parameters (RF
,PRF) and parameter ranges (PD,SP)
KB TAHs based on RF and PRF peak parameters
TAHs based on PD and SP parameter ranges
Case 1 emitter signals without noise
Case 2 add noise - PD SP (10), PRF (5), RF
(2.5) Sample Size 1000 signals Emitter
Types 75
This research is a joint effort between CoBase
and Lockheed Martin Communication Systems (Russ
Frew, et al.), Camden, NJ
45
Current CoBase Users and Applications
46
(No Transcript)
47
XML Query Relaxation
48
Outline

• Motivations
• Relaxation Systems
• XML Overview
• XML Query Languages
• Relaxation Types
• CoXML
• X-TAH

49
Motivations

• XML (eXtensible Markup Language) is becoming the
  standard for information structured documents and
  sharing of data on the web

• The use of XML as a data source has the following
  properties that make query relaxation essential

• The schema of an XML model can be very large.
  Users of such a system cannot be required to know
  the entire schema.

• On the web there are many heterogeneous data
  sources. Users cannot be expected to know the
  structure of each source separately.

50
Relaxation Systems

• CoSQL
• Transfer XML to relational tables
• Cooperatively answer queries on the relational
  system using generated TAHs.

• CoXML
• Answer queries directly on the XML data using
  X-TAHs.

51
XML Overview

• XML (eXtensible Markup Language) is a format for
  specifying structured documents and data.

• XML is extensible since it allows users to define
  their own schema (unlike HTML which is a
  pre-defined markup language).


52
XML (cont.)

• XML is a hierarchical data model.
• A XML document consists of two parts
• Schema
• Data
• The schema describes the structure of the data.
• Example

ng, body) rom (PCDATA) ELEMENT body (PCDATA) Tove Jani Reminder Don't forget me this weekend! note
Schema
Data
53
XML Query Languages

• XML can be represented as an ordered tree with
• Nodes representing elements and attributes
• Edges representing inclusion relationships
• An XML query can similarly be represented as a
  tree with edges of two types

• / for parent-child relationships
• // for ancestor-descendent relationships

54
XML Query Language Example

• The following XML
• Yields the following tree
• 1,a
• 2,d 4,c
• 3,b
• A possible query is
• 1a
• 2b 3c

55
Query Relaxation

• XML Query Relaxation can be categorized into two
  main types

• Value Relaxation values are relaxed to expand
  the scope values are allowed to take

• Structure Relaxation the structure of the query
  tree is relaxed to allow for more answers


56
Value Relaxation

• In value relaxation, the scope of a value is
  expanded to allow additional answers to be
  returned by a query.

• For example,
• find a person with salary of 50K to 55K
• Can be relaxed to find a person with salary of
  45K to 60K

57
Structure Relaxation

• In structure relaxation nodes and/or edges of the
  query tree can be relaxed to allow for more
  answers.

• There are three types of structural relaxation
• Edge Relaxation
• Node Relaxation
• Order Relaxation

58
Edge Relaxation

• A parent-child edge can be relaxed to a
  ancestor-descendent edge.

• For example
• 1,a
• 2,b 4,b 7,b 9,d 12,d
• 3,d 5,d 8,c 10,b 13,b
• 6,c 11,c 14,d
• 15,c
• Original query a/b/c ? 1,7,8

59
Node Relaxation

• Nodes can be relaxed in several ways
• A node can be relabeled with a similar tag name
  based on the domain knowledge.

• For example article/sec ? article/section
• A node can be replaced with a dont care such
  that it will match any non-null answer.

• For example /a/b/c ? a/_ /c
• A node can be removed while ensuring the
  superset property.

• For example a/b/c ? a/b

60
Order Relaxation

• The order in an XML query can be relaxed to allow
  any ordering of search conditions.

• For example
• 1a ? 1a
• 2b
• Two documents
• D1 D2
• Original query ? matches D1 only
• Relaxed query ? matches D1 and D2

61
CoXML

• Cooperative XML Query Answering

62
Knowledge Base

• The knowledge base of an XML query answering
  system facilitates query relaxation by providing
  the query processor with the following
  information
• Domain Ontology the semantic relationships among
  the tag names. This aids with node re-labeling

• X-TAH Knowledge-based XML Relaxation Index

63
X-TAH

• Two types of X-TAHs can be generated from the
  data

• Value X-TAH for value relaxations
• Structure X-TAH for structural relaxations
• Internal nodes summarize the characteristics of
  the objects in the cluster

• Leaf nodes are objects in a cluster
• Value for a value X-TAH
• Structure fragment for a structure X-TAH

64
X-TAH Examples

• Value X-TAH
• 1-6
• 3-6 1-2
• 5-6 3-4 1 2
• 5 6 3 4


• Structure X-TAH
• R3
• R1 R2
• O1 O2 O3 O4 O5 O6
• O1 //article/bm/sec O2 //article/bm/sec/ss1
• O3 //article/bm/sec/ss1/ss2 O4
  //article/bm/app/sec

• O5 //article/bm/app/sec/ss1 O6
  //article/bm/app/sec/ss1/ss2


65
Query Relaxation

• CoXMLs Query Relaxation Manager relaxes a query
  in the following three steps

• A set of relaxable conditions and their order are
  generated

• For each condition, a X-TAH is selected to help
  guide the relaxation process

• The relaxed queries are sent to the Query
  Processor to derive approximate answers

66
Conclusions

• Provide user and context sensitive query
  relaxations (structured ,semi-structured and
  unstructured data)

• Provide additional information (associative query
  answering) based on past cases

• CoSQL (Cooperative SQL)
• similar-to, near-to, approximate
• relaxation control operators
• CoXML( Cooperative XML)
• Value relaxation
• Structure relaxation ( edge, node, order)

67
References

• 1 W.W.Chu,H.Yang, K.Chiang, M.Minock, G.Chow,
  and C.Larson, "CoBase A Scalable and Extensible
  Cooperative Information System", Journal of
  Intelligence Information Systems, 6, 1996
• 2 Shaorong Liu and Wesley W. Chu, Cooperative
  XML(CoXML) Query Answering at INEX 2003, INEX
  Workshop 2003

• 3 Dongwon Lee "Query Relaxation for XML Model
  In Ph.D Dissertation, University of California,
  Los Angeles, June 2002

• 4 Dongwon Lee, Murali Mani, Wesley W.
  Chu"Effective Schema Conversions between XML and
  Relational Models In European Conf. on
  Artificial Intelligence (ECAI), Knowledge
  Transformation Workshop (ECAI-OT), Lyon, France,
  July 2002 (Invited)
• http//www.cobase.cs.ucla.edu
