A Multigrid Solver for Boundary Value Problems Using Programmable Graphics Hardware

1
A Multigrid Solver for Boundary Value Problems
Using Programmable Graphics Hardware
Nolan Goodnight Cliff Woolley Gregory
LewinDavid Luebke Greg Humphreys
University of Virginia
augmented by Klaus Mueller, Stony Brook University
2
General-Purpose GPU Programming

• Why do we port algorithms to the GPU?
• How much faster can we expect it to be, really?
• What is the challenge in porting?

3
Case Study

• Problem Implement a Boundary Value Problem (BVP)
  solver using the GPU
• Could benefit an entire class of scientific and
  engineering applications, e.g.
• Heat transfer
• Fluid flow

4
Related Work

• Krüger and Westermann Linear Algebra Operators
  for GPU Implementation of Numerical Algorithms
• Bolz et al. Sparse Matrix Solvers on the GPU
  Conjugate Gradients and Multigrid
• Very similar to our system
• Developed concurrently
• Complementary approach

5
Driving problem Fluid mechanics sim

• Problem domain is a warped disc

regular grid
regular grid
6
BVPs Background

• Boundary value problems are sometimes governedby
  PDEs of the form
• L? f
• L is some operator
• ? is the problem domain
• f is a forcing function (source term)
• Given L and f, solve for ?.

7
BVPs Example

• Heat Transfer
• Find a steady-state temperature distribution T in
  a solid of thermal conductivity k with thermal
  source S
• This requires solving a Poisson equation of the
  form
• k?2T -S
• This is a BVP where L is the Laplacian operator
  ?2
• All our applications require a Poisson solver.

8
BVPs Solving

• Most such problems cannot be solved analytically
• Instead, discretize onto a grid to form a set of
  linear equations, then solve
• Direct elimination
• Gauss-Seidel iteration
• Conjugate-gradient
• Strongly implicit procedures
• Multigrid method

9
Multigrid method

• Iteratively corrects an approximation to the
  solution
• Operates at multiple grid resolutions
• Low-resolution grids are used to correct
  higher-resolution grids recursively
• Very fast, especially for large grids O(n)

10
Multigrid method

• Use coarser grid levels to recursively correct an
  approximation to the solution
• may converge slowly on fine grid -gt restrict to
  course grid
• push out long wavelength errors quickly (single
  grid solvers only smooth out high frequency
  errors)
• Algorithm
• smooth
• residual ?
• restrict
• recurse
• interpolate

? L?i - f
11
Implementation - Overview

• For each step of the algorithm
• Bind as texture maps the buffers that contain the
  necessary data (current solution, residual,
  source terms, etc.)
• Set the target buffer for rendering
• Activate a fragment program that performs the
  necessary kernel computation (smoothing, residual
  calculation, restriction, interpolation)
• Render a grid-sized quad with multitexturing

source buffer texture
source buffer texture
render target buffer
render target buffer
fragment program
12
Implementation - Overview
13
Input buffers

• Solution buffer four-channel floating point
  pixel buffer (p-buffer)
• one channel each for solution, residual, source
  term, and a debugging term
• toggle front and back surfaces used to hold old
  and new solution
• Operator map contains the discretized operator
  (e.g., Laplacian)
• Red-black map accelerate odd-even tests (see
  later)

14
Smoothing

• Jacobi method
• one matrix row
• calculate new value for each solution vector
  element
• in our application, the aij are the Laplacian
  (sparse matrix)

15
Smoothing

• Also factor in the source term
• Use Red-black map to update only half of the grid
  cells in each pass
• converges faster in practice
• known as red-black iteration
• requires two passes per iteration

16
Calculate residual

• Apply operator (Laplacian) and source term to the
  current solution
• residual ? k?2T S
• Store result in the target surface
• Use occlusion query to determine if all solution
  fragments are below threshold (e lt threshold)
• occlusion query true means all fragments are
  below threshold
• this is an L? norm, which may be too strict
• less strict norms L1, L2, will require reduction
  or fragment accumulation register (not available
  yet), could run in CPU instead

17
Multigrid reduction and refinement

• Average (restrict) current residual into coarser
  grid
• Iterate/smooth on coarser grid, solving k?2 ?
  -S
• Interpolate correction back into finer grid
• or restrict once more -gt recursion
• use bilinear interpolation
• Update grid with this correction
• Iterate/smooth on fine grid

18
Boundary conditions

• Dirichlet (prescribed)
• Neumann (prescribed derivative)
• Mixed (coupled value and derivative)
• Uk value at grid point k
• nk normal at grid point k
• Periodic boundaries result in toroidal mapping
• Apply boundary conditions in smoothing pass

19
Boundary conditions

• Only need to compute at boundaries
• boundaries need significantly more computations
• restrict computations to boundaries
• GPUs do not allow branching
• or better, both branches are executed and the
  invalid fragment is discarded
• even more wasteful
• decompose domain into boundary and interior areas
• use general (boundary) and fastpath (interior)
  shaders
• run these in two separate passes, on respective
  domains

20
Optimizing the Solver

• Detect steady-state natively on GPU
• Minimize shader length
• Use special-case whenever possible
• Limit context switches

21
Optimizing the Solver Steady-state

• How to detect convergence?
• L1 norm - average error
• L2 norm RMS error (common in visual sim)
• L? norm max error (common in sci/eng apps)
• Can use occlusion query!

secs to steady statevs. grid size
22
Optimizing the Solver Shader length

• Minimize number of registers used
• Vectorize as much as possible
• Use the rasterizer to perform computations of
  linearly-varying values
• Pre-compute invariants on CPU
• Compute texture coodinate offsets in vertex shader

23
Optimizing the Solver Special-case

• Fast-path vs. slow-path
• write several variants of each fragment program
  to handle boundary cases
• eliminates conditionals in the fragment program
• equivalent to avoiding CPU inner-loop branching

fast path, no boundaries
slow path with boundaries
24
Optimizing the Solver Special-case

• Fast-path vs. slow-path
• write several variants of each fragment program
  to handle boundary cases
• eliminates conditionals in the fragment program
• equivalent to avoiding CPU inner-loop branching

secs per v-cyclevs. grid size
25
Optimizing the Solver Context-switching

• Find best packing data of multiple grid
  levelsinto the pbuffer surfaces - many p-buffers

26
Optimizing the Solver Context-switching

• Find best packing data of multiple grid
  levelsinto the pbuffer surfaces - two p-buffers

27
Optimizing the Solver Context-switching

• Find best packing data of multiple grid
  levelsinto the pbuffer surfaces - a single
  p-buffer
• Still one front- and one back surface for
  iterative smoothing

28
Optimizing the Solver Context-switching

• Remove context switching
• Can introduce operations with undefined results
  reading/writing same surface
• Why do we need to do this?
• there is a chance that we write and read from the
  same surface at the same time
• Can we get away with it?
• Yes, we can. Just need to be careful to avoid
  these conflicts
• What about RGBA parallelism?
• was not used in this implemtation, may give
  another boost of factor 4

29
Data Layout

• Performance

secs to steady statevs. grid size
30
Data Layout

• Possible additional vectorization

• Compute 4 values at a time
• Requires source, residual, solution values to be
  in different buffers
• Complicates boundary calculations
• Adds setup and teardown overhead

Stacked domain
31
Results CPU vs. GPU

• Performance

secs to steady statevs. grid size
32
Applications Flow Simulation
33
Applications High Dynamic Range
CPU
GPU
34
Conclusions

• What we need going forward
• Superbuffers
• or Universal support for multiple-surface
  pbuffers
• or Cheap context switching
• Developer tools
• Debugging tools
• Documentation
• Global accumulator
• Ever increasing amounts of precision, memory
• Textures bigger than 2048 on a side

35
Acknowledgements

• Hardware
• David Kirk
• Matt Papakipos
• Driver Support
• Nick Triantos
• Pat Brown
• Stephen Ehmann
• Fragment Programming
• James Percy
• Matt Pharr

• General-purpose GPU
• Mark Harris
• Aaron Lefohn
• Ian Buck
• Funding
• NSF Award 0092793
