Astronomy Data Collections of the Future: Massive Data Mining Opportunities

1
Astronomy Data Collections of the Future Massive
Data Mining Opportunities

• Kirk D. Borne

George Mason University and QSS Group Inc.,
NASA-Goddard kborne_at_gmu.edu or kirk.borne_at_gsf
c.nasa.gov http//rings.gsfc.nasa.gov/borne/nvo_
datamining.html
2
Discovery Informatics for Large Database Astronomy

• Kirk D. Borne

George Mason University and QSS Group Inc.,
NASA-Goddard kborne_at_gmu.edu or kirk.borne_at_gsf
c.nasa.gov http//rings.gsfc.nasa.gov/borne/nvo_
datamining.html
3
Astronomy Data Collections of the Future Massive
Data Mining Opportunities

• INTERFACE 2006 Symposium on Massive Data Sets and
  Streams

• Pasadena, CA
• http//www.galaxy.gmu.edu/Interface2006/i2006webpa
  ge.html

• Thursday May 25 Session 1030am-1200noon
• San Marino Room, Westin Pasadena, 191 North Los
  Robles Avenue

• Distributed Data, Parallel Computing, and
  Computational Strategies I (David Marchette,
  chair)

• Kirk Borne (George Mason University) Astronomy
  Data Collections of the Future Massive Data
  Mining Opportunities Thursday 1030-1050, San
  Marino Abstract Astronomers are producing
  ever-increasing data volumes from a variety of
  large projects, including NASA missions and
  ground-based telescope projects. One of the
  largest of these will be the Large Synoptic
  Survey Telescope (LSST) project, which is planned
  to produce nearly 30 Terabytes of data per night
  of observation, every night, for 10 years. The
  LSST will image the entire visible sky repeatedly
  every 4 nights. Astronomers refer to the
  resulting combined data set as "cosmic
  cinematography". Other similar projects are also
  envisioned. The temporal, spatial, and
  high-dimensional data mining opportunities posed
  by this massive data environment are exploding
  before us. Consequently, the scientific discovery
  potential of these data sets is enormous. All of
  these large astronomical data repositories will
  be geographically distributed. To facilitate
  access to these distributed data collections,
  astronomers are working with database experts and
  computer scientists to build a worldwide virtual
  data system the National Virtual Observatory
  (NVO). I will describe the NVO and LSST projects,
  plus other large astronomy data-producing
  projects, including some of the corresponding
  discipline-driven research challenges, and
  finally some astronomical data mining activities
  now underway. It is anticipated that an
  Astro-informatics research paradigm will evolve
  from this -- in fact, this is already becoming
  important and soon will become imperative.
  Grid-based mining, Web Services-enabled mining,
  and ontology-enhanced semantic mining will all
  play a role in the astronomical research of the
  future.
• Send proceedings manuscript to ysaid99_at_hotmail.com
  by July 31, 2006 (Yasmin Said).

4
Existing Astronomy Space Science Data
Infrastructure

• The Recent Past many independent distributed
  heterogeneous data archives

• Today NVO the National Virtual
  Observatory ( http//www.us-vo.org/ )

• Web Services-enabled e-Science paradigm
  (middleware, standards, protocols)

• Part of the IVOA (International VO Alliance _at_
  IVOA.net )

• Precursor to VAO Virtual Astronomical
  Observatory (NSFNASA co-funded)

• Provides seamless uniform access to distributed
  heterogenous data sources

• Find the right data, right now
• One-stop shopping for all of your data needs
• One of many VxOs for example
• VSO Virtual Solar Observatory
• VSPO Virtual Space Physics Observatory
• NVAO National Virtual Aeronomy Observatory
• VITMO Virtual Ionospheric, Thermospheric,
  Magnetospheric Observatory

• VHO Virtual Heliospheric Observatory
• IVOA-approved standards for data formats,
  data/metadata exchange, data models, registries,
  Web Services, VO queries, query results, semantic
  astronomical catalog table headings (UCDs
  Uniform Content Descriptors)
• And of course The Grid, Web Services,
  Semantic Web, etc. ...

5
Massive Astronomy Data Collections

• NVO (IVOA) registry of 14,000 data resources
  (collections, repositories, services)

• Large Astronomy Data Archives (including NASA
  space astronomy missions)

• Large Astronomy Sky Surveys (past and present)
  uniform data sets, including

• MACHO and related surveys for dark matter
  objects 1 Terabyte

• DPOSS (Digital Palomar Observatory Sky Survey)
  3 Terabytes

• 2MASS (2-Micron All Sky Survey) 10 Terabytes
• GALEX (Ultraviolet Space Telescope) 30
  Terabytes

• SDSS (Sloan Digital Sky Survey) 40 Terabytes
• Future Massive Astronomy Sky Surveys,
  including

• PanSTARRS 10 Terabytes per night, 40 Petabyte
  final archive anticipated

• LSST (Large Synoptic Survey Telescope _at_
  http//www.lssto.org/ )

• Begin operations in 2012, with 3-Gigapixel
  camera

• 10 Gigabytes every 30 seconds
• 30 Terabytes every night for 10 years
• 100 Petabyte final image data archive anticipated
  all data are public!!!

• 30 Petabyte final catalog anticipated
• Real-Time Event Mining 10,000-100,000 events
  per night, every night, for 10 yrs

• Repeat images of the entire night sky every 3
  nights Celestial Cinematography

6
NASA Astronomy Mission Datathe tip of the data
mountain
NSSDCs astrophysics data holdings
One of many science data collections for astron
omy
across the US and the world!
NSSDC National Space Science Data Center _at_ N
ASA/GSFC
http//nssdc.gsfc.nasa.gov/astro/astrolist.html
7
The Electromagnetic Spectrum

• Radiation is the Astronomers only source of
  information about the Universe!

• And it is a remarkably rich diverse source!

8
Why so many Telescopes?
9
Why so many Telescopes?
Because

• Many great astronomical
• discoveries have come
• from inter-comparisons
• of various wavelengths
• Quasars
• Gamma-ray bursts
• Ultraluminous IR galaxies
• X-ray black-hole binaries
• Radio galaxies
• . . .

10
Therefore, our science data systems should enable
multi-wavelength distributed database access,
discovery, mining, and analysis.
? DISCOVERY INFORMATICS
11
What is Informatics?

• Informatics is the discipline of structuring,
  storing, accessing, and distributing information
  describing complex systems.

• Examples
• Bioinformatics
• Geographic Information Systems (
  Geoinformatics)

• New! Discovery Informatics for Astronomy (
  Astroinformatics)

• Common features of X-informatics
• Basic object granule is defined
• Common community tools operate on object
  granules

• Data-centric and Information-centric approaches
• Data-driven science
• X-informatics is key enabler of scientific
  discovery in the era of large data science

12
X-Informatics Compared

• Discipline X
• Bioinformatics
• Geoinformatics
• Astroinformatics

• Common Tools
• BLAST, FASTA
• GIS
• Classification, Clustering, Bayes
  Inference, Cross Correlations, Principal
  Components, ???

• Object Granules
• Gene Sequence
• Points, Vectors, Polygons
• Time Series, Event List, Catalog, Astronomical
  Object

13
General Themes in Informatics Research

• Information and knowledge processing, including
  natural language processing, information
  extraction, integration of data from
  heterogeneous sources or domains, event
  detection, feature recognition
• Tools for analyzing and/or storing very large
  datasets, data supporting ongoing experiments,
  and other data used in scientific research

• Knowledge representation, including vocabularies,
  ontologies, simulations, and virtual reality

• Linkage of experimental and model results to
  benefit research

• Innovative uses of information technology in
  science applications, including decision support,
  error reduction, outcomes analysis, and
  information at the point of end-use
• Efficient management and utilization of
  information and data, including knowledge
  acquisition and management, process modeling,
  data mining, acquisition and dissemination, novel
  visual presentations, and stewardship of
  large-scale data repositories and archives
• Human-machine interaction, including interface
  design, use and understanding of science
  discipline-specific information, intelligent
  agents, information needs and uses.
• High-performance computing and communications
  relating to scientific applications, including
  efficient machine-machine interfaces,
  transmission and storage, real-time decision
  support
• Innovative uses of information technology to
  enhance learning, retention and understanding of
  science discipline-specific information.

14
Discovery Informatics

• Key enabler for new science discovery in large
  databases

• Essential tool (Large data science is here to
  stay)

• Common data integration, browse, and discovery
  tools will enable exponential knowledge discovery
  within exponentially growing data collections

• X-informatics represents the 3rd leg of
  scientific research experiment, theory, and
  data-driven exploration (Reference Jim Gray,
  KDD-2003)
• Discovery Informatics should parallel
  Bioinformatics and Geoinformatics become a
  stand-alone research sub-discipline

15
Key Role of Data Mining

• Data Mining (KDD) is the killer app for
  scientific databases

• Space and Earth Science Examples
• Neural Network for Pixel Classification Event
  Detection and Prediction (e.g., Wildfires)

• Bayesian Network for Object Classification
• PCA for finding Fundamental Planes of Galaxy
  Parameters

• PCA (weakest component) for Outlier Detection
  anomalies, novel discoveries, new objects

• Link Analysis (Association Mining) for Causal
  Event Detection (e.g., linking Solar Surface,
  CME, and Space Weather events)

• Clustering analysis Spatial, Temporal, or any
  scientific database parameters

• Markov models Temporal mining of time series
  data

16
Space Science Knowledge Discovery
17
This is the Informatics Layer
18
This is the Informatics Layer

• Informatics Layer
• Provides standardized representations of the
  information extracted for use in the KDD
  (data mining) layer.

• Standardization is not required (nor feasible) at
  the data source layer.

• The informatics is discipline-specific.
• Informatics enables KDD across large distributed
  heterogeneous scientific data repositories.

19
Space Weather Example
CME Coronal Mass Ejection SEP Solar Energetic
Particle
20
Key Role of Discovery Informatics

• The key role of Discovery Informatics is
• ... data integration and fusion ...
• ... across multiple heterogeneous data
  collections ...

• ... to enable scientific knowledge discovery ...
• ... and decision support.

21
Personal Reflection

• Distributed Data Mining
• ( mining of distributed data)
• versus
• Distributed Data Mining
• ( distributed mining of distributed data)

22
Future Work Discovery Informatics Applications

• Query-By-Example (QBE) science data systems
• Find more data entries similar to this one
• Find the data entry most dissimilar to this
  one

• Automated Recommendation (Filtering) Systems
• Other users who examined these data also
  retrieved the following...

• Other data that are relevant to these data
  include...

• Information Retrieval Metrics for Scientific
  Databases

• Precision How much of the retrieved data is
  relevant to my query?

• Recall How much of the relevant data did my
  query retrieve?

• Semantic Annotation (Tagging) Services
• Report discoveries back to the science database
  for community reuse

• Science / Technical / Math (STEM) Education
• Transparent reuse and analysis of scientific data
  in inquiry-based classroom learning
  (http//serc.carleton.edu/usingdata/ , DLESE.org
  )
• Key concepts that need defining (by community
  consensus) Similarity, Relevance, Semantics
  (dictionaries, ontologies)

23
Data Mining and Discovery InformaticsIt is more
than just connecting the dots
Reference http//homepage.interaccess.com/purc
ellm/lcas/Cartoons/cartoons.htm
