Evaluating the Potential of Commercial GIS for Accelerator Configuration Management

1
Evaluating the Potential of Commercial GIS for
Accelerator Configuration Management

• T. Larrieu, Y. Roblin, K. White, R.
  SlominskiJefferson Lab, Newport News, VA 23606,
  USA

2
Jefferson Lab has a Large and Complex
Infrastructure

• CEBAF ( 24/7 electron utility )
• 7 km of beamline
• 2000 magnets power supplies
• 338 5kW klystrons
• 42 Cryomodules each with 8 RF cavities
• 400,000L Low Conductivity Water system
• A 2K helium refrigeration plant
• 65,000 I/O Control Points
• 250,000 EPICS records, 140 IOCs, 80 Unix hosts

3
So does Salt Lake City, Utah

• Water Utility District
• 29 pump stations with 104 pumps
• 1,400 miles of pipeline
• 15,000 valves
• 8500 Hydrants
• 48,000 wastewater connections
• 181,000 customers

4
Or Sacramento, California

• Municipal Electrical Utility District
• 900 square miles service area
• 553,337 customers
• 10 Transmission bulk substations
• 500 circuit miles of Transmission lines
• 9,885 circuit miles of Distribution lines

5
The Premise

• Most Utility Companies use Geographic Information
  Systems (GIS) to operate and manage their large
  and complex infrastructure networks.

According to American Waterworks Association 90
of water agencies now use GIS at least partially
in their daily operation
6
What is GIS?

• A GIS is a computer system capable of capturing,
  storing, analyzing, and displaying geographically
  referenced information that is, data identified
  according to location. Practitioners also define
  a GIS as including the procedures, operating
  personnel, and spatial data that go into the
  system.

Source USGS Geographic Information Systems
Poster http//erg.usgs.gov/isb/pubs/gis_poster/
7
GIS Software (General)

• Database View
• A GIS is a structured database that can describe
  the world spatially.
• Map View
• A GIS is a set of intelligent maps and other
  views that show features and feature
  relationships spatially
• Model View
• A GIS is a set of information transformation
  tools that derive new datasets from existing
  datasets.

8
Utility GIS Usage Examples

• Inventory (mains, valves, hydrants, meters, etc.)
• Water distribution system master planning
• Population and demand projections
• Groundwater management/modeling
• Water quality monitoring
• Hazardous materials tracking
• Site analysis
• Development review and approval
• Right-of-way engineering
• Water flow analysis
• Automated mapping
• Capital improvement project tracking
• Underground service alert

9
Analagous (Possible) JLAB GIS Usage

• Inventory (iocs, camac crates, power supplies,
  etc.)
• Configuring online model server
• 12 GeV upgrade planning/tracking
• Hazardous materials tracking
• Radcon tracking/mapping
• Environmental Regulatory Compliance
• Fault analysis
• Spatial selection display of PVs

10
Commercial GIS vendors
Source GISmonitor, November 7, 2002,
http//www.gismonitor.com/articles/comment/110702_
Daratech.php
11
GIS Software (ArcGIS)

• Data Management Tools
• (Geo)Database
• CAD File Integration
• UI Tools
• View/Query
• Add/Edit data
• Other
• SDK
• Tracking Server/Analyst
• Schematics

12
Geodatabase sits on RDBMS
Source M. Zeiler, Modeling our World ESRI
Press, Redlands, CA 1999
13
Geodatabase Versioning

• Conceptually similar to CVS
• Version is named state of geodatabase
• Multiple versions can coexist
• A user can connect to any version
• Differences between versions can be
  merged/reconciled

14
Versioning Benefits

• Could create named versions at useful savepoints
  such as the completion of an experiment, or just
  prior to or following a maintenance period.
• Tables containing CAD objects, software
  configuration info, Optics could all be versioned
  consistently.

15
Spatial Indexes Operators

• Allow efficient queries based on geometric
  relationships such as proximity, adjacency, and
  overlay.
• Select Objects that
• intersect
• are within a distance of
• contain
• are contained by
• share a line Segment with
• crossed by outline of
• have their center in

16
Via ArcObjects (Microsoft COM) Available in the
Unix SDK via MainWin
As Simple Features (ArcSDE) Java C APIs

• Via SQL
• Provided by RDBMS vendor

Source M. Zeiler, Modeling our World. 199pp.,
Environmental Systems Research Institute,
Redlands, CA, 1999.
17
CAD Files
CAD drawings have limitations

• Engineering staff who maintain drawings must be
  notified to make changes by installers or Survey
  Alignment team.
• Changes to the as-built drawings are made
  separately from changes to software configuration
  and physics models.
• The CAD drawings are tiled.
• The CAD annotation is static.

18
ArcGIS can Integrate CAD

• Option 1 - Use entire file as a layer.
• Option 2 - Decompose the CAD file and import its
  contents into geodatabase.
• Objects now stored in DB can be extended with
  additional attributes.
• Can be joined/related to other DB tables.
• Can be used to generate new CAD files, not
  constrained to tiling, labelling of original.

19
CAD Superimposed on Magnet Centers obtained from
Survey Alignment
20
Overlay CAD on Alignment Magnet Centers
21
(No Transcript)
22
User Interfaces

• Data Source Management (ArcCatalog)
• Usable by non-programmers
• Wizard-like toolboxes Import/Export/Convert etc.
• Graphical Display (ArcMap)
• View/Display Data Layers
• Search/Query Data
• Add/Edit Data

23
ArcCatalog
24
ArcMap Display
25
ArcMap Query
26
Beamline Editing w/ArcMap
27
Beamline Editing OptiM Style
28
Tracking Server

• We could write a CA plugin
• Realtime display of spatially-selected PVs.
• Playback archiver data super-imposed over
  as-built drawings to give context.

http//www.esri.com/trackingserver
29
Schematics

• Select a magnet and on-the-fly generate a
  schematic of all magnets, shunts, and
  shunt-adders in its circuit.

• Select a rack containing Camac crate and click to
  generate a schematic showing logical connectivity
  of iocs, gpib devices, serial devices, and cables

http//www.esri.com/schematics
30
Benefits

• Highly functional UI without custom programming.
• Complementary to non-spatial database-building
  efforts (à la IRMIS).
• Location-awareness fits operational goal of
  region-centric rather than system-centric control
  system.
• Potential to manage controls, engineering, and
  model data consistently.

31
Drawbacks

• The software is not free.
• The software might be overkill.
• There is limited Prior Art to emulate.

32
Exploratory Project

• Use ArcGIS and Geodatabase for configuration of
  new Art model server
• Import data from OptiM, DIMAD, and CAD
• Maintain/Update in Geodatabase
• Export Up-to-date layout element properties to
  Art

33
Exploratory Project
34
No problem importing Optim, DIMAD
35
Importing CAD - Troublesome

• Songsheets in arbitrary drawing units.
• Must open each, define pair of matchpoints to
  correlate drawing coordinates to accelerator
  coordinate system.
• Songsheets make no use of layers.
• Cross-section, plane-view, annotation, and page
  template are all intermingled in a single drawing
  layer,
• Elements are all lines, not polygons.
• Processing is required to merge related lines
  into a single geodatabase polygon object.
• Annotation is simply written onto page.
• Not attached to elements as Xdata

36
But Exploration Can Proceed

• Interface for Model Server to Read GIS
• Geodatabase ? AML ? Art
• Work around or fix CAD limitations
• Heads-up digitizing of some components
• Collaborate with ME to update standards
• Outsource retrofit of old drawings?
• Work on additional layers
• Control System Data for example (IRMIS)

37
Summary

• The ArcGIS software appears to be a capable
  framework to consistently manage Engineering,
  Controls, and Optics data.
• The ability to buy a ready-made interface for
  displaying, querying, and analyzing data could
  free us to concentrate on data and processes
  rather than GUI development.

38
The application of GIS is limited only by the
imagination of those who use it.

• Jack Dangermond, founder of ESRI
