Title: Motherboard


1
COMP2060
  • The Motherboard

2
Types of Motherboards
3
Types of Motherboards
4
Main Components on a Motherboard
  • CPU and its chip set
  • System clock
  • ROM BIOS
  • CMOS configuration chip and its battery
  • RAM
  • RAM cache (optional)
  • System bus with expansion slots
  • Jumpers and DIP switches
  • Ports directly on the board
  • Power supply connections

5
Typical AT Motherboard
6
Typical ATX Motherboard
7
Selection of a Motherboard Determines
se refiere a un grupo de circuitos integrados, o
chips, que están diseñados para trabajar juntos.
  • CPU types and speeds
  • Chip set on the board
  • Memory cache type and size
  • Types and number of expansion slots ISA, PCI,
    and AGP
  • Type of memory ECC, EDO, SDRAM, SIMMs, or DIMMs
  • Type of memory what kind of and how much SRAM
    and DRAM

continued
8
Comment
  • El Chipset es el que hace posible que la placa
    base funcione como eje del sistema, dando soporte
    a varios componentes e interconectandolos de
    forma que se comuniquen entre ellos haciendo uso
    de diversos buses.

9
Selection of a Motherboard Determines
  • Type of case
  • ROM BIOS
  • Type of keyboard connector
  • Presence/absence of proprietary video and/or
    proprietary local bus slots
  • Presence/absence of IDE adapters and SCSI
    controller
  • Presence/absence of COM ports, LPT ports, and
    mouse port

10
Considerations When Selecting a System Board
  • Support the CPU you plan to use?
  • Type of BIOS?
  • Bus speeds and type of memory memory capacity?
  • Use many embedded devices?
  • Fit the case?
  • Warranty? How much manufacturer support?
  • How extensive and user-friendly is documentation?

11
Major Manufacturers o Motherboards
12
The System Clock
  • Keeps the beat for motherboard activities
  • Frequency is measured in megahertz (MHz)
  • Wait state
  • Occurs when the CPU must wait for another
    component

13
How the CPU Works
  • Input/output (I/O) unit
  • Manages data and instructions entering and
    leaving the CPU
  • Arithmetic logic units (ALUs)
  • Do all comparisons and calculations
  • Control unit
  • Manages all activities inside the CPU itself

14
Types of Pentium CPUs
continued
15
Types of Pentium CPUs
16
Competitors of Advanced Pentiums
17
Intel Itaniums
18
CPU Slots and Sockets
continued
19
CPU Slots and Sockets
20
(No Transcript)
21
CPU Slots and Sockets
  • The physical connection used to connect the CPU
    to the system board
  • Slots 1 and 2 are proprietary Intel slots
  • Slot A is a proprietary AMD slot
  • Current CPU sockets are called zero insertion
    force (ZIF) sockets and have a small lever on the
    side of the socket that lifts the CPU up and out
    of the socket

22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
CPU Slots and Sockets
28
The Chip Set
  • Set of chips on the system board that
    collectively controls the memory cache, external
    buses, and some peripherals
  • Intel dominates the market
  • Most compatible with Pentium family of CPUs
  • Investment in RD has led to other developments
    (eg, PCI bus, universal serial bus, AGP, and
    Accelerated Hub Architecture)

29
Chipset
  • El chipset es el que se que conecta con el
    microprocesador con el motherboard, y por lo
    tanto, con el resto del equipo. Este se compone
    de dos partes básicas - el northbridge y el
    southbridge. Todos los diversos componentes de la
    computadora pueden comunicarse con el CPU a
    través del chipset.

30
(No Transcript)
31
(No Transcript)
32
Chip Set Manufacturers
33
According to "Guide to managing and maintaining
your PC" by Jean Andrews the three most common
BIOS are
  • 1. AMI BIOS 2. Award BIOS 3. Phoenix BIOS

34
(No Transcript)
35
Hardware Configuration
  • Tells CPU what hardware components are present in
    the system and how they are set up to interface
    with the CPU
  • Provided on motherboard in three ways
  • DIP switches
  • Jumpers
  • CMOS

36
Setup Data Stored by DIP Switches
37
Setup Data Stored by Jumpers
38
Setup Data Stored by Jumpers
39
How to Access CMOS Setup
40
How to Access CMOS Setup
41
Coin-Cell CMOS Battery
42
CMOS
  • Setting startup passwords in CMOS
  • Categories of CMOS settings
  • Standard CMOS setup
  • Advanced CMOS setup (aka BIOS Features setup)
  • Advanced Chip Set Setup
  • Power Menu (aka Power Management)
  • IDE HDD Auto-detect Hardware Device Settings (on
    jumperless motherboards only)
