K12 Network Upgrade Fall 2001

1
K12 NetworkUpgradeFall 2001
Georgia Department of Education Linda C.
Schrenko, State Superintendent of Schools
2
K12 Network Upgrade

• DOE-BellSouth Partnership
• Provide infrastructure to rural Georgia
• Increase bandwidth to districts
• Increase bandwidth to the Internet

Georgia Department of Education Linda C.
Schrenko, State Superintendent of Schools
3
Multimedia Digital InfrastructureCore Switch
Deployment
BellSouth does not own and operate InterLATA
Facilities
4
Multimedia Digital InfrastructureADSL Deployment
5
Multimedia Digital InfrastructureK-12
Legend
6
Multimedia Digital Infrastructure
BellSouth does not own and operate InterLATA
Facilities
7
K12 Network Upgrade

• Current Plan - Frame Relay
• T1 fully burstable
• 384 CIR to Internet
• 256 CIR to GALILEO
• Upgrade Plan - ATM
• 256 (GIB) to each school (aggregated at BO)
• 1 Mb connection to each school (aggregated at BO)
• Connection burstable

Georgia Department of Education Linda C.
Schrenko, State Superintendent of Schools
8
K12 Network Upgrade

• LATA Bandwidth to Internet

Georgia Department of Education Linda C.
Schrenko, State Superintendent of Schools
9
K12 Network Upgrade

• Upgrade Plan - What this means

Georgia Department of Education Linda C.
Schrenko, State Superintendent of Schools
10
K12 Network Upgrade

• Project Schedule
• ATM switches installed 9/1/00
• Service inquiries begin 6/15/01
• E-rate approval 7/23/01
• Cost

Georgia Department of Education Linda C.
Schrenko, State Superintendent of Schools
11

12
K12 Network Upgrade
Regional Hub Site
13
K12 Network Upgrade
Regional Hub Site
14
K12 Network Upgrade
District Installation
15
K12 Network Upgrade

• Installation
• New router - Cisco 2650
• 2650 will be programmed identically to the 1720
• There should be little or NO interruption in
  service
• Help numbers remain the same

16
K12 Network Upgrade

• Installation schedule
• Circuits begin 9/4/01
• Routers begin 10/1/01
• Criteria
• CO facilities OK
• Site needs no work
• DOE priority

17
K12 Network Upgrade

• Hub site changes
• 2 hub sites currently at K12 sites
• Atlanta LATA - DeKalb
• Augusta LATA - Richmond
• 3 hub sites moved to K12 sites
• Albany LATA - Dougherty
• Macon LATA - Bibb
• Savannah LATA - Chatham

Georgia Department of Education Linda C.
Schrenko, State Superintendent of Schools
18
K12 Network Upgrade

• Network name
• Georgia Education and Resource Network
• gearnet.org

Georgia Department of Education Linda C.
Schrenko, State Superintendent of Schools
19
K12 Network Upgrade
K12 Network Upgrade

• Url-http//www.doeatm.com
• User ID - doeuser
• Password - gearnet

20
K12 Network Upgrade
Georgia Department of Education Linda C.
Schrenko, State Superintendent of Schools
21
K12 Network Upgrade
Georgia Department of Education Linda C.
Schrenko, State Superintendent of Schools
22
K12 Network Upgrade

• Looking ahead to PY5
• Increase bandwidth as new schools are built
• Adjust bandwidth based on enrollment
• Adjust bandwidth based on number of Internet
  ready computers

23
K12 Network Upgrade

• Installation schedule
• Trouble reporting procedures
• Changes in your site
• Add a web server
• Mail server
• Internal LAN /WAN problems vs K12 network

24
K12 Network Upgrade

• BellSouth contacts before during installation
• Beverly Prendergast 404-829-6871 Account Manager
• Jeynell Goodson 404-829-0221 Project Manager
• Michelle Samples 404-829-6870 contact for all
  network, and router questions, IP addressing,
• Doris Walker 404-829-0096
• Linda Latham 404-829-0093
• Service Consultant- works the circuit orders- can
  answer questions about circuit installation and
  orders in general

25
K12 Network Upgrade

• After installation
• 1-888-393-4870

26
DOE - BellSouth
Bridging The Digital Divide
