ISO STANDARDS FOR THE OIL AND GAS INDUSTRY (AND HOW IT WORKS)

1
ISO STANDARDS FOR THE OIL AND GAS INDUSTRY(AND
HOW IT WORKS)

• Cheryl Stark
• BP Houston
• Chair, ISO/TC67

2
DISCUSSION POINTS

• RECAP OF YESTERDAY AWARENESS
• ISO STANDARDS
• ISO TECHNICAL COMMITTEES FOR OIL AND GAS
• ISO/TC 67
• ISO/TC67 ORGANIZATION ROLE
• DELIVERABLES
• PARTICIPANTS
• UPCOMING EVENTS

3
ISO ORGANIZATION

• Consensus-based
• Market driven
• Technically current
• Internationally expertise
• Voluntary, not mandated
• Meet requirements of WTO Technical Barriers to
  Trade

4
ISO ORGANIZATION

• One country, one vote
• Equal footing for all countries
• Right to join any technical committee or policy
  committee of commercial/technical interest
• Voting rights on all standards
• Access to global community of technical experts

5
(No Transcript)
6
ISO FOR OIL AND GAS INDUSTRY

• ISO technical committees cover many energy (and
  related) sectors including
• TC 27 Coal
• TC 28 Petroleum Products
• TC 67 Materials, equipment offshore
  structures for the PPNGI
• TC 85 Nuclear energy
• TC 180 Solar energy
• TC 193 Natural gas
• TC 197 Hydrogen energy
• TC 203 Technical energy

7
ISO/TC67 Materials, equipment and offshore
structures for petroleum, petrochemical and
natural gas industries

• Secretariat API on behalf of ANSI
• Created 1947, reactivated 1987
• Scope Standardization of the materials,
  equipment and offshore structures used in
  drilling, production, transport by pipelines and
  processing of liquid and gaseous hydrocarbons
  within the petroleum, petrochemical and natural
  gas industries.
• Excluded aspects of offshore structures subject
  to IMO regulations (TC8 Ships and marine
  technology)
• Participating countries 28
• Observing countries 28
• Standards published - 135

8
DISCUSSION POINTS

• RECAP OF YESTERDAY AWARENESS
• ISO STANDARDS
• ISO TECHNICAL COMMITTEES FOR OIL AND GAS
• ISO/TC 67
• ISO/TC67 ORGANIZATION ROLE
• DELIVERABLES
• PARTICIPANTS
• UPCOMING EVENTS

9
ISO/TC 67

• TITLE
• Materials, equipment and offshore structures
  for petroleum, petrochemical and natural gas
  industries
• Excludes aspects of offshore structures subject
  to IMO regulation (ISO/TC8 Ships and marine
  technology)
• SCOPE
• Standardization of the materials, equipment and
  offshore structures used in drilling, production,
  transport by pipelines and processing of liquid
  and gaseous hydrocarbons within the petroleum,
  petrochemical and natural gas industries.

10
ISO/TC67

• MISSION
• To create value-added standards for the oil and
  natural gas industries
• VISION
• Global standards used locally worldwide

11
VISION OF GLOBAL STANDARDS
12
ISO/TC67 MEMBERS

• Participating members 28
• Argentina, Brazil, Canada, China, Denmark,
  Finland, France, Germany, Indonesia, Italy,
  Japan, Kazakhstan, Korea (Republic of), Mexico,
  Netherlands, Nigeria, Norway, Oman, Portugal,
  Qatar, Romania, Russian Federation, South Africa,
  Spain, Ukraine, United Kingdom, United States,
  Venezuela
• Observing members 28
• Australia, Austria, Azerbaijan, Belgium,
  Bulgaria, Colombia, Croatia, Cuba, Czech
  Republic, Ecuador, Egypt, Hong Kong, Hungary,
  Iran (Islamic Republic), Ireland, Malaysia,
  Moldova (Republic of), Mongolia, Poland, Saudi
  Arabia, Serbia, Singapore, Slovakia, Sweden,
  Switzerland, Thailand, Trinidad and Tobago, Viet
  Nam

13
(No Transcript)
14
ISO/TC67 ORGANIZATION
15
ISO/TC67 WORKING GROUPS

• WG2 - Conformity assessment (TS29001)
• WG4 Reliability engineering
• WG5 Aluminium pipe
• WG7 Materials for H2S-containing environments
  (CRA and non-metallics)
• WG9 Life cycle costing
• WG10 LNG (equipment)
• Considering reactivation of WG 8 metallurgy
  (NWI in voting)

16
ISO/TC67 SC2PIPELINE TRANSPORTATION SYSTEMS

• 3183 Linepipe (including X120)
• 13623 Pipelines
• 13847 Pipeline welding
• 14313 Pipeline valves
• 14723 Subsea pipeline valves
• 15889 Cathodic protection
• 15590 Induction bends, fittings and flanges
• 21329 Mechanical connectors

17
ISO/TC67 SC3DRILLING AND COMPLETION FLUIDS, AND
WELL CEMENTS

• 13500 Drilling fluids material specifications
• 10426-1 Cement materials specifications
• 13501 Solids processing systems
• 13503-1 Measurement of viscous completion
  fluids
• 13503-3 Testing of heavy brines
• 10414 Testing of drilling fluids
• 10427 Centralizer specification
• 13503-4 Stimulation and gravel pack fluid leakoff
  under static conditions

18
ISO/TC67 SC4DRILLING AND PRODUCTION EQUIPMENT

• 10423 Wellheads christmas tree equipment
• 13533 Drill through equipment (BOPs)
• 13624 Marine drilling riser systems
• 14310 Packers bridge plugs
• 10432 Subsurface safety valve equipment
• 17824 Sand control screens
• 13628 Subsea production systems
• 13628-7 Workover completion risers
• 13628-13 ROTs ROVs

19
ISO/TC67 SC5OCTG

• 11960 Casing and tubing
• 11961 Steel drillpipe
• 10400 Formulae calculations for casing,
  tubing and drill pipe properties
• 13678 Evaluation of thread compounds
• 13679 Testing of casing and tubing
  connections
• 13680 CRA seamless tubing for casing, tubing
  and coupling stock
• 15464 Gauging and inspection of casing, tubing
  and line pipe threads

20
ISO/TC67 SC6REFINERY EQUIPMENT

• 10434 Steel gate valves
• 10437 Steam turbines
• 10439 Centrifugal compressors
• 13704 Heat-exchanger tube thickness
• 13706 Air-cooled heat exchangers
• 13707 Reciprocating compressors
• 13709 Centrifugal pumps
• 15649 Piping
• 14692 Glass-reinforced plastic piping
• 15547 Plate heat exchangers

21
ISO/TC67 SC7OFFSHORE STRUCTURES

• 19900 Offshore structures
• 19901-1 Metocean design
• 19901-2 Seismic design and criteria
• 19901-4 Geotechnical and foundation design
• 19901-5 Weight control during engineering and
  construction
• 19902 Fixed steel offshore structures
• 19903 Fixed concrete offshore structures
• 19904 Floating structures monohulls, semis,
  SPARs, TLPs
• 19905 Mobile offshore units jack-ups
• 19906 Arctic structures

22
ISO/TC67MANAGEMENT COMMITTEE

• Representative from each P country
• Coordinates TC67 activities with ISO CS
• Seeks resources for SC technical experts,
  funds, etc.
• Publishes the Business Plan (requirement of ISO
  Technical Management Board)
• Maintains N435-Policies and Procedures,
  N654-Management System, and N731-Management Plan
• Accepts TC publication targets, and works toward
  guiding documents through DIS and FDIS

23
ISO/TC67 N731

• Management Plan
• Status of all projects in October 2006
• Includes
• ISO number and Project title
• Equivalent standards in API and/or CEN/TC12
• Project leader
• Project registration date
• Goal of stages for upcoming years

24
ISO/TC67MANAGEMENT COMMITTEE

• Brazil, Canada, China, France, Germany, Italy,
  Japan, Netherlands, Norway, Qatar, United
  Kingdom, United States
• Liaisons OGP, IADC and CEN/TC12

25
DISCUSSION POINTS

• RECAP OF YESTERDAY AWARENESS
• ISO STANDARDS
• ISO TECHNICAL COMMITTEES FOR OIL AND GAS
• ISO/TC 67
• ISO/TC67 ORGANIZATION ROLE
• DELIVERABLES
• PARTICIPANTS
• UPCOMING EVENTS

26
ISO/TC67 PARTICIPANTS

• Operators
• Service/supply companies
• Manufacturers
• Government regulators
• Consultants
• Academics
• Experts are nominated by their national standards
  body to participate in work effort

27
COST SAVINGS OF TOP 30 ISO STANDARDS
28
DISCUSSION POINTS

• RECAP OF YESTERDAY AWARENESS
• ISO STANDARDS
• ISO TECHNICAL COMMITTEES FOR OIL AND GAS
• ISO/TC 67
• ISO/TC67 ORGANIZATION ROLE
• DELIVERABLES
• PARTICIPANTS
• UPCOMING EVENTS

29
ISO/TC67 SC/MC MEETINGS

• Management Committee San Francisco, 29 June
  2007 Pangbourne (UK), 19 October 07
• SC6 Rio, 8-9 May 2007
• SC7 Calgary, 5-6 June 2007
• SC4 San Francisco, 21-22 June 2007
• SC5 San Francisco, 23 June 2007
• SC3 San Francisco, 27 June 2007
• Brussels, 4-5 December 2007

30
ISO/TC67 PLENARY MEETING

• Held annually
• Rotates among P member countries
• 2007 UK
• 17-18 October 2007
• Pangbourne
• 2008 China, Beijing
• 2009 Canada, Calgary or Ottawa (tentative)

31
INFORMATIONAL WEBSITESisotc.iso.orgorwww.tc67.
net
32
THANK YOU

• AND QUESTIONS?
