ISQA 572/ 449 Models for Quality Control/ Process Control and Improvement

1
ISQA 572/ 449Models for Quality Control/ Process
Control and Improvement

• Dr. David Raffo
• Tel [phone], Fax [phone]
• Email davidr_at_sba.pdx.edu

2
Intro to TQM

• TQM originates from a desire to improve and a
  necessity to compete.
• Product Designed-gt Process Designed -gt Product is
  Manufactured
• Typically, management and engineers design the
  production system.

3
Intro to TQM

• How does TQM fit in?
• Have those who are in the best position to know
  how the system is working.
• Use basic tools to use basic data and gain feed
  back on the process?

4
What is Quality?

• Quality of Conformance
• Suitable for use by form, fit , function
• Conformance to standard or specification
• Reliability and Consistency
• Quality of Design
• Meets customer needs
• Kinds of materials used
• Tightness of tolerances

5
What is Quality?

• Customer Satisfaction
• Providing features and functions to satisfy
  customer
• Total Quality Management
• Customer focus
• Obsession with quality
• Recognizing the structure in work
• Freedom through control
• Unity of purpose/teamwork
• Continuous improvement

6
What is Quality?

• Customer Value
• Customer focus
• What do customers want?
• How much are they willing to pay?
• Why do they purchase one product or service over
  another?
• Drive organization to provide products and
  services to meet or exceed customer expectations

7
Evolution of the Quality Movement
8
Quality Leaders

• Demming
• 14 Points
• Plan-Do-Check-Act Loop
• Focus on management involvement and quality
  improvement

9
Demings 14 Points

• 1. Create constancy of purpose for improvement of
  product and service.
• 2. Adopt the new philosophy.
• 3. Cease dependence on mass inspection.
• 4. End the practice of awarding business on price
  tag alone.
• 5. Constantly and forever improve the system of
  production and service.
• 6. Institute modern methods of training on the
  job.
• 7. Institute modern methods of supervising.

10
Demings 14 Points

• 8. Drive out fear.
• 9. Break down barriers between departments.
• 10. Eliminate numerical goals for the work force.
• 11. Eliminate work standards and numerical
  quotas.
• 12. Remove barriers that hinder the hourly
  workers.
• 13. Institute a vigorous program of education and
  training.
• 14. Create a structure in top management that
  will push every day on the above 13 points.

11
Quality Leaders

• Juran
• 80 of quality defects are management
  controllable and it is management which needs to
  change most.
• 7 Points

12
Jurans 7 Points

• 1. Breakthrough in attitudes.
• 2. Identify the vital few projects.
• 3. Organize for breakthrough in knowledge.
• 4. Conduct the analysis.
• 5. Determine how to overcome resistance to
  change.
• 6. Institute the change.
• 7. Institute controls.

13
Quality Leaders

• Crosby
• Zero Defects is the Quality Goal Slogan
• Acceptable Quality Level (AQL) Automobile
• 14 Step program

14
Crosbys 14 Step Program

• 1. Management commitment
• 2. Quality improvement team
• 3. Quality measurement
• 4. Cost of quality evaluation
• 5. Quality awareness
• 6. Corrective action
• 7. Zero-defects planning

15
Crosbys 14 Step Program

• 8. Supervisory training
• 9. Zero-defects day
• 10. Goal setting
• 11. Error cause removal
• 12. Recognition
• 13. Quality councils
• 14. Do it all over again

16
Comparative Assessment Matrix Quality
Management Tasks
17
Quality Leaders

• Taguchi
• Must Design in Quality
• Design of Experiments to reduce variation
  (Orthogonal Array 15/16)
• Quality Loss Function
• Feigenbaum
• The Hidden Plant is the proportion of plant
  capacity that exists in order to rework
  unsatisfactory parts. Generally 15-40

18
Quality Leaders

• Shewhart
• Formulas used for X-bar and R charts
• Ishikawa
• 7 Quality tools - histogram, check sheet, scatter
  diagram, flow chart, control chart, Pareto
  diagram, cause effect diagram
• Quality Circles

19
Continuous Process Improvement

• Action is the bottom- line PDCA cycle and TQM
  tools.
• Involves integrating people, processes, and
  technology
• Benchmarking
• Business Process Re-engineering

• Benchmarking Steps
• Identify processes needing improvement
• Identify world leader
• Visit world leader
• Analyze data
• How to implement processes observed in one
  organization at another?

20
Steps in Quality Improvement

• Recognize Problem/ Est. Priorities (BS, PA)
• Form Quality Improvement Teams
• Define problem (Why-Why, Fishbone)
• Analyzing problem/ process (Flowchart)

21
Steps in Quality Improvement

• Define possible causes
• Fishbone diagram
• Check sheets, histograms
• Scatter diagrams
• Control charts and run charts
• Identify potential solutions
• Implement solution
• Evaluate
• Make permanent, CPI

22
TQM Observations

• TQM approaches essentially
• Emphasize customer service
• Seek to eliminate defects in production
• Seek to empower employees as key actors and
  agents of change.
• Management must support the improvement process
  or it will go nowhere
• Improving the process is the central focus

23
Quality Certifications

• Examples of quality certifications and awards
• ISO-9000
• Capability Maturity Model
• Malcolm Baldridge, Demming Prize, etc.

24
A Commonly Used Standard

• ISO 9000

25
ISO 9000

• Series of standards
• Promoted strongly by the European Community
• Intentionally vague (covers wide variety of
  businesses)
• Do what you say and say what you do
• Important for competitive purposes
• Important spirit of law is followed
• Get certified by external auditor

26
ISO 9000 Series

• ISO 9000 Quality Management Quality Assurance
  Standards
• Guidelines for selection use
• ISO 9001 Quality Systems
• Model for quality assurance in design
  development, production, installation servicing
• ISO 9002 Quality Systems
• Model for quality assurance in production
  installation
• ISO 9003 Quality Systems
• Model for quality assurance in final insp. test

27
ISO 9000 Series

• ISO 9004 Quality Management Quality System
  Guidelines
• Marketing marketing research
• Design/specification engineering
• Purchasing
• Production
• Inspection, test examination
• Handling, packaging storage
• Sales distribution
• Installation operation
• Technical assistance maintenance
• Disposal after use

28
Application to Software

• Capability Maturity Model

29
Motivation for Process Improvement

• Competition at home and abroad is driving the
  need to reduce costs, reduce cycle time and
  improve quality.
• At the same time, systems are getting
  increasingly complex and the integration of
  hardware and software is more challenging.
• Companies need to improve performance.
• Key question is HOW?

30
Introduction
To improve performance, companies have
previously looked at technology and people.
Technology
People
Process
Currently, improving software process is a major
focus for many organizations. Moving to a
Balanced approach.
Source Software Engineering Institute (SEI)
31
Capability Maturity Model

• Provides a framework for process improvement
• Processes are assessed to determine their current
  level of process maturity
• Five levels of maturity
• 17 Key Process Areas (KPAs) related to essential
  core software development processes
• Actions to be taken based on current state of the
  process

32
The Five Levels of Software Process Maturity
33
Implications Of Advancing Through CMM Levels
34
Visibility Into The Software Process At Each
Maturity Level
35
Key Practice Areas

• Level 2 - Repeatable
• Software requirements management
• Software configuration management
• Project planning
• Project monitoring and control
• Level 3 - Defined
• Organization process definition
• Training program
• Peer Reviews
• Integrated software management

36
Key Process Areas

• Level 4 - Managed
• Software quality management
• Quantitative process management
• Level 5 - Optimizing
• Process change management
• Technology change management
• Defect prevention

37
The CMM Structure
38
Process Improvement Benefits
Source Software Engineering Institute, CMU/
SEI-94-TR-13, p15
39
Malcolm Baldrige Award Criteria

• Leadership
• Information Analysis
• Strategic Quality Planning
• Human Resource Utilization
• Quality Assurance of Products Services
• Quality Results
• Customer Satisfaction

40
Malcolm Baldrige National Quality Award Criteria

• 1.0 Leadership
• 1) Senior Executive Leadership
• 2) Quality Values
• 3) Management for Quality
• 4) Public Responsibility
• 2.0 Information Analysis
• 1) Scope management of quality data
  information
• 2) Competitive comparisons benchmarks
• 3) Analysis of quality data information
• 3.0 Strategic Quality Planning
• 1) Strategic quality planning process
• 2) Quality goals plans

• 4.0 Human Resource Utilization
• 1) Human resource management
• 2) Employee involvement
• 3) Quality education training
• 4) Employee recognition performance measurement
• 5) Employee well-being morale
• 5.0 Quality Assurance of Products Services
• 1) Design introduction of quality products
  services
• 2) Process quality control
• 3) Continuous improvement of processes
• 4) Quality assessment
• 5) Documentation
• 6) Business process support service quality
• 7) Supplier quality

41
Malcolm Baldrige National Quality Award Criteria

• 6.0 Quality Results
• 1) Product service quality results
• 2) Business process, operational support
  service quality results
• 3) Supplier quality results
• 7.0 Customer Satisfaction
• 1) Determining customer requirements
  expectations
• 2) Customer relationship management
• 3) Customer service standards

• 4) Commitment to customers
• 5) Complaint resolution for quality improvement
• 6) Determining customer satisfaction
• 7) Customer satisfaction results
• 8) Customer satisfaction comparison

42
MBNQA Results - Employee Relations

• Average improvement of 1.4 in overall employee
  job satisfaction.
• Above average industry attendance rates in 9 of
  11 reporting companies.
• Lower employee turnover than industry averages
  report in 7 of 11 participating companies.
• Safety and health rates were better than industry
  averages in 12 of 14 companies.
• Increase in the total number of quality
  improvement suggestions submitted in 5 of 7
  companies.

43
MBNQA Results - Employee Relations

• Millikens suggestion system yielded 262,000
  suggestions during 1989 with an 87 completion
  rate. In 1990 it rose to 472,884.
• At Commercial Nuclear Fuel Division at
  Westinghouse, employee suggestions increased from
  425 in 1985 to 2,000 in 1988.
• Cadillacs employee turnover rate has been cut in
  half. They also experienced a 33 improvement in
  injury and illness rates.
• IBM Rochesters safety record was 57 better,
  absenteeism rate was 48 less and turnover rate
  was 88 less.

44
MBNQA Results - Operating Procedures

• Average improvement in reliability was 11.3.
• On-time delivery improved 4.7 on an average
  annual basis.
• Overall average annual order processing time
  improved 12.
• Overall reduction in errors was 10.3 on an
  annual basis.
• Overall product lead time was reduced 5.8.
• Average annual inventory turnover increased 7.2.
• Quality costs improved 9 on an annual basis.
• The range in annual average cost savings was 1.3
  million to 116 million.

45
MBNQA Results - Operating Procedures

• Milliken improved from 75 on-time deliveries in
  1984 to 99 in 1988 60 reduction in cost of
  nonconformance productivity increased 43 since
  1983.
• Since 1989, Motorolas quality improvements have
  reduced by 250 million the cost incurred through
  internal and external failures. In the cellular
  telephone operation there was a 30 to 1 reduction
  in factory cycle time and a 90 reduction in
  defects/unit.
• At Commercial Nuclear Fuel Division of
  Westinghouse, first time yields on fuel rods
  increased to 87 in 1987 from 50 in 1984.

46
MBNQA Results - Customer Satisfaction

• Customer satisfaction increased an annual average
  rate of 2.5.
• Complaints declined at an average annual rate of
  11.6.
• Customer retention at Cadillac improved 24
  between 1987 and 1990. Customer satisfaction
  with service has increased 17 since 1989.
• Globes customer complaints went from 41 in 1985
  to 4 in 1987.
• At Federal Express, overall customer satisfaction
  for domestic service has averaged better than 95
  since 1987 94 for international service.

47
MBNQA Results - Financial Performance

• Market share increased 13.7 annually.
• Sales per employee increased 8.6 annually.
• Return in assets increased 1.3 annually.
• Return on sales increased an average of 0.4.

48
Quality Certifications

• Many good ideas
• Process improvement and change are not easy.
• Takes effort and perseverance
• Management commitment
• Mixed results for standard processes Need
  application of the Spirit over the Formality

49
(No Transcript)
