Molecular Geometry and 3D Structures of Molecules

1
Molecular Geometry and 3D Structures of Molecules
2
Methane Lewis Dot Structure
3
Sites on an atom

• A site is something that takes up space around
  the atom.
• Attached atoms
• Unshared pairs of electrons
• Total sites attached atoms unshared
  pairs

4
Sites in Methane

• Carbon is central atom
• 4 atoms (H) attached
• no unshared pairs
• sites 4 0 4
• 4 sites

5
VSEPR Theory

• Electrons repel
• Will move as far apart as possible in 3
  dimensions
• Actually electron clouds that repel.
• Attached atoms positioned by repulsion of
  electrons clouds bonded to.

6
Methane Summary

• clouds arrange tetrahedrally
• clouds 109.5o apart
• Shape is tetrahedral

7
Methane ball and stick
8
3D representation of methane

• Wedge is coming out of plane of paper
• dash behind
• compare to ball and stick

9
Comparison of Methane Structures
10
Space filling model of methane
11
Summary sheet
12
Ammonia Lewis Dot Structure
13
Sites in Ammonia

• 3 attached atoms
• 1 unshared pair
• total of 4 sites
• Clouds tetrahedral

14
Ammonia Ball and Stick
15
3D Representation of Ammonia

• Clouds still tetrahedral
• one cloud has unshared pair
• invisible cloud
• repels more strongly than bonds
• pushes bonds together
• bond angle 107.7
• trigonal pyramidal

16
Comparison of Ammonia Structures
17
Ammonia space fill
18
Summary sheet
19
Water Lewis Dot Structure
20
Sites in Water

• 2 attached atoms
• 2 unshared pairs
• 4 sites
• Clouds tetrahedral

21
Water Ball and Stick
22
3D Representation of Water

• Clouds still tetrahedral
• two clouds have unshared pairs
• invisible clouds
• repel more strongly than bonds
• push bonds together
• bond angle 105
• bent

23
Comparison of Water Structures
24
Water Space Fill
25
Summary sheet
26
HCl Lewis Dot Structure
27
Sites in HCl

• 1 attached atom
• 3 unshared pairs
• 4 sites
• Clouds tetrahedral

28
HCl Ball and Stick
29
3D Representation of HCl

• Clouds still tetrahedral
• three clouds have unshared pairs
• invisible clouds
• bond angle 180
• linear

30
Comparison of HCl Structures
31
HCl Space Fill
32
Summary sheet
33
CH2O Lewis Dot Structure
34
Sites in CH2O

• 3 attached atoms
• 0 unshared pairs
• 3 sites
• Clouds trigonal planar

35
CH2O Ball and Stick
36
3D Representation of CH2O

• clouds go to corners of equilateral triangle
• bond angle 120
• trigonal planar

37
Comparison of CH2O Structures
Since planar, both structures are the same.
38
CH2O Space Fill
39
Summary sheet
40
SO2 Lewis Dot Structure
41
Sites in SO2

• 2 attached atoms
• 1 unshared pairs
• 3 sites
• Clouds trigonal planar

42
SO2 Ball and Stick
43
3D Representation of SO2

• Clouds go to corners of equilateral triangle
• unshared pair is invisible cloud
• bond angle between 105 and 120
• bent

44
Comparison of SO2 Structures
Since bent, both structures are the same.
45
SO2 Space Fill
46
Summary sheet
47
SO2 Lewis Dot StructureDouble bonded oxygen
48
Sites on O in SO2

• 1 attached atoms
• 2 unshared pairs
• 3 sites
• Clouds trigonal planar

49
3D Representation of SO2

• Clouds go to corners of equilateral triangle
• unshared pairs are invisible clouds
• bond angle 180
• linear around double bound oxygen

50
Comparison of SO2 Structures
Linear around double bonded O
51
Summary sheet
52
CO2 Lewis Dot Structure
53
Sites in CO2

• 2 attached atoms
• 0 unshared pairs
• 2 sites
• Clouds linear

54
CO2 Ball and Stick
55
3D Representation of CO2

• Clouds linearly arranged.
• bond angle 180
• linear

56
Comparison of CO2 Structures
Since linear, both structures are the same.
57
CO2 Space Fill
58
Summary sheet
59
N2 Lewis Dot Structure
60
Sites in N2

• 1 attached atom
• 1 unshared pair
• 2 sites
• Clouds linear

61
N2 Ball and Stick
62
3D Representation of N2

• Clouds linearly arranged.
• bond angle 180
• linear

63
Comparison of N2 Structures
Since linear, both structures are the same.
64
N2 Space Fill
65
Summary sheet
