Title: Corporate PPT Template


1
(No Transcript)
2
Andrew MendelsohnSenior Vice President
Database Oracle Corporation
3
Oracle Database 10gA Revolution in Database
Technology
4
Oracle Database 10g Goals
  • Highest Quality of Service
  • Highest Availability, Reliability, Security
  • Highest Performance, Scalability
  • Half the Cost
  • Lower hardware, software, labor costs
  • Easiest to Manage

5
Problem Islands of Computation
  • Limited scalability, no resource sharing
  • Must be configured for peak loads
  • Single point of failure
  • Slow to adjust to business needs

Sales
Files
HR
Procurement
Service
Supply Chain
Financials
6
Grid Computing Eliminates Islands of Computation
Coordinated use of many small servers acting as
one large computer.
IT Problem
Grid Solution
  • Expensive Components
  • High incremental costs
  • Configured for peak
  • Single point of failure
  • Hard to change
  • Difficult to manage
  • Low cost, modular components
  • Low incremental costs
  • Capacity on demand
  • Fault tolerant
  • Flexible
  • Unified management

7
Oracle Grid Computing
Coordinated use of many small servers acting as
one large computer.
8
Reducing IT Costs
Oracle Grid Computing
Large Dedicated Server
Grid Control
  • Expensive components
  • High incremental costs
  • Configured for peak
  • Single point of failure
  • Enterprise service at high cost
  • Low cost modular components
  • Low incremental costs
  • Capacity on demand
  • Fault tolerant
  • Enterprise service at low cost

9
Introducing Oracle 10g
  • Complete, integrated grid infrastructure

10
Introducing
11
Oracle Grid Computing
  • Highest quality of service
  • Lowest cost
  • Easiest to Manage

12
Automatic Storage Management (ASM)
  • Eliminates need for conventional file system and
    volume manager
  • Capacity on demand
  • Add/drop disks online
  • Automatic I/O load balancing
  • Stripes data across disks to balance load
  • Best I/O throughput
  • Automatic mirroring
  • Easy

Automatic Storage Management
13
Automatic Storage Management (ASM)
  • Eliminates need for conventional file system and
    volume manager
  • Capacity on demand
  • Add/drop disks online
  • Automatic I/O load balancing
  • Stripes data across disks to balance load
  • Best I/O throughput
  • Automatic mirroring
  • Easy

Automatic Storage Management
14
Automatic Storage Management Summary
  • Low Cost
  • Eliminates need for volume manager and file
    systems
  • Works well with inexpensive, modular storage
  • Better storage utilization
  • Easy up to 50 less DBA/Sys Admin work
  • Fault tolerant
  • Raw disk performance
  • Capacity on demand
  • Automatic I/O load balancing

15
Storage Grid - Highest Data Protection for Lowest
Cost
16
Database Server Grid Real Application Clusters
  • Runs Real Applications
  • Proven
  • Over 1000 production sites
  • Certified with leading apps
  • Runs on standard,low cost servers
  • Fault tolerant

ERP
CRM
DW
17
Cost savings as much as 25-50 in hardware and
maintenance were real and undeniable.
  • Gartner

Source Gartner Early Adopters Experiences with
Oracle9i RAC, Nov 2003
18
Database Server Grid -Integrated Clusterware
  • Portable to all platforms
  • Low Cost
  • No need to purchase additional software
  • Easy to install, manage
  • Easy
  • Deploys in hours not days
  • Improved single system image
  • Single-vendor support
  • Remains open to third-party clusterware

19
Database Server Grid Workload Management
  • Push-button, online add/drop server to cluster
  • Automatic Load Balancing
  • Based on service concept
  • Automatic routing of service connection requests
    to appropriate server with lowest load
  • On server failure, automatic re-allocation of
    surviving servers to services
  • Dynamic load balancing when service levels not
    met (coming soon)

20
Grid Fault Tolerance
Database App. Server Total
Failover Detection Recovery Time
minutes
minutes
Oracle9i Oracle 10g
lt 1 minute
seconds
seconds
seconds
  • Fastest end-to-end application failover with
    Oracle 10g infrastructure

21
Low Cost Servers - HP TPC-C Benchmark
1,184,893
1,008,144
7.9 MTotal Cost
2.6 MTotal Cost
TPM-C
Same 1.5 GHz Itanium2 CPUs
Source http//www.tpc.org - Audited Results
22
Oracle RAC 10g - Only Solution for Enterprise
Grids
  • Mission Critical Quality of Service on Industry
    Standard, Low Cost Servers
  • Integrated clusterware makes RAC easy for
    everyone
  • Fault tolerant, scales all applications
  • Capacity on demand
  • Automatic load balancing

23
Oracle 10g Grid ManagementOne-half to one-tenth
the cost
  • Self-Managing Database
  • OEM Grid Control
  • Grid-wide operations
  • Scale from one to hundreds of systems with little
    incremental cost

24
Business Challenge How to Scale DBAs to the
Grid ?
Installation 6
Others 15
DataLoading 6
Software Maintenance 6
Ongoing System Management 55
Source IOUG 2001 DBA Survey
25
Oracle Database 10gSelf-managing Database
  • Built-in Intelligent Infrastructure
  • Code instrumentation
  • Workload repository
  • Automation of Routine Tasks
  • Automatic disk-based backup and recovery
  • Automatic optimizer statistics collection
  • Automatic PGA and SGA Memory Management
  • Automatic Storage Management
  • Tools to Empower the DBA
  • Automatic Database Diagnostic Monitor
  • Automatic Tuning Optimizer
  • Lots more

26
Sophisticated Simplicity.
  • Infoworld

Source Infoworld.com, March 22, 2004
27
Oracle has clearly gone farther than any other
vendor to instrument the database and provide
expert advice to administrators.
  • Charlie Gary, Meta Group

Source Source META Group Oracle 10g Managing
Reality, December 17, 2003
28
Oracle OEM 10g Grid Control
  • Manages the Oracle Grid environment
  • Scales to thousands of servers
  • Application Service Level Management
  • Configuration Management
  • Provisioning
  • Cloning
  • Patch Management

29
We now can manage hundreds of servers throughout
the world from within one powerful management
console.
  • Warwick CalkinNational Manager, Telstra IT
    Infrastructure and Operations

30
Business Intelligence on the Grid
  • Lower Cost
  • Leverage hardware, software, labor savings
  • Manage millions of terabytes
  • Intelligence when you need it
  • Cross-platform transportable tablespaces
  • Asynchronous change data capture
  • More value from your data
  • Mature OLAP, Data Mining
  • Improved SQL Analytics SQL Model Clause

31
HTML DB Rapid Web Development Tool
  • Builds database-driven Web applications
  • For non-programmers
  • App developers and app users just need a web
    browser
  • Addresses MS Access proliferation problem
  • Supports hosted development and deployment
    environment

32
Oracle Database 10g Performance Metrics
  • PLSQL up to 2x
  • Table Scans up to 2x
  • SQL Profile Tuning huge
  • Floating point math up to 10x
  • Bulk LOB Update up to 3x
  • Import up to 15x
  • Export up to 35
  • Incremental backup up 10x
  • Parallel media recovery 2-4x
  • Backup compression 17x
  • Infiniband interconnect ½ latency, 2x block
    transfer
  • TPC-C
  • 1.2 million on RAC, 1 million SMP
  • Best absolute and best on 4-way Intel
  • 28 on same hardware

33
Easy Transition to the Grid
  • Oracle 10g preserves investment
  • Runs all existing apps on clusters
  • Moves data to new platforms as fast as FTP
  • Low risk - Start small and add capacity on demand

ERP
EMAIL
DW
34
Oracle 10g Grid Computing
  • Half the Cost
  • Low cost, modular storage and servers
  • Complete, integrated software infrastructure
  • Half the labor cost
  • Highest Quality of Service
  • Rapidly Adjust to Business Needs
  • Capacity on demand
  • Load balancing
  • Easy to Manage

35

The best thing about the Grid is that it is
unstoppable. The Economist June 2001
2
36
(No Transcript)
