Title: Laboratory Diagnosis What is laboratory diagnosis


1
Laboratory Diagnosis
2
What is laboratory diagnosis?
  • Laboratory diagnosis is such a diagnostic process
    in which the samples coming from patients blood
    , body fluid , secretion , excretion , tissues
    and cells are examined by using various
    laboratory methods to get useful data which
    may reflects body s functional status ,
    pathological changes and etiological hints.

3
Why to study laboratory diagnosis?
  • Laboratory diagnosis is a very important part in
    diagnostics. After we have finished the study of
    physical diagnosis and instrument examination ,
    we might be able to judge what kind of disease
    this patient probably suffer from . For further
    diagnosis , it is still not enough if we only
    master physical examination . We have to depend
    upon some laboratory data to ensure our diagnosis
    .

4
How to learn laboratory diagnosis?
  • First, the methods used in laboratory diagnosis
    are more automatic and computerized.
  • Second , the aim is to train for clinical
    application .
  • For each test, referential values and clinical
    significance always should be known very well.

5
Chapter 1 Blood Test Blood routine test
(BRT)
  • 1. content (items) of BRT
  • red blood cell count (RBC)
  • hemoglobin(HB)concentration determination
  • total white blood cell count (WBC)
  • leukocyte differential count (DC)
  • platelet count (PC)

6
Rferential values of BRT
  • Table 1. Deferential values for blood routine
    test in different age and sex
  • ___________________________________
  • male female
    newborn
  • ___________________________________

  • RBC 4.0-5.5 3.5-5.0 6.0-7.0
  • HB 120-160 110-150 170-200
  • WBC 4-10 4-10 15-20
  • PLT 100-300 100-300
  • ___________________________________

7
Table 2 Referential values of differential
count
  • ___________________________________
  • type percent value() absolute value
  • ___________________________________
  • N st 1-5 0.04-0.5
  • N se 50-70 2-7
  • LYM 20-40 0.8-4
  • Mo 3-8 0.12-0.8
  • Eo 0.5-5 0.02-0.5
  • Ba 0-1 0-0.1
  • ___________________________________

8
Morphology of blood cells
  • Red blood cell normocyte 6-9um, discocyte-
    shape, no nucleus
  • white blood cell divided in five types
    neutrophilic granulocyte neutrophil stab cell
    (Nst), neutrophil segmented cell (Nse),
    lymphocyte, basophil granulocyte, eosinophil
    granulocyte
  • Platelet smallest cell in peripheral blood

9
In automatic blood cell analyzer,25 items are
included together
  • WBC 4.010.0x109/L
  • LYM 0.8 4.0 x109 /L (2040)
  • MID( middle cells) monocyte, eosinocyte,
    basocyte , immature cells(rare be seen)
  • GRAN(granulocyte)2.07.8x109/L(5070)
  • RBC4.05.5x1012/L(male),3.55.0x 1012 /L
    (female)
  • HGB 120160 g/L (male), 110150 g /L (femal)

10
-
  • HCT(hematocrit)0.40.5L/L(male), 0.37 0.48
    L/L (female)
  • MCV ( mean corpuscular volume) 8295 fl
  • MCH(mean corpuscular hemoglubin) 2731 pg
  • MCHC ( mean corpuscular hemoglubin
    concentration) 320360 g/L
  • RDW ( red cell distribution width ) 11.514.5
  • PLT( platelet) 100300x109 /L
  • MPV ( mean platelet volume) 8.716.5 fl
  • PDW ( platelet distribution width) 15.821.4

11
Clinical significance
  • Anomalies of RBC and HB
  • 1. decrease of RBC and HB
  • Anemia When RBC and HB of individual is lower
    than the referential values of the people in same
    age , same sex and same area. Usually, if Hb of
    adult male and female is lower than 120g/L or
    110g/L respectively, they are considered as
    anemia.

12
According to the level of Hb, anemia is divided
into four degrees in clinic
  • mild anemia Hb lt 120g/L(male) or lt
    110g/L(female)
  • medium anemia Hb lt90 g/L
  • severe anemia Hb lt60g/L
  • extreme severe anemia Hb lt30g/L

13
Physiological anemia
  • infant and children aged between 3 months to 15
    years,
  • pregnant women in middle or terminal periods of
    pregnancy,
  • elderly people.

14
Pathological anemia.
  • decrease in synthesis of red blood cell in bone
    marrow
  • increased destroy of red blood cell in peripheral
    blood
  • blood loss

15
Decrease in synthesis of red blood cell in bone
marrow
  • disorder of hemopoiesis in bone marrow
    aplastic anemia
  • infiltration of bone marrow by tumorous cell
    leukemia, multiple myeloma , lymphoma ,
    metastatic tumor
  • deficiency of hemopoietic materials or factors
    iron deficiency anemia(IDA), megaloblastic anemia
    (folic acid deficiency)

16
Destroy of RBC in peripheral blood
-- hemolytic anemia
  • Hereditory disease hereditory sphrocytosis
    (HS) , G6PD deficiency,
    thalassmia , Hb
    disease
  • Acquired anomalies hemolysis by immunological
    , physical, chemical , biological and
    mechanical factors

17
Blood loss --
hemorrhagic anemia
  • acute blood loss acute upper digestive tract
    bleeding , splenic rupture
  • chronic blood loss hemorrhoid, hookworm
    disease, hypermenorrhea, GI tumor

18
  • Increase of RBC and Hb
  • Comparative increase of RBC and Hb due to the
    decrease of volume of plasma--severe dehydration
    severe vomoting, diarrhea, severe burn
  • Absolute increase of RBC and Hbery-throcytosis
    polycythemia vera(PV), chronic cardiopulmonary
    diseases cor pulmonale, obstructive emphysema,
    scarcity of oxygen.

19
  • Anomalies of WBC and DC
  • In most cases, increase and decrease of WBC is
    chiefly depend on the numbers of neutrophil
    granuiocyte in the blood.
  • Leukocytosis WBC is high than 10 x109 /L
  • Leukopenia WBC is lower than 4 x109 /L

20
  • 1. Neutrophil granulocyte
  • A. granulocytosis 5 causes leading to
    granulocytosis
  • acute infection or inflammation acute pyogenic
  • tonsilitis, acute appendicitis,
    hematosepsis
  • damage or necrosis of tissue severe burn, acute
    myocardiac infarction

21
  • acute blood loss digestive tract bleeding,
  • splenic rupture
  • Acute poisoning uremia, ketoacidosis
  • Malignant blood diseases and tumor
  • leukemia, metastatic tumor

22
  • Granulocytopenia
  • leukopenia WBC lt 4 x109 /L
  • granulocytopenia
  • neutrophil granulocyte lt 1.5 x109 /L
  • agranulocytopenia
  • neutrophil granulocyte lt 0.5 x109 /L

23
  • 5 causes for granulocytopenia
  • Infection of bacteria and virus typhoid,
    influenza,
  • measles
  • some physical and chemical factors drug
  • autoimmune diseases systemic lupus
    erythematosis (SLE),
  • malignant blood diseases aplastic
    anemia,leukemia
  • hypersplenism

24
  • Changes of nucleus
  • nucleus shift to left
  • mild shift to left Nst gt 6 only
  • medium shift to left Nst gt 10 with meta-
  • myelocyte
  • severe shift to left Nst gt 25 with more
  • immuture cell (leukemiod reaction )
  • nucleus shift to left cab be seen in acute
    infection,
  • acute poisoning, acute hemolysis

25
  • Nucleus shift to right multi-segmented Nse
    gt3
  • 3-lobed Nse is normal segmented neutrophil in
    BP
  • nucleus shift to right can be seen
  • megaloblastic anemia
  • administration of anti-metabolic drugs

26
  • 2. lymphocyte
  • A . Lymphocytosis DC Lym gt 40
  • Virus infection infectious mononucleosis,
  • chickenpox,
  • Lymphocytic leukemia ALL, AA, lymphoma
  • GVHD or GVHR after BMT

27
  • B. lymphocytopenia
  • administration of anti-tumor drugs, prednision
  • radiation x-ray, r-ray , isotope
  • 3. monocytosis
  • malaria, black fever, TB, subacute bacterial
  • endocarditis(SBE)
  • monocytic leukemia, malignant histocytosis,

28
  • 4. eosinophilia
  • allergic diseases, hypersensitive diseases
  • parasites infection
  • Skin diseases psoriasis
  • blood diseases CML, eosinophilic leukemia,
  • lymphoma
  • Infectious diseas scarlatina
  • Hypereosinophilic syndrome

29
5. Basophil granulocyte bosophilia CML,
basophilic leukemia,
myelofibrosis
30
Other tests for red blood cell
  • Reticulocyte count (RC)
  • 0.05-0.015 (0.5-1.5)
  • 24-84 x109 /L
  • Reticulocytosis hemolytic anemia
  • acute hemorrhagic
    anemia
  • index of therapeutic
    effect
  • IDA, megaloblastic
    anemia

31
  • Reticulocytopenia
  • Aplastic anemia
  • leukemia

32
  • 2. Hematocrit(Hct)
  • 0.4-0.5L/L(male), 0.37-0.48L/L(female)
  • increase of Hct
  • blood concentration
  • water loss
  • polycythemia(PV)
  • decreas of Hct anemia

33
3. Mean values of RBC Mean corpuscular volume
(MCV) MCVHct/RBC
82-95fl Mean corpuscular hemoglubin(MCH)
MCHHb/RBC 27-31pg Mean corpuscular
hemoglubin concentration
MCHCHb/Hct 320-360g/L
34
Morphological classification of
anemia Classification MCV MCH MCHC
diseases Normocytic 82-95 27-31
320-360 AA, HA, leukemia Macrocytic gt100
gt 31 320-360 MA, pernicious

anemia Microcytic lt 80 lt
27 320-260 infection, tumor,

uremia Microcytic lt 80 lt 27
lt 320 IDA, thalassemia Hypochromic

sideroblastic
anemia
35
  • Erythrocyte sedimentation rate(ESR)
  • 0-15mm/h (male), 0-20mm/h (female)
  • higher ESR
  • infection and inflammation rheumatic
    diseases,tuberculosis
  • malignant tumor
  • anemia
  • damage or necrosis of tissue
  • globulinemia, cholesterolemia

36
Chapter 2. Bone MarrowExamination
  • 1. Clinical application of marrow examination
  • Diagnosis for hematopoietic system diseases
  • leukemia, myeloma, aplastic anemia, etc
  • parasite infectious diseases malaria, black
  • fever
  • metabolic diseases Gaucher disease. Niemann-Pick
    disease

37
  • Indications
  • Fever origin unknown (FOU)
  • Cachexia
  • Hepatomegaly, splenomegaly, lymphoadenovarix
  • Abnormal in quantity and quality in peripheral
  • blood cell

38
  • Contraindication
  • Hemophilia
  • Pyogenic infection in local skin
  • Methods
  • bone marrow aspiration
  • bone marrow biopsy

39
  • Development of blood cells
  • myeloblast promyelocyte
    myelocyte metamyelocyte Nst
    Seg
  • normoblast basophilic normoblast
  • polychromatic normoblast
    orthochromatic
  • normoblast erythrocyte

40
Monoblast promonocyte
monocyte macrophage
histiocyte Megakaryoblast promega
granular Meg thrombocytogenous Meg
platelet B-lymphoblast
B-prolymphoblast B-lymphocyte
plasmablast proplasmacyte
plasmacyte
41
3. Regulation of blood cell development
  • Cytobody from large to small,
  • Mega is an exception
  • Cytoplasma from less to more,
  • color from blue to pink or orange red,
  • granules from invisible to visible,
  • granules from non-specific to specific

42
  • Nucleus
  • from large to small, Mega is an exception,
  • shape of nucleus from round to irregular,
  • chromatin patten of nucleus from fine to
  • coarse.
  • nucleolus from existance to nonexistance
  • Ration of nucleus to cytoplasma
  • from bigger to smaller

43
(No Transcript)
44
(No Transcript)
45
5.Contene and step of marrow examination
  • Myelogram
  • Low power(LP)
  • Wright stain of marrow film
  • plastic degree 5 classification
  • Meg count 7-35/1.5x3cm2
  • ousspecial cell metastatic tumorous cell

46
  • Oil immersion
  • Nucleated cell count () 200-500
  • Ratio of myeloid to erythroid (ME) 2-41
  • Morpholigical description of every series
  • Special cells and parasite
  • Diagnosis

47
  • Hemogram
  • Low power(LP)
  • Oil immersion len differential count 100
  • leukocyte (DC)
  • Immature cell (nucleated cell)
  • parasites

48
6. Normal myelogram and hemogram
  • 1. Myelogram
  • Normal cellularity erythrocyte nucleated cell
  • ME2-41
  • Granulocytic series is 40-60 in all nucleated
    cells
  • Erythrocytic series is 20 in all nucleated cells
  • Lymphocyte is 20 , monocyte is lt4 in all
    nucleated cells
  • Meg count is 7-35, platelet is normal
  • Other cell plasmacyte and histiocyte are rare
  • No specific cells and parasite

49
Plastic degree of
marrow Plastic degree erythrocyte
nucleated diseases Extreme
hypercellularity 11
leukemia Significant hyper- 101
leukemia, ITP,
Cellularity
plastic anemia Normal
cellularity 201
anemia, normal

myelogram Hypocellularity
501 AA,agranulocy-

topenia Extreme hypocellularity
3001 aplastic anemia
50
  • 2. Hemogram
  • DC is normal
  • No nucleated red blood cell
  • No immature white cell
  • Platelet is normal

51
(No Transcript)
52
(No Transcript)
53
7. Characters of common blood diseases in
microscope
  • Iron deficiency anemia(IDA)
  • Aplastic anemia(AA)
  • Acute leukemia(AL)
  • Chronic myelocytic leukemia(CML)
  • Idiopathic thrombocytopenia purpura(ITP)

54
1. Iron Deficiency Anemia(IDA)
  • Hemogram
  • Hb , RBC , normal RC,
  • RBC hypochromia, exaggeration of central
    pallor to from rings, anisocytosis
  • normal WBC and platelet

55
  • Myelogram
  • Significant hypercellularity
  • ME
  • Erythroid hyperplasia with small normoblast
  • Pycnotic nuclei and scanty cytoplasma
  • irregular margin

56
(No Transcript)
57
2. Aplastic Anemia(AA)
  • Hemogram
  • pancytopenia Hb ,RBC , WBC ,PLT
  • RC lt0.005 or absolute value lt 15 x109 /L
  • RBC is normocytic

58
  • Myelogram
  • Hypocellularity or extreme hypocellularity,
  • Hematopoietic cell decrease erythroid, myeloid
  • cells , meg or absent, platelet rarely
    be seen
  • Non-hematoietic cell increase lymphocyte
  • Reticular cell , plasmacyte

59
(No Transcript)
60
3. Acute Leukemia(AL)
  • FAB classification
  • acute lymphocytic leukemia L1-L3
  • acute non-lymphocytic leukemia M0-M7
  • Hemogram
  • Hb, RBC
  • WBC uncertain normal, increase, decreas
  • platelet

61
  • Myelogram
  • Extreme or significant hypercellularity
  • ME
  • Hyperplasia of certain line
  • Myeliod(M0,M1-3), monocyte(M4-5), meg(M7),
    lymphocyte(L1-3) , erythroid(M6)
  • Depressed erythroid and meg line

62
(No Transcript)
63
(No Transcript)
64
(No Transcript)
65
(No Transcript)
66
(No Transcript)
67
(No Transcript)
68
(No Transcript)
69
(No Transcript)
70
(No Transcript)
71
(No Transcript)
72
(No Transcript)
73
(No Transcript)
74
4. Chronic Myelocytic Leukemia(CML)
  • Hemogram
  • WBC increase rxtremly
  • DC E0, Ba increas, myelocyte,
  • metamyelocyte, band cell increase
  • normal Hb, RBC or mild decrease
  • normal plt

75
  • Myelogram
  • Extreme hypercellularity
  • ME increase
  • Extreme hyperplasia of granulocyte with increas
    of myelocyte, metamyelocyte, band cell, E0, Ba
  • Normal erythroid and Megakaryocyte

76
(No Transcript)
77
(No Transcript)
78
(No Transcript)
79
5. Idiopathic Thrombocytopenic Purpura(ITP)
  • Hemogram
  • normal Hb, RBC
  • normal WBC and DC
  • PC decreas with abnormal morphology

80
  • Myelogram
  • Significant hypercellulerity or normal
    cellularity
  • Normal myeloid, erythroid line
  • Significant hyperplasia of Meg.
  • Impaired maturation of Meg
  • Granular Meg or promeg increase
  • Platelet producting Meg absent
  • Platelet rarely be seen

81
(No Transcript)
Write a Comment
User Comments (0)
About PowerShow.com
