Fundamentals of Acquired Immunity

1
Fundamentals of Acquired Immunity
2

• I. Definitions

3

• Immunology the study of all aspects of host
  defense against infection and of adverse
  consequences of immune response
• Immunity the state of protection fro infectious
  diseases utilizing both innate and acquired
  mechanisms

4

• Immune response - a specific and complex series
  of events throughout the animals body that helps
  it defend against disease-causing organisms or
  substances
• Antigen particular foreign molecules that
  stimulate and immune response
• Often immunogenic on its own, otherwise requires
  a carrier molecule)
• Non-self substances to which lymphocytes can
  respond

5

• Innate Immunity non-specific protective
  mechanisms conferring basic resistance to disease

6

• general, physical, chemical, and biological
  barriers against disease
• discussed in previous unit
• also referred to as innate or natural immunity

7
II. Different Types of Acquired Immunity
8

• Acquired Immunity specific protective
  mechanisms displaying specificity, diversity,
  memory and self/non-self discrimination
• Often dependent on innate immunity for full
  activation
• Can be acquired actively or passively

9

• Naturally acquired active immunity - An
  individual comes in contact with an antigen (Ag)
  and produces sensitized lymphocytes and/or
  antibodies that inactivate the antigen
• Ag is encountered naturally
• Immune responses are activated
• Antibodies made
• Lymphocytes sensitized
• Result Ag inactivated or destroyed
• Memory generated (long-lasting immunity)

10

• Naturally acquired passive immunity - transfer of
  antibodies (Abs) from one individual to another
• Abs transferred from a donor to a recipient
  (adoptive transfer)
• Maternal transfer of IgG Abs to fetus across the
  placenta
• Maternal transfer of IgA Abs to newborn in
  colostrom and breast milk
• Newborn has immunity to infections encountered by
  mother previously
• Short-lived (weeks to months)

11

• Artificially acquired active immunity -
  deliberate exposure of an individual to a vaccine
  with subsequent development of an immune response
• Vaccine preparation of attenuated or killed
  microbes or inactivated toxins (toxoids)

12

• Artificially acquired passive immunity -
  deliberate introduction of antibodies into an
  individual
• Abs made deliberately in another animal or
  synthesized using in vitro methods
• Antiserum
• Antitoxins
• Antivenom
• Monoclonal antibodies (in vitro)

13

• III. Origin, Maturation and Function of
  Lymphocytes

14
B Lymphocytes

• Birds Bursa of fabricius
• Part of the chicken cloaca where B cells mature
• Absent in mammals
• Humans
• Fetal liver
• Bone marrow stem cells
• Two types
• T-dependent B cells (require T cell help)
• T-independent B cells (do not require T cell help)

15
T Lymphocytes

• Originate in the thymus
• DiGeorge Syndrome athymic no T cells
• Specialized anatomicl locations responsible for
  educating T cells
• Cortex
• Medulla
• Education involves two main processes
• Positive selection
• Negative selection

16

• Three types
• TH1 Inflammatory T cells
• Help macrophages (and B cells)
• TH2 Helper T cells
• Help B cells
• Tcyt Cytotoxic T cells (killer T cells)
• Kill target cells using perforin and granzyme

17
Natural Killer Cells (NK cells)

• Probably derived from prethymic lymphocytes
• Do not have the characteristics of either B-cells
  or T-cells
• AKA Large Granular Lymphocytes (LGL)
• AKA Null cells
• Not equivalent to killer T cells but kill their
  target cells using same mechanism (perforin and
  granzyme)
• Participate in ADCC

18

• Humoral Immunity

19
B Cells and Their Role in Humoral Immunity

• Involvement of Ab in immune responses
• T-dependent
• T-independent
• Protects against pathogens that exist in fluid
  spaces
• Bacteria and their toxins
• Viruses
• Protozoans
• Helminths
• When B cells begin to produce antibody upon
  activation by antigen, they differentiate into
  plasma cells

20
Cell-Mediated Immunity
21
T Cells and Their Role in Cell-Mediated Immunity

• Involvement of T cells subsets
• TH1
• TH2
• Tcyt
• Requirement for direct interaction with infected
  cell or foreign cells
• Involves complex of T cell receptor (TCR), Major
  Histocompatibility Complex molecule (MHC) and
  Antigenic peptide fragment

22

• Functions
• Lysis of host cells infected by viruses
• Elimination of cancer cells
• Productin of cytokines to assist other cells in
  eradicating foreign Ags
• Cytokines Molecules secreted by one cell and
  affecting a different cell type ? specific
  regulatory interactions
• Trasplantation rejection
• Due to differences in MHC class I and class II
  molecules (alloantigens)

23
NK Cells and Their Role in Cell-Mediated Immunity

• Nonspecifically kill tumor cells, virus-infected
  cells, and other parasite-infected cells
• Play a role in regulating the immune response
• Exhibit antibody dependent cell-mediated
  cytotoxicity (ADCC)

24
Figure 31.20
25

• IV. The Nature of Antigens

26
SELF VERSUS FOREIGN
27
Self

• Prior to and after birth, the immune system
  develops and is able to differentiate between
  self proteins and foreign proteins
• T cells that are responsive to self Ags are
  eliminated early in their developmental pathway
• Negative selection
• Apoptosis occurs in the thymus
• Never enter periphery

28

• B cells interacting with self Ags either apoptose
  or anergize
• Apoptosis programmed cell death
• Anergy induction of non-responsive state

29
Self-Tolerance

• The process of elimination of self-reactive
  lymphocytes is called self tolerance
• Leads to removal of what could initiate harmful
  autoreactive response Autoimmunity
• Is very efficient, but not complete

30
FOREIGN
31
Immunogenicity

• The term immunogen is often used synonymously
  with the term antigen
• Careful!!!!
• All immunogens are antigens, but not all antigens
  are immunogens
• An immunogen is any substance that can mediate an
  immune response

32

• Types of Antigens (immunogens)
• Antigens recognized by B cells
• Proteins, peptides, glycoproteins,
  nucleoproteins, polysaccharides, lipids,
  glycolipids, and small chemical groups (haptens)
• B cell receptor Antibody (Ab)
• Antigens recognized by T cells
• Peptide in association with MHC molecule
• T cell receptor TCR

33
Epitopes

• Epitopes (antigenic determinant sites) are areas
  of an antigen that can stimulate production of
  specific antibodies and that can combine with
  them
• Some antigens have more than one site capable of
  interacting with Abs

34

• Valence - the number of epitopes on an antigen
  determines number of antibody molecules an
  antigen can combine with at one time
• Generally the high the valency, the more
  immunogenic the substance
• Epitopes (determinants) that are more easily
  accessible stimulate better immune response
  (projections or NH2/COOH ends)

35
Figure 32.3 The number of antigenic determinant
sites (epitopes) on an antigen is its valence.
36

• Hapten - a small organic molecule that is not
  itself antigenic but that may become antigenic
  when bound to a larger carrier molecule
• Examples
• Dinitrophenol (DNP)
• Penicillin

37
Figure 32.4 Effect of carrier on immunogenicity
of hapten.
38

• V. Structure and Function of Antibodies
  (Immunoglobulins)

39

• What is an antibody?

40
Antibodies

• A group of glycoproteins in the blood, serum, and
  tissue fluids of mammals
• Produced in response to an antigen and can
  combine specifically with that antigen
• In the serum, four major classes can be measured
  electrophoretically, but there are actually five
  classes

41
Figure 32.6 Electrophoresis of human serum
showing distribution of serum proteins and four
major classes of immunoglobulins.
42

• Immunoglobulin structure
• Multiple antigen-combining sites (usually two
  some can form multimeric antibodies with up to
  ten combining sites)
• Composed of four polypeptide chains (two heavy or
  long, and two light or short) that form a
  flexible Y with a hinge region
• Heavy chain 440 aa, 50-70kDal (GAMED)
• Light chain 220 aa, 25kDal (kappa or lambda)

43

• The stalk of the Y (called the Fc) is constant in
  amino acid sequence (i.e., the amino acid
  sequences of antibodies of the same subclass do
  not vary significantly)
• Constant regions are relatively invariable
  between Igs belonging to the same class (
  isotype, IgG, IgA, IgM, IgE, IgD)
• Constant regions confer different biological
  properties upon the Ig classes (in vivo half
  life, anatomical location, interactions with
  other molecules)

44

• B cells can switch from production of one type of
  Ig to another type (isotype) by a mechanism known
  as ISOTYPE SWITCHING
• Isotype switching is mediated by signals received
  during ongoing immune responses (e.g. T cell
  cytokines)

45

• The arms of the Y have variable regions and
  constitute the antigen-binding domains (Fab)
• Each Ab has 2 Ag-combining sites (bivalent) made
  up of H and L chain regions encoded by the
  variable portion of the Ig (VLVH)
• Some Abs exist as dimers (IgA) or pentamers (IgM)
  and so have 4 or 10 Ag-binding sites, respectively

46

• Intrachain disulfide bonds create loops on both
  heavy and light chain
• Each loop contains 25 aa making up a single
  domain
• Interchain disulfide bonds hold the heavy and
  light chains together
• H to H
• H to L

47

• Within the Fab segment are hypervariable (or
  complementarity determining) regions
• these regions are responsible for the diversity
  of antibodies

48
Figure 32.8 Constant and Variable Domains in
Heavy and Light Chains Dark blue
hypervariable regions in the variable
domains Hypervariable regions are also known as
complementarity determining regions (CDRs).
49
Pockets Grooves Extended Surfaces Peptide Ag
Red HIV peptide Orange HEL F(ab) frag. 5
CDRs used Red Ab contact sites Blue
Backbone Yellow Ag
50

• There are five types of heavy chains that
  determine the five classes (isotypes) of
  immunoglobulins (IgG, IgA, IgM, IgD, and IgE)
• In IgG there are four subclasses, and in IgA
  there are two subclasses

51

• Categories of immunoglobulin types
• Isotypes - variations in the constant regions of
  heavy chains that are associated with different
  classes and subclasses
• Allotypes - genetically controlled allelic forms
  of the immunoglobulin molecule
• Idiotypes - individual-specific immunoglobulin
  molecules that differ in the hypervariable
  regions of the Fab segments

52

• Review of Immunoglobulin Function
• Fab region binds to antigen
• Fc region mediates binding to host tissue, to
  various cells of the immune system, to some
  phagocytic cells, or to the first component of
  the complement system

53

• Binding of antibody to an antigen does not
  destroy the antigen, but marks (targets) the
  antigen for immunological attack or attack by the
  nonspecific defense mechanisms that do destroy it
• Opsonization - coating a bacterium with
  antibodies to stimulate phagocytosis

54
Figure 31.15
55

• Immunoglobulin classes (Isotypes)
• IgG - monomeric protein, 70 to 75 of Ig pool
• Antibacterial and antiviral
• Enhances opsonization
• Neutralizes toxins
• Only IgG is able to cross placenta (naturally
  acquired passive immunity for newborn)

56

• Activates the complement system by the classical
  pathway
• Four subclasses with some differences in function
• IgG1
• IgG2
• IgG3
• IgG4

57

• IgM - pentameric protein, 10 of Ig pool
• First antibody made during B-cell maturation
• First antibody secreted into serum during primary
  antibody response
• Never leaves the bloodstream
• Activates complement by classical pathway
• Enhances phagocytosis of target cells

58

• Agglutinates bacteria and foreign red blood cells
• Up to 5 may be hexameric which is better able to
  activate the complement system than pentameric IgM

59
Figure 32.11
60

• IgA - dimeric protein, 15 of Ig pool
• Associated with secretory mucosal surfaces
• Protects gastrointestinal tract, respiratory
  tract, and genitourinary tract
• Also found in saliva, tears, and breast milk
  (protects nursing newborns)
• Secretory form (sIgA) helps rid the body of
  antibody-antigen complexes by excretion into the
  gut lumen and subsequent excretion from the body
• Adherence Inhibition

61
Figure 32.12
62

• IgD - monomeric protein, trace amounts in serum
• Abundant on surface of B cells
• May play a role in B-cell recognition of antigens
• May play a role in B cell anergy
• Does not activate the complement system
• Cannot cross the placenta

63
Figure 32.13
64

• IgE - monomeric protein, less than 1 of Ig pool
• Skin-sensitizing and anaphylactic antibodies
• When an antigen cross-links two molecules of IgE
  on the surface of a mast cell or basophil, it
  triggers release of histamine, and it increases
  intestinal motility, which helps to eliminate
  helminthic parasites

65
Figure 32.14
66

• Diversity of Antibodies

67

• A number of mechanisms contribute to the
  generation of antibody diversity
• Somatic recombination (gene shuffling)
• Combinatorial joining (unique H and L chains)
• Somatic Hypermutation
• Isotype switching

68

• Somatic Recombination
• Ig genes contain multiple segments of variable
  encoding regions of heavy and light chains (VDJ
  for heavy VJ for light)
• During differentiation of B cells, these genes
  are rearranged on the chromosome to form various
  combinations
• The number of different antibodies possible is
  the product of the number of light chains
  possible and the number of heavy chains possible

69

• Imprecise joining - during combinations, the same
  segments can be joined at different nucleotides,
  thus increasing the number of codons and the
  possible diversity (N and P nucleotides)
• Somatic mutations - the V regions of germ-line
  DNA are susceptible to a high rate of somatic
  mutation following B cell activation
• The total diversity produces more than 2x108
  different antibody molecules

70
Fig. 32.15
71
Figure 32.16
72
Figure 32.17
73

• Specificity of Antibodies

74

• The Clonal Selection Theory

75

• Because of somatic recombination, combinatorial
  joining and somatic mutation, there are a small
  number of B cells capable of responding to any
  given antigen

76

• Each group of cells is derived asexually from a
  parent cell and is referred to as a clone
• There is a large, diverse population of B-cell
  clones that collectively are capable of
  responding to many possible antigen
• The surface receptor molecules of the B cells
  bind to the appropriate antigen

77

• The cell is then stimulated to divide and
  differentiate into two populations of cells
• Plasma cells
• Memory cells
• Plasma cells are protein factories that produce
  about 2,000 antibodies per second for their brief
  life span (5-7 days)

78
Figure 32.18
79

• Memory cells, like the original B cells, can
  differentiate into plasma cells if they are
  stimulated by being bound to the antigen
• because there are more memory cells than original
  B cells, the secondary (anamnestic) response can
  be (and usually is) faster and larger than the
  primary response
• they have long life spans (years or decades)

80

• Sources of Antibodies (pure homogeneous
  preparations)

81

• Immunization

82

• Procedure
• Inject animal with antigen to stimulate primary
  immune response
• Initial lag phase of several days
• Log phase antibody titer rises logarithmically
• Plateau phase antibody titer stabilizes
• Decline phase antibody titer decreases because
  the antibodies are metabolized or cleared from
  the circulation
• Mostly IgM low-affinity antibodies

83
Fig. 32.19
84

• After a period of time, give animal a series of
  booster injections with same antigen to stimulate
  secondary immune response, or anamnestic response
• Shorter lag phase, higher antibody titer
• Mostly IgG high-affinity antibodies (affinity
  maturation)
• Withdraw blood from animal allow it to clot and
  remove fluid (serum), which is referred to as
  antiserum since it is from a specifically
  immunized host

85
Fig. 32.19
86

• Limitations
• This method results in polyclonal antibodies
  which have different epitope specificities thus
  sensitivity is lower, and the antibodies often
  cross-react with closely related antigens
• Repeated injections with antiserum from one
  species into another can cause serious allergic
  reactions
• Antiserum contains a mixture of antibodies, not
  all of which are of interest

87

• Hybridomas - overcome some of the limitations of
  antisera
• Inject animals with antigen
• Separate spleen cells (which contain plasma
  cells)
• Fuse spleen cells with myeloma cells (tumor cells
  of the immune system that produce large
  quantities of antibodies and that are easy to
  culture)

88

• Culture fused cells (hybridomas) so that each
  grows into a separate colony
• Some plasma cells that fused with a myeloma cell
  will produce the desired antibody
• Screen colonies for those producing desired
  antibody

89

• Can grow many desired colonies to obtain large
  amounts of antibody
• Antibodies produced by this method are monoclonal
  (react with only one epitope) since they come
  from the fusion of a single plasma cell with the
  tumor cell

90
Figure 32.20
91

• Have a variety of uses in which high specificity
  is required
• Tissue typing for transplants
• Identification and epidemiological study of
  infectious microorganisms
• Identification of tumor and other surface antigens

92

• Classification of leukemias and T-cell
  populations
• Sensitive diagnostic procedures
• Immunotoxins - used in the targeted delivery of a
  toxic substance to a particular cell type
  chemotherapeutic agents

93
Box 32.1
94

• Catalytic Antibodies

95

• They are monoclonal antibodies made by subjecting
  an animal to an enzyme-substrate transition-state
  analogue and then producing a hybridoma
• The binding pocket on the antibody lowers the
  energy of activation of a reaction by ensuring
  the proper orientation of the reactant(s)

96

• Currently, catalytic antibodies have been
  produced that can transform relatively simple
  compounds, but the potential is great if
  antibodies that act on proteins and nucleic acids
  can be produced
