Title: Sources, Types & Distribution of Air Pollution
1(No Transcript)
2Chapter 2
- Sources, Types Distribution of Air Pollution
3Major Sources of Air Pollution
- The number of different types of pollution
sources in modern society is almost endless. - We look at only the most significant sources of
air pollutants. - Mobile (50 - 70), and stationary sources.
- 15-25 from heavy industrial stationary sources
and as much as 25 from other stationary sources.
4Major Sources of Air Pollution
5Major Sources of Air Pollution
- The table is from USA. The total amount emitted
in Australia will be far less - A significant reduction in the amounts of CO and
H/Cs when compared to the previous decade - levels of other pollutants has been steady or
shown only a slight increase
6Transportation Combustion Sources
- The most important transportation sources at
present are major polluters - Motor vehicles CO, CO2 H/Cs, NOx and small
amounts of SOx - Motor vehicle exhaust accounts for 40 of all H/C
air pollutants and 90 of all NO2
7Transportation Combustion Sources
- Motor vehicles pollutants react to form more
reactive (and dangerous) pollutants such as
photochemical smog. - diesel fuel a source of very dangerous H/Cs
(PAHs). - Pb has decreased in significance, and according
to the latest national SoE report, is no longer
considered a problem - vehicles running on unleaded fuels emit lower
levels of NOx and SOx
8Transportation Combustion Sources
- Aircraft and trains are less significant sources
of pollution compared with road transport
vehicles. - Aircraft run on kerosene, burnt efficiently, but
they fly very high in the atmosphere the
pollutants most of which are H/Cs are spread
and diluted in the upper atmosphere. DISCUSS NEW
PROBLEM - Trains mostly run on electricity contribute
very little to air pollution (except CO2 some
ozone)
9Stationary Combustion Sources
- Some of the more important sources include
- furnaces - and their combustion of carbonaceous
fuels - boilers
- ovens and dryers
- process systems which produce volatile chemicals,
gases, etc.
10Stationary Combustion Sources
- Solvent evaporation (fugitive) from
- solvent-based materials
- leaking pipe joints
- maintenance work
- spills, unloading /loading procedures
- an important part of photochemical pollution
11Stack Emissions
- Emission of waste gases, fumes, vapours and
smokes to the atmosphere are usually by the use
of a smoke stack or chimney. - stack emission becomes a plume in the atmosphere.
- The plume is an area of concentrated waste
emissions that slowly become diluted with the
other atmospheric gases.
12Stack Emissions
- How dilution happens depends on many factors
- Nature of the waste emission
- Toxic emissions need to be very dilute
- Volume of the waste
- Is emission constant or only at certain times in
the process. - Local topography
- Many cities located in areas surrounded by hills
or mountains. - low wind and cooler temperatures photochemical
smog.
13Stack Emissions
- Prevailing climate
- direction of prevailing winds
- e.g. Queenstown, Tasmania
- The Existing Atmosphere
- In very polluted cities, more stack emissions not
desirable. - e.g. build power stations in the country away
from NOx from cars
14Plume Behaviour
- Effects of plumes are considered local within 500
metres of the stack, and regional beyond this. - Mixing or dispersion of the waste gases and
products into the atmosphere plume behaviour.
15Types of Plumes
- Fanning plumes
- Looping plumes
- Coning plumes
- Fumigating
- Lofting
16The Fanning Plume
- Fanning Plumes
- Require stable air and slow vertical movement of
the emission - common after calm clear nights
- temperature inversion limits the rise of the
plume into the upper atmosphere
17The Fanning Plume
- creates a higher conc. of polluted air at lower
levels - exists for several hours
- Commonly seen from Eraring Power station
18Looping plumes
- Looping plumes
- Require windy conditions which cause the plume
can swirl up and down - common in the afternoon.
- Moderate and strong winds are formed on sunny
days creating unstable conditions - Exists for several hours.
19Coning plumes
- Coning plumes
- Require moderate winds and overcast days
- wider than it is deep, and is elliptical in shape
- exists for several hours.
20Fumigating plume
- Fumigating plume
- Is short-lived (fraction of an hour), but reaches
the earth's surface. - occur when the conditions move from stable to
unstable - A fanning plume develops overnight under stable
conditions but as the day heats up, unstable air
is produced
21Fumigating Plume
- Fumigating plume (cont)
- unstable air causes the plume to move up and down
- can cause localised pollution. - become looping or coning plumes as the air
conditions stabilise.
22Lofting plume
- Lofting plume
- When plume is above the inversion layer (or there
is no inversion), it becomes a lofting plume. - Normal wind direction and speed will disperse the
plume into the atmosphere without effect from
ground warming or cooling.
23Stack emissions
- factors used to establish the amount of stack
emission allowed, and its conc. to the atmosphere
include - smoke stack (chimney) height,
- local topography,
- temperature,
- emission rates,
- chemical reactivity, and
- existing air pollution problems
- wind allow rapid dispersal of pollutants.
24Fugitive Emissions
- Fugitive emissions are emissions which escape
from a process rather than being discharged - They often have serious consequences because
their levels are not monitored and they are
untreated when entering the atmosphere
25Fugitive Emissions
- There are many sources of fugitive emissions
including - industrial sources (particulate fluorides from
aluminium smelters) - small business (e.g. dry cleaning solvents)
- agriculture (e.g. dust from ploughing)
- natural sources (e.g. volcanoes, forest fires)
26Fugitive emissions
- Often the result of poor maintenance of plant and
equipment - Can be eliminated by SOPs that involve timed
maintenance and quality control checks - Some are almost impossible to control (e.g.
natural sources)
27Types of air pollutants
- There are four types of air pollutants
- particulate pollutants and
- gaseous pollutants,
- odour and
- noise.
28Primary vs Secondary pollutants
- Not all of the pollutants found in the atmosphere
are the direct result of emissions. - Many pollutants arise from chemical reactions in
the atmosphere with other substances or light
(photochemical reactions).
291 vs 2 pollutants
- Pollutant substances that are directly emitted
into the atmosphere primary pollutants. - Substances not directly emitted into the
atmosphere, formed by chemical reactions in the
atmosphere secondary pollutants.
30Particulate Pollutants
- Very small solid or liquid particles
- Individual particles may vary in size, geometry,
chemical composition and physical properties - May be of natural origin (pollen or sea spray) or
man made (dust, fume and soot)
31Particulate Pollutants
- Provide a reactive surface for gases and vapours
in the formation of secondary pollutants - Particles also diffuse light reducing visibility
- Come from stack emissions, dusty processes,
unsealed roads, construction work and many other
sources
32Particulate Pollutants
- Dusts
- large solid particles
- Fume
- solid particles (metallic oxides) formed by
condensation of vapours from a chemical reaction
process or physical separation process
33Particulate Pollutants
- Mist
- liquid particles formed by condensation of
vapours or chemical reaction. - SO3 H2O H2SO4
- Smoke
- solid particles formed as a result of incomplete
combustion of carbonaceous materials. - Spray
- a liquid particle formed by the atomisation of a
parent liquid.
34Particle Size
- Particles range in size from 0.005 - 500?m.
- Smallest of these are clusters of molecules
whilst the largest are easily visible with the
naked eye. - Sizes given are not the physical size, but rather
the aerodynamic equivalent diameter which relates
the particle to the behaviour of an equivalent
spherical particle.
35(No Transcript)
36Particle Size
- Particles less than 1?m in diameter behave like
gases (remain suspended, may coalesce, move in
fluid streams), - Larger particles act like solids (affected by
gravity, dont stay suspended long, dont
coalesce). - Smaller particles generally derive from chemical
reactions, whereas the larger particles (10?m or
greater) are usually generated mechanically and
tend to be basic.
37Particle Size
- Smaller particles most dangerous to health,
- In urban areas there is an approx. even
distribution between fine and coarse particles,
this is weather dependent. - Calm conditions more fine particles than coarse,
- Fine particulate matter spread over much greater
distances
38Particle behaviour in the atmosphere
- Particles can undergo many physical and chemical
changes - grow in size,
- absorb or desorb gases from their surfaces,
- change electrical charge,
39Particle behaviour in the atmosphere
- Particles can undergo many physical and chemical
changes - collide or adhere with other particles,
- absorb water.
- changes the particle size and affect its
atmospheric lifetime.
40Total Suspended Particles (TSP)
- Most particles concentrated into three main size
groups - Larger particles around 10?m in size
- Smaller particles in size groups centred around
0.2 and 0.02?m.
41TSP
- Only particles of lt10?m penetrate into the human
lung - Analyse air for only this fraction to estimate
its potential danger to human health PM10
sampling. - Particles lt2.5?m in size can penetrate deep into
the lung tissue and are especially dangerous
PM2.5 sampling
42Organic Particulates
- PAH most significant
- Found on soot and dust particles, and are formed
from smaller H/Cs at high temperatures (coal
furnace effluent may contain 1mg/m3 of PAH
cigarette smoke 0.1mg/m3) - Urban atmospheres PAH levels 20 ug/m3 but is
highly variable
43Lead Particulates
- Was the most serious atmospheric heavy-metal
pollutant, but is no longer - primary source was exhaust from vehicles
44Gaseous Pollutants
- CO, H/Cs, H2S, NOx, O3 and other oxidants, and
SOx - Measured in micrograms per cubic meter (ug/m3) or
parts per million (ppm). - 1 ppm 1 volume of gaseous pollutant
- 106 volumes of (pollutant air)
45Gaseous Particulates
- At 25C and 101.3 kPa the relationship between
ppm and ug/m3 is - ug/m3 ppm x molecular weight x 103
- 24.5
46Carbon Monoxide
- a colourless, odourless and tasteless gas.
- atmosphere has an avg. burden of around 530
million tonnes (about 0.00001), - avg. residence time of 36 to 100 days.
- Much of the CO in the atmosphere occurs naturally
from volcanic eruptions, photolysis of methane
and terpenes, decomposition of chlorophyll,
forest fires and microbial action in oceans.
47Carbon Monoxide
- Anthropogenic sources transportation, solid
waste disposal, agricultural burning, steel
production, etc. - emitted directly into the atmosphere through the
inefficient combustion of fossil fuels. - removed by reactions in the atmosphere which
change it to CO2 and by absorption by plants and
soil micro-organisms.
48Carbon Monoxide
- It is removed by reactions in the atmosphere
which change it to CO2 and by absorption by
plants and soil micro-organisms. - In combustion, carbon is oxidised to CO2 in a two
step process. - 2C O2 2CO
- 2CO O2 2CO2
49Carbon Monoxide
- Typical conc's
- Background levels of CO tend to vary greatly
depending on location. - avg. global levels 0.2ppm.
- Peak conc's during autumn months when large
volumes are generated by the decomposition of
chlorophyll in leaves. - In urban areas diurnal conc. pattern
50(No Transcript)
51Carbon Monoxide
- The internal combustion engine contributes much
of the anthropogenic CO (up to 90 in the Sydney
region) - Maximum levels of this gas tend to occur in
congested urban areas at times when the maximum
number of people are exposed, such as during rush
hours. - At such times, CO levels in the atmosphere may
become as high as 50-100ppm.
52Carbon Dioxide
- Since the Clean Air Act in NSW in 1972 (and
subsequent acts), the levels of CO in Sydney have
dropped from an avg. of 25ppm to around 10ppm - The accepted standard is 9ppm over an eight-hour
period - http//www.environment.nsw.gov.au/air/24hr.htm
53Carbon Monoxide
- Sinks
- CO is removed from the air mostly by conversion
to CO2 - This may occur through aerial oxidation or
through the action of soil micro-organisms - The reason for very high conc's occurring in
urban areas is that high emission rates are
combined with a lack of soil
54Carbon Dioxide
- Carbon dioxide is produced when organic matter
is - combusted
- weathered
- biologically decomposed
- It is removed from the atmosphere by plants in
photosynthesis and released by biological
reactions
55Carbon Dioxide
- Over hundreds of millions of years CO2 has been
withdrawn from the atmosphere and stored in coal,
oil and natural gas. - The intensive use of these fuels has resulted in
significant CO2 emissions and an increase of
atmospheric conc's - Since 1958, CO2 values measured at Mauna Loa
Observatory in Hawaii have increased from 310 to
more than 350ppm.
56Carbon Dioxide
- Significant seasonal variations are also observed
to occur in CO2 levels - This seasonal variability appears to be
associated with growing season photosynthetic
needs and metabolic releases of CO2 in excess of
plant uptake at the end of the growing season.
57Carbon Dioxide
- Not all CO2 emitted to the atmosphere from
anthropogenic sources contributes to increased
atmospheric levels. - Because of its solubility in water, the oceans
are a major sink for CO2, absorbing 50 of all
man made emissions. - The world's forests, particularly tropical
forests, also serve as a sink.
58Carbon Dioxide
- As a thermal absorber (read greenhouse gas), CO2
prevents some IR emissions from the Earth being
radiated back to space - Greenhouse Effect.
59Sulfur Compounds
- A variety of sulfur compounds are released to the
atmosphere from both natural and anthropogenic
sources - The most important of these are the sulfur oxides
(SOx) and hydrogen sulfide (H2S) - Significant SOx emissions may occur from volcanic
eruptions and other natural sources - Man made emissions are responsible for much of
the atmospheric emissions
60Sulfur Oxides
- These are produced by roasting metal sulfide ores
and by combustion of fossil fuels containing
appreciable inorganic sulfides and organic sulfur
- Of the four known sulfur oxides, only SO2 is
found at appreciable levels in the atmosphere.
61Sulfur Oxides
- Sulfur trioxide (SO3) is emitted directly into
the atmosphere in ore smelting and fossil fuel
combustion and is produced by the oxidation of
SO2. - Because it has a high affinity for water, it is
rapidly converted to sulfuric acid.
62Sulfur Oxides
- The formation of SO2, SO3, and sulfuric acid in
the atmosphere is summarised in the following
equations. - S O2 SO2
- 2 SO2 O2 2SO3
- SO3 H2O H2SO4
63Sulfur Dioxide
- Sulfur dioxide may be directly absorbed by water
bodies such as the oceans to form sulfurous acid.
- This is one of the sources of acid rain, which
has dramatically affected the environment in
Europe and North America.
64Sulfur Dioxide
- SO2 is an acidic colourless gas which may remain
in the atmosphere for periods up to several weeks - It can be detected by taste and odour in the
conc. range of 0.38 - 1.15ppm - Above 3 ppm, it has a pungent, irritating odour
65Sulfur Dioxide
- It is estimated that 65 million tonnes of SO2 per
year enter the atmosphere as a result of man's
activities, primarily from the combustion of
fossil fuels. - Of these, coal (and oil) is by far the greatest
contributor, even in Australia
66Sulfur Dioxide
- Background levels of SO2 are very low, about 1ppb
- In urban areas maximum hourly conc's vary from
less than 0.1 to more than 0.5ppm.
67Sulfur Dioxide
- Sinks
- SO2 is removed from the atmosphere by both dry
and wet deposition processes. - It is believed that plants are responsible for
most SO2 removal that occurs by dry deposition. - SO2 can also dissolve in water to form a dilute
solution of sulfurous acid (H2SO3). This water
can be in clouds, in rain droplets, or at the
surface.
68Sulfur Dioxide
- A major sink process for SO2 is its gas-phase
oxidation to H2SO4 and subsequent aerosol
formation by nucleation or condensation - Sulfuric acid will react with ammonia (NH3) to
form a variety of salts
69Sulfur Dioxide
- About 30 of atmospheric SO2 is converted to
sulfate aerosol - Sulfate aerosols are removed from the atmosphere
by dry and wet deposition processes. - In dry deposition, aerosol particles settle out
or impact on surfaces. - In wet deposition, sulfate aerosol is removed
from the atmosphere by forming rain droplets (in
cloud) or being captured by falling rain droplets
(below cloud). - These removal processes are called rainout and
washout.
70Hydrogen Sulfide
- H2S is a very toxic gas with a characteristic
rotten egg odour. - The principal concerns associated with H2S are
its smell (foul) toxicity (same as HCN)
71Hydrogen Sulfide
- Background levels of H2S are approx. 0.05ppb
- Natural sources, which include anaerobic
decomposition of organic matter, natural hot
springs and volcanoes - Anthropogenic sources include oil and gas
extraction, petroleum refining, paper mills,
rayon manufacture, and coke ovens
72Hydrogen Sulfide
- The major sink process for H2S is its atmospheric
conversion to SO2. - This SO2 is then removed from the atmosphere in
the gas phase or as an aerosol by wet or dry
deposition processes.
73Nitrogen Compounds
- There are five major gaseous forms of nitrogen in
the atmosphere. - These include
- molecular nitrogen (N2),
- ammonia (NH3),
- nitrous oxide (N2O),
- nitric oxide (NO), and
- nitrogen dioxide (NO2).
74Nitrogen Compounds
- N2 the major gas in the atmosphere.
- N2O present in unpolluted air due to microbial
action - NO and NO2 significant air pollutants
- NH3 not considered a significant man made
pollutant, but enormous quantities generated
through natural emissions.
75Elemental Nitrogen (N2)
- 78 of the air we breathe
- Relatively inert (unlike O2)
- Significant biological use by microbes
76Nitrous Oxide (N2O)
- colourless, slightly sweet, non-toxic gas.
- natural part of the atmosphere avg. conc.
0.30ppm. - used as anaesthetic in medicine and dentistry
(laughing gas) - product of natural soil processes, produced by
anaerobic bacteria. - photolytically dissociates in stratosphere to NO.
77Nitric Oxide (NO)
- colourless, odourless, tasteless, relatively
non-toxic gas. - produced naturally by
- anaerobic biological processes in soil and water,
- combustion processes and by photochemical
destruction of N compounds in stratosphere.
78Nitric Oxide (NO)
- Major anthropogenic sources include
- automobile exhaust
- fossil fuel-fired electric generating stations
- industrial boilers
- incinerators
- home space heaters
79Nitric Oxide
- Nitric oxide is a product of high-temperature
combustion. - N2 O2 2NO
80Nitrogen Dioxide (NO2)
- light yellow to orange colour at low concs and
brown at high concs. - pungent, irritating odour , and extremely
corrosive especially in wet environments - toxic - can cause anoxia
81Nitrogen Dioxide (NO2)
- Some of the NO2 in air produced by direct
oxidation of NO - 2NO O2 2NO2
82Nitrogen Dioxide (NO2)
- At low atmospheric NO levels, oxidation is slow,
accounts for lt25 of NO conversion -
- Photochemical reactions involving O3, peroxy
radical (RO2) and reactive hydrogen species such
as OH?, HO2, H2O2, are primary means by which NO
is converted to NO2 in the atmosphere.
83Nitrogen Dioxide (NO2)
- Other NO2 formation mechanisms
- NO O3 NO2 O2
- RO2 NO NO2 RO
- HO2 NO NO2 OH
84Nitrogen Dioxide
- Background concs of NO and NO2 are approx. 0.5
and 1ppb respectively - In urban areas, 1 hour avg. concs of NO may
reach 1-2ppm, with max NO2 levels of approx.
0.5ppm. - decay of NO rapid as polluted air moves from
urban to rural areas, with concs dropping to
near background levels.
85Nitrogen Dioxide
- Atmospheric NO level related to transport/work
cycle. - Peak conc's observed in early morning hours, with
a second smaller peak late in the day (See Figure
2.8). - Peak morning NO conc's followed several hours
later by peak levels of NO2 produced by the
chemical and photochemical oxidation of NO.
86Nitrogen Dioxide
- Atmospheric levels of NO and NO2 also show
seasonal trends - Emissions of NO greater during winter when there
is increased use of heating fuels - Since the conversion of NO to NO2 is related to
solar intensity, higher NO2 levels occur on warm
sunny days.
87Nitrogen Dioxide
- NOx in vehicle exhausts controlled by legislation
as with CO - catalytic converter in the exhaust system
increases reduction of NOx to N2. - Australian Design Rules limit emission of NOx
from exhausts to 1.9g/km - to maintain the levels in Sydney below the
recommended standard of 0.16ppm (1 hour avg.).
88Figure 2.8 Levels of NO, NO2, and ozone on a
smoggy day in Los Angeles
89Nitrogen oxides (NOx)
- Sinks
- most significant sink for NO is conversion by
both direct oxidation and photochemical processes
to NO2 - A major sink process for NO2 is its conversion to
nitric acid
90Nitrogen Oxides (NOx)
- OH? NO2 M HNO3 M
- M is an energy-absorbing species (generally O2 or
N2). NO2 is also converted to nitric acid by
night-time chemical reactions involving O3. - NO2 O3 NO3? O2
- NO2 NO3? N2O5
- N2O5 H2O 2HNO3
91Nitrogen Oxides (NOx)
- NO3? is nitrate free radical
- key factor in night-time chemistry
- reaction product of NO2 and NO3 is dinitrogen
pentoxide (N2O5) - reacts with water rapidly to
produce HNO3
92Nitrogen Oxides (NOx)
- Some of the HNO3 in the atmosphere reacts with
ammonia (NH3) or other alkaline species to form
salts such as NH4NO3 - Nitrate aerosol is generally removed by the dry
and wet deposition processes in much the same way
as sulfate aerosol
93Ammonia (NH3)
- relatively unimportant man made pollutant
- Most comes from biological decomposition
- Background conc's vary from 1 to 20ppb
- The avg. atmospheric residence time is approx. 7
days
94Organic Nitrates
- produced in the atmosphere by reaction of NOx and
hydrocarbons - Examples are peroxyacyl nitrates (PANs) and
peroxybutylnitrates (PBNs). - discussed in detail in photochemical smog section
95Hydrocarbons
- organic materials in the atmosphere.
- In the atmosphere simple hydrocarbons react with
substances containing - oxygen,
- nitrogen,
- sulfur,
- chlorine
- bromine
- even some metals (Pb)
96Hydrocarbons
- Atmospheric hydrocarbons exist in gas, liquid and
solid phases - gases and volatile liquids the most significant
pollutants - Solid hydrocarbons generally of higher MW and
exist as condensed particles in atmospheric
aerosols
97Hydrocarbons
- Methane (CH4) most common hydrocarbon in the
atmosphere - formed from many natural sources - termites,
- cows
- decomposition of organic matter
- It and the other alkanes found in the atmosphere
are fairly un-reactive
98Hydrocarbons
- atmospheric hydrocarbons of most significance in
terms of chemical reactivity are the alkenes - highly reactive alkene hydrocarbons are formed
naturally by plants (e.g. terpenes from citrus
plants and eucalyptus haze)
99Hydrocarbons
- greatest source of non-methane hydrocarbons are
motor vehicles and petroleum processing - Alkenes are the major air pollutant responsible
for photochemical smog and other gross oxidants
in the atmosphere
100Hydrocarbons
- Once in the atmosphere non-methane H/Cs combine
with O2 to form many different oxygenated H/Cs
including - alkanones
- alkanals
- alkanoic acids
- alkanols
- ethers
101Hydrocarbons
- Aromatic H/Cs not very reactive, but can react
with other very reactive chemical oxidants to
form toxic substances, such as - benzo?pyrene
- poly-aromatic hydrocarbons (PAHs)
102Benzo?pyrene
103Hydrocarbons
- H/Cs emitted from a variety of natural and man
made sources - important pollutants because of their role in
atmospheric photochemistry - biological and geological processes release
hydrocarbon compounds naturally
104Hydrocarbons
- Sources include
- plant and animal metabolism
- vaporisation of volatile oils from plant surfaces
- biological decomposition
- emission of volatiles from fossil fuel deposits
105Hydrocarbons
- Sinks
- most important sink processes are
- photochemical conversion of hydrocarbons to CO2
and H2O or - to soluble or condensable products such as
dicarboxylic acids - a major component of
photochemical aerosol. - aerosols are removed from the atmosphere by both
dry and wet deposition processes.
106Methane
- was initially considered an unimportant H/C
- Measurements of total H/C subtracted the conc. of
CH4 - Hence ambient air quality standard for H/Cs is a
non-methane hydrocarbons standard
107Methane
- recognised as one of the trace gases that may
have significant greenhouse effect on global
climate
108Methane
- by far the most abundant H/C in the atmosphere,
with a 1980 conc. of 1.65ppm. - It has been increasing at a rate of 1.2-1.9 per
year. The rate itself is also increasing.
109Methane
110Ozone Photochemical Smog
- O3 a normal component of the atmosphere
- mostly in the middle stratosphere where it
controls UV light reaching the planets surface - here depletion of the substance results in air
pollution loss of ozone is causing
deterioration in quality of life
111Ozone
- not listed as a major primary air pollutant in
the lower atmosphere - high toxicity and involvement in production of
other pollutants - very important atmospheric
pollutant - Over 90 of photochemical smog is ozone
112Ozone
- Sources
- Electrical discharges, e.g. lightning and
electrical devices - Light driven upper atmospheric chemical reactions
e.g. reaction of molecular oxygen with oxygen
atoms
113Ozone
- O2 O M O3 M
- In this reaction M is any third substance
(usually O2 or N2) that removes the energy of the
reaction and stabilises O. In the lower
atmosphere (troposphere) the only significant
source of atomic oxygen is the photolysis of NO2.
- NO2 h? NO O
- The reaction of O with O2 produces O3, which
reacts immediately with NO to regenerate NO2. - NO O3 NO2 O2
114Ozone
- All reactions proceed rapidly with approx. conc.
of 20ppb - atmospheric NO2/NO conc. ratios can be equal to 1
- Hence conc's of ozone remain low unless
imbalances in the levels of NO2 or other
alternate chemical reactants are available
115Oh dear! The chemistry!
- We need to look closely at the chemistry we have
seen thus far. -
116Photochemical Smog
- refers to an atmosphere laden with secondary
pollutants that form in the presence of sunlight
as a result of chemical reactions in the
atmosphere - arises in urban areas, where there is a heavy
build-up of vehicle exhausts - greatly exacerbated by weather conditions
117Photochemical Smog
- normally primary air pollutants are dispersed
over a large region or to the upper atmosphere - A good prevailing wind is important for cities
and large urban areas to reduce smog - At certain times of the year, when wind is very
still, primary pollutants build up over cities. - Autumn worst for photochemical smog
118Photochemical Smog
119Photochemical Smog
- In autumn, days are sunny and warm, with cool
nights - Under still conditions, a warm inversion layer
forms under a layer of higher cooler ai - Large urban areas store heat, which provides the
warmth for the inversion layer - The inversion layer limits air mixing and
dispersal trapping primary pollutants at lower
altitudes over urban areas
120Photochemical Smog
121Photochemical Smog
- primary pollutants (NOx), and H/Cs trapped in
the lower atmosphere are subjected to UV
radiation from the sun photochemical smog
forms.
122Photochemical Smog
- products called gross photochemical oxidants,
defined by their ability to oxidise I- to I2. - They include
- ozone (O3)
- hydrogen peroxide (H2O2)
- organic peroxides (ROOR')
- organic hydroperoxides (ROOH) and
- by far the most serious to health, peroxyacyl
nitrates (RCO3NO2), known as PAN's.
123Photochemical Smog
- The key chemical reactants in the formation of
photochemical smog are NOx and hydrocarbons. - The reactions undergone by these substances in
the atmosphere are many and varied. - Many of the reaction mechanisms are not well
understood.
124Photochemical Smog
- In the lower atmosphere O3 conc's are often much
higher than those that occur from NO2 photolysis
alone. - This is because there are chemical reactions that
convert NO to NO2 without consuming O3. - In polluted atmospheres, these changes in O3
chemistry can be attributed to peroxy radicals
(RO2) and other species produced by the oxidation
of hydrocarbons as shown in the reactions below.
125Photochemical Smog
- RO2 NO NO2 RO
- NO2 h? NO O
- O O2 M O3 M
- Net RO2 O2 h?
RO O3
126Photochemical Smog
127Photochemical Smog
- The rate of O3 formation is closely related to
the conc. of RO2. - Peroxy radicals are produced when hydroxy
radicals OH? and HOx react with hydrocarbons. - Hydroxy radicals are produced by reactions
involving the photolysis of O3, carbonyl
compounds (mostly alkanals), and nitrous acid.
128Photochemical Smog
- In polluted atmospheres, O3 conc's are directly
related to - the intensity of sunlight,
- NO2/NO ratios,
- the hydrocarbon type and conc's,
- and other pollutants, such as alkanals and CO,
which react photochemically to produce RO2. - The increase in NO2/NO ratios caused by
atmospheric reactions involving RO2 results in
significant increases in lower atmosphere O3
levels.
129Photochemical Smog
- summary of reactions in smog formation can be
compressed into 4 stages. - explains time variations in levels of H/Cs,
ozone, NO2 and NO (see Figure 2.13).
130Photochemical Smog
- 1. Primary photochemical reaction producing
oxygen atoms - NO2 h? NO O
- 2. Reactions involving oxygen species (M is an
energy-absorbing third body) - O O2 M O3 M
- NO O3 NO2 O2
131Photochemical Smog
- Because last reaction is rapid, the conc. of O3
remains low until that of NO falls to a low
value. - Automotive emissions of NO tend to keep O3 conc's
low along freeways.
132Photochemical Smog
- 3.Production of organic free radicals from
hydrocarbons, RH - O RH R? other products
- O3 RH R? and/or other products
- (R? is a free radical that may or may not contain
oxygen.)
133Photochemical Smog
- 4. Chain propagation, branching, and termination
by a variety of reactions such as the following - NO ROO? NO2 and/or other products
- NO2 R? products (e.g. PAN)
134Photochemical Smog
- Some of the many other reactions which are known
to occur in photochemical smog formation are
listed below. - O hydrocarbons HO?
- HO? O2 HO3?
- HO3? H alkanals, alkanones
- HO3? NO HO2? NO2
- HO3? O2 O3 HO2?
- HOx? NO2 PAN's
135Photochemical Smog
- all H/Cs may form smog, but there are
considerable differences in their reactivities - methane, very slow to react, having an approx.
atmospheric lifetime of more than 10 days - branched alkenes and aromatic compounds the most
reactive - naturally-occurring alkenes (d-limonene) the most
reactive compounds
136Photochemical Smog
- With complex reactions and changing vehicle
emissions during a day, conc's of the major
components vary considerably over a 24-hour
period. - typical pattern of variations shown in fig2.13.
137(No Transcript)
138Photochemical Smog
- morning rush hour begins, NO rises rapidly,
followed by NO2. -
- NO2 reacts with sunlight giving ozone and other
oxidants - H/C level increases in the morning, then
decreases as compounds are oxidised to form PAN's
and other species.
139Photochemical Smog
- air mass moves toward an urban center, picks up
NO, and H/Cs. - OH? begins to degrade H/Cs, producing RO2 while
O3 precursors peak and then decline with
increasing downwind distance. - Ozone conc's increase and are sustained over a
period of 1-5 hours as more reactive alkene and
aromatic H/Cs are depleted by photochemical
reactions.
140Photochemical Smog
- After 5-10 hours, moderately reactive H/Cs play
a more important role in O3 production -
- O3 levels decrease due to dilution, conversion of
NO2 to HNO3, and surface adsorption - At night no O3 produced
141Photochemical Smog
- Under inversion layer, O3 may persist for 80 hrs.
- allows O3 to be transported over long distances
- At sunrise, inversion breaks up, bringing O3 and
other products to the ground, where they mix with
the pollutants held in by the inversion layer,
and begin cycle all over again
142Photochemical Smog
- In unpolluted atmospheres O3 conc's near ground
are 10-20ppb (0.01-0.02ppm) during the warm
months - O3 conc's over landmasses with large motor
vehicle numbers often well above this even at
remote sites - Los Angeles basin 1 hour conc's are 0.20-0.40ppm
143Photochemical Smog
- warm, sunny NSW central coast means Sydney Basin
has high photochemical smog production - (NHMRC) ozone standard of 0.12ppm (1hr avg.)
should not be exceeded on more than one day per
year.
144Photochemical Smog
- Ozone removed from the atmosphere by reactions
with plants, soil, and man made materials
(rubber) - O3 produced in the atmosphere removed by chemical
processes involving NOx - principal scavenger of O3 is NO Night reactions
with NO2 destroy O3
145Chlorofluorocarbons (CFCs)
- What are they?
- halogenated H/C compounds used as refrigerant
gases and propellants in aerosol cans
146Chlorofluorocarbons (CFCs)
- unique because of their environmental persistence
- examples
- DDT, Chlordane, Dieldrin, and Aldrin (pesticides)
- polyhalogenated biphenyls (PCBs, PBBs) solvents
and fire retardants - dichloromethane, trichloroethene,
perchloroethene, tetrachloroethene, and
tetrachloromethane (solvents) - CFCs - refrigerants, degreasing agents, foaming
agents, aerosol propellants
147Chlorofluorocarbons (CFCs)
- serious atmospheric threat because of their great
stability - leads to damage the O3 layer - Also absorb IR energy and are greenhouse gases
148Chlorofluorocarbons (CFCs)
- most commonly used (most common atmospheric
contaminants) are - Trichlorofluoromethane (CFC13)
- Dichlorodifluoromethane (CF2C12),
- Trichlorotrifluoroethane (C2C13F3).
149Chlorofluorocarbons (CFCs)
- no sink in the lower atmosphere - CFC conc's
increase with time - For CFC-11 and CFC-12, atmospheric lifetimes are
75 and 111 years, respectively
150Chlorofluorocarbons (CFCs)
- Naming CFCs
- The decoding system for CFC-01234a is
- 0 Number of double bonds (omitted if zero)
- 1 Carbon atoms -1 (omitted if zero)
- 2 Hydrogen atoms 1
- 3 Fluorine atoms
- 4 Replaced by Bromine ("B" prefix added)
151Fluoride
- Aluminium smelters major source of both gaseous
and particulate fluorides, as are - brick and glass works
- some smelters
- steel plants and
- coal fired power stations
- Fluoride is a localised problem
152Minor Gaseous Pollutants
- Hydrogen sulfide
- odour
- noise
153Odour as air pollution
- odour pollution increasing importance
-
- from a regulatory point of view, seen as a
welfare not a health issue this is changing
154Odour as air pollution
- odour is response to the inhalation of a chemical
substance - cannot yet be reliably measured by
chemically - sensory attributes of odours measured by exposing
individuals under controlled conditions
155Odour as air pollution
- Elements of odour subject to measurement are
- detectability
- intensity
- character (quality)
- hedonic tone (pleasantness, unpleasantness)
156Odour as air pollution
- limit of detection odour threshold
characterized in 2 ways - detectable difference from the background
- first conc. at which an observer can positively
identify quality of odour
157Odour as air pollution
- characters of a variety of selected chemicals
summarised in Table 2.2 - For example, dimethylamine is described as fishy,
phenol as medicinal, 1,4-dihydroxybenzene
(paracresol) as tar-like.
158(No Transcript)
159Odour as air pollution
- olfactory response to an odourant decreases as
the odourant conc. decreases (nonlinear) - responses to malodours include
- Nausea and vomiting
- Headaches and other sensory disturbance
- Coughing respiratory ailments
- Depression
160Odour as air pollution
- Odour Problems
- Bad odours generate complaints to regulatory
agencies more than any other form of air
pollution - A new area of management that deals with odour
and noise is called modelling
161Odour as air pollution
- Odour Problems
- Likely sources of bad odours include
- soap-making facilities
- petrochemical plants and refineries
- pulp and paper mills
- food-processing plants
- sewage treatment plants
- abattoirs
162Odour as air pollution
- Bad odours associated with
- amines
- sulfur gases (e.g. H2S)
- phenol, ammonia etc
- Hydrocarbons
- And many more
163Odour and the Law
- Legal/Regulated aspects of odour
- Local Council
