Electrical Signals in Animals

1
Electrical Signals in Animals

• Chapter 45

2
Nervous Systems

• Consist of circuits of neurons and supporting
  cells
• All animals except sponges have some type of
  nervous system
• Differ in the way that the neurons are organized
  into circuits
• The simplest animals with
• nervous systems, the cnidarians
• Have neurons arranged in nerve nets

3
Nervous Systems

• More complex animals contain nerve nets as well
  as nerves
• Bundles of fiber-like extensions of neurons
• Sea stars have a nerve net in each arm
• Connected by radial nerves to a central nerve ring

4
Nervous Systems

• Cephalization evolved with greater complexity in
  nervous systems
• Clustering of neurons in a brain near the
  anterior end in worms
• Small brain, longitudinal nerve chords
  constitute the simplest central nervous system

5
Nervous Systems

• Annelids and arthropods have more complicated
  brains
• Have segmentally arranged clusters of neurons
  called ganglia
• These ganglia connect to the
• CNS
• And make
• up a peripheral
• nervous system
• (PNS)

6
Nervous Systems

• Nervous systems in mollusks
• Correlate with the animals lifestyles
• Sessile mollusks have simple systems
• While more complex mollusks have more
  sophisticated systems
• Can complete complicated tasks

7
Nervous Systems

• In vertebrates
• The central nervous system consists of a brain
  and dorsal spinal cord
• The PNS connects to the CNS

8
Neuron Structure

• The ability of the neuron to receive and transmit
  information depends on their structure. Consists
  of
• Cell body- where most of the organelles are
  housed
• Numerous dendrites- highly branched extensions
  that receive signals from other neurons
• Axon- larger extension that transmits signals,
  may be covered with a myelin sheath

9
(No Transcript)
10
Dendrite

• Receives electrical signals from the axons of
  adjacent cells.
• Axon then sends the signal to the dendrites of
  other neurons
• Cell body, or soma, which includes the nucleus,
  integrates the incoming signals and generates an
  outgoing signal in the axon

11
Neurons

• Neurons have a wide variety of shapes
• That reflect their input and output interactions
• Reflects the number of synapses it has with other
  neurons

12
Glia

• Glia are supporting cells
• That are essential for the structural integrity
  of the nervous system and for the normal
  functioning of neurons
• In the CNS astrocytes regulate extracellular ion
  concentrations

13

• Oligodendrocytes (in the CNS) and Schwann cells
  (in the PNS)
• Are glia that form the myelin sheaths around the
  axons of many vertebrate neurons
• Act as insulators
• Multiple Sclerosis is deterioration of the myelin
  sheath

14
Resting Potential of a Cell

• Ion pumps and ion channels maintain the resting
  potential of a neuron
• The resting potential
• Is the membrane potential of a neuron that is not
  transmitting signals
• Across its plasma membrane, every cell has a
  voltage
• Called a membrane potential
• The inside of a cell is negative
• Relative to the outside

15
Resting Potential of a Cell

• The concentration of Na is higher in the
  extracellular fluid than in the cytosol
• While the opposite is true for K
• A neuron that is not transmitting signals
• Contains many open K channels and fewer open Na
  channels in its plasma membrane
• The diffusion of K and Na through these
  channels
• Leads to a separation of charges across the
  membrane, producing the resting potential

16
(No Transcript)
17
Gated Ion Channels

• Ungated ion channels are always open, results in
  the resting potential of the cell
• Gated ion channels open or close
• In response to membrane stretch or the binding of
  a specific ligand
• In response to a change in the membrane potential
• Neurons have gated ion channels
• Responsible for generating the signals of the
  nervous system

18
Starting An Action Potential?

• An action potential is a rapid, temporary change
  in a membrane potential
• Has three phases depolarization, repolarization,
  and the undershoot
• The initial event is a rapid depolarization of
  the membrane
• Membrane potential must shift from its resting
  potential of 70 mV to about 55 mV

19
(No Transcript)
20

• If the threshold potential is reached, channels
  in the axon membrane open and ions rush into the
  axon, following their electrochemical gradients
• The current flow causes further depolarization
• When the membrane potential reaches about 40 mV
  the membrane experiences a rapid repolarization
  as ions flow out of the axon

21

• The repolarization event results in the membrane
  becoming more negative than the resting potential
• Called the undershoot
• All phases occur in about a millisecond

22
Regeneration of the Action Potential

• An action potential can travel long distances
• By regenerating itself along the axon
• At the site where the action potential is
  generated
• An electrical current depolarizes the neighboring
  region of the axon membrane

23
Regeneration of the Action Potential
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
Action Potentials

• The speed of an action potential
• Increases with the diameter of an axon
• In vertebrates, axons are myelinated
• Also causing the speed of an action potential to
  increase
• Causes the membranes to have a simulated wider
  width
• Action potentials in myelinated axons
• Jump between the nodes of Ranvier in a process
  called saltatory conduction

29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
Synapses

• Neurons communicate with other cells at synapses
• In an electrical synapse
• Electrical current flows directly from one cell
  to another via a gap junction
• Synchronize the activity of neurons responsible
  for rapid responses (flight response)
• The vast majority of synapses
• Are chemical synapses
• Not as fast as electrical synapsis

33
Chemical Synapses

• In a chemical synapse, a presynaptic neuron
• Releases chemical neurotransmitters, which are
  stored in the synaptic terminal

34
Synapses

• The interface between two neurons is called a
  synapse.
• Just inside the synapse, the axon contains
  synaptic vesicles that serve as storage sites for
  neurotransmitters
• The sending cell is called the presynaptic neuron
  and the receiving cell is called the postsynaptic
  neuron

35
(No Transcript)
36
(No Transcript)
37
What Do Neurotransmitters Do?

• There are several categories of
  neurotransmitters
• Many neurotransmitters function as ligands that
  bind to ligand-gated ion channels
• Cause the ion channels to open, generating a
  postsynaptic potential
• Causes the start of a new action potential

38
The Vertebrate Nervous System

• The vertebrate nervous system is regionally
  specialized
• In all vertebrates, the nervous system
• Shows a high degree of cephalization and distinct
  CNS and PNS components

39
The Central Nervous System

• The brain provides the integrative power
• That underlies the complex behavior of
  vertebrates
• The spinal cord integrates simple responses to
  certain kinds of stimuli
• And conveys information to and from the brain
• The central canal of the spinal cord and the four
  ventricles of the brain
• Are hollow, since they are derived from the
  dorsal embryonic nerve cord

40
The Central Nervous System

• CNS consists of spinal chord and four ventricles
  in the brain
• Contain cerebrospinal fluid
• Assists in supply of nutrients and hormones to
  parts of the brain and in removal of wastes

• Grey matter contains mostly dendrites
• White matter contains long axons with great
  bundles of myelin sheaths

41
The Peripheral Nervous System

• The PNS transmits information to and from the CNS
  and plays a large role in regulating a
  vertebrates movement and internal environment
• The cranial nerves originate in the brain
• And terminate mostly in organs of the head and
  upper body
• The spinal nerves originate in the spinal cord
• And extend to parts of the body below the head

42
The Peripheral Nervous System

• The PNS can be divided into two functional
  components
• The somatic nervous system and the autonomic
  nervous system

43
The Peripheral Nervous System

• The somatic nervous system
• Carries signals to skeletal muscles
• Often considered voluntary
• The autonomic nervous system
• Regulates the internal environment, in an
  involuntary manner
• Is divided into the sympathetic, parasympathetic,
  and enteric divisions

44
(No Transcript)
45
Brain Structures in an Adult
46
Parts of The Brain

• The brainstem consists of three parts
• The medulla oblongata, the pons, and the midbrain

47
Brainstem

• The medulla oblongata
• Contains centers that control several visceral
  functions
• The pons
• Also participates in visceral functions
• The midbrain
• Contains centers for the receipt and integration
  of several types of sensory information

48
The Cerebellum

• The cerebellum
• Is important for coordination and error checking
  during motor, perceptual, and cognitive functions
• The cerebellum
• Is also involved in
• learning and
• remembering motor
• skills

49
Diancephalon

• The embryonic diencephalon develops into three
  adult brain regions
• The epithalamus, thalamus, and hypothalamus
• The epithalamus
• Includes the pineal
• gland and the
• choroid plexus
• Produce cerebro-
• spinal fluid

50
Diancephalon

• The thalamus
• Is the main input center for sensory information
  going to the cerebrum and the main output center
  for motor information leaving the cerebrum
• The hypothalamus regulates
• Homeostasis
• Basic survival behaviors such as feeding,
  fighting, fleeing, and reproducing

51
Cerebrum

• The cerebrum has right and left cerebral
  hemispheres
• That each consist of cerebral cortex overlying
  white matter and basal nuclei

52
Cerebrum

• The basal nuclei
• Are important centers for planning and learning
  movement sequences
• In mammals
• The cerebral cortex has a convoluted surface
  called the neocortex
• Sensory information is analyzed , motor commands
  are issued, and language is generated
• Corpus callosum allows communication between
  hemispheres

53
Cerebral Cortex

• In humans, the largest and most complex part of
  the brain
• Is the cerebral cortex, where sensory information
  is analyzed, motor commands are issued, and
  language is generated
• Controls voluntary movement and cognitive
  functions
• Each side of the cerebral cortex has four lobes
• Frontal, parietal, temporal, and occipital

54
Cerebral Cortex
55
Lateralization

• During brain development, in a process called
  lateralization
• Competing functions segregate and displace each
  other in the cortex of the left and right
  cerebral hemispheres
• The left hemisphere
• Becomes more adept at language, math, logical
  operations, and the processing of serial
  sequences
• The right hemisphere
• Is stronger at pattern recognition, nonverbal
  thinking, and emotional processing

56
CNS Injuries

• Unlike the PNS, the mammalian CNS
• Cannot repair itself when damaged or assaulted by
  disease
• Current research on nerve cell development and
  stem cells
• May one day make it possible for physicians to
  repair or replace damaged neurons

57
Diseases of the Nervous System

• About 1 of the worlds population suffers from
  schizophrenia
• Schizophrenia is characterized by
• Hallucinations, delusions, blunted emotions, and
  many other symptoms
• Available treatments have focused on
• Brain pathways that use dopamine as a
  neurotransmitter

58
Diseases of the Nervous System

• Two broad forms of depressive illness are known
• Bipolar disorder and major depression
• Bipolar disorder is characterized by
• Manic (high-mood) and depressive (low-mood)
  phases
• In major depression
• Patients have a persistent low mood
• Treatments for these types of depression include
• A variety of drugs such as Prozac and lithium

59
Diseases of the Nervous System

• Alzheimers disease (AD)
• Is a mental deterioration characterized by
  confusion, memory loss, and other symptoms
• AD is caused by the formation of
• Neurofibrillary tangles and senile plaques in the
  brain

60
Diseases of the Nervous System

• Parkinsons disease is a motor disorder
• Caused by the death of dopamine-secreting neurons
  in the substantia nigra
• Characterized by difficulty in initiating
  movements, slowness of movement, and rigidity
• There is no cure for Parkinsons disease
• Although various approaches are used to manage
  the symptoms
