Title: Neisseria gonorrhoeae


1
Neisseria gonorrhoeae
  • Nealia House

2
Gonorrhea
  • Topic Overview
  • Biology of Neisseria gonorrhoeae
  • Survival Within Host
  • Screening
  • Treatment
  • Control/Surveillance

http//www2.chemie.uni-erlangen.de/education/medch
em/harnsteine/urs_infektion.html
3
Gonorrhea
  • Sexually transmitted disease
  • Infection Rate
  • socioeconomic class
  • Age
  • Very common infectious disease
  • STI second only to chlamydia
  • Increasing antibacterial resistance
  • Increases efficiency of HIV transmission

http//www.cat.cc.md.us/courses/bio141/labmanua/la
b1/dkngon.html
4
Affected Populations
STI Rates World-Wide
http//www.agi-usa.org/pubs/ib_std.html
5
Gonorrhea
  • Humans only natural host
  • Reproductive tract
  • Infection can be asymptomatic
  • Infertility
  • Several tests available for detection of gonorrhea

http//evolution.berkeley.edu/evosite/relevance/im
ages/Kunkel_97210C.jpg
6
Gonorrhea
  • Topic Overview
  • Biology of Neisseria gonorrhoeae
  • Survival Within Host
  • Screening
  • Treatment
  • Control/Surveillance

http//www.nature.com/genomics/images/neisseria_20
7
Transmission
  • Does not survive in the environment, must be
    transmitted through contact
  • Unprotected sex
  • Contact with eyes, mouth
  • Mother to child during birth

Neonatal hyperacute purulent conjunctivitis
http//www.aafp.org/afp/980215ap/morrow.html
8
Transmission
  • Transmissibility dependent on
  • Strain
  • Male to female transmission more effective
  • Higher number of organisms present in male
    urethral discharge than female vaginal secretions

http//www.biology.arizona.edu/human_bio/problem_s
ets/stds/graphics/Gonorrhea.gif
9
Structure
  • Diplococcus
  • Gram-negative
  • Fimbriae extend several micrometers from cell
    surface

http//textbookofbacteriology.net/BSRP.html
10
http//gsbs.utmb.edu/microbook/images/fig97_2.JPG
11
Systemic Infection
http//www.infocompu.com/adolfo_arthur/ingles/gono
rrea.htm
http//www.dermnet.com/thumbnailIndex.cfm?moduleID
16moduleGroupID234groupIndex0numcols0
12
Infection
  • N. gonorrhoeae attaches to mucosal cells via pili
    and other surface proteins
  • Induces production of inflammatory cytokines by
    epithelial cells

http//www.brown.edu/Courses/Bio_160/Projects1999/
av/gonorrhea.html
13
Infection
http//www.ncbi.nlm.nih.gov/books/bv.fcgi?ridmmed
.figgrp.898
14
Survival Within Host
  • Evades host immune system by changing surface
    proteins
  • Often asymptomatic infection
  • The RdgC protein is required for efficient pilin
    antigenic variation

http//www.brown.edu/Courses/Bio_160/Projects1999/
av/gonorrhea.html
15
Antigenic Variation
  • Pilus promotes attachment of gonococcal cell to
    host epithelial cell
  • Must retain some consistency
  • Conserved N-terminal and variable C-terminal
    regions
  • Constant regions
  • Semi-variable regions
  • Hypervariable regions
  • Phase variation from piliated to non-piliated

16
Immune Memory
  • Infection history did not alter antibody levels
    in patients with current infection
  • Suggests immunological memory not induced by
    uncomplicated gonococcal infections
  • Local and systemic immune responses to gonococci
    extremely modest
  • Slight increase in serum immunoglobulin G (IgG)
    in infected males
  • Slight increase in serum IgA1 antibodies in
    infected females

17
Survival Within Host
  • Pili, outer membrane proteins, lipopolysaccharides
  • Binding to epithelial surfaces
  • Passage through epithelium
  • Interaction with phagocytes
  • Variations in outer membrane protein (P1, Por)
  • Requires
  • Carbon dioxide
  • Sulfur in form of cysteine
  • Iron

http//www.med.monash.edu.au/assets/images/microbi
ology/gono.jpg
18
Antimicrobial Resistance
  • Gonococcal strains resistant to
  • Penicillins
  • Tetracyclines
  • Spectinomycin
  • Fluoroquinolones
  • Presently, ciprofloxacin and ofloxacin
    recommended by CDC for treatment

19
Biotechnology
  • Oligonucleotide chips now used to screen for
    antimicrobial resistance
  • Point mutations in the gyrA and parC genes
  • Determine the prevalence of ciprofloxacin-resistan
    t strains
  • Results identical to sequencing results
  • Rapid and reliable analysis

20
Gonorrhea
  • Topic Overview
  • Biology of Neisseria gonorrhoeae
  • Survival Within Host
  • Screening
  • Treatment
  • Control/Surveillance

http//thailabonline.com/bacteria7.htm
21
Screening
  • Gold Standard
  • Nucleic acid amplification assays
  • Polymerase chain reaction
  • Cell culture to confirm diagnosis
  • Oxidase positive

http//education.med.nyu.edu/courses/microbiology/
courseware/infect-disease/Gram_Neg_Bacilli5.html
22
Types of Tests
  • Gram-Stained Smear
  • Sensitivity reduced in asymptomatic infections
  • Less that 50 sensitive as cell culture
  • Not useful in rectal infections

http//www.lahey.org/Medical/InfectiousDiseases/ID
_Gonorrhea.asp
23
Types of Tests
  • Culture Based Systems
  • High degree of specificity
  • Expensive
  • Trained personnel
  • Media requirements
  • Presumptive identification
  • Growth on selective GC agar, gram stain, oxidase
    and superoxol positivity

http//www.asu.edu/it/spotlight/archive/genesis/
24
Types of Tests
  • Antigen Detection and Enzyme Immunoassays
  • Extensively investigated
  • Low/high prevalence
  • Symptomatic/asymptomatic
  • Few to no situations for which this assay
    recommended
  • Because of antigenic variation

http//wfrc.usgs.gov/research/fish20populations/S
TMaule5.htm
25
Types of Tests
  • DNA Probe Hybridization
  • Specific chemiluminescent label on probe
  • Available commercially
  • 85 sensitivity
  • 99 specificity

http//www.ebiotrade.com
26
Types of Tests
  • Nucleic Acid-Based Amplification Assays (NAAT)
  • 95 accurate
  • False positives due to specimen
    cross-contamination, environmental contamination

http//www.biologicalprocedures.com/bpo/arts/1/6/m
6.htm
27
Current Screening
  • No test for samples from all major sites of
    gonococcal infection
  • Rapid
  • Inexpensive
  • Reliable
  • Such a test would improve case-finding
  • Efficient treatment
  • Disease management

28
Gonorrhea
  • Topic Overview
  • Biology of Neisseria gonorrhoeae
  • Survival Within Host
  • Screening
  • Treatment
  • Control/Surveillance

http//neisseria.org/ng/images/
29
Treatment
http//www.cdc.gov/STD/treatment/4-2002TG.htmGono
coccal
30
Treatment
  • Fluoroquinolones

Levofloxacin
Ciprofloxacin
http//www.ncbi.nlm.nih.gov/books/bv.fcgi?ridmmed
.figgrp.686
http//www.alchemchina.com/products/apis_l.files/L
Ofloxacin
http//www.m-ww.de/pharmakologie/arzneimittel/anti
infektiva/antibiotika/ofloxacin.html
31
Treatment
  • Ceftriaxone (Rocephin)
  • Single dose intramuscularly
  • Introduced as treatment in 1985
  • Retained resistance
  • Beta-lactam antibiotic
  • Action against penicillinase

http//www.m-ww.de/pharmakologie/arzneimittel/anti
infektiva/antibiotika/ceftriaxon.html
32
Treatment
  • Possible co-infection with Chlamydia trachomatis

Azithromycin
Doxycycline
http//www.cbwinfo.com/Pharmaceuticals/Structures/
http//www.bmb.leeds.ac.uk/mbiology/ug/ugteach/icu
8/images/antibiotics/azithromycin.gif
33
Vaccine
  • Hard to develop
  • No animal model
  • No immune memory to Neisseria gonorrhoeae
  • Antigenic variation strategy
  • Difficulty finding target common to all strains
  • Research continues to identify possible vaccine
    targets
  • DNA vaccines
  • Mucosal immunization

34
Gonorrhea
  • Topic Overview
  • Biology of Neisseria gonorrhoeae
  • Survival Within Host
  • Screening
  • Treatment
  • Control/Surveillance

http//www.mediscan.co.uk/cfm/img_coll.cfm?action
searchimageID020864collectionID21nameElectro
n20Micrographslognk
35
Prevention
  • Abstinence
  • Safe/smart sex
  • Barrier contraceptives
  • Educational programs
  • Reduce misuse of antimicrobials

http//www.pueblo.gsa.gov/cic_text/health/contrace
pt/condom.gif
36
Governmental Programs
  • Health Canada
  • Educational plans
  • STD Screening
  • Free STD clinics

37
Governmental Programs
  • CDC Gonococcal Isolate Surveillance Project
    (GISP)

38
Conclusions
  • More research
  • Reliable, fast screening
  • Preventative therapeutics
  • Non-biotechnological interventions
  • Prudent antimicrobial use

http//www.agma.med.uni-giessen.de/cfagma/andro/ve
rz.dbm
39
References
  • Alary, M, 1997. National goals for the
    prevention and control of sexually transmitted
    diseases in Canada. Canada Communicable Disease
    Report, vol. 23Sb.
  • Barron, S, Peake, R, James, D, Susman, M,
    Kennedy, C, Singleton, M, Schuenke, S, 1996.
    Medical microbiology, 4th Edition. The
    University of Texas Medical Branch at Galveston.
    Galveston, TX.
  • Bos, M, Tefsen, B, Voet, P, Weynants, V, van
    Putten, J, Tommassen, J, 2005. Function of
    neisserial outer membrane phospholipase a in
    autolysis and assessment of its vaccine
    potential. Infection and Immunity. 73(4)
    2222-31.
  • Bowden, F, Tabrizi, S, Garland, S, Fairley, C,
    2002. Sexually transmitted infections new
    diagnostic approaches and treatments. MJA
    Practice Essentials Infectious Diseases. 176
    (11) 551-557.
  • Brooks, G, Lammel, C, 1989. Humoral immune
    response to gonococcal infections. Clinical
    Microbiology Review. 2(Suppl) S510.
  • Centers for Disease Control and Prevention, 2005.
    STD facts and information Gonorrhea. National
    Center for HIV, STD, and TB Prevention, Division
    of Sexually Transmitted Diseases Prevention.
    http//www.cdc.gov/nchstp/dstd/GonorrheaInfo.htm
    last accessed 3/29/05.
  • Charnas, R, Then, R, 1988. Mechanism of
    inhibition of chromosomal beta-lactamses by
    third-generation cephalosporins. Reviews in
    Infectious Disease, 10(4) 752-760.
  • Chen, A, Boulton, I, Pongoski, J, Cochrane, A,
    Gray-Owen, S, 2003. Induction of HIV-1 long
    terminal repeat-mediated transcription by
    Neisseria gonorrhoeae. AIDS, 17(4) 625-628.
  • Fletcher, L, Bernfield, L, Barniak, V, Farley, J,
    Howell, A, Knauf, M, Ooi, P, Smith, R, Weise, P,
    Wetherell, M, Xie, X, Zargursky, R, Zhang, Y,
    Zlotnick G, 2004. Vaccine potential of the
    Neisseria meningitides 2086 lipoprotein.
    Infection and Immunity. 72(4) 2088-2100.
  • Forest K, Bernstein, S, Getzoff, E, Tribbick, S,
    Geysen, H, Deal, C, Tainer, J, 1996. Assembly
    and antigenicity of the Neisseria gonorrhoeae
    pilus mapped with antibodies. Infection and
    Immunity. 64(2) 644652.
  • Fredlund, H, Falk, L, Jurstrand, M, Unemo, M,
    2004. Molecular genetic methods for diagnosis
    and characterization of Chlamydia trachomatis and
    Neisseria gonorrhoeae impact on epidemiological
    surveillance and interventions. Acta
    Pathologica, Microbiologica et Immunologica
    Scandinavica. 112(11-12) 771-84.
  • Hamilton, H, Dominguez, N, Schwartz, K, Hackett,
    K, Dillard, J, 2005. Neisseria gonorrhoeae
    secretes chromosomal DNA via a novel type IV
    secretion system. Molecular Microbiology.
    55(6)1704-21.
  • Hedges, S, Mayo, M, Mestecky, J, Hook, E,
    Russell, M, 1999. Limited local and systemic
    antibody responses to Neisseria gonorrhoeae
    during uncomplicated genital infections.
    Infection and Immunity. 67(8) 3937-3946.
  • Jacoby, GA, 1994. Genetics of extended-spectrum
    beta-lactamase. Journal of Clinical Microbiology
    and Infectious Diseases, 13 Suppl 1S2-11
  • Judson, F, Beals, B, Tack, K, 1986. Clinical
    experience with ofloxacin in sexually transmitted
    disease. Infection, 14(4) 309-310.

Title Slide picture http//www.visualsunlimited.
com/browse/vu197/vu197395.html
40
  • Leclercq, R, 2001. Overcoming antimicrobial
    resistance profile of new ketolide
    antibacterial, telithromycin. Journal of
    Antimicrobial Chemotherapy, 48(T1) 9-23.
  • Levy, S, Marshall, B, 2004. Antimicrobial
    resistance worldwide causes, challenges, and
    responses. Nature Medicine Supplement. 10(12)
    122-128.
  • Massari, P, Ram, S, Macleod, H, Wetzler, L, 2003.
    The role of porins in neisserial pathogenesis
    and immunity. Trends in Microbiology. 11(2)
    87-93.
  • Merz, A, So, M, 2000. Interactions of pathogenic
    Neisseriae with epithelial cell membranes.
    Annual Review of Cell and Developmental Biology.
    Vol. 16 423-457.
  • Moore, T, Sharples, G, Lloyd, R, 2004. DNA
    binding by the meningococcal rdgC protein,
    associated with pilin antigenic variation.
    Bacteriology, 186(3) 870874.
  • Nassif, X, So, M, 1995. Interaction of
    pathogenic neisseriae with nonphagocytic cells.
    Clinical Microbiology Review. 8(3) 376388.
  • Naumann, M, Wessler, S, Bartsch, C, Weieland, B,
    Meyer, T, 1997. Neisseria gonorrhoeae epithelial
    cell interaction leads to the activation of the
    transcription factors nuclear factor kB and
    activator protein 1 and the induction of
    inflammatory cytokines. Journal of Experimental
    Medicine, 186(2) 247-258.
  • Nusbaum, M, Wallace, R, Slatt, L, Konrad, E,
    2004. Sexually transmitted infections and
    increased risk of co-infection with Human
    Immunodeficiency Virus. The Journal of the
    American Osteopathic Association, 104(12)
    527-535.
  • Perrin, A, Nassif, X, Tinsley, C, 1999.
    Identification of regions of the chromosome of
    Neisseria meningitides and Neisseria gonorrhoeae
    which are specfici to the pathogenic Neisseria
    species. Infection and Immunity. 67(11)
    61196129.
  • Price, G, Hobbs, M, Cornelissen, C, 2004.
    Immunogenicity of Gonococcal Transferrin Binding
    Proteins during Natural Infections. Infection
    and Immunity. 72(1) 277283.
  • Rotchford, K, Strum, A, Wilkinson, D, 2000.
    Effect of coinfection with STDs and of STD
    treatment on HIV shedding in genital-tract
    secretions systematic review and data synthesis.
    Sexually Transmitted Diseases, 27(5) 243-248.
  • Suzuki, K, Matsumoto, T, Murakami, H, Tateda, K,
    Ishnii, N, Yamaguchi, K, 2004. Evaluation of
    rapid antigen detection test for Neisseria
    gonorrhoeae in urine sediment for diagnosis of
    gonococcal urethritis in males. Journal of
    Infection and Chemotherapy, 10(4) 208-211.
  • Shang, S, Xia, L, Zhong, M, Zhang, J, Zhao, J,
    Gong, X, Mabey, D, Wang, Q, 2005. In vitro
    effects of spectinomycin and ceftriaxone alone or
    in combination with other antibiotics against
    Chlamydia trachomatis. Antimicrobial Agents
    Chemotherapy, 49(4) 1584-1586.
  • Taha, M, Marchal, L, 1990. Conservation of
    Neisseria gonorrhoeae pilus expression regulatory
    genes pilA and pilB in the genus Neisseria.
    Infection and Immunity, 58(12) 4145-4148.
  • Tapsall, J, 2001. Anitmicrobial resistance in
    Neisseria gonorrhoeae. World Health
    Organization.
  • Virji, M, Heckels, J, 1985. Role of anti-pilus
    antibodies in host defense against gonococcal
    infection studied with monoclonal anti-pilus
    antibodies. Infection and Immunity. 49(3)
    621-628.
  • Zhou, W, Du, W, Cao, H, Zhao, J, Yangs, S, Li, W,
    Shen, Y, Zhang, S, Du, W, Zhang, X, 2004.
    Detection of gyrA and parC mutations associated
    with ciprofloxacin resistance in Neisseria
    gonorrhoeae by use of oligonucleotide biochip
    technology. Journal of Clinical Microbiology.
    42(12) 5819-24.
Write a Comment
User Comments (0)
About PowerShow.com
