Title: Introduction to Inkjet Printers


1
Introduction to Inkjet Printers
2
What is Industrial Inkjet Printer?
  • An Industrial inkjet printer creates image by
    propelling droplets of ink onto substrates.
  • The continuous inkjet method is used for marking
    and coding of products and packages especially
    for marking the mandatory/ Regulatory information
    on the product

3
The Process
  • A high-pressure pump directs liquid ink creating
    a continuous stream of ink droplets via the
    Plateau-Rayleigh instability.
  • A piezoelectric crystal causes the stream of
    liquid to break into droplets
  • The ink droplets are subjected to an
    electrostatic field that varies according to the
    degree of drop deflection
  • The charged droplets pass through an
    electrostatic field and only a small fraction of
    these droplets are used to print, the majority
    being recycled

4
Working
5
Technologies Used
  • Continuous Inkjet
  • In continuous inkjet technology, a high-pressure
    pump directs liquid ink from a reservoir through
    a gun body and a microscopic nozzle, creating a
    continuous stream of ink droplets
  • Drop on Demand
  • Thermal DOD inkjet
  • To eject a droplet from each chamber, a pulse of
    current is passed through the heating element
    causing a rapid vaporization of the ink in the
    chamber to form a bubble, which causes a large
    pressure increase, propelling a droplet of ink
    onto the paper
  • Piezoelectric DOD inkjet
  • When a voltage is applied, the piezoelectric
    material changes shape, which generates a
    pressure pulse in the fluid forcing a droplet of
    ink from the nozzle.

6
Small CIJ Product Lines
Videojet 1000 Line
Videojet 1610
Videojet 1610 Dual Head
Videojet 1510
Visit - http//www.videojet.com/in/en/small-charac
ter-ink-jet-systems for more information.
7
Why Videojet?
  • Broadest range of technologies
  • Pan India Presence
  • Quality Service
  • Customer Satisfaction
  • Wide range of products
  • Offers printing solutions with maximum uptime and
    less cost

8
  • Website www.videojet.com/in/en/index
  • Phone 022-30933155 /022-27780619
  • Toll Free No. 1800-3000-1199
  • Email marketing.india_at_videojet.com

  • Address 101/102, Bldg 5, Millennium
    Business Park Sector 2, Mahape, Navi Mumbai
    400 710
