War Driving, Why and How

1
War Driving, Why and How

• George Beranek gberanek_at_anl.gov (630)
  252-7219
• Senior Security and Network Administrator
• Argonne National Laboratory
• NETSECURE 06, Illinois Institute of Technology's
  Rice Campus Center for Professional Development
• 08-Mar-2006 Room 118 1000 am 1130 am

2
What is War Driving?

• war driving n. A computer cracking technique that
  involves driving through a neighborhood with a
  wireless-enabled notebook computer and mapping
  houses and businesses that have wireless access
  points.
• Wardriving is driving around a city searching for
  the existence of Wireless LAN (802.11) Networks.
  It's locating and logging wireless access points
  while in motion. Often, this task is automated
  using dedicated wardriving software and a GPS
  unit.
• Wardriving was invented by Peter Shipley and is
  now commonly practiced by hobbyists, hackers and
  security analysts worldwide.
• "Wireless technology sets data free from the
  physical confines of wire which also means that
  controlling who receives the data is problematic.
  Peter Shipley, the director of labs at OneSecure,
  told me about his new hobby of driving around
  Silicon Valley and picking up networks on his
  laptop. war driving is replacing war dialing in
  the wireless age." Carole Fennelly, Unix
  Insider, December 2000

3
Why War Drive?

• Do tech managers know where all their wireless
  LAN access points (AP) are? Since they can be
  plugged into a LAN and stashed almost anywhere,
  even by users, they can be a challenge to manage
  internally. Meanwhile, strangers can be
  discovering them be "war driving," cruising
  around with a wireless-enabled laptop seeking
  wireless LANs that can be entered and explored.
  "IBM Tool Targets Wireless 'War Driving',"
  e-Business Advisor, August, 2002t
• From a technical perspective War Driving can be
  very interesting, White Hat Hacking
• As a hobbyist War Driving is both FUN technically
  challenging.
• Bandwidth Stealers (warez sharing, etc...)
• Anonymity Seekers (legal and illegal motives)
• True Black Hat Hackers

4
Hardware

• Required
• A portable computer (laptop / palmtop)
• Dell Latitude D810 (ear bud recommended)
• A compatible built in or pcmcia Wireless NIC
• external antennae (omnidirectional /
  unidirectional)
• A GPS http//www.cantenna.com/
• http//www.deluoelectronics.com/
• Optional (but very very cool)
• Linksys WRT54G Wireless Router / Access Point

5
Netstumbler vs. Kismet (Windows vs. Linux)

• Netstumbler http//www.netstumbler.com/
• Runs on Windows XP
• Great for a quick war-walk / war-drive or a quick
  vulnerability assessment (rogue access point
  detection) or coverage / interference testing on
  an unprotected network, but....
• Netstumbler sends out 802.11 Probe Request
  frames for SSID Any providing no real
  advantage, but making it easily detectable.
• Netstumbler does not sniff.
• Kismet http//www.kismetwireless.net/
• Runs on Linux / Unix (client ported to Windows)
• Kismet puts your wireless NIC into RFMON mode and
  does Passive Scanning
• Kismet will discover and report the IP address,
  netmask, and default gateway as well as the SSID
  of no ssid sites if possible.
• Kismet sniffs and records packets for later use
  with Ethereal, AirSnort, AirCrack, etc...
• Kismet's intrusion detection feature will detect
  many probing / attack fingerprints including
  Netstumbler

6
Basic Software

• Packages that you'll need
• gpsd GPS (Global Positioning System) service
  daemon http//gpsd.berlios.de/
• kismet Wireless 802.11b monitoring tool
  http//www.kismetwireless.net/
• Packages that you'll want
• Ethereal network traffic analyzer
  http//www.ethereal.com/
• gpsdrive Car navigation system
  http//gpsdrive.kraftvoll.at/
• festival general speech synthesis
  http//www.cstr.ed.ac.uk/projects/festival/
• MySQL database package http//www.mysql.com/
• xgps gui client for the GPS service daemon
  http//gpsd.berlios.de/xgps.html
• wifi-radar gui for managing Wi-Fi profiles
  http//www.bitbuilder.com/wifi_radar/
• Other Packages
• Airsnort WLAN sniffer http//airsnort.shmoo.com/

• Aircrack wireless WEP cracker
  http//www.wirelessdefence.org/Contents/AircrackMa
  in.htm
• Dsniff sniffs network traffic for cleartext
  insecurities http//www.monkey.org/dugsong/dsnif
  f/

7
Setup

• Install NIC, GPS, and Software Paclages
• Compile RFMON mode NIC driver kernel modules if
  necessary
• Setup the MySQL database
• mysql -u root -p lt /usr/share/gpsdrive/create.sql
  (This will add a user gast / gast)
• Edit /etc/kismet/kismet.conf for your NIC and
  configuration.
• sourceipw2915,eth1,BuiltIn,6
• sourceorinoco,eth2,BuiltIn,6
• sourcecisco,eth2,BuiltIn,6
• sourcekismet_drone,192.168.108.13501,drone

8
Execution

• Start the GPS daemon
• ps -ef grep -i gps Kill gpsd -F
  /var/run/gpsd.sock if present
• dmesg grep -i usb check to make sure your
  GPS has associated with a port
• ln -s /dev/ttyUSB0 /dev/gps gpsd -K -f
  /dev/gps ps -ef grep -i gps
• make sure that mysqld is running ps -ef grep
  -i sql , /etc/init.d/mysql restart if not
• make sure festival is running ps -ef grep -i
  sql , festival --server if not
• Add localhost to xhosts xhost xhost
  localhost xhost
• Start xgps xgps -speedunits mph -altunits ft
• Make sure that no kismet components are running
  ps -ef grep -i kismet, kill if present
• Start Kismet kismet
• Start gpsdrive gpsdrive
• Start wifi-radar wifi-radar
• Now Do Your War Drive!

9
Kismet can be integrated with MySQL, GPSDrive,
and SNORT
10
War Driving with Kismet http//www.kismetwireless
.net/

• Synthesized voice announces discoveries. (Great
  while driving, but an ear bud makes it even
  better)
• Real Time Commands
• s Sort network list
• l Show wireless card power levels
• i Detailed information about selected network
• r Packet rate graph
• a Statistics
• d Dump printable strings
• e List Kismet servers
• m Toggle muting of sound and speech
• c Show clients in current network
• H Return to normal channel hopping
• x Close popup window
• h Help (Many Other Controls)

11
Mapping the results

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k
  -S 2 Kismet-date-numbers

12
Power

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

13
Power

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

14
IIT Rice Campus with Intel ipw2915 mini pci
internal

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

15
IIT Rice Campus with Orinoco Gold pcmcia card and
external antenna

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

16
IIT Rice Campus with Linksys WRT54G OpenWRT
Kismet Drone

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

17
IIT Rice Campus aggregate of all 3 war drives

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

18
ShoniBrook I

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

19
ShoniBrook II

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

20
ShoniBrook III

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

21
1840

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

22
2648

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

23
FCC Berwyn

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

24
Argonne 200

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

25
Argonne 300

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

26
Unidirectional Antenna War Walk to eliminate
clutter

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

27
ShoniBrook GPSDrive with Kismet (friends mode)

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

28
ShoniBrook GPSDrive with MySQL

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

29
IIT Rice Campus GPSDrive with Kismet

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

30
IIT Rice Campus GPSDrive with MySQL

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

31
IIT Rice Campus using Orinoco NIC and
Unidirectional Cantenna

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

32
A War Walk using Windows XP

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

33
NetStumbler War Walk of IIT Rice Campus

• gpsmap -v -l ssid -L 0 -G -t -D -p -r -a -e -k -S
  2 Kismet-date-numbers.

34
Results of Kismet IIT Rice Campus War Walk (No
GPS indoors)

• Network 1 "rice_wireless" BSSID
  "00C049A97BB1" infrastructure 06
  10.0.0.67
• Network 2 "rice_wireless" BSSID
  "00C049A9755A" infrastructure 06 10.0.0.0
• Network 3 "rice_wireless" BSSID
  "00C049A9A0FF" infrastructure 06
  10.0.0.173
• Network 4 "rice_wireless" BSSID
  "00C049A9758E" infrastructure 01 10.0.0.1
• Network 5 "voiplab" BSSID "004096A1111D"
  infrastructure 03 WEP
• Network 6 "tsunami" BSSID "000D288E56DE"
  probe 00
• Network 7 "rice_wireless" BSSID
  "00C049A9757A" infrastructure 11
  216.47.135.65
• Network 8 "cuwireless.net" BSSID
  "02026F21E91A" ad-hoc 11 169.254.233.26
• Network 9 "rice_wireless" BSSID
  "00C049A97580" infrastructure 11
  192.168.1.3
• Network 10 "rice_wireless" BSSID
  "00C049A97588" infrastructure 11
  10.0.0.101
• Network 11 "BlackHole" BSSID "001217087458"
  infrastructure 01 WEP
• Network 12 "wirelessR624" BSSID
  "000F3D3B42A8" infrastructure 06 WEP
• Network 13 "2WIRE501" BSSID "000D72D5C399"
  infrastructure 06 WEP
• Network 14 "linksys" BSSID "0013100550AE"
  infrastructure 06
• Network 15 "2WIRE937" BSSID "00149578BEB1"
  infrastructure 06 WEP
• Network 16 "ltno ssidgt" BSSID "001217E4CE22"
  probe 00
• Network 17 "2WIRE085" BSSID "000D72A20DF9"
  infrastructure 06 WEP
• Network 18 "Aegus 243" BSSID "00146C458DE6"
  infrastructure 11

35
Map Sources GPS maps are available from many
sources

• Mapblast http//www.slhonline.org/MapBlast!
  Mapblast!.htm http//www.mapblast.com/
• MapPoint http//mappoint.msn.com/
• Terraserver http//www.terraserver.com/
  http//terraserver.microsoft.com/
• Tiger Census http//tiger.census.gov/cgi-bin/mapb
  rowse-tbl
• FreeGIS http//www.freegis.org/
  http//www.freegis.org/browse.en.html
• NASA satellite topology maps ftp//mitch.gsfc.nas
  a.gov/pub/stockli/bluemarble/
• USGS http//www.usgs.gov/
• Netstumbler data can be plotted at a number
  of websites http//www.wifimaps.com/

36
Data Analysis (/var/log/kismet/Kismet-Mar-03-2006
-10.dump)

• Kismet's .dump files can be read and analyzed by
  Ethereal, AirSnort, AirCrack, etc...
• Kismet

37
Data Analysis

• AirSnort load pcap file Kismet-Feb-15-2006-3.dum
  p

38
Data Analysis

• AirCrack Kismet-Feb-15-2006-2.dump
• aircrack Kismet-Feb-15-2006-2.dump

39
Linux on the Linksys WRT54G

• History
• The WRT54G was released in 2003 in anticipation
  of the 802.11g standard.
• In June 2003 some folks on the Linux Kernel
  Mailing List sniffed around the WRT54G and found
  that its firmware was based on Linux components.
  Because Linux is released under the GNU General
  Public License, or GPL, the terms of the license
  obliged Linksys to make available the source code
  to the WRT54G firmware. As most router firmware
  is proprietary code, vendors have no such
  obligation. It remains unclear whether Linksys
  was aware of the WRT54Gs Linux lineage, and its
  associated source requirements, at the time they
  released the router. But ultimately, under
  outside pressure to deliver on their legal
  obligation under the GPL, Linksys open sourced
  the WRT54G firmware in July 2003.
• With the code in hand, developers learned exactly
  how to talk to the hardware inside and how to
  code any features the hardware could support. It
  has spawning a handful of open source firmware
  projects for the WRT54G that extend its
  capabilities, and reliability, far beyond what is
  expected from a cheap consumer-grade router.
  Seattle Wireless is generally credited as being
  the first to upload new firmware to the WRT54G.
  You can now actually run snort or kismet right on
  your wireless router.

40
Linksys Firmware Replacements

• There now exists plethora of firmware
  replacements for the WRT54G, such as
• Sveasoft (no longer free) http//www.sveasoft.com/

• Wifi-Box https//sourceforge.net/projects/wifi-box

• BatBox http//www.batbox.org/wrt54g-linux.html
• These distributions can provide a lot of
  additional functionality
• Radio Transmit power adjustment
• Antenna selection
• Iptables filtering / Shorewall firewall
• Snort intrusion detection
• Telnet, SSH, local caching DNS, SNMP daemons
• Kismet Drone
• With the right replacement firmware, it can do
  what youd only expect to be able to on a
  commercial-grade router costing several times as
  much BUT it can be difficult to find a firmware
  that contains exactly the functionality that
  you're looking for.

41
OpenWRT http//openwrt.org/

• The OpenWRT firmware takes a completely different
  approach, turning your WRT54G into a complete
  generalized interactive Linux system including
  package (ipkg list) management. It is not based
  on Linksys code at all.
• Some notable features are the ability to
  telnet/SSH to your router, install software such
  as Snort, Kismet, Mini-Sendmail, and Iptables,
  and create and control VLANs for every Ethernet
  port on the device.
• By default, OpenWrt's installation emulates the
  normal Linksys firmware functionality. This means
  that although you installed OpenWrt, your router
  still acts as a wireless access point and switch.
  (nvram show more)
• OpenWrt obeys common networking conventions,
  taking advantage of route, ifconfig, and
  /etc/resolv.conf.
• One of the great things about OpenWrt is its use
  of iPKG, a tiny package management system
  inspired by Debian's APT. With iPKG, installing
  packages, such as tcpdump, is simple as running a
  command like ipkg install tcpdump. Use ipkg
  update and ipkg list to see what add-on software
  is available.
• You could use the WRT54G as a repeater or a
  bridge. Create a wireless distribution system
  (WDS) or a mesh network. Run a VPN server or a
  VoIP server or a managed hotspot with a RADIUS
  server. Manage bandwidth use per protocol.
  Control traffic shaping. Support IPv6. Boost
  antenna power. Remotely access router logs.
  Operate the router as a miniature low-power PC,
  running a variety of Linux applications. (UART
  hardware mod)

42
http//192.168.108.11840/

• http//192.168.108.11840/cgi-bin/webif.sh

43
http//192.168.108.11840/cgi-bin/webif/wireless-c
onfig.sh

• http//192.168.108.11840/cgi-bin/webif.sh

44
http//192.168.108.11840/cgi-bin/webif/ipkg.sh

• http//192.168.108.11840/cgi-bin/webif.sh

45
Wireless intrusion detection using stationary
Kismet drones

• Kismet will provide alerts based on fingerprints
  (specific netstumbler versions, other specific
  attacks) and trends (unusual probes, excessive
  disassociation, etc). Kismet focuses on the
  802.11 (layer 2) network layer, and provides
  integration via named pipes with layer3 IDS
  systems such as Snort.
• You can create inexpensive Kismet drone(s) using
  WRT54G Wireless Routers and place them
  strategically at your facility. A single Linux
  system can act as the Kismet client for all of
  these drones. In this way your wireless
  installation can be continuously and
  inexpensively monitored. Logs can even be
  intelligently parsed for the appearance of rogue
  access points with perl, swatch, etc.

46
Turn your Wireless Laptop / Desktop into an
Access Point

• By building your own Access Point on a Linux
  server you can
• Run an iptables firewall to protect your network
• Set up intrusion detection
• Build a captive portal
• Build a web caching server
• Actually you can do ALMOST ANYTHING!
• The ability to turn you laptop into a WAP can
  come in very handy at times. It can overcome the
  disadvantages of ad-hoc mode. It can also be
  used to spoof an existing AP to attack / audit a
  wireless installation.
• What is actually necessary to achieve access
  point functionality is to get your wireless NIC
  into MASTER mode or to emulate this mode.
  iwconfig wlan0 essid myAP mode master
• This can be accomplished through the use of
  enhanced driver software depending upon your
  NIC's chipset hostap for Prism / cisco Aironet
  , Hermes AP for Orinoco cards , madwifi for
  Atheros , etc.

47
Specialized Linux Distributions

• If you're a Windows user who doesn't want to
  install Linux then here's a live filesystem CD
  distribution that will run everything you need
  without touching your hard drive!
• Knoppix STD (Security Tool Distribution)
  http//www.knoppix-std.org/
• Contains http//www.knoppix-std.org/tools.html
• airsnarf rogue AP setup utility
• airsnort sniff, find, crack 802.11b
• airtraf 802.11b network performance analyzer
• gpsdrive use GPS and maps
• kismet 3.0.1 for 802.11 what else do you need?
• kismet-log-viewer manage your kismet logs
• macchanger change your MAC address
• wellenreiter 802.11b discovery and auditing
• patched orinoco drivers automatic (no scripts
  necessary)
• WARLINUX
• an easy form of Linux with Kismet for windows
  users to try out https//sourceforge.net/projects/
  warlinux/

48
Some Useful Commands

• iwconfig used to configure the basic operating
  parameters of your wireless NIC.
• cardctl - used to monitor and control the state
  of PCMCIA sockets
• iwlist - shows current parameters and available
  access points - iwlist eth1 scanning
• iwspy - shows quality of link parameters
• iwpriv allows you to configure private wireless
  options specific to a single wireless driver.

49
Wireless Security Countermeasures

• Change Default Administrator Passwords (and
  Usernames)
• Turn on highest level WPA / WEP Encryption
• Change the Default SSID
• Enable MAC Address Filtering
• Disable SSID Broadcast
• Assign Static IP Addresses to Devices
• Position the Router or Access Point Safely
• Turn Off the Network During Extended Periods of
  Non-Use
• Use strong encryption like ssh for all
  applications you use over the wireless network.
• Encrypt wireless traffic using a VPN
• Keep firmware up to date
• Authenticate wireless users with protocols like
  EAP
• Create a dedicated segment for your Wireless
  Network, and take additional steps to restrict
  access to this segment
• Regularly TEST the security of your wireless
  network, using the latest Wardriving Tools.
• Enable strict LOGGING on all devices and
  routinely audit these logs.
• Implement Wireless Intrusion Detection

50
Some Excellent References

• Linux Unwired by Roger Weeks
• A comprehensive and thoroughly useful treatment
  of the basics of wireless Linux.
• Great sections on Blue Tooth and IR for Linux
  too.
• http//www.oreilly.com/catalog/lnxunwired/

• WI-FOO The Secrets of Wireless Hacking Andrew
  Vladimirov, Konstantin V. Gavrilenko, Andrei A.
  Mikhailovsky
• A much more advanced reference.
• The definitive guide to wireless attack and
  defense.
• http//www.wi-foo.com/

51
QUESTIONS?

• USE OPEN SOURCE http//www.opensource.org/
• UBUNTU http//www.ubuntu.com/
• FIREFOX http//www.mozilla.com/firefox/
• Open Office http//www.openoffice.org/
  http//www.anl.gov/
• Argonne National Laboratory is located on 1,500
  acres, 25 miles southwest of downtown Chicago.

52
Speaker Bio

• George Beranek began his professional computer
  career in the early 1980's as a test engineer /
  designer programming in HP Rocky Mountain Basic,
  Pascal, Fortran, and C supplying intelligent
  replacement for electro-mechanical test systems
  as an independent contractor for Eaton
  Corporation and Gould Research Center. In 1990
  he transitioned into Unix System and Network
  administration at Motorola where he eventually
  headed a team of system administration and
  networking professionals dedicated to quick
  response and high performance technical computing
  for their Cellular Infrastructure International
  Systems Engineering Group during the peak of
  their cellular boom. George is presently a
  Senior Security and Network Administrator at
  Argonne National Laboratory where he essentially
  functions as an internal Linux consultant.
  George received a BS in Electrical Engineering
  and Computer Science from Northwestern
  University's Technological Institute and a MS in
  Electrical Engineering and Computer Engineering
  from IIT. He is also a RedHat Certified Engineer
  (RHCE) but of late has become passionate about
  the Debian based Ubuntu Linux distribution.
  George has been a member of the IEEE for the past
  24 years.

53

• The Advanced Photon Source (APS) is the nations
  brightest source of X-rays for research.
