Title: .net frame work


1
Microsoft.NET Framework
Overview

2
.NET Enterprise Vision
UsersAny device,Any place,Any time
XML Web ServicesIntegrate business applications
and processes
Authentication
Scheduling
Notification
Back OfficeHeterogeneous application and server
infrastructure
Sales
Customer Service
ERP Billing
3
Category of Programmers
  • System Programmers One who programs directly
    for a given hardware eg Device Drivers or
    extremely low level o/p services.
  • Application Programmers One who programs
    applications used by people for their
    requirements eg Calculator, Calendar,
    MS-Office like packages, Accounting Packages etc
  • .NET is for Application programming and not for
    System programming.

4
Definitions
  • Platform is an environment for developing and
    executing application.
  • Framework is ready to use collection of Classes
    and Interfaces used for developing a particular
    type of application.

5
What is a Platform?

Assembly Code Operating System
MS.NET Framework
MS.NET Applications
JAVA Applications
H/W
JRE
C/ C Applications
6
What is .NET?
  • MS.Net is a Framework built on open internet
    protocols standards with tools and services
    that meld computing and communication in new ways
  • Its an environment for developing and running
    software applications featuring ease of
    development of web based services, rich standard
    runtime services available to components written
    in variety of programming languages provides
    inter language inter machine inoperability

7
Framework Components
  • MS.NET Framework Runtime
  • Used for both Development and Production of .NET
    applications
  • MS.NET Framework SDK
  • Mostly used only for Development of .NET
    application
  • Visual Studio.NET
  • IDE and RAD Tool for Developing .NET applications
  • Not needed on Production machine
  • Common environment for multiple languages like
    VB.NET, C, VC
  • Can be used any type of MS.NET Application
  • Can be used also for non .net based applications
    like PHP pages. For this we need a plug-in to be
    installed over Studio.

8
MS.NET Framwork Versions
  • Version 1.0 in Year 2002
  • Version 1.1 in Year 2003
  • Version 2.0 in Year 2005
  • Version 3.0 in Year 2006
  • Version 3.5 in Year 2007
  • All versions can be installed side by side on
    same machine.

9
Versions Dependency
  • 1.0 is a standalone version
  • 1.1 is also a standalone version
  • 2.0 is also a standalone version
  • 3.0 is installed over 2.0
  • 3.5 is installed over 3.0
  • So the machine having 3..5 will also have version
    2.0 and 3.0 installed on it but 1.0 and 1.1 need
    not will be installed

10
Version Compatibility
  • Doesn't support Forward or Backward
    compatibility.
  • The version used on development machine and
    production machine must be same.
  • If 1.1 has been used for development and on the
    production machine even if 2.0 is installed and
    if 1.1 is not, then the application will not work.

11
The Core of .NET Framework
  • Application Services
  • Framework / Base Class Library
  • Provides the core functionality
  • ASP.NET, Web Services, ADO.NET, Windows Forms,
    IO, XML, etc.
  • Common Language Runtime
  • Garbage collection
  • Language integration
  • Multiple versioning support (no more DLL hell!)
  • Integrated security

12
.NET Framework Stack
C
C
VB
Perl
J

Common Language Runtime
Operating System
13
TYPES OF MS.NET APPLICATION
  • Console Based Applications (e.g. Compiler)
  • Windows Application (WinForms)
  • Windows Services
  • ASP.NET Web Applications
  • ASP.NET Web Services
  • Remoting Application.
  • Mobile / Smart Device Applications

14
Base Class Libraries (BCL)orFramework Class
Libraries (FCL)
15
Base Class Library
  • The .NET base class library is a collection of
    object-oriented types and interfaces that provide
    object models and services for many of the
    complex programming tasks we routinely face
    during application development

16
Base Class Library Adv
  • Language Independent.
  • Completely Object Oriented.
  • Most of the types presented by the .NET base
    class library are fully extensible, allowing you
    to build types that incorporate your own
    functionality
  • Packaged with .NET Framework in the form of DLL
    files.
  • Well optimized for performance

17
Base Class Library includes
  • Data types, conversions, formatting
  • Collections ArrayList, Hashtable, etc.
  • Globalization Cultures, sorting, etc.
  • I/O Binary and text streams, files, etc.
  • Networking HTTP, TCP/IP sockets, etc.
  • Reflection Metadata and IL emit
  • Security Permissions, cryptography
  • Text Encodings, regular expressions

18
What is Namespace?
  • A namespace is a logical collection of classes
    and other types with unique name.
  • The structure of the namespace is like a tree
    where all the related classes are like leaves
  • All BCL begin with the namespace System.

19
Base Class Library Namespaces
System
Security
Collections
ServiceProcess
Configuration
Text
Diagnostics
Threading
Globalization
IO
Runtime
InteropServices
Net
Remoting
Reflection
Serialization
Resources
20
MSIL and PE
21
.NET Languages
  • Languages provided by Microsoft
  • C, C, J, VB.NET, JScript
  • Third-parties languages
  • Perl, Python, Pascal, APL, COBOL, Eiffel,
    Haskell, ML, Oberon, Scheme, Smalltalk
  • Advanced multi-language features
  • Cross-language inheritance and exceptions
    handling
  • Object system is built in, not bolted on
  • No additional rules or API to learn

22
Code Compilation and Execution
Compilation
Also called Assembly (.EXE or .DLL file)
Before installation or the first time each method
is called
Execution
23
MSIL
  • It stands for Microsoft Intermediate Language.
  • MSIL instructions are platform independent
    instructions.
  • MSIL is an intermediate instruction set which is
    independent of processor and hardware.

24
Example of MSIL Code
  • .assembly MyAssembly
  • .class MyApp
  • .method static void Main()
  • .entrypoint
  • ldstr Hello, IL!"
  • call void System.ConsoleWriteLine("Hello")
  • ret

25
PE Portable Executable
  • Is a Microsoft Win32 compatible format file for
    .Net applications which contains the MSIL code
    and Metadata in binary form.
  • It has the extension .exe or .dll.
  • PE is based on all Win32 platforms compatible
    COFF (Common Object File Format) specification.

26
Compiler Assembler
Language Source Code
Portable Executable (MSIL - Binary Format)
Language Compiler
ILASM.EXE
Reverse Engineering
ILDASM.EXE
MSIL (Text Format)
27
COMMONLANGUAGE RUNTIME(CLR)
28
What is the Difference between
  • Street DOG
  • and
  • Pet DOG?

29
Managed Code
  • Code that targets the CLR is referred to as
    managed code
  • All managed code has the features of the CLR
  • Object-oriented
  • Type-safe
  • Cross-language integration
  • Cross language exception handling
  • Managed code is represented in special
    Intermediate Language (IL)

30
CLR Advantages
  • Vastly simplified development.
  • Seamless integration of the code written in
    various languages.
  • Evidence-based security with code identity.
  • Assembly-based deployment that eliminates DLL
    Hell.
  • Side-by-side versioning of reusable components.
  • Code reuse through implementation inheritance.
  • Automatic object lifetime management.
  • Self describing objects.

31
Components in CLR
  • Common Type System (CTS)
  • Automatic Memory Management
  • JIT Compiler
  • Garbage Collector
  • Security Manager
  • Class Loader

32
CTS and CLS
  • The common Type System defines how types are
    declared, used, and managed in the runtime, and
    is also an important part of the runtime's
    support for cross-language integration.
  • Common Language Specification is an agreement
    among language designers and class library
    designers to use a common subset of basic
    language feature that all language have to follow.

33
Automatic Memory Management
  • The CLR manages memory for managed code
  • All allocations of objects and buffers made from
    a Managed Heap
  • Unused objects and buffers are cleaned up
    automatically through Garbage Collection
  • Some of the worst bugs in software development
    are not possible with managed code
  • Memory Leakages
  • Dangling Pointers
  • Reading of uninitialized variables
  • Pointerless environment

34
JIT Compiler
  • CLR compiles IL in just-in-time (JIT) manner
    each function is compiled just before execution.
    Also the JIT code stays in memory for subsequent
    calls
  • NGen.EXE (Native Generator) is used for compiling
    all the MSIL code in PE file into Native code.
    This is done before the code is executed or
    during the deployment of PE on target machine.
    This way even the first time execution of code is
    fast as it doesnt need any more runtime
    compilation

35
.NET Framework on Linux
  • Mono Project
  • Open Source C compiler, CLR and Framework Class
    Library
  • Runs on various platforms and hardware
  • Linux, Unix, FreeBSD, Windows JIT-compiler for
    x86
  • s390, SPARC, PowerPC interpreter for these
    hardware architectures
  • Supports also
  • ADO.NET and XML
  • Windows Forms (not fully)
  • ASP.NET
  • Web Services

36
By.RAMESH.PAGILLA
  • Thank You All
