Title: New Technologies for Understanding the Relationship between Health and Place
1New Technologies for Understanding the
Relationship between Health and Place
- Lecture 1
- Introduction and Overview
- GIS and RS in Public HealthEdmund Seto,
Ph.D.School of Public HealthUniversity of
California, Berkeley
2The Study of Health Place
- Spatial epidemiology
- Medical geography
- Geographic pathology
- Medical ecology
- Geographical epidemiology
- Geomedicine
3A Historical Perspective
Public Health professionals have long recognized
the importance of place in health.
4- A more modern, structured view of how place
influences health is provided in Meades Medical
Geography text
Health
5The Three Vertices
- Population
- Susceptibility age, race, and genetics
- Habitat
- Natural climate, vegetation, geology, hydrology
- Built buildings and patterns of settlement
- Behavior
- Exposure, culture, technology how we live and
interact with each other and the environment
affects our health
6Epidemiology
- From Lasts Dictionary of Epidemiology
- Epidemiology is defined as the study of the
distribution and determinants of health-related
states or events in specified populations. - It follows then, that a Spatial Epidemiologist
would be interested in the spatial distribution
of health events, and the spatial relationship of
associated health determinants.
7A picture is worth 10,000 words
- Maps are the most fundamental tool for describing
the spatial distribution of data.
8The earliest map?
6200 BC Ankara, Turkey excavation of Çatalhöyük
site in Anatolia
9(No Transcript)
10History of Disease Maps
- The 1700s were the golden age of mapping, and
graphs in general. - Map in 1798 of cases of yellow fever in New York
by Valentine Seaman. - Maps documented the spread of cholera from India
to Europe in the early 1800s. - Famous John Snow Cholera map of 1855.
11(No Transcript)
12(No Transcript)
13- Spatial epidemiology has only relatively recently
become popular due to advances in information
technology - Availablity of spatial data (both health and
non-health data) - Desktop computing power
14The Introduction of GIS
- GIS term first used in the 1960s
- Federal Geographic Data Committee (FGDC)
definition A Geographical Information System is
a computer system for the input, storage,
maintenance, management, retrieval, analysis,
synthesis, and output of geographic or
location-based information.
15(No Transcript)
16John Snow 1855 Cholera Outbreak of London
Start
17GIS Pros and Cons
- The availability of GIS has greatly simplified
the ability to create maps and perform
exploratory spatial data analysis. - Perhaps too simple, though.
- Need to critically review the quality of data
that goes into mapping and the methods used in
modeling spatial processes - Evaluate the analyses for potential confounders
18GIScience
Spatial Data
Spatial Analysis
Information
GIS Geographic Information Sciences
19How to lie with maps
- Monmonier writes, "Not only is it easy to lie
with maps, it's essential...." The cartographer's
paradox is that "to avoid hiding critical
information in a fog of detail, the map must
offer a selective, incomplete view of reality."
20Thematic Maps
- Thematic (or choropleth) maps are maps of polygon
data, for instance county data that vary in
shading or color according to a quantity
associated with each county. - Thematic or choropleth maps are a model of
reality. We model the data by creating legends
that tell a particular story.
21Choropleth Maps
Natural break
The story we tell depends upon how we choose to
create the legend
Equal ranges
Equal counts
22Choosing map data
- If we map number of cases instead of rates
Is the disease risk in A really similar to
B? Misleading because the underlying population
may be much greater in A.
A
B
23(No Transcript)
24Modifiable Area Unit Problem
- The scale at which we perform spatial analyses
can influence the results. - The larger the unit of aggregation the more
likely attributes will be correlated. - ex. Analysis at the census block level versus the
census tract level. - Also by aggregating into different groups you can
get different results
25Small population problems
- Rates based on small populations and areas and
for rare diseases in particular may be
unreliable. - Example variance of the SMR is proportional to
(exp deaths)-1 - Possible solutions
- Present the data anyway, but with caveats.
- Use smoothing procedures such as Bayesian
Smoothing, and document the smoothing procedure
used. - Accumulate data over years and area (but MAUP).
26Breast Cancer Incidence forCape Cod 1982-94 from
the Silent Springs Institutes work
27(No Transcript)
28Ecological Fallacy
- Also known as Aggregation bias, or Cross-level
bias. - Making inferences from data collected at one
scale to individuals or communities aggregated at
other scales. - Example the hung jury
- vs Atomistic Fallacy
29Some Examples
Things to think about
Spatial Data
Spatial Analysis
Information
Whered the data come from?
How was the map produced?
To whom is the information useful? and How is the
information being communicated?
30Global Distribution of Malaria
31Snail Density, risk factor schistosomiasis
within a Chinese village
32(No Transcript)
33Drinking Water risks
34Pesticide Risks
35(No Transcript)
36(No Transcript)
37THE OCTOBER 17, 1989 LOMA PRIETA
EARTHQUAKEOCTOBER 1989 Introduction At 504
P.M., Tuesday, October 17, 1989, as over 62,000
fans filled Candlestick Park for the third game
of the World Series and the San Francisco Bay
Area commute moved into its heaviest flow, a
Richter magnitude 7.1 earthquake struck. It was
an emergency planner's worst-case scenario. The
20-second earthquake was centered about 60 miles
south of San Francisco, and was felt as far away
as San Diego and western Nevada. Scientists had
predicted an earthquake would hit on this section
of the San Andreas Fault and considered it one of
the Bay Area's most dangerous stretches of the
fault.
38(No Transcript)
39(No Transcript)
40(No Transcript)
41East Bay Hills 1991 Fire
42(No Transcript)
43California Flood Hazards
44Toxics Release Inventory
The TRI is a publicly available EPA database that
contains information on toxic chemical releases
and other waste management activities reported
annually by certain covered industry groups as
well as federal facilities. This inventory was
established under the Emergency Planning and
Community Right-to-Know Act of 1986 (EPCRA) and
expanded by the Pollution Prevention Act of 1990.
45(No Transcript)
46(No Transcript)
47(No Transcript)
48(No Transcript)
