Title: NASA Research and Education Network NREN Update


1
NASA Research and Education Network (NREN) Update
  • Pacific Rim Network Meeting
  • February 2002
  • Kevin Jones

2
Agenda
  • The New NREN
  • Effects of the Transition
  • NREN/NPN Relationship
  • Network Architecture
  • POCs

3
The New NREN
  • Same name, different network
  • Transitioned from Sprint to Qwest
  • ARC and GSFC upgraded from OC-3 to OC-12
  • NGIX-E peering at OC-12
  • New Sites NASA HQ MSFC
  • 3 hub design Sunnyvale, Chicago and Washington
    DC

GRC
NGIX-CHI
CHI
NGIX-East
NGIX-West
GSFC
QWEST
ARC
DC
SNV
HQ
JPL
MSFC
4
Effects of the Transition
  • In August 2001, we notified people that our
    Sprint circuits would be going away on or after
    September 1, 2001
  • All of them were officially disconnected mid
    January 2002
  • NREN peering in Chicago will be down for about 2
    months while we are waiting for our new Qwest
    circuits
  • Glenn Research Center (GRC) will experience a
    similar disruption in service
  • Langley Research Center (LRC) connectivity is
    postponed indefinitely due to funding constraints

5
NREN Multicast Architecture before the Transition
AboveNet Global Crossing IDT
Qwest
ATT Global Crossing Level3
Sprint Sprint-ICM Qwest
Teleglobe Verio
Abilene CAnet II
Merit NCSA
NORDUnet STARTAP vBNS
Abilene DREN ESnet
GRC
CHI
ARC
GSFC
2
1
LRC
NREN PIM-SM
Abilene DREN
3
4
JPL
UUnet
NISN
1 - Ames MIX 2 - NGIX-West 3 - MAE-West 4 -
FIX-West
6
Current NREN Multicast Architecture
ATT Global Crossing Level3
Sprint Sprint-ICM Qwest
Teleglobe Verio
Abilene DREN ESnet
ARC
GSFC
2
1
HQ
NREN PIM-SM
Abilene DREN
3
4
JPL
UUnet
NISN
1 - Ames MIX 2 - NGIX-West 3 - MAE-West 4 -
FIX-West
7
NREN/NPN Relationship
  • Advanced Applications
  • Advanced Technologies
  • Enterprise Future Missions Goals

Current Enterprise Requirements
NREN
NISN Operational
NPN
  • Experimental
  • Proof of concept
  • Technology demonstrations
  • Application research and demonstrations
  • Stable for end-to-end
  • Application Prototyping
  • Cost Analysis
  • Scalability
  • Security
  • Standards
  • 24x7 Operational Stability
  • Budget
  • Configuration Control
  • Operations

8
NREN / NPN Relationship
  • NREN Description
  • The NASA Research and Education Network (NREN) is
    part of the Computing, Information and
    Communications Technologies (CICT) Program
    managed at NASA Ames Research Center
  • Infuses emerging network technologies into NASA
    mission-critical applications
  • Coordinate technology transfer to NPN
  • NREN serves several purposes
  • Experiment with network hardware and software
    that provides leading edge capabilities
  • Prototype applications enabling NASA missions
    that cannot be supported by todays commodity
    Internet
  • Demonstrate emerging technologies and
    applications

9
NREN / NPN Relationship
  • NPN Description
  • The NASA Prototype Network (NPN) is a network
    being developed as part of the NASA Integrated
    Services Network (NISN)
  • NPN will serve as a bridge between the NASA
    Research and Education Network (NREN) and NASAs
    operational network services
  • Sufficiently stable infrastructure to
    appropriately transition leading edge NASA
    applications to NISN operations
  • NPN serves several purposes
  • Foster the transition of application and
    protocols from NREN to the NASA operational
    network
  • Investigate operational impacts such as cost,
    technology, support and performance
  • Drive the NASA operational network configuration

10
NREN / NPN Relationship
  • Protocol and technology research shall relate to
    NASA communications technical issues and be
    geared to improve operational network services
  • NREN and NPN serve as the NASA WAN testbed and
    thus will not compete with NASA operational
    network services

11
NREN/NPN Network Architecture
GRC
NGIX-Chi
NGIX-East
ARC/NGIX-West
GSFC
NASA WAN Testbed
HQ
JPL
MSFC
NPN Sites OC-3 ATM Future sites
(dashed lines) NREN Sites OC-12ATM
Hybrid Ground Station (35 Mbps)
12
Fully Meshed Router PVC Layout
NPN Router Mesh
NREN Router Mesh
ARC
HQ
JPL
GSFC
MSFC
13
NREN-NPN Initial Configuration
  • Point-to-point PVCs
  • Fully meshed
  • 8 NREN routers 5 NPN routers
  • Shared backbone PVPs between regional core hubs
  • East region core hub (Washington DC)
  • HQ, GSFC, NGIX-E
  • North region core hub (Chicago, IL)
  • NGIX-Chi, GRC
  • West region core hub (Sunnyvale, CA)
  • ARC, JPL, NGIX-W
  • Direct PVPs to MSFC from east and west core hubs

14
NREN-NPN Initial Configuration
  • Traffic parameters between 3 regional hubs
  • OC-12 between east and west hubs
  • OC-3 to and from the north hub
  • VBRnrt
  • SCR 150 Mb/s, PCR 600 Mb/s
  • Traffic contract parameters to MSFC from core
    hubs
  • OC-3
  • VBRnrt
  • SCR 37.5 Mb/s, PCR 150 Mb/s

15
Peering Plans
  • NGIX West Status (OC-12)
  • Currently peering with Abilene, DREN, ESnet,
    NISN
  • USGS Planned
  • NGIX East Status (OC-12)
  • Currently sharing a GSFC connection, soon to be
    transitioned to a NREN only connection
  • No private peering established
  • Planned Peering Abilene, DREN, NISN, USGS

16
Peering Plans
  • NGIX Chicago Status (OC-3)
  • Plans to connect to StarLIGHT in April 2002
  • I-WIRE Gigabit Ethernet circuit from Qwest Hub
    (455 North CityFront Plaza) to StarLIGHT (710
    North Lakeshore Drive)
  • Source for international peering
  • Planned Peering TRANSPAC, Abilene, NORDUNET,
    SURFnet, AMPATH, Argonne, Northwestern University

17
Key Technologies
  • ATM Network
  • IP Native Multicast
  • PIM Sparse Mode
  • MBGP
  • MSDP
  • QoS
  • DiffServ
  • IPv6 still in planning stage

18
International Science Collaborations
  • Past Collaborations
  • Trans-Pacific Demonstrations
  • Visible Human
  • Remote Astronomy
  • GOIN99
  • Planned Collaborations
  • APAN
  • QoS and multicast engineering
  • NASA and NASDA Applications
  • International Spacecraft Checkout (ESDIS)

19
Passive Monitoring PCMon
Traffic flow bandwidth
  • Development and installation of Quality of
    Service and multicast data collection tool
    (PCMon) that
  • Enables detailed analysis of individual traffic
    flows
  • Enables determination of the effectiveness of
    assigning preferential treatment to specified
    traffic flows

20
Passive Monitoring PCMon
  • The measurement PC passively captures signal from
    optical splitter
  • Summarized data is sent out-of-band to the
    management and collection platform
  • Supports OC3 ATM upgraded to OC12 and POS using
    Endace/University of Waikato DAG cards

Router / Switch
WAN Switch
Splitter
NREN
Measurement Meter (Linux PC)
Out-of-Band
Traffic source
21
Whats Next?
  • Complete performance testing
  • Network Management
  • Exploring Qwest Total Care
  • Connect more centers
  • GRC, MSFC
  • Re-establish connectivity in Chicago
  • QoS Testing
  • Migrating from ATM to POS once it is cost
    effective

22
NREN / NPN POCs
NPN Administrative Lead Bessie
Whitaker/MSFC 256.544.4812 bessie.whitaker_at_msfc.
nasa.gov NREN Administrative Lead Ken
Freeman/ARC 650.604.1263 kfreeman_at_arc.nasa.gov
  • NPN Engineering Lead
  • Ken White/MSFC
  • 256.544.1882
  • ken.white_at_msfc.nasa.gov
  • NREN Engineering Lead
  • Kevin Jones/ARC
  • 650.604.2006
  • kjones_at_arc.nasa.gov

23
For more Information
  • NREN Website
  • http//www.nren.nasa.gov
  • NREN Network Management Alias
  • nren-ops_at_nren.nasa.gov

24
Hardware Specifications
NREN
25
Cisco 2511
  • Ethernet - 1 Port
  • High Speed - Serial Interface - 2 Ports
  • High Speed - Async Serial - 16 Ports
  • Aux Port - 1 Port
  • Dimensions (H x W x D)
  • 1.75 x 17.5 x 10.56" / (4.44 x 44.45 x 26.82 cm)
  • one rack unit

26
Cisco 7500s
  • Ports
  • Fast Ethernet
  • Ethernet
  • OC-3 ATM
  • OC-12 ATM
  • Gigabit Ethernet
  • Dimensions (H x W x D)
  • 7507
  • 19.3 x 17.5 x 25.1 in. (48.9 x 44.67 x 63.8 cm)
  • 12 Rack Units
  • 7505
  • 10.5 x 17.5 x 17.0 in. (26.67 x 44.45 x 43.18
     cm)
  • 7 Rack Units

7505
7507
27
Cisco Catalyst 8540
  • 40-Gbps shared memory, nonblocking fabric
  • Ports
  • OC-12 ATM
  • OC-3 ATM
  • Dimensions (H x W x D)
  • 25.25 x 17.3 x 18.25 in. (64.14 x 43.9 x 46.36
    cm)
  • 15 Rack Units

28
Cisco Catalyst 8510
  • Dimensions (H x W x D)
  • 10.5 x 17.2 x 18.14 in. (26.7 x 43.7 x 46.1 cm)
  • 6 Rack Units

29
NetReach NPS-115
  • Remote 115 VAC Power Control
  • Eight (8) Individual Outlets
  • Integrated 10-BaseT Interface
  • RS-232 Modem and Console Ports
  • Dimensions (H x W x D)
  • 2.8"H x 17"W x 6.8"D (W19" w/ Rack Mounts)
  • Two Rack Units

30
NetReach RPC-48
  • High Amp -48V DC Power Reboot
  • Power Buss Input 0 Volts, -48V DC 10
  • Interface 10 2-screw terminal block for main
    input and each of the 1 or 2 switched outputs.
  • Switched Outlets Up to 2 separate circuits,
    each rated at 40 Amps. Total switched power not
    to exceed 40 amps _at_-48V DC
  • Dimensions (H x W x D)
  • 3.5"H x 19"W x 7.5"D (W19" w/ Rack Mounts)
  • Two Rack Units
