North Carolina Geodetic Survey

1
North Carolina Geodetic Survey

• National Height Modernization System in
• North Carolina

2
National Height Modernization System

• National Height Modernization Study (June
  1998)
• Performed pilot project in Asheville area
• Report to Congress

3
Benefits to North Carolina

• Geodetic control network
• Global Positioning System (GPS) base station
  network
• North Carolina Floodplain Mapping Program
• Highway construction
• North Carolina Land Records Management Program
• Environment and natural resources programs
• Emergency management

4
NHMS Activities in North Carolina
5
North Carolina HARN
6
North Carolina HARN
7
(No Transcript)
8
Operational Proposed GPS Base Stations (CORS)
9
NHMS Activities In North Carolina
10
NHMS Project Areas
11
Effects of Hurricane Floyd on North Carolina

• 51 deaths
• 3.5 billion in damages to homes, businesses,
  roads, and infrastructure
• 31,000 jobs lost

Goldsboro, NC
12
North Carolina Floodplain Mapping Program
13
Components of a DFIRM

DFIRM
14
LIDAR Laser Sensor

• First returns provide Digital Surface Models
  (DSMs)
• Roof tops
• Tree tops

• Last returns can provide Digital Elevation
  Models (DEMs) of the bare earth if fully
  processed to remove buildings and vegetation that
  were not penetrated by the LIDAR pulses

15
Multiple Returns
16
(No Transcript)
17
(No Transcript)
18
Bare-Earth Post-Processing
19
First Return
Courtesy of the Joint Precision Strike
Demonstration Project Office (JPSD-PO)
20
LIDAR Digital Elevation Model
21
LIDAR Digital Elevation Model
22
TIN
23
Intensity Return
Courtesy of the Joint Precision Strike
Demonstration Project Office (JPSD-PO)
24
(No Transcript)
25
(No Transcript)
26
Terrain Data Download
27
Bare Earth Terrain Data
28
Objective of the QC Surveys

• Establish quality control (QC) checkpoints to
  evaluate the vertical accuracy of the elevation
  data
• 20-cm vertical RMSE for coastal counties
• 25-cm vertical RMSE for inland counties
• Require 120 checkpoints per county
• 20 checkpoints required for the following four
  classes bare earth and low grass, weeds/crops,
  scrub, and built-up
• 40 checkpoints required for the forest class

29
Bare-Earth Low Grass Land Class
30
Forest Land Class
31
QC Assessment Report Halifax County, Tar-Pamlico
Portion

• RMSE summary using
• 100 of the checkpoints
• 95 of the checkpoints
• Checkpoints categorized by land cover type

The LIDAR data for Halifax County met the
specification as per the RMSE criteria of 25 cm.
All figures represented the data with the 95
data set. The data was of good quality with the
smaller data limited to the Tar-Pamlico basin
only. The land class type of built-up was
slightly high, but was well within specifications.
32
Providing Access With NC OneMap
33
(No Transcript)
34
Jones County- Effective Mapping
35
New Panels - Statewide
36
The North Carolina Flood Insurance Rate Map (FIRM)
37
Flood Insurance Rate Map

• 1 annual chance floodplain-cyan dots (FEMA
  Standard)
• Floodway White Hatch (FEMA Standard)
• 0.2 annual chance floodplain-black dots
• Numbered cross sections

38
Jones County- 2003 Mapping
Blue 2003 Zone AE
BFE
Cross Section
39
The Boundaries
2002 Detail Mapping vs. Effective Approximate
Mapping
40
2003 Mapping vs FEMA Q3
Orange Effective Zone A
Green 2003 Zone AE
41
2002 Mapping
42
Effective vs 2002 Mapping
2002 Limited Detail Boundary (blue)
Old Zone A Boundary (red)
43
Features of New Maps
44
Vertical Datum Information

• Explains vertical offset from NGVD 29 to NAVD 88
• County Average Vertical Datum Offset Table
  displays datum offset by county

45
www.ncfloodmaps.com
46
(No Transcript)
47
(No Transcript)
48
Collection of High Water Marks (HWM)
NHMS supported these activities in NC
49
North Carolina FMP Imagery/LIDAR Quality Control
50
Monitoring Subsidence
51
Network RTK Positioning
52
Network RTK Expansion
53
Data Flow in the Network
Raw Data
CMR / RTCM
LAN
NMEA Position
54
(No Transcript)
55
North CarolinaFlood Warning System
Stream Gage
Rain Gage
56
Tar River at Tarboro, bank full 22.4 ft.
elevation (12 ft gage ht.)
57
Tar River at Tarboro 37 ft. elevation (27.0
gage ht.) Hurricane Fran
58
Tar River at Tarboro 44 ft. elevation (34.0
gage ht.)
59
Tar River at Tarboro 52 ft. elevation (41.5
gage ht.) Hurricane Floyd
60
Tidal Station Surveys
NC NHMS Project
GPS and traditional leveling will be use to
connect tidal stations to the vertical control
network
Tidal station
61
Education Outreach
Height Modernization Workshops is a traveling
workshop designed for government agencies,
professional surveyors, academic departments,
school groups, and other interested parties in
North Carolina.

• Workshops are tailored to each groups respective
  needs
• PDH credit

62
(No Transcript)
63
Questions?
