Lecture 12: Waves versus particles

1
Lecture 12 Waves versus particles
2
Corpuscular Theory of Light (1704)

• Isaac Newton proposed that light consists of a
  stream of small particles, because it
• travels in straight lines at great speeds
• is reflected from mirrors in a predictable way

Newton observed that the reflection of light from
a mirror resembles the rebound of a steel ball
from a steel plate
3
Wave Theory of Light (1802)

• Thomas Young showed that light is a wave, because
  it
• undergoes diffraction and interference (Youngs
  double-slit experiment)

Thomas Young (1773-1829)
4
Particles

• Position x
• Mass m
• Momentum p mv

5
Waves

• Wavelength l
• Amplitude A
• Frequency f
• number of cycles per second (Hertz)

f c / l
6
Waves versus Particles

• A particle is localised in space, and has
  discrete physical properties such as mass
• A wave is inherently spread out over many
  wave-lengths in space, and could have amplitudes
  in a continuous range
• Waves superpose and pass through each other,
  while particles collide and bounce off each other

7
Diffraction
8
Interference
applet
9
Interference Fringes on a Screen
applet
10
Blackbody Radiation

• A blackbody is an object which totally absorbs
  all radiation that falls on it
• Any hot body (blackbodies included) radiates
  light over the whole spectrum of frequencies
• The spectrum depends on both frequency and
  temperature

11
Spectrum of Blackbody Radiation
Plot of intensity of the blackbody radiation
versus wavelength for various temperatures
applet
12
Ultraviolet Catastrophe
Classical theory predicts a graph that deviates
from experimental data, especially at short
wavelengths
13
Plancks Quantum Postulate (1900)

• A blackbody can only emit radiation indiscrete
  packets or quanta, i.e., in multiples of the
  minimum energy E
  hfwhere h is a constant and f is the frequency
  of the radiation

Max Planck (1858-1947) is generally regarded as
the father of quantum theory
14
Plancks Quantum Postulate (contd)

• Thus, it is harder for a blackbody to emit
  radiation at short wavelengths (high frequency)

• since higher energies are required to produce
  each quanta of radiation, by Plancks formula
• This explains the origin of the ultraviolet
  catastrophe

15
Plancks Constant

• Experimentally determined to be
  h 6.63 x 10-34 Joule sec(Joule kg m2 /
  sec2)
• A new constant of nature, which turns out to be
  of fundamental importance in the new quantum
  theory

16
Photoelectric Effect
When blue light is shone on the emitter plate,a
current flows in the circuit
17
Photoelectric Effect (contd)
But for red light, no current flows in the circuit
video clip
18
Experimental Observations

• Only light with a frequency greater than a
  certain threshold will produce a current
• Current begins almost instantaneously, even for
  light of very low intensity
• Current is proportional to the intensity of the
  incident light

19
Problems with Wave Theory of Light

• The wave theory of light is unable to explain
  these observations
• For waves, energy depends on amplitude and not
  frequency
• This implies that a current should be produced
  when say, high-intensity red light is used

20
Einsteins Explanation (1905)

• Light consists of particles, now known as
  photons
• A photon hitting the emitter plate will eject an
  electronif it has enough energy
• Each photon has energy E
  hf(same as Plancks formula)

Albert Einstein won a Nobel Prize for his work
on the photoelectric effect and not his theory
of relativity!
21
Everyday Evidence for Photons

• Red light is used in photographic darkrooms
  because it is not energetic enough to break the
  halogen-silver bond in black and white films
• Ultraviolet light causes sunburn but visible
  light does not because UV photons are more
  energetic
• Our eyes detect colour because photons of
  different energies trigger different chemical
  reactions in retina cells

22
Double-Slit Experimentto illustrate wave nature
of light
23
Double-Slit Experiment with a machine gun!
24
Double-Slit Experiment with electron gun
Electrons behave like waves!
25
Interference Pattern of Electrons

• Determines the probability of an electron
  arriving at acertain spot on the screen
• After many electrons, resembles the
  inter-ference pattern of light

applet
Electron interference pattern after (a) 8
electrons, (b) 270 electrons, (c) 2000electrons,
and (d) 6000 electrons
26
Double-Slit Experiment with electron gun and
detector
Trying to detect which slit the electrons pass
through causes them to behave like particles
27
Summary

• Waves and particles exhibit very different
  behaviour
• Yet, light sometimes behaves like particles
• spectrum of blackbody radiation
• photoelectric effect
• And electrons sometimes behave like waves
• interference pattern of electrons
• In quantum theory, the distinction between waves
  and particles is blurred
