A Framework for Automated Web Application Security Evaluation

1
A Framework for Automated Web Application
Security Evaluation

• By
• Razieh Rezaei Saleh

2
Security Evaluation

• Security Evaluation The examination of a system
  to determine its degree of compliance with a
  stated security model, security standard, or
  specification.
• The evaluation may be conducted
• (a) by analyzing the detailed design, especially
  of the software, often using verification and
  validation,
• (b) by observing the functional behavior of the
  system, or
• (c) by attempting to penetrate the system using
  techniques available to an attacker.

3
Security Testing

• The Process to determine that an IS (Information
  System) protects data and maintains functionality
  as intended.
• The six basic security concepts that need to be
  covered by security testing are
• Confidentiality
• Integrity
• Authentication
• Authorization
• Availability
• non-repudiation

4
Vulnerability

• the word vulnerability refers to a weakness in a
  system allowing an attacker to violate the
  security of the system or the data and
  applications it hosts.
• Vulnerabilities may result from bugs or design
  flaws in the system.
• A vulnerability can exist either only in theory,
  or could have a known exploit.

5
Security Tollgates in Software Development Life
Cycle (SDLC)
Product Requirements
Functional Design
Technical Design
Implementation
Testing
Beta
Security Tollgates
Security Requirements Document
Architectural Risk Analysis
Security Testing
Secure Coding
6
Security testing tools

• There is eight security tool categories
• source code analyzers,
• web application (black-box) scanners,
• database scanners,
• binary analysis tools,
• runtime analysis tools,
• configuration management tools,
• HTTP proxies,
• miscellaneous tools.

7
Types of Web Application Security Test

• There are two approaches for security test
• Manual approach
• Penetration test
• Code review
• Automated approach
• Vulnerability scanners
• Static analyzers

8
A Framework for Automated Web Application
Security Evaluation
9
Why Web Application?

• Because of globalization of web and being of
  internet as the major tool for international
  information exchange, security of web application
  is becoming more and more important.
• Web applications are very much vulnerable to DOS
  attacks or security and access compromise.

10
Why Web Application?
"70 of today's successful hacks involve Web
Application attacks "
SPI Dynamics
11
Why Automated?

• Automated testing tools are vital because of
  growth in web applications extension and
  complication.
• Manual penetration testing and automated scanning
  are used to find security vulnerabilities in Web
  applications.
• Each has inherent strengths and weaknesses.

12
Why Automated?

• Web application vulnerabilities categories
• Technical vulnerabilities
• cross-site scripting (XSS), injection faws and
  buffer overflows.
• Logical vulnerabilities
• Logical vulnerabilities are security weaknesses
  that can be exploited by circumventing the
  typical flow of an application.

13
Technical vs. Logical Vulnerabilities

• Logical Flaws
• Security vulnerabilities that arise with some
  contextual logic in application.
• Example
• Multi step procedure that can be bypassed with
  direct invocation

Technical vs. Logical Vulnerabilities at WhiteHat
14
Automated Tools

• Strength saving time and money
• Weakness false positive and false negative
• As automated Web application security testing
  tools have matured, enterprises have experienced
  fewer incidents of false positives and false
  negatives.

15
Why Black box?

• Efficient when used on Larger systems
• The environment the program is running is also
  tested.
• The invested effort can be used multiple times.
  (regression testing)
• Tests will be done from a hacker's point of view.

• There is no need of having detailed functional
  knowledge of system to the tester.
• As the tester and developer are independent of
  each other, test is balanced and unprejudiced
• Tester can be non-technical.

16
Why Leveling?

• Each application may need different level of
  security.
• Leveling helps better comparison of system.

17
Scanning web application

• Two categories of automated security tool
• Static
• Analyzes the source code for security defects
• Known as white box security test
• Needs source code
• Dynamic
• Elicits vulnerabilities by sending malicious
  requests, and investigating replies
• When source code is not available
• Tester looks at the application from the
  attackers perspective
• Analyzes only applications deployed in test or
  production environments

18
Scanning web application

• Uses vulnerability scanners to find security
  vulnerabilities.
• In an automated security test, there are three
  fundamental steps
• Discovering new URLs and forms by crawling
• Creating test script with crafted data
• Sending malicious request to the web application
• Analyzing response to detecting vulnerabilities

19
Most Powerful Scanners

• Acunetix
• Nmap
• Nikto
• Burp Suit
• W3AF
• Web Scarab
• Web Inspect
• Wikto
• ..

20
Categorizing Found Vulnerabilities

• OWASP top ten vulnerabilities
• Cross Site Scripting (XSS)
• Injection Flaws
• Malicious File Execution
• Insecure Direct Object Reference
• Cross Site Request Forgery (CSRF)
• Information Leakage and Improper Error Handling
• Broken Authentication and Session Management
• Insecure Cryptographic Storage
• Insecure Communications
• Failure to Restrict URL Access

Open Web Application Security Project (OWASP)-
The ten most critical web application security
vulnerabilities,2007
21
Measuring Metrics

• Selected web application vulnerabilities from
  OWASP top ten for evaluation
• Cross Site Scripting (XSS)
• Injection Flaws
• Malicious File Execution
• Insecure Direct Object Reference
• Cross Site Request Forgery (CSRF)
• Information Leakage and Improper Error Handling
• Insecure Communications
• Failure to Restrict URL Access

22
Application Security Verification Standard

• The ASVS defines four level of verification that
  increase in both breadth and depth.
• The breadth is defined in each level by set of
  security requirements that must be addressed.
• The depth of verification is defined by the
  approach and level of rigor required in verifying
  each security requirement.
• Has a close resemblance to ISO-IEC 18045, but
  customized for web application.

OWASP- Application Security Verification Standard
(ASVS),2009
23
ASVS levels

• ASVS four level of verification
• Level 1 Automated Verification
• 1A Dynamic Scan
• 1B Source Code Scan
• Level 2 Manual Verification
• Level 3 Design Verification
• Level 4Internal Verification

24
Some requirement of level 1A

• Verify that all pages and resources require
  authentication except those specifically intended
  to be public.
• Verify that all password fields do not echo the
  users password when it is entered, and that
  password fields (or the forms that contain them)
  have autocomplete disabled.
• Verify that if a maximum number of authentication
  attempts is exceeded, the account is locked for a
  period of time long enough to deter brute force
  attacks.
• Verify that sessions are invalidated when the
  user logs out.
• Verify that sessions timeout after a specified
  period of inactivity.
• .

25
Weighting Metrics

• Not all metrics have the same importance to the
  security of application.
• Using CVSS score for weighting.
• Using OWASP risk assessment approach.

26
Common Vulnerability Scoring System (CVSS)

• CVSS is composed of three metric groups

Represents the characteristics of a vulnerability
that change over time but not among user
environments.
Represents the intrinsic and fundamental
characteristics of a vulnerability that are
constant over time and user environments.
Represents the characteristics of a vulnerability
that are relevant and unique to a particular
users environment.
27
Common Vulnerability Scoring System (CVSS)

• When the base metrics are assigned values, the
  base equation calculates a score ranging from 0
  to 10

28
Calculated weights

• The result of calculating weight for each
  selected vulnerability is as below
• Cross Site Scripting (XSS) 4.3
• Injection Flaws 7.1
• Malicious File Execution 7.1
• Insecure Direct Object Reference 6.8
• Cross Site Request Forgery (CSRF) 6.8
• Information Leakage and Improper Error Handling
  4.1
• Insecure Communications 6.9
• Failure to Restrict URL Access not assigned yet.

29
Using ASVS
30
Using ASVS
31
Using ASVS
32
Identifying Applications Security Level

• The security level of application can be
  specified according to the results of calculated
  metrics.
• This level of security is with assurance of level
  1A in ASVS.

33
Thanks for your attention.
