WESTERN ARCTIC SHELFBASIN INTERACTIONS SBI

1
WESTERN ARCTIC SHELF-BASIN INTERACTIONS
(SBI) PHASE 2 PI MEETING FIELD PROJECT
OVERVIEW Jacqueline M. Grebmeier SBI Project
Office, University of Tennessee Knoxville,
Tennessee, 37932, USA USCGC
Healy Seattle, Washington January 29-30,
2000 http//sbi.utk.edu
2
SBI Goal and Focus

• Overall hypothesis climate change will
  significantly and preferentially impact the
  physical and biological linkages between arctic
  shelves and the adjacent ocean basins
• Focus area
• outer shelf, shelf break and upper slope, where
  key processes control water mass exchange and
  biogeochemical cycles
• greatest responses to climate change are
  expected
• US SBI focus is Chukchi and Beaufort seas and
  slopes

3
General schematic of SBI study area and research
topics
4
(No Transcript)
5
SBI PHASE II PROJECTS-PI/CO-PI'S (n42) AND
PROJECT TITLES (n14)

• Ashjian, Carin-WHOI, Gallager, Scott-WHOI, and
  Gallagher, Scott-LSU, Collaborative Research
  Shelf-Basin Exchange of Biogenic Material Between
  the Chukchi and Beaufort Seas
• Christensen, John, and Devol, Allan-UW,
  Collaborative Proposal Denitrification and
  Sediment Nutrient Dynamics in the Chukchi and
  Beaufort Seas summer 2002 and spring 2004
• Dirks, Richard-JOSS/UCAR, and Moore,
  James-JOSS/UCAR, Data Management Support for
  Western Arctic SBI Phase II
• Gradinger, Rolf-UAF and Eicken, Hajo-UAF,
  Physical-biological control of primary
  production in Beaufort and Chukchi Sea ice Its
  contribution to shelf-basin interactions in the
  western Arctic
• Grebmeier, Jackie-UTK, Cooper, Lee-UTK, Cota,
  Glenn-ODU, Dunton, Kenneth-UTX, Kirchman,
  Dave-UDL, Maslowski, Wieslaw-NPS, Moran,
  Bradley-URI, and Walsh, John J.-USF,
  Collaborative SBI Research Carbon Cycling in
  the Chukchi and Beaufort Seas-Field and Modeling
  Studies
• Hansell, Dennis-U Miami, and Bates,
  Nicholas-BBS, Collaborative Research Transport
  and Transformations of Carbon and Nitrogen in the
  Western Arctic Ocean A Contribution to the SBI
  Project
• Harvey, Roger-UMD, Macdonald, Robie-IOS, and
  Benner, Ronald-USC, Collaborative Research
  Biogeochemical Cycling of Particulate and
  Dissolved Organic Matter in the Arctic Ocean
  using Molecular Markers
• Kadko, David-U Miami, Investigation of the Rate
  of Shelf-Basin Interaction in the Western Arctic
  Using Radium Isotopes SBI Phase II
• Sherr, Evelyn-OSU, Sherr, Barry-OSU, Campbell,
  Robert-URI, and Ashjian, Carin-WHOI,
  Collaborative Research Mesozooplankton-Microbial
  Food Web Interactions in Western Arctic Shelf
  and Basin Regions
• Smith, Sharon-U Miami, and Fell, Jack-U Miami,
  Shelf-Basin Exchange of Large-Bodied Zooplankton
  Copepods in the Chukchi and Beaufort Seas
  summer 02, spring and summer 2004

6
SBI Field Program

• 2002 and 2004
• USCGC HEALY
• 6 May-15 June (Nome-Nome, AK)
• 17 July-26 August (Nome-Nome, AK)
• USCGC POLAR STAR
• July (Dutch Harbor-return, AK)
• RV ALPHA HELIX
• 23-27 June (Dutch Harbor-Nome, AK)
• 2003
• USCGC/TBD
• 1-30 July (Nome-Nome, AK)
• RV ALPHA HELIX
• September

USCGC HEALY
USCGC POLAR STARSEA
USCGC POLAR STAR
RVALPHA HELIX
RV ALPHA HELIX
7
SBI Phase II-Field Program
8
SBI Service Field Measurements

• SERVICE FIELD MEASUREMENTS (Swift et al.)
• CTD-based temperature, salinity and dissolved
  oxygen measurements (Swift)
• Acoustic Doppler Current Profiler (ADCP) data
  (Padman, Münchow)
• In situ-fluorescence and transmissivity
• Photosynthetic active radiation (PAR)
  measurements
• Rosette for discrete water sampling
• Determination of inorganic nutrients (nitrate,
  nitrite, phosphate, dissolved silicon, ammonium)
  (Whitledge, Codispoti), chlorophyll-a (Whitledge
  Stockwell), salinity, and dissolved oxygen
  (Swift)
• Underway surface observations, including
  temperature, salinity and meteorological data
  (Swift et al.)

9
Service Program
CTD Rosette Swift et al. 4 casts with two
12-10L and two 12-30L bottle configurations
10

SBI Process Studies-Water Column (10 projects,
plus service measurements)

• RATE MEASUREMENTS FOR PROCESS CRUISES (details in
  SBI water column sampling spreadsheet in meeting
  folder)
• Primary production, nutrient uptake, biomass,
  pigments, optics (Cota)
• Stable oxygen isotopes (Cooper)
• POC/N, DOC/N, DIC (Hansell and Bates)
• Bacterial production, biomass, respiration
  (Kirchman)
• Microzooplankton biomass and grazing (Sherr and
  Sherr)
• Biomarkers (Harvey and Benner)
• Sediment metabolism (Grebmeier)
• Denitrification (Christensen/Devol)
• Radium isotopes (Kadko)

11
Active optical sensor Passive
optical sensor
Glenn Cota primary production, optics, satellite
12
On deck incubator for dilution assays
36 inches


Inflow buffer
52 inches
Lexan tube, 6 diameter x 22 long, holes
drilled in sides to allow water flow
Ashjian, Campbell, Sherr(s)-zooplankton
13
Deck incubators for zooplankton
studies
Seawater hoses out
Wooden base
Seawater hoses in
14
Clear hinged lexan top with hinges to keep water
in
12 inches high
Zooplankton component-deck incubator
15

SBI-Macro/Meso Zooplankton Field Studies (4
projects)

• Macro-zooplankton biomass and production
  (Ashjian and Campbell, Smith and Lane)
• Zooplankton abundance via sensors on CTD
  (Ashjian, Gallagher Benfield)
• C-13, N-15 stable isotope analyses of
  macro/meso-zooplankton (Dunton)

16
Ring Net

• Carin Ashjian/Bob Campbell (zooplankton)
• Our ring nets will be 1m in diameter and up to 6
  m long
• Used for
• Vertical tows (ship stationary)
• Oblique tows (ship moving)
• Used off the side of the ship

17
Bongo Nets

• Sharon Smith/Peter Lane (zooplankton)
• Deployed off the side
• Towed either vertically (ship stationary ice) or
  obliquely (ship moving no ice)

18
MOCNESS

• Deployed off stern using 0.68 conducting wire

MOCNESS being deployed
MOCNESS ready on deck
19

SBI Benthic Field Studies (5 projects

• Benthic macrofaunal biomass (Grebmeier)
• C-13, N-15 of benthic fauna (Dunton)
• Benthic metabolism (Grebmeier and Cooper)
• Denitrification (Christensen and Devol)
• Biomarkers, sediment DOC flux w/Grebmeier
  (Harvey and Benner)
• Sedimentation rates and mixing Th-234, Pb-210
  (Moran)

20
Van Veen (Grebmeier and Cooper)
21
HAPS Corer
HAPS Multicorer
22
Coring sectioning and Canning
23
Multi-corer, Soutar core, and off-ice
mini-lander (John Christensen and Al Devol)
24

SBI Off-ship Field Studies

• denitrification/sediment metabolism (Christensen
  and Devol)
• sea ice algal production and physical properties
  (Gradinger and Eicken)
• off-ship access needed for both projects
  deployment on ice at start of station via basket
  or helicopter operations, as necessary if by
  helicopter, possible coordination with USWFS
  objectives

25
Ice sampling ice algae and properties (Rolf
Gradinger and Hajo Eicken)
26
Marine Mammals and Seabird Surveys-USFWS/NMML

• Spring 2002 Marc Webber (USFWS)
• bird and marine mammal surveys from
• bridge (spring cruise only)
• coordinate/assist with Hajo Eickens
• ice observations
• opportunistically test images on helo
• missions when time, ice, walrus observed
• note spring helo ops limited marine mammal hunt
  issues
• Summer 2002 mooring cruise-possible NMML seals
  surveys

27

• Data Management
• JOSS (Joint Office for Science Support)
  responsible for both shipboard field catalog and
  land-based data management (Dirks Moore)
• Remote Sensing
• Need to provide regional and basin scale spatial
  and temporal coverage
• (needs Cota, Gradinger Eicken, Maslowski,
  Pickart, Weingartner et al.)

SBI Process Studies (relevant Healy cruise)
28
Other Core SBI Studies

• Time Series Moorings
• conductivity/salinity, temperature, ADCP
  (Weingartner, Aagaard Woodgate, Pickart)
• biochemical sensors nutrient, chlorophyll,
  transmissivity (pending)
• Modelling
• biophysical coupled modelling (Maslowski and
  Walsh)
• sea-ice modelling (Gradinger and Eicken)
• Winter sampling
• helicopter study (Christensen Melling)
• April 2003 US Navy ice camp

29
Why Would A Teacher Participate?

• Research takes the teacher and the classroom
  beyond the textbook science. Inquiry-based
  experiences that show science as a human
  endeavor, and the relevance of science to
  societal issues. Science will come alive in
  the classroom.

30
SBI port Nome, Alaska
31
SBI PIs arrive Nome May 4 (spring)/July 14
(summer) Healy arrives Nome/PIs board May 5
(spring)/July 15 (summer) Healy departs Nome May
6/7 (spring)/July 16/17 (summer) Healy returns
Nome June 15 (spring)/Aug. 26 (summer) PIs
depart ship June 15 (spring)/Aug. 26 (summer)

• cargo to Healy April 1-20
• lab set-up April 15-20
