Title: Eli%20Lilly:%20Leveraging%20SAP%20XI%20in%20Your%20Landscape:%20Costs,%20Benefits,%20Lessons%20Learned


1
Eli Lilly Leveraging SAP XI in Your Landscape
Costs, Benefits, Lessons Learned
  • Timothy S Yates tyates_at_dataxstream.com
  • Scott A Sanneman sanneman.s_at_lilly.com

2
Learning Points
  • This presentation will give you a solid starting
    point for determining / cost justifying an SAP XI
    Implementation.
  • This presentation will give you specific
    considerations that need to addressed up front in
    order to control scope creep and cost.
  • This presentation will give you specific
    technical lessons learned that can potentially
    impact implementation timeline, delivery quality
    and overall implementation cost.

3
Background On Eli Lilly XI Implementation
  • General Company Information
  • SAP Project History
  • SAP Integration Infrastructure History
  • SAP XI Project

4
Eli Lilly General Company Information
  • Pharmaceutical company founded on May 10, 1876
  • gt 41,000 employees worldwide
  • 20,000 OUS, 8000 R/D
  • Research and development facilities located in 9
    countries
  • Manufacturing plants located in 13 countries
  • Products marketed in 143 countries
  • Headquarters Indianapolis, Indiana, U.S.A
  • gt 15 Billion in net sales in 2006

5
Eli Lilly SAP Project History
  • The Eli Lilly philosophy was to implement common
    business processes worldwide enabled by an
    integrated information environment
  • Introduced the Global Business Integration
    Project (GBIP) to the organization in 1998
  • Intent on standardizing common data and systems
    worldwide
  • Scope included HR, Finance, SCM PMP.
    Implemented 1st 2 countries (France Spain) in
    1999
  • Strict release timeline of 6 month cycles for new
    countries
  • 16 countries implemented SAP, all currently on
    SAP R/3 4.6c
  • SAP payroll for the USA introduced in 2006
  • All other (Non-SAP) countries following many SAP
    processes through integration (i.e. HR data for
    all Non-SAP countries integrated into SAP via
    global interfaces)
  • XI successfully implemented, intended to
    eventually replace existing data movement
    infrastructure
  • Lilly is currently undertaking an upgrade to
    ECC6.0.

6
Eli Lilly SAP Infrastructure History
  • In The Late 90s Identified The Need For An
    Integration Infrastructure To Support The
    Integration Needs Of The Project.
  • Tools Like Mercator and MQSeries Where Selected
    Because They Represented The Best Of Class Tools
    For Enterprise Architecture Integration At The
    Time.
  • The Last 6 7 Years Have Been Spent Developing A
    Set Of Lilly Specific Tools Based On These
    Technologies.

7
Eli Lilly Existing Infrastructure Challenges
  • Infrastructure Built Using Different Tools
  • Requires diverse skill set, Upgrade complexities,
    Change control
  • Tool Stability, Agility, Reproducibility
  • Using several tools requires many resource to
    diagnose issues
  • Future Of Current Tool Set Not Clear
  • Mercator Was Purchased Last Year By Accential
    Software. Accential Software Was Purchased By
    IBM This Year. Implications Unknown In Short
    Term. In The Long Term Should Be Good But
    Changes To Tools May/Should Eventually Drive
    Significant Upgrades. (Past Changes Have Been
    Implemented Without Backward Compatibility)

8
Eli Lilly SAP Infrastructure
  • Eli Lilly has developed a custom designed routing
    system as part of existing infrastructure, which
    includes
  • Transformation and Routing
  • Mercator (IBM DataStage TX), Gentran,
    Informatica, C Programs
  • Messaging
  • IBM MQ Series
  • Delivery
  • C Programs (Wrapper / Unwrapper)
  • Database
  • Oracle
  • Source Control
  • Rational Clear Case
  • Configuration Web Interface
  • Java
  • Maintenance, Trouble Shooting, Migration and
    Consistency Checking
  • UNIX - Scripting and Security, Manual FTP

9
Eli Lilly Existing Infrastructure Diagram
10
XI Concept at Eli Lilly Scope
  • Implement functionality to determine capabilities
    and positioning in GBIP architecture
  • Pilot Design and implement 40 interfaces
  • Technical Criteria Re-implement minimal
    interfaces to cover most scenarios (File, IDOC
    and MQ to JMS adapters)
  • Build entire XI infrastructure, including
    configuration, development, testing (QA)
    production environments
  • Pilot implementation would be seamless to
    existing business users when compared to existing
    infrastructure!

11
XI Concept at Eli Lilly
  • Reduce Number Of Tools To Support Interfaces
  • Built On Robust SAP Technology With SAP Support
  • Will Reduce Long Term Support
  • Eliminates Need To Fund Additional Data Sharing
    Infrastructure Improvement Projects.
  • Technology Is Mature And SAP Community Is Moving
    In This Direction
  • Will Be Required To Leverage New SAP Integration
    Development

12
Starting Point For Determining / Cost Justifying
SAP XI Implementation
  • Building The Foundation
  • Project Types
  • Project Approaches
  • Understanding Project Cost / Savings
  • Project Cost Considerations
  • Project Cost Savings

13
Project Types
  • New EAI / B2B Implementation
  • Adding SAP XI To Existing EAI / B2B
    Implementation
  • Legacy EAI / B2B Replacement Implementation
  • Legacy EAI / B2B Consolidation Implementation

14
New EAI / B2B Implementation
  • Current Infrastructure
  • No Existing EAI / B2B Tools In Use Today
  • Business Drivers
  • EAI / B2B Functionality Required
  • Leverage Existing SAP Skill Sets (ABAP / JAVA)
  • Alternative Options
  • Build Point To Point Interfaces With Available
    Programming Tools
  • Implement Solution From Different Vendor
  • Challenges
  • Building Out SAP XI Support Infrastructure
  • Internal EAI / B2B Experience
  • Finding Good External EAI / B2B Experience

15
Adding SAP XI To Existing EAI / B2B Implementation
  • Current Infrastructure
  • Currently Have Other EAI / B2B Tools In Use Today
    You Intend To Keep
  • Business Drivers
  • New SAP XI Functionality Required
  • Leverage Existing SAP Skill Sets (ABAP / JAVA)
  • Alternative Options
  • Implement Solution From Different Vendor
  • Continue / Expand Use Of Current Tools
  • Challenges
  • Building Out SAP XI Support Infrastructure
  • Finding Good External EAI / B2B Experience
  • Supporting Additional Tool SAP XI

16
Legacy EAI / B2B Replacement Implementation
  • Current Infrastructure
  • Currently Have Another EAI / B2B Tool In Use
    Today You Intend To Replace
  • Business Drivers
  • New SAP XI Functionality Required
  • Leverage Existing SAP Skill Sets (ABAP / JAVA)
  • Consolidation Of Existing Designs
  • Current Infrastructure
  • Complexity
  • Deficiencies
  • Substantial Upgrades Required
  • Current Vendor Support / Direction Concerns
  • Alternative Options
  • Implement Solution From Different Vendor
  • Continue / Expand Use Of Current Tools
  • Challenges
  • Building Out SAP XI Support Infrastructure
  • Finding Good External EAI / B2B Experience
  • Supporting Additional Tool SAP XI (In Phased
    Replacement Approach)
  • Adapting Source and Target Applications To
    Leverage New Tool Set

17
Legacy EAI / B2B Consolidation Implementation
  • Current Infrastructure
  • Currently Have Multiple EAI / B2B Tools In Use
    Today You Intend To Replace/Consolidate Into XI
  • Business Drivers
  • New SAP XI Functionality Required
  • Current Infrastructure
  • Complexity
  • Deficiencies
  • Substantial Upgrades Required
  • Current Vendor Support / Direction Concerns
  • Consolidation Of
  • Existing Designs, Tools, Skill Sets, Teams and
    Resources
  • Alternative Options
  • Continue / Expand / Consolidate Use Of Current
    Tools
  • Challenges
  • Building Out SAP XI Support Infrastructure
  • Finding Good External EAI / B2B Experience
  • Supporting Additional Tool SAP XI (In Phased
    Replacement Approach)
  • Adapting Source and Target Applications To
    Leverage New Tool Set
  • Managing Functional / Technical Trade Offs To
    Maximize Overall Project Benefit

18
Project Approach Types
  • Proof Of Concept
  • Implement A Representative Set Of SAP XI
    Functionality Required To Meet Overall
    Architectural Goals.
  • Big Bang
  • Implement All Required SAP XI Functionality In
    One Software Release.
  • Only Really Practical For New and Small
    Replacement Implementations.
  • Phased
  • Implement Required SAP XI Functionality Over A
    Series Of Software Releases
  • Only Practical Approach For Large Replacement and
    Consolidation Projects

19
Project Cost Considerations
  • SAP XI Platform Software
  • Third Party Adapter Software
  • Hardware
  • Consulting Services
  • Project Approach

20
SAP XI Platform Software Costs
  • There Are Three Primary Components That Make Up
    The Cost Of The SAP XI Platform
  • SAP XI Software
  • Database Software
  • Third Party Infrastructure Tools
  • Alert Software
  • Job Scheduling
  • Archiving
  • Etc
  • Interesting Point About Our Project. The
    Software Had Already Been Purchased In A Bundle
    Of Functionality Years Earlier
  • SAP Had Since Moved From An Instance Based
    License To A Volume Based License.
  • The Volume Based License Presented Us With
    Several Challenges
  • How To Measure Volume?
  • What Volume Level Would We Need Licensed If We
    Fully Implemented XI?

21
Third Party Adapter Requirement Costs
  • If you are implementing EDI you will need a third
    party adapter.
  • If you require complex content conversion you
    will need a third party adapter.
  • Understand and identify the initial cost and
    maintenance cost associated with them when
    developing your project costs.

22
Hardware Costs
  • Hardware Components
  • Servers
  • Storage
  • Network
  • Drivers Of Hardware Costs
  • Landscape Design
  • Number Of Environments Support SAP Promote and
    Support Structure
  • Production Volume Requirements
  • Testing Requirements
  • Infrastructure Techniques
  • Volume / Stress Testing
  • Tuning

23
Consulting Services Cost
  • Cost Of Third Party Assistance
  • Consulting Services Cost Vary Drastically By
    Provider And So Can The Quality Of The Services
    Provided
  • Drivers Of Consulting Services Costs
  • Project Scope
  • What Constitutes The Boundaries Of Your Scope Of
    Project?
  • Project Timeline
  • How Long Will The Project Take?
  • Balanced Pace Business Capacity, Technical
    Capacity, Testing Capacity

24
Project Approach Impact On Cost
  • Each Of The Approaches Has A Cost Associated With
    Them. Typically Each Phase Is Aimed At Reducing
    Overall Project Risk
  • Initial Project Assessment
  • Many Consulting Firms Will Do This For Free. Get
    More Than One And Compare Findings
  • A Workable Assessment Will Still Typically
    Require A Paid In Depth Assessment
  • Prototype Environment
  • Get Your Feet Wet Learn The Tool Identify Early
    Areas Of Concern And Monitor As Project
    Progresses
  • Identify Project Specific Cost Drivers That Will
    Impact Your Specific Project
  • Proof Of Concepts Phase
  • Test The Functionality Required To Completely
    Implement Your Vision
  • Find The Hidden Challenges / Costs Early
  • Overall Implementation
  • Internal VS External Resources
  • Timeline / Pace
  • Other External Drivers That Impact Overall
    Implementation Cost
  • R/3 Upgrades, Existing Infrastructure Upgrades
    Required, Unplanned Business Events

25
Project Cost Savings
  • Cost Savings
  • Maintenance Cost Of Existing Software
  • Reduction Of Redundant Hardware Support Costs
  • Cost Of Skill Sets To Support Existing
    Functionality
  • Maintenance and Support Cost Of Custom Designed
    Infrastructure Functionality
  • Cost Avoidance
  • Cost Of Required Infrastructure Software Upgrades
  • Cost Of Required or Need Infrastructure
    Enhancements

26
Maintenance Cost Of Existing Software
  • This Cost Savings Will Vary Depending On Your
    Type and Scope Of Project
  • Each Infrastructure Tool Has A Software Support
    Cost Associated With It. Therefore Each Tool You
    Retire Represents A Potential Maintenance Cost
    Savings.
  • Consideration Some Maintenance Contracts On
    Infrastructure Tools Have Different Levels Of
    Support, The Higher Levels Can Have Significant
    Yearly Costs Associated With Them.
  • In Large Projects It Will Take Time To Phase Out
    The Use Of Certain Tools. So Make Sure Your ROI
    Calculations Consider This.

27
Reduction Of Redundant Hardware Support Costs
  • This Cost Savings Is Primarily Driven By A
    Reduction In Hardware Required To Support
    Multiple Infrastructure Tools
  • There Is A Monthly Support Cost Associated With
    Any Server Hosted Within A Data Center
  • On Tool Consolidations Projects, A Significant
    Number Of Physical Servers Can Be Eliminated And
    Their Associated Support Costs
  • Hardware Upgrades To Aging Tools Servers Can Also
    Be Avoided

28
Cost Of Skill Sets To Support Existing
Functionality
  • Each Infrastructure Existing Infrastructure Tool
    Requires A Team Of Different Software Specific
    Skills To Develop, Administer, and Monitor.
  • Consolidation Of Tools Can Significantly Reduce
    The Number Of Resource Skills Required To Support
    An Infrastructure
  • Reduce The Number Of Resource Required Overall To
    Support The Infrastructure
  • This Particular Area Obviously Will Be Subject To
    Political Debate Because Of Its Potential Impact
    On Head Count.
  • We Found In Our Project That Our DataStage TX
    Resources Easily Adapted Their Mapping Skills To
    The XI Skills Required, And Became Productive
    Quickly.

29
Maintenance and Support Cost Of Custom Designed
Infrastructure Functionality
  • Many Existing Integration Infrastructures Are
    Developed From Tools Introduced To The Market
    Over The Last Ten Years.
  • As a Result Many Existing Integration
    Infrastructures Rely on Custom Developed
    Components To Meet Required Infrastructure
    Functionality.
  • This Custom Functionality Can Be Quite Complex
    And Require Expert Level Skills In Multiple
    Infrastructure Software Products To Effectively
    Maintain.
  • These Infrastructure Components Are Unique Thus
    When An Issue Occurs Either You Will Require
    Knowledgeable In-house Resources Or You Will Need
    Expert Level External Help.
  • The Cost Of Supporting This Existing Custom
    Functionality Is Usually Significant.

30
Cost Avoidance Of Required Infrastructure
Software Upgrades
  • Many Existing Infrastructure Tools Require
    Upgrades To Keep The Product In Support
  • If Your Infrastructure Is Made Up Of Many
    Different Tools. Chances Are One Of Them Is
    Going To Be Driving An Infrastructure Upgrade
  • Some Tool Upgrades Provide Very Little Challenge
    From An Effort And Staffing Perspective, Some Are
    Significant.
  • Understand The Impact Of And Drivers Of Future
    Tool Upgrades, They Can Be A Driver Of Cost
    Savings From An Avoidance Perspective.
  • When Upgrading A Custom Developed Infrastructure
    Made From Different Software Tools, Projecting
    The Impact / Required Scope / Cost Of An Upgrade
    Can Be A Challenging Undertaking.

31
Cost Avoidance Of Required or Need Infrastructure
Enhancements
  • If You Have Developed Your Integration
    Infrastructure From Off The Shelf Tools and
    Custom Designed Components. You Will Find
    Yourself Continually Adapting That
    Infrastructures Capabilities To Keep Up With
    Changing Business Needs and Changing Technology
    Needs.
  • As You Continue To Plan Ahead For Future Business
    Requirements, You Will Find The Need To Scope
    Design Changes And Improvement Projects.
  • Most Of Our Future Scoped Functionality Existed
    In SAP XI Out Of The Box
  • In Addition Because It Is An SAP Industry
    Supplied Tool As Future Functionality Is
    Required, It Will Most Likely Be Added As The
    Tool Matures.

32
Project Controls and Project Scope Definition
  • Scope In Infrastructure Tools Early
  • Understand Your Interface Volumes
  • Understand Your Adapter Requirements
  • Dont Underestimated Content Conversion
  • Assessing The Impact Of Environment Copy Backs
  • Try Not To Get Sucked Into The Number Of SLDs
    Required Vortex

33
Scope In Infrastructure Tools Early
  • Leave some room in your plan for development of
    simple infrastructure tools.
  • These tools will help you implement better more
    maintainable designs as you project progresses.
  • Some will be required from a technical
    perspective. Some will significantly simplify
    other activities later.
  • Dont cut scope on this in early phases of your
    project.

34
Understand Your Interface Volumes
  • Specifically what impact does XML have on your
    volume estimates.
  • Dont get to integration testing and figure out
    that your design brings XI to its knees!
  • Study your interface volumes. Specifically at
    production and initial conversion loading
    conditions.
  • Make sure your design accounts for these volumes
    and can handle the load effectively.
  • Specifically do the math on content conversion
    for each interface.
  • Flat file to XML conversion.
  • Calculate a conversion factor.
  • Multiply production volume estimates by the
    conversion fact.
  • The troublesome interfaces will become apparent
    very quickly.
  • Reworking an interface design can be a costly
    mistake and can significantly impact project
    timelines.

35
Understand Your Adapter Requirements
  • What adapters do you need to accomplish your
    goals?
  • Understand that your are not going to implement
    EDI in XI without the help of a third party
    adapter.
  • Understand which adapters you will require and
    their delivered functionality and functional
    gaps.
  • Some adapters support multiple capabilities such
    as FTP and SFTP by changing configuration
    settings. Dont buy custom adapters you already
    have.
  • Some standard adapters will require custom
    adjustments via custom Java modules. Understand
    and scope these custom requirements early in your
    project.

36
Dont Under Estimated Content Conversion
  • Content conversion in SAP XI can prove to be one
    of the most difficult tasks to overcome in an
    implementation.
  • Content conversion is somewhat cryptic to
    configure and effort balloons as content
    structure complexity increases.
  • We underestimated this effort the most in our
    project implementation.
  • The more complex content conversion requirements
    we had forced us to eventually rework a number of
    our interface and implement SAP Conversion Agent
    by Itemfield.

37
Assessing The Impact Of Environment Copy Backs
  • In the initial phases of building out a landscape
    this is not an important consideration.
  • Once a landscape is built however you will most
    likely not want to copy back XI. This is counter
    to most other SAP applications best practices.
  • Each SAP XI instance has unique ID configuration
    for the environment. Copy backs will erase this
    unique configuration.
  • You will not need to copy back your SAP XI
    landscape so dont spend a lot of time planning
    it or debating it. It will only cause you issues.

38
Try Not To Get Sucked Into The Number Of SLDs
Required Vortex
  • There is no right answer here. You will find
    documentation that states there should only be
    one. You will find documentation that says there
    could be more than one.
  • When a consultant tells you it depends on your
    project he is right.
  • Our experience is that less is easier to manage.
  • Set a direction and move on.

39
Technical Lessons Learned
  • Packet Processing Not Supported By IDOC Adapter
  • User Defined Java Functions
  • Custom Cross Reference Functionality
  • Required Setup To Use ABAP Maps
  • Message Size After Content Conversion
  • Large Message Processing
  • Message Pointers
  • ABAP Mapping
  • JMS Adapter
  • Conversion Agent By Itemfield
  • Adapter Tracing

40
Packet Processing Not Supported By IDOC Adapter
  • On the surface this does not appear to be an
    issue or a concern.
  • Each outbound packet from SAP is split into
    individual messages in XI.
  • However this has a negative effects on downstream
    applications like Gentran. When outbound EDI
    data is processed by Gentran it is typically
    grouped by trading partner. This caused Gentran
    to generate significantly more EDI envelopes than
    normal.
  • It also impacted other downstream applications by
    making them process lots of individual messages
    instead of groups of messages. This created
    performance issues for certain applications.
  • Only way to process IDOCs as a group was to
    process using a collection BPM.

41
User Defined Java Functions
  • Writing Custom Code Inside A GUI Map Is Sometimes
    A Good Thing
  • We used user defined JAVA functions in the
    following way.
  • We identified and created user defined functions
    that replicated all existing DataStage TX mapping
    functions not supported by XI.
  • When we identified that a particular mapping
    requirement was creating specific difficult
    challenges for GUI mapping techniques we would
    build the required functionality in a user
    defined JAVA funciton.
  • One technical challenge to user defined JAVA
    function was that they are map specific. If you
    want to reuse a function you must copy it from
    another map.
  • In general our functions required 20 lines of
    code or less but significantly simplified our map
    conversions and mapping rules.

42
Custom Cross Reference Functionality
  • SAP provides GUI mapping rules that allow you
    convert mapping data via a cross reference. The
    issue is the cross reference data is map specific
    and can not be reused.
  • We had many instances where the same cross
    reference data was required across multiple maps.
  • We create with minimal development effort a
    custom cross reference solution that utilized a
    custom ABAP table, a custom function module and a
    custom user defined JAVA function.
  • The user defined JAVA function had to be copied
    from map to map but the logic and cross reference
    data was stored in the function module and ABAP
    table. Thus allowing us to reference the same
    cross reference data across multiple maps.

43
Required Setup To Use ABAP Maps
  • The exchange profile needs to be modified before
    mapping can be done on the ABAP stack.
  • Modify the exchange profile setting
    com.sap.aii.repository.mapping.additionaltypes.
  • We added the entry R3_ABAPABAP-Class
    MapR3_XSLTABAP-XSL.
  • This allows both ABAP class maps and XSLT maps
    via the ABAP kernel.

44
Message Size After Content Conversion
  • Make sure you consider the size of you message
    after it is converted to XML when designing your
    interfaces.
  • A inbound 5mb flat file can grow to a 50mb xml
    document.
  • An interface that appears to be well within
    processing limits quickly becomes too big.

45
Large Message Processing
  • Why Does XI Not Handle Large Messages Well?
  • Netweavers dual stack design (ABAP Java)
    results in a bottleneck whenever large data sets
    move from processing on one stack to another.
    The standard way for the two stacks to
    communicate is via RFC.

46
Large Message Processing
  • The following diagram shows the communication
    between the ABAP and Java stacks during normal
    message processing.

47
Large Message Processing
  • Message Pointers
  • Lillys existing interfaces were enormous by XI
    standards (gt500MB).
  • These large files usually contained full
    refreshes of the data due to technical
    constraints on the receiving, non-SAP system.
  • XIs architecture is not structured to handle
    large amounts of data.
  • The key to processing large messages with XI is
    to minimize stack boundary traversal.
  • We were able to do this by saving the message as
    a file and only passing a pointer to the data (ie
    filename). It was the job of the processing
    agent to delete the file after it was confirmed
    that it was sent to the receiver.

48
Large Message Processing
  • ABAP Mapping
  • Some messages were brought in via the J2EE
    Adapter Engine, but not converted to XML. This
    unconventional design decision was made because
    the conversion to XML required added processing
    and memory requirements that caused message
    processing to take too long. We decided to pass
    the data directly to the map unconverted.
  • In an effort to further streamline message
    processing and in addition to the removal of XML
    conversion overhead, we also decided to do away
    with some of the stack traversal overhead. We
    accomplished this by implementing our mapping
    requirements with ABAP.

49
Large Message Processing
  • ABAP Mapping continued
  • Doing the mapping in ABAP was doubly advantageous
    because message mapping and XSL mapping requires
    that the data be in XML format. Since our data
    was still in flat file format, our only options
    were Java mapping and ABAP mapping. With the
    added requirement of reduced stack traversal, our
    only remaining option was ABAP.
  • Our data was in a structured text format. ABAP
    turned out to be a very good language for this
    type of data mapping. Our large team of
    competent ABAP developers made short work of the
    ABAP maps.

50
JMS Adapter
  • The JMS configuration is not out-of-the-box! JMS
    drivers must first be installed.including
  • The correct JAR files in order for the JMS
    adapter to function correctly, which is one of
    the challenges we faced with the use of JMS.
  • Performance tuning for XI to operate effectively
    that impacted JMS. SAP provides a document that
    outlines performance tuning requirements in XI
    version 3.0 (see appendix for information).

51
JMS Adapter
  • Secondly, during integration testing, we
    discovered an issue regarding a message of 30mb
    in size
  • Issue The following error occurred when
    attempting to connect to the JMS adapter
    "Delivery of the message to the application using
    connection AFW failed, due to MQJMS1016 an
    internal error has occurred. Please contact your
    system administrator. Detail java.nio.BufferOverf
    lowException.
  • Resolution The Java Development Kit (JDK) had to
    be upgraded to version 1.4.2_08 or higher (or if
    using version 1.3.1, upgrade to JDK 1.3.1_16 or
    higher). We upgraded our server version to
    1.4.2_12 in order to process messages gt25mb (see
    appendix for additional information)

52
SAP Conversion Agent by Itemfield
  • At Eli Lilly, we implemented the SAP Conversion
    Agent by Itemfield as an adapter module to help
    deal with more complex and unstructured messages!
  • Issue identified that some special characters
    (i.e. German Umlaut) were not displaying
    correctly (showing as ??), even though the
    character set was configured as Western
    ISO-8859-1.

53
SAP Conversion Agent by Itemfield
  • Resolution CM_TransformModule.sda module that
    related to Content Master (as it was known then)
    service pack 15 (SP15) was not working to provide
    adequate translation of special characters
    following data conversion. The
    CM_TransformModule.sda of SP17 was deployed in
    each environment which eventually fixed the
    problem. For information, Eli Lilly was using XI
    SP15 and Conversion Agent SP15 at the time this
    issue occurred (see appendix)

54
SAP Conversion Agent by Itemfield
  • Issue We identified that several messages
    by-passed the SAP Conversion Agent. Thus, the
    payload was not being converted into an XML
    format and XI was receiving a flat file instead
    of an XML file.
  • Resolution The fix for this was based on an
    existing OSS note (930598). This note was not
    only pertained to Conversion agent but it was
    more generally specified for any module that was
    attached to the adapter.

55
Adapter Tracing
  • Each Java Adapter Can Be Traced At A Technical
    Level.
  • Adapter Tracing Is Activated By Using The J2EE
    Administrator Tool To Change Trace Levels.
  • Warning At Higher Adapter Trace Levels The
    Adapter Polling Frequency Can Really Impact Trace
    File Growth.
  • Make Sure You Polling Frequency Are Reduced
  • Or Make Sure You Only Activate Traces For Short
    Periods Of Time

56
Key Learnings
  • Calculating A Cost Savings On An SAP XI
    Implementation Will Depend On Your Project Goals,
    Your Current Infrastructure, and Your Specific
    Infrastructure Challenges.
  • Prototyping Environments and Proof Of Concept
    Implementations Will Help You Control Overall
    Project Scope And Requirements By Identifying
    Areas In The Project That Will Require Specific
    Consideration Up Front
  • Dont Underestimate Content Conversion
  • Scope In Simple Infrastructure Tools That Will
    Simplify Long Term Maintenance And Reduce
    Interface Development Time.
  • SAP XI Can Handle Large Sized Message Interfaces.
    You Just Have To Handle Them Differently.

57
