Transportation Infrastructure Improvements Needed to Support Efficient Gas Pipeline Construction Gas Pipeline Corridor Prudhoe Bay to Canadian Border

1
Transportation Infrastructure Improvements Needed
to Support Efficient Gas Pipeline
ConstructionGas Pipeline Corridor Prudhoe Bay
to Canadian Border
2
Gas pipeline construction different than TAPS

• Twice the population in Alaska
• Multi-billion-dollar tourism industry
• Higher background traffic
• More public and media scrutiny on safety
• Greater use of large modules
• Heavier pipe
• Buried construction, more earthwork truck loads
• More ports of entry
• More pavement at risk

3
Why the industry should care

• Time and Efficiency Money
• DOTPF is advocating for State funds, not seeking
  user-funds
• Bad Roads slower gas line construction and
  increased costs
• Infrastructure projects will be training ground
  for trades needed for gas line
• Transportation investment reduces economic losses

4
Why now?

• Only 6 construction seasons until gas line
  construction start
• Even with pipeline delays timelines flow
  together (transportation construction and
  pipeline construction)
• Too much work to be compressed into a 2 to 3 year
  construction window
• Bid ready projects save future inflation as well
  as maintenance costs by doing projects now
• Funding not identified
• Must start to identify funding and advocate for
  legislative support

5

• Note
• 6 construction seasons 2010 2015
• Alaska construction season May Oct
• Pipeline constructionwinter only in permafrost
• Pipeline logistics start in earnest after project
  sanction
• DOT focus Dalton Hwy (common to all projects)
  and bridges on Alaska and Richardson Highways

6
Program funding for transportation
7
Program in support of pipeline activities

• Lots of needs funding not identified
• Current infrastructure WILL slow logistics for
  pipeline activities
• Everyone has a stake in efficient safe
  transportation
• Active support of DOT efforts in securing
  funding. Talk to legislators. Testify.
• When in Juneau Testify and support DOT in
  hearings
• 2 Billion in trans infrastructure needs
  identified

8
Needs

• Upgrade bridges, highways, airports, material
  sites
• Weigh station bypass technology
• Will improve state and carriers efficiencies
• Safety features needed
• Truck pull outs to allow passing
• Module movements safety pull out areas at bridges
• More passing lanes
• Improve safety and drivability
• Width
• Alignment
• Grades
• Embankment
• Surfacing improvements

9
Examples of major considerations
Problem?
Bridges
Smaller Loads More Loads Slower Speeds Increased
Logistics Safety Reduced More Time Money
Parks Hwy Dalton Hwy
10
Key chokepoints

• Atigun Pass
• Yukon River Bridge
• Fairbanks, North Pole, Delta Junction
• Alaska Range and Thompson Pass
• Haines and Haines Highway
• Anchorage to Wasilla

11
Dalton Hwy Corridor

• Scope
• Projects Along 415-Mile Dalton Hwy Corridor
• 24 Hwy projects
• 3 Airports
• 2 Bridges
• Cost
• 1 Billion (average)
• 167 Million per year for 6 Years

12
Elliot Hwy Corridor

• Scope
• Projects along 73-mile segment
• 3 Hwy projects
• 1 Airport
• 1 Bridge
• Cost
• 100 Million

13
Richardson Hwy Corridor

• Scope
• Projects Along 95-mile Corridor
• 15 Hwy projects
• 2 Bridges
• Cost
• 300 Million

14
Alaska Hwy Corridor

• Scope
• Projects Along 200-mile Corridor
• 9 Hwy projects
• 2 Airports
• 9 Bridges
• Cost
• 600 Million

15
Financial responsibility

• Federal highway funds tapped out
• Highway Trust Fund expenses gt revenues
• Federal highway funds cannot be diverted to
  gas pipeline
• Urban and other transportation modal needs are
  great
• This requires program funding
• DOT is advocating for state funding
• Requires support of industry and users

16
DOT work to-date

• Key work identified (bridges, passing lanes,
  highway reconstruction)
• Full-time coordinator in place
• Federal funded projects underway
• GO Bond project underway
• Continued discussions with Legislature
• Working with T/C Alaska and Denali Project
• Highway Use Agreement discussions
• Project needs reviewed
• Statewide Infrastructure owners meeting
• Included communities/Alaska Railroad/ports that
  may be impacted/industry users

17
Visible progress
2007 Elliott Highway New Washington Creek Bridge
and realignment
2007 Dalton Highway Grade heightening at MP 241
to 242 to alleviate snow drifting, and aufeis.
18
lost if hauling through work zones
Construction Season
No highway construction along pipeline routes
Design, Permitting, ROW Project Bidding
2017
2018
2019
Pipeline Construction
Logistics Begin
Need Program Funding
19
Take-aways

• Lots of needs funding not identified
• Current infrastructure WILL slow logistics for
  pipeline activities
• Support DOT efforts in securing funding
• Talk to legislators
• When in Juneau Testify and support DOT in
  hearings
• Program funding

20
Thank you

• Contact
• Frank Richards, P.E.
• Deputy Commissioner
• Alaska DOTPF
• [phone]
• frank.richards_at_alaska.gov

Support Program funding for transportation
infrastructure for pipeline construction
Industry and citizens all benefit
