Title: IPv6 in a Mobile Wireless Internet


1
IPv6 in a Mobile Wireless Internet
  • Hesham Soliman
  • H.Soliman_at_flarion.com

2
Worldwide Cellular Subscribers
Worldwide Cellular Subscriber Projections
00-07 CAGR 17.4
1990-07 CAGR 35.8
Source Gartner and In-Stat/MDR
3
Heterogeneous access networks
PAN
  • Different wireless technologies for different
    scenarios PAN (e.g. Bluetooth), LAN (e.g.
    802.11) and WAN (e.g. GSM/3G/FLASH-OFDM)
  • Different characteristics for each wireless
    technology Coverage, QoS, Cost, reliability etc
  • Different IP versions IPv4 and IPv6

4
Mobility is now the Norm
Internet
WLAN
Cellular
5
The future is peer!
  • Peer to peer communication already exists in
    cellular networks
  • IP-based cellular networks inherit the same
    services and more
  • Multimedia sessions (VoIP, streaming, PTT etc)
  • Gaming
  • Chatting
  • IP-based cellular networks are all about IP-based
    multi-service networks and radio access.

6
Enabling IP-based Cellular systems
  • Scalable support for Peer-2-Peer multimedia
    applications.
  • Efficient and scalable support for IP mobility
  • Design Cellular technologies in a Packet
    friendly way.

7
Why IP mobility?
DNS
Router A
Router B
Router C
8
Requirements for IP Mobility
  • Compatibility with existing Internet hosts and
    applications
  • No modification of existing routers or routing
    mechanisms
  • Internet-wide mobility reachable everywhere
  • No modification of non-mobile hosts (i.e. TCP/IP
    stacks)
  • No modification of applications
  • Maintain connections while moving between subnets

9
Mobile IPv6 Routing through HA
HomeAgent
IPv6 Data
Home Network
MIPv6 messages
CorrespondentNode (CN)
MobileNode (MN)
IP Network
ForeignNetwork
Foreign Network
Access Router
10
Mobile IPv6 Route Optimisation
Home Network
HomeAgent
IPv6 Data
MIPv6 BU/BA
CorrespondentNode (CN)
MobileNode (MN)
ForeignNetwork
Foreign Network
11
A Packet friendly cellular networkWHY is data
different?
12
What do you want from your cellular vendor?
  • Packet-friendly radio access
  • Support for seamless mobility
  • Security
  • Same Services regardless of the access
  • Native Multicast support
  • Scalable support of various QoS levels

13
Is Power Conservation and Paging Different for
Data and Voice?
Are there also opportunities for power
conservation during bursty and/or intermittent
data sessions?
Data
Data Session 1
Data Session 2
Conserve Power
Time
14
Fast Statistical Multiplexing
  • Duty cycles for data access are low
  • 4 average usage can be high
  • Fast Multiplexing Essential
  • efficient multiplexing is required on short
    timescales (ms)
  • only 8ms required to send an 1500byte Ethernet
    Frame at 1.5Mbps
  • Need to quickly switch users On/Off data resource

15
Statistical Multiplexing
  • The impact of Stat Mux. on user rate

16
FLASH-OFDM
Optimized, converged solution IETF standard
components, protocols Wireless link is
transparent to IP apps End-to-End IP connectivity
Public Internet
Mobility Agents
Gateway
Operator IP-based Network
Back End Systems
Base Stations
Mobility Management
Chipsets
User Terminals
17
Network Comparison with UMTS
Back End
Back End
Back End
Back End
Systems
Systems
Systems
Systems
GGSN
Host
MT
IP
Host
MT
IP
BSC
BTS
RNC
Node B
SGSN
MSC
HA
PDN
PDN
Back End
Back End
Systems
Systems
Radio Router
Radio Router
Host
MT
BS
IP
Host
MT
BS
IP
HA
HA
IP Network
IP Network
flash
-
OFDM
flash
-
OFDM

18
FLASH-OFDM Radio Features
  • Under 50 ms RTT over the air (comparable to DSL).
  • Fast statistical multiplexing
  • Operates over a wide range of frequencies
  • Cellular range coverage of cells
  • Native multicast
  • Support for strong airlink encryption

19
FLASH-OFDM Network Features
  • Easy integration into standard IP networks
  • No synchronisation requirements between BSs
  • Mobile IP for IP mobility
  • Strong support for QoS
  • Roaming support
  • VoIP support

20
Conclusions
  • The Internet is growing even more rapidly due to
    the convergence between IP and Cellular nets.
  • IPv6 is KEY in enabling the Internet to scale.
  • The driver for successful IP-based cellular
    network are application and radio-driven.
