Therapeutic Drug Monitoring of Immunosuppressant Drug

1
Therapeutic Drug Monitoring of Immunosuppressant
Drug

• Todd K Fox
• Medical Advisor
• Novartis Pharmaceuticals Canada
• email address toddk.fox_at_novartis.com

2
Outline

• Introduction
• Pharmacology
• Cyclosporine, Tacrolimus, Sirolimus, Mycophenolic
  Acid
• Pharmacokinetics
• High Variable Drug
• Metabolized via Liver - Cyp 3A4
• P-Glycoprotein Substrate/Inhibitor
• Therapeutic Drug Monitoring

3
Introduction

• Clinical Pharmacokinetics
• Is the discipline that describes the absorption,
  distribution, metabolism and elimination of the
  drug in patients requiring drug therapy.
• What the body does to the drug.

4
(No Transcript)
5
Introduction

• Pharmacodymics
• The relationship between the concentration of a
  drug and the response obtained in a patient.
• What the drug does to the body.

6
Introduction

• Therapeutic Drug Monitoring
• Measured drug levels to ensure appropriate effect
  or prevent toxic effect
• Assumes a concentration-effect correlation exists
  and is known

7
Narrow Therapeutic Window
Drug A has a narrow therapeutic window
A
Probability ()
B
Therapeutic Response
Adverse Events
Drug Concentration (ng/mL)
8
Introduction

• Immunosuppresants
• Narrow therapeutic index
• Pharmcodynamic Endpoints are crude

Rejection
Toxicity
Biopsy
Nephrotoxicity Neurotoxicity
9
Pharmacology(Pharmacodynamics)
10
PMN cells,
APC
NK cells,
IL-1
basophils, etc.
IL-2
Tc cell
Th cell
B cell
Cytotoxic Activity
Phagocytosis
Graft Rejection/Destruction
11
Steroids
Cyclosporine, Tacrolimus
APC
IL-1
Aza, MMF, Brequinar, ERL 080
IL-2
CD3,CD25 Abs
Tc cell
Th cell
B cell
Aza, MMF, Brequinar, ERL 080
Sirolimus, RAD
Cytotoxic Activity
Phagocytosis
Graft Rejection/Destruction
12
Calcineurin Inhibitors Cyclosporine Tacrolimus
13
Antiproliferative Agents Sirolimus
14
Cell cycle (Lymphocytes)
Mitosis
G2
G0

• DNA Synthesis

G1
S-phase
Hypoxanthine-guanine Phosphoribosyltransferase
Synthesis of Purines
Guanosine Monophosphate
Inosine Monophosphate
Guanine
5-Phosphoribosyl-1-Phosphate
Salvage Pathway

• Inosine
• Monophosphate
• Dehydrogenase
• (IMPDH)

Mycophenolate inhibits IMPDH
15
Cell cycle (Lymphocytes)
Mitosis
G2
G0
Cyclosporine Tacrolimus
G1
S-phase
Sirolimus
Mycophenolic Acid
16
Summary of Immunosuppresant Pharmacology
17
Pharmacokinetics Cyclosporine, Tacrolimus,
Sirolimus, Mycophenolic Acid

• High Variable Drug
• Metabolized via Liver - Cyp 3A4
• P-Glycoprotein Substrate/Inhibitor

18
Highly Variable Drugs
1. AUC 2. Cmax 3. Tmax
19
Highly Variable Drugs
AUC0-4
1400
1200
AUC0-12
1000
800
Cyclosporine Concentration (ng/mL)
600
400
200
0
0
2
4
6
8
10
12
Hours Post-Dose
C-0
C-2
Extent and rate of absorption are highly
variable.Patient differences are highlighted in
the absorption phase.
Adapted from Johnston A et al. Transplant Proc.
20003253S-56S.
20
Cyclosporine Pharmacokinetics Differs by Organ
Recipient Type
Dose-Normalised AUC(ngh/mL/mg)
De Novo Renal1
De Novo Liver3
De Novo Heart2
1. Kovarik JM et al. Transplantation.
199458658-663. 2. Cooney GF et al.
Transplantation. 1998301892-1894. 3. Freeman D
et al. Ther Drug Monit. 199517213-216.
21
Mycophenolic Acidinter-subject variability of
MPA AUC
MMF 1 g bid
Shaw et al AJT 20033534
Shaw L. et al. Ther Drug Monit 200426347
22
Metabolism of Immunosuppresents

• Tacrolimus, Cyclosporine, and Sirolimus are all
  low extraction Drugs
• Clearance of the drug is dependent on enzyme
  efficiency of the liver
• Protein binding is important - Unbound or Free
  Fraction is what can be metabolized.
• Enzyme substrate Cyp - 3A4

23
Cyp 3A4 isoform
24
Protein Binding Sites

• Red Blood Cells Whole Blood levels done for all
  3 drugs
• White Cells T-Lymphocytes
• Lipids HDL, LDL, Apolipoproteins
• Others Albumin, a-Acid Glycoprotein

25
P-Glycoprotein

• Transmembrane protein first associated with MDR
  in certain tumor cells
• Acts as transporter pump which prevents drug
  accumulation in cells ( ? activity)
• Physiologic role not fully understood
• In transplant patients, P-gp is critically
  involved with T-cell apoptosis and the
  pharmacokinetics of corticosteroids,
  cyclosporine, tacrolimus (Tac), and sirolimus.

26
P-Glycoprotein

• Location
• Adrenal Cortex - Cortisol secretion
• Kidney - Brush Border - Urinary Excretion
• Liver - Biliary Excretion
• Small Intestine - Absorption
• Brain - Blood Brain Barrier

27
P-Glycoprotein

• P-glycoprotein (P-gp) can actively transport
  drug from cells, resulting in
• decreased drug absorption (gastrointestinal
  tract) enhanced elimination into bile (liver)
  and urine (kidney) prevention of drug entry
  into the central nervous system
  (blood-brain-barrier).

28
P-Glycoprotein
Drug
Drug
Drug
Extracellular space
Drug
On
Drug
Plasma Membrane
/-

• Allosteric Binding Site

off
Drug
ATP
ATP
Cytoplasm
Drug
P-glycoprotein
Drug
29
P-Glycoprotein
P-Glycoprotein Interactions Increasing
recognition as an important factor in influencing
drug pharmacokinetics and efficacy Can
significantly affect disposition of medications
30
P-Glycoprotein

• Substrates
• ImmunosuppressantCyclosporine, Tacrolimus,
  Sirolimus,
• Calcium Channel Blockers Verapamil, Diltiazem,
  Nifediine
• Antineoplastics Etoposide, Doxorubicin, Taxol
• Opioids Morphine, Methadone
• Misc Digoxin, Corticosteroids

• Inhibitors
• Cyclosporine, Tacrolimus
• Nifedipine, Diltiazem, Verapamil

31
Summary P-Glycoprotein
Tacro/siro/cyclo
P-GP
Cyclosporine
Metabolites
Cyp 3A4
Hepatic Portal Vein To Liver
32
General TDM Monitoring Strategy

• Starting Dose Loading Dose may be required
• Obtain Trough (C0) Level Determine Desired
  Trough level
• Assess Patients Risk
• Introduction or discontinuation of Cyp-3A4
  inducers or inhibitors
• Introduction or discontinuation of P-GP
  substrates or inhibitors
• Assess blood work - Serum Creatinine, Lipid
  profile, WBC,RBC
• Repeat serum levels based on risk assessment

33
General Strategies of TDMLoading Dose
Van Hest et al. Ther Drug Monit 2005
34
General Strategies of TDMLoading Dose
Van Hest et al. Ther Drug Monit 2005
35
Drug exposure and systemic effect

• MPA AUC Acute Efficacy
  mghr/L Rejection
• 0 60 0
• 15 30 50
• 25 15 75
• 40 6 90
• MPA AUC 0-12 median over first 6 months
• Hale et al Clin Pharm Ther 1998
• Shaw et al TDM 2000
• Weber et al JASN 2002

Therapeutic threshold
30
Therapeutic threshold
60
36
General TDM Monitoring Strategy

• Starting Dose Loading Dose may be required
• Obtain Trough (C0) Level Determine Desired
  Trough level
• Assess Patients Risk
• Introduction or discontinuation of Cyp-3A4
  inducers or inhibitors
• Introduction or discontinuation of P-GP
  substrates or inhibitors
• Assess blood work - Serum Creatinine, Lipid
  profile, WBC,RBC
• Repeat serum levels based on risk assessment

37
Desired Levels
38
Pharmacokinetics Equations

• Current Status Algebra
• Assumes Linearity
• Provides no phsiologically meaningful
  information I.E. Clearance

Cpss Desired
New Dose
Current Dose

Cpss Current
39
Pharmacokinetics Equations
Pharmacokinetics Equations

• Example
• 45 yr old Renal Tx patient
• Current Dose 200mg Twice a day
• Current Level - 105
• Desired Level - 200

200
Cpss Desired
200 380.9
Current Dose

New Dose
105
Cpss Current
Dose 375-400mg
Is this a steady State? Renal Function of
Patient? Cyp 3A4 or P-GP drugs
40
Pharmacokinetics Equations

• Traditional Methods
• Clearance Total Body
• Cltb Ke Vd

Cltb
Ke
or
Vd
41
Pharmacokinetics Equations

• Traditional Methods
• Patient Elimination Rate (Kd)

(S)(F)(Dose)
Cpss min
Vd
ln
Cpss min
Kd
t
Patient Specifics Measurements Dose Cpssmin
Vd,S, F are reference Values
42
Pharmacokinetics Equations

• Traditional Methods
• Calculate New Dose

-kdt
(Cpss min)(Vd)(1-e )
Dose
-kdt
(S)(F)(e )
43
New Approaches

• C2 - Monitoring
• Abbreviated AUC
• Absorption Profile AUC absorption Phase

44
Case

• BG 51 yr old female
• Admitted for Liver tx - Amyloidosis
• Hx of Seizures 6 months earlier
• Meds - Dilantin and Phenobarb
• Started on Sirolimus and Mycophenolate
• What dose of Sirolimus do you recommend?

45
Case

• What do we need to worry about for the dilantin
  or phenobarb?
