Title: CLOSE PROXIMITY RADIOGRAPHIC SYSTEMS


1
CLOSE PROXIMITY RADIOGRAPHIC SYSTEMS
RADIATION PROTECTION
Making Industrial Radiography Safe and Productive
2
Index
  • Lo-Rad Overview Concept
  • How will you benefit from Lo-Rad?
  • Lo-Rad Features
  • Complete system
  • Lo-Rad Mazel Mats
  • Lo-Rad Mazel Mats Ellipse Stand
  • Lo-Rad Mazel Guide Tubes Collimator
  • Mazel Flash Box
  • Step By Step
  • Source Selenium 75
  • Barrier Distances Demarcation Areas
  • Services
  • Why Use Lo-Rad?
  • Conclusion

3
Overview Concept
  • It is essential to understand that the Lo-rad
    system is simply an addition to existing
    radiographic equipment and techniques
  • The Concept is to collimate the radiation beam
    towards an area of interest. The area of interest
    is then enclosed with the Lo-Rad Mazel mats. This
    enclosed system eliminates all unwanted radiation
    and scatter from the primary beam.
  • The Lo-Rad system when used in conjunction with a
    Selenium 75 will reduce safe working distance
    If used correctly, the system will allow you a
    1-3 meter barricade and still give you an
    acceptable reading 7.5 uSv/h
  • The clear benefit for your client is a decrease
    in loss of production and down time. Due to the
    small barricading areas required, the system
    allows you to carry out radiography continuously
    for a 24 hour period

4
How will Lo-Rad benefit you?
  • Lo-Rad system and technique will assist you in
    achieving earlier start up of plants
  • Lo-Rad system will also allow you to meet demands
    and deadlines of shut downs
  • With the Lo-Rad system NO production is lost
    due to radiography
  • Lo-rad system will eliminate the need to evacuate
    personnel
  • Lo-Rad system will highlight overhead cost
    savings due to NO none productive wages being
    paid
  • Using the Lo-Rad system you will NO longer need
    to plan and manage windows for radiography shifts

5
Lo-Rad Features
  • Lo-Rad is a flexible system which fits any shape
    and size of steel or pipe work.
  • Lo-Rad operates efficiently under varying
    temperature conditions
  • -50 to 120 Degrees Celsius
  • Lo-Rad system is easily attached to any specimen
    due to the patented self adhesive envelopes
  • Lo-Rad system allows you to use your existing and
    standard radiographic equipment, Techops 660,
    880 Gammamat TI, TIF etc
  • NO new techniques!
  • NO new equipment!

6
Complete System
  • The system is easily transported on site. With
    the interior foam cut outs, it is designed to
    protect the system and your investment. The unit
    is waterproof and has castor wheels for
    maneuverability and storing.
  • The case will hold the following
  • 4 Mazel mats with envelopes
  • 2 primary beam Mazel mats envelope
  • Mazel Outer and standard inner guide tube
  • Collimator
  • Ellipse stand
  • Flash box

7
Lo-Rad Mazel Mats
  • 915 x 305 x 9.5mm
  • 11.3kg
  • Lead equivalent of 3.3mm

Specifications
Flexible!!!
8
Self Adhesive Mats Ellipse Stand
For work on 2 Inch pipe work - DWDI Allows for
required SFD
9
Mazel Guide Tube Collimator
  • 39mm od 19 mm id
  • 8 kg
  • Max Temp 120 Deg
  • Length 1.5m

Specifications
Tungsten Collimator
Standard Guide Tube
Flexible!
Mazel Guide Tube Shield
10
Mazel Flash Box
  • For Techops or Gammamat
  • Flash Box weight 11Kg

Specifications
  • The Mazel Flash Box is designed to reduce any
    flash radiation which might be emitted when the
    source is wound out

11
Step by Step
Step 1 Attach Guide Tube to Isotope/Container
Step 3 Attach collimator to weld or specimen
Step 5 Expose Weld
Step 2 Insert Isotope/Container into Flash Box
Step 4 Enclose collimator and weld with Mazel Mats
12
Source Se75 (Not supplied with system)
  • Se75 has a more softer gamma ray spectrum than
    Ir192
  • Se75 has a significantly longer half life than
    Ir192
  • Se75 will give you better contrast and improved
    sensitivity over Ir192
  • Se75 works at optimal working range of 5-30mm FE
  • Se75 has real performance benefits when used with
    Lo-Rad system providing better radiographic
    quality
  • Typically at least 1 additional IQI wire is seen
    on radiograph

13
Barrier Distances Demarcated Areas
  • Traditionally while using Ir192 and no shielding,
    large areas have to be cordoned off, up to 80
    meters
  • With the LO-Rad system Se75 only 1 to 3 meters
    is required to be Demarcated and cordoned off
  • With the correct Lo-Rad procedure used. At a
    distance of 1 to 3 meters a reading of 7.5 uSv
    can be expected

14
Services
  • We offer our clients 2 options
  • Option 1- Clients who have Se75
  • These clients may make an out right purchase of
    our system. This will allow you to offer the
    benefits to any of your customers at any time.
  • Option 2- Clients who do not have Se75
  • These clients can rent any number of systems
    systems from us.
  • We offer the full system, all relevant equipment
    including mats, guide tube, Se75 Isotope as well
    as Technicians.
  • We will provide the full service, Radiographs,
    Processing film, Interpretation and Reports.

15
Why use Lo-Rad?
  • Lo-Rad Increases your customers productivity by
    utilizing 24 hour production.
  • Lo-Rad will assist in accelerating your
    construction program
  • Lo-Rad is an easy to use technique utilizing
    standard radiographic equipment
  • Lo-Rad reduces dose rates as well as Safe Working
    Distances
  • Lo-Rad technique improves radiographic quality
  • Lo-Rad is a robust yet flexible solution for
    shielding NDT radiation.
  • Lo-Rad allows you to make use of standard
    radiographic techniques
  • Single Wall Single Image
  • Double Wall Double Image
  • Double Wall Single Image

16
Conclusion
  • Lo-Rad will make a significant impact on your
    safety standards as well as your customers.
  • Because of 24 hour production, Your customers
    will benefit from increased productivity levels.
  • Lo-Rad products will provide you with better
    quality radiographs

17
CONTACT
Thank you for your time
