Firewalls

1
Firewalls
2
Firewalls

• Most widely sold solution for Internet security
• Solution in a box appeal
• Not a substitute for proper configuration
  management
• Firewall needs to be configured properly for
  intended protection

3
Types of Firewalls

• IP packet level
• Packet filtering
• TCP session level
• Circuit gateways
• Application level
• Application relays/gateway
• Dynamic packet filtering
• Combination of packet filtering and circuit-level
  gateways, often with application level semantics
• NATs, IDSs, Logging
• Ingress vs. Egress filtering

4
Firewalls and OSI Layers
5
Packet Filters

• Read the header and filter by whether fields
  match specific rules
• Administrator makes a list of acceptable/unaccepta
  ble field values
• Ingress/Egress filtering
• Come in standard, specialized, and stateful
  models
• Weaknesses
• Easy to botch rules
• Logging difficult
• Lack of authentication between end points

6
Network Topology and Address Spoofing

• Consider a three network (N1, N2, and N3) system
  with one router firewall
• N1 the DMZ net connecting the GW
• Very limited connection between GW and outside
• Very limited connection (different set) between
  GW and N2/N3 (Why?)
• Anything can pass between N2 and N3
• Outgoing connections only from N2 or N3
• How to set the packet filter rules
• External nodes can spoof internal addresses
  block all the source addresses same as internal
  addresses

7
Routing Filters

• Perfect security if the node is completely
  unreachable
• Routers do not advertise internal routes
• Output route filtering
• Input route filtering ?
• To prevent subversion by route confusion
• Route leaks

8
Stateful Packet Filters (SPFs)

• Track last few minutes of network activity.
• If a packet doesnt fit in, drop it
• Stronger inspection engines search for
  information inside the packets data
• Have to collect and assemble packets in order to
  have enough data
• Examples
• Firewall One, SeattleLabs, ipfilter

9
Packet Filtering Performance

• May affect the router optimization in handling
  packets
• Still the serial link from the router to the
  Internet may be the bottleneck
• Keep the rules simple and uniform
• Ordering the rules to get the most common type
  traffic through, first

10
Proxy Firewalls

• Pass data between two separate connections, one
  on each side of the firewall.
• Types
• Circuit level proxy
• Application proxy
• Store and forward proxy
• Higher latency and lower throughput

11
Circuit Level Proxy

• Client asks connects to the relay host and
  request a connection to the server
• FW connects to server
• Server usually do not get details such as IP
  address of the client
• All IP tricks are stopped at the relay host
• Fragments
• Fire walking probes

12
Application Proxy

• FW transfers only acceptable information between
  the two connections
• The proxy can understand the protocol and filter
  the data within
• Example mail proxies
• Usually sore-and-forward

13
Caching Proxies

• Client asks firewall for document the firewall
  downloads the document, saves it to disk, and
  provides the document to the client. The firewall
  may cache the document
• Can do data filtering.
• More administration time, hardware, and cost

14
Network Address Translation (NAT)

• Changes ip addresses in a packet
• Address of the client inside never shows up
  outside
• Many IPs inside to many static IPs outside
• Many IPs inside to many random IPs outside
• Many IPs inside to one IP address outside
• Examples Cisco PIX, Linux Masquerading,
  Firewall One, ipfilter

15
Logging

• Cheap solution to most behavioral problems
• program logging
• syslog /NT event log
• sniffers
• TCPdump, SSLdump Argus, Network General, HP
  Openview
• Down side
• Overhead intensive
• Does not prevent damage (more reactive than
  proactive)

16
Firewall Pitfalls

• Single point of failure
• Useful ones are difficult to configure and
  integrate
• Performance requirements tend to create back
  doors
• False sense of security
• May be 40 protection against the top attacks

17
Where to Put FW
18
Where (contd)
19
(No Transcript)
20
DMZ

• Neither internal nor external
• Placed between the external router and the
  bastion host
• Idea is to minimize the services and hence
  potential attacks
• Example For a web server stop everything but
  http
• Multiple zones for increased availability/security

21
Distributed Firewalls (DFWs)

• To avoid S-P-O-F
• To distribute risks
• Better scalability
• Trend to use sophisticated protocols
• IPSec
• Instead of IP headers use authentication codes

22
Switched Firewalls (Air-gap Technology)
