Status of Calleguas Creek Chloride TMDL October 22, 2002

1
Status of Calleguas Creek Chloride TMDLOctober
22, 2002

• L. Donald Duke, Ph.D., P.E.
• Regional Water Quality Control Board, Los Angeles

2
Los Angeles Regional Water Quality Control Board
Staff

• Don Duke 213-576-6806 dduke_at_rb4.swrcb.ca.go
  v
• Elizabeth Erickson
• Melinda Becker
• Jon Bishop

3
Calleguas Creek Chloride TMDL

• History Impaired Conditions
• Proposed Water Quality Objectives
• Critical Conditions
• Waste Load Allocations
• Implementation Plan

4
(No Transcript)
5
Calleguas Creek Water Quality Problems, Chloride

• 303(d) impaired listing in 1998
• Consent Decree requirements TMDL to be
  completed March 2001
• Growth of urban areas and agricultural use
• Water quality problems
• Chloride affects agricultural beneficial uses
• Chloride concentration has increased

6
Historical Chloride Concentration, Calleguas
Creek System, 3 Areas
7
Watershed Chloride Loading
8
Calleguas Creek Chloride TMDL

• History Impaired Conditions
• Proposed Water Quality Objectives
• Critical Conditions
• Waste Load Allocations
• Implementation Plan

9
WQO Specification

• WQO specified for each reach to protect
  beneficial uses
• existing beneficial uses
• local conditions
• Allowable load takes advantage of assimilative
  capacity pollutant load a waterbody can accept
  without affecting beneficial uses (i.e.,
  exceeding WQO)

10
WQO Selection Cl- Concentrations and
Agricultural Beneficial Uses

• Rainwater 5-20 mg/L
• First Effect on Avocado 70-100
• Avocado Sustained Yield 100-120
• Average Crop Sustained Yield 140-160
• Avocado Damage 170-180
• Aquatic Life Drinking Water 230-250
• Seawater 18,000

11
Proposed WQOs by Reach

• Where avocados are most Cl--sensitive 110
  mg/L (Arroyo Simi / Las Posas system)
• Where other crops control 150 mg/L (Remainder of
  watershed)
• Where groundwater recharge controls Protect most
  sensitive groundwater use

12
(No Transcript)
13
Calleguas Creek Chloride TMDL

• History Impaired Conditions
• Proposed Water Quality Objectives
• Critical Conditions
• Waste Load Allocations
• Implementation Plan

14
Critical Conditions Linkage Model
15
Critical conditions Projected Effects of Flow
Diversion, Reach 9B
16
Seasonality Monthly Average Flow, Three Locations
17
Patterns of Daily Discharge at Conejo Creek
Gauge, Jan - Feb 1983
18
Low Flow Percent by Month, Calleguas Creek at
Potrero Road
19
Critical conditions used for Waste Load
Allocations

• Routine days Based on maximum non-storm flow
  and load
• Drought conditions Based on post-drought
  flow and load

20
Calleguas Creek Chloride TMDL

• History Impaired Conditions
• Proposed Water Quality Objectives
• Critical Conditions
• Waste Load Allocations
• Implementation Plan

21
TMDL Approach Allocating loads to meet WQOs
22
Margin of Safety

• Implicit
• Conservative assumptions in LAs and critical
  flow conditions
• Explicit
• In-stream numeric target less than WQO ( target
  x 110 WQO )

23
Basis, Proposed WLAs, North Routine
24
Proposed WLAs Routine Conditions
25
Proposed WLAs Drought Conditions
26
Calleguas Creek Chloride TMDL

• History Impaired Conditions
• Proposed Water Quality Objectives
• Critical Conditions
• Waste Load Allocations
• Implementation Plan

27
Implementation Summary

• Target in Arroyo Simi attainable with Cl-
  removal for major and minor dischargers
• Target in Conejo Creek usually attainable at
  Hill Canyon WWTF with present eqpt.
• Downstream impacts remedied by others
• Minor dischargers may need to use treatment eqpt.
• Calleguas Creek main stem target attainable with
  treatment at Camarillo WWTP / Camrosa WWRF
• Minor dischargers may need to use treatment eqpt.
• Brine line to carry saline waste
• Diversion of desalted water (lower Conejo)
  accommodated--minimum flow remains in stream

28
Enforcement

• NPDES Permits
• Waste Discharge Requirements
• Pollution Prevention Plans
• Porter Cologne 13263.3(d)(1)

29
Schedule for Proposed Actions

• TMDL and Technical Support Evaluations available
  for public comment October 2001
• Revised WQO adoption 2002
• TMDL adoption 2002
• Implementation Phased to brine line completion

30
Concluding Summary

• WQOs determined by reach
• Critical conditions used to calculate WLAs
• Max. non-storm flow all days except storms
• Post-drought loadings all drought periods
• Implementation plan accommodates financially
  efficient remedy strategy
• Economic calculations project costs to be
  attainable, may be equitably distributed

31
Basis, Proposed WLAs, South Routine
32
Basis, Proposed WLAs, Calleguas Creek Main Stem
Routine Conditions
33
Statistical calculations Drought
34
Calleguas Creek Chloride TMDL

• History Impaired Conditions
• Selection of Numeric Targets
• Critical Conditions
• Waste Load Allocations
• Implementation Plan

35
Calleguas Creek Chloride TMDL

• History Impaired Conditions
• Selection of Numeric Targets
• Critical Conditions
• Waste Load Allocations
• Implementation Plan

36
Critical conditions Routine days

• Based on maximum non-storm flow/load
• Linkage modeled using flow/loads for critical
  ile flow (statistical method)
• Numeric targets determined specific to each
  reach depend on flow conditions, known variation
  of groundwater loads, WQOs

37
Critical conditions Drought

• Based on post-drought flow/load
• Numeric targets specific to each reach depend on
  flow, groundwater loads, WQOs
• Begins June 1 when previous 12 months rainfall lt
  15ile distribution (11 inches)
• Ends June 1 when previous 12 months rainfall gt
  25ile distribution (12.2 inches)
• Distribution data NWS CA Zone 6

38
Mass Balance Example Hill Canyon, Reach 10
39
Beneficial UsesAgriculture

40
Beneficial Uses Ecosystem and Human Health
41
Assimilation of Waste
42
Calleguas Watershed Reaches
43
Summary of TMDL Results

• WLAs lb/day (mg/L at current flow)
• Simi Valley WQCP
• Ventura Co. WWTP
• Hill Cyn WWTF
• Camarillo WWTP
• Camrosa WWRF
• (show also reduction?)
• Minor dischargers Conc. equal to numeric target
  (WQO-MOS) for each reach

44
Calleguas Creek System Reach Designations, Ben.
Uses, and WQOs

• Reach designations sources?
• WQOs selected by reach
• REFER TO MAP

45
WLA Calculation Basis

• Achieve numeric target specified for each
  reach
• WLAs computed using LAs and flow during
  critical conditions
• Maximum non-storm routine days
• Post-drought drought periods
• In-stream explicit margin of safety 10
