The Fedora Project March 10, 2003

1
The Fedora Project March 10, 2003

• Sandy Payette
• Cornell Information Science

2
Motivation

• The Problem of Complex Content

3
Digital Library Contentnot just documents ...

• Some familiar objects

• Complex, compound, dynamic objects

4
Key Research Questions

• How can clients interact with heterogeneous
  collections of complex objects in a simple and
  interoperable manner?
• How can complex objects be designed to be both
  generic and genre-specific at the same time?
• How can we associate services and tools with
  objects to provide different presentations or
  transformations of the object content?
• How can we associate specialized, fine-grained
  access control policies with specific objects, or
  with groups of objects?
• How can we facilitate the long-term management
  and preservation of complex objects with
  dependencies on distributed content and services?

5
Shortcomings of commercial digital library
products

• Narrow focus on specific media formats (e.g.
  image databases, document management)
• Fail to effectively address interrelationships
  among digital entities
• Fail to address interoperability no open
  interfaces to facilitate sharing of services no
  standard protocols for cross-system
  interoperability
• Fail to provide facilities for managing programs
  and tools that are integral to delivering digital
  content.
• Not extensible does not enable easy integration
  of new tools and services
• Do not address fine-grained access control and
  preservation issues.

6
The Flexible Extensible Digital Object Repository
Architecture (FEDORA)

• DARPA and NSF-funded research at Cornell
  (1997-present)
• CORBA-based reference implementation
  (Payette/Lagoze)
• Extensive interoperability testing (with
  Arms/Blanchi/Overly)
• Policy Enforcement (Payette/Schneider)
• Interpreted and re-implemented at U of Virginia
  (1999-)
• Simple web-oriented implementation, focused on
  access to collections
• Java servlet and relational db
• Testbed of 10,000,000 objects with performance
  metrics (1999-2001)
• Mellon-Funded FEDORA Software(2002-)
• University of Virginia and Cornell - joint
  development
• Open source
• Web services and XML
• Mediation of distributed services
• Preservation focus

7
The Fedora Architecture

• Digital Object Model
• The Repository
• Web Services

8
FEDORA Basic Object Architecture

• Digital Object Model
• Container to aggregate digital content of any
  type
• Data or metadata
• Local or distributed
• Behavior definitions (like abstract interfaces)
• Hooks to external services
• Enables multiple disseminations of content

9
Digital Object Model Functional View

• dynamic

Application

• services

10
Digital Object Model Architectural View
Globally unique persistent id
Persistent ID (
PID
)
Public view access methods for obtaining
disseminations of digital object content
Disseminators
Internal view metadata necessary to manage the
object
System
Metadata
Datastreams
Protected view content that makes up the
basis of the object
11
Digital Object Model Service Relationships
12
FEDORA Basic Repository Architecture

• Repository System
• Object Management
• Lifecycle (Ingest/create ? Store ? Delete ?
  Approve ? Purge)
• Validation
• PID Generation
• Version management
• Access Control
• Preservation support
• Object Access
• Object Dissemination
• Object Reflection
• Service Mediation

13
FedoraA Programmers View

• Understanding the system implementation
• Web Services
• Server Design

14
What is a Web Service?

• A distributed application that runs over the
  internet.
• An addressable network endpoint which receives
  structured messages returns structured responses.
• A web application that publishes an open
  interface through which clients can send requests
  and received responses.

15
How is this different from plain old web
applications?

• Formally defined API (application programming
  interface) defines a set of abstract operations
  for a web service
• Published bindings for client to run operations
• Standard protocol for invoking operations on the
  service.
• XML as standard means of encoding service
  requests and responses.

16
Why are Web Services important?

• Interoperability
• Web applications can interact and build upon each
  other
• Data is transferred in an interoperable manner
  (HTTP)
• Data is encoded in an interoperable format (XML)
• Works in decentralized, distributed,
  operating-system independent environment.
• Standards-oriented
• Means to expose complex operations with rich data
  typing (via XML Schema language typing)
• Ease of integrating distributed systems via the
  Web
• W3C effort to develop this service architecture

17
How are Web Services Implemented?

• Simple Object Access Protocol (SOAP)
• SOAP is a messaging protocol that can run over
  different transport protocols (e.g., HTTP, SMTP)
• Operation oriented (send a request to a end
  point)
• Like CORBA, RMI, DCOMbut for Web and simpler
• Application APIs can be defined and published
  using the Web Service Description Language (WSDL)
• Requests and responses sent as XML messages
• Supports simple and complex data typing in
  requests and responses
• Supports transmission of binary data within
  requests or response packages

18
How are Web Services Implemented?

• REST (Representational State Transfer)
• URI HTTP XML
• URI/resource driven message built into a URL
• HTTP GET or POST
• Response is XML data
• Issues
• Not a standard, but a style of doing web apps
  arguably it just gives a fancy name to how lots
  of people do applications on the web by default
  nothing really new here just argues to do things
  the way we have been, maybe a little more
  standard by using XML.
• Fragile service definition URLs change
• No data typing on requests
• Limited ability to transmit complex requests on
  URL
• W3C behind SOAP one strong voice out there for
  REST (Prescod).

19
Example of Web Service using SOAP
My Application
SOAP Request (XML)
Google Web Service
SOAP/HTTP
SOAP/HTTP
doSpellingSuggestion(payet)
payette
SOAP Response (XML)
20
XML SOAP Request
lt?xml version"1.0" encoding"UTF-8"?gt SOAP-ENVEn
velope xmlnsSOAP-ENVhttp//schemas.xmlsoap.org/s
oap/envelope/
xmlnsxsi"http//www.w3.org/1999/XMLSchema-inst
ance
xmlnsxsd"http//www.w3.org/1999/XMLSchema"gt
ltSOAP-ENVBodygt ltmdoSpellingSuggestion
xmlnsm"urnGoogleSearch"gt ltkeygt/e325JlNPASJult/k
eygt ltphrasegtpayetlt/phrasegt lt/mdoSpellingSuggest
iongt lt/SOAP-ENVBodygt lt/SOAP-ENVEnvelopegt
21
XML SOAP Response
lt?xml version"1.0" encoding"UTF-8"?gt ltSOAP-ENVE
nvelope xmlnsSOAP-ENV"http//schemas.xmlsoap.org
/soap/envelope/"
xmlnsxsi"http//www.w3.org/1999/XMLSche
ma-instance"
xmlnsxsd"http//www.w3.org/1999/XMLSchema"gt
ltSOAP-ENVBodygt ltns1doSpellingSugges
tionResponse xmlnsns1"urnGoogleSearch"
SOAP-ENVencodingStyle"http//sc
hemas.xmlsoap.org/soap/encoding/"gt
ltreturn xsitype"xsdstring"gtpa
yettelt/returngt lt/ns1doSpellingSuggestionRespons
egt lt/SOAP-ENVBodygt lt/SOAP-ENVEnvelope
gt
22
Fedora and Web Services

• Fedora Repository system exposed as two related
  Web services
• Access (API-A) and Management (API-M)
• Both described using WSDL
• Both have SOAP and HTTP bindings
• Back-end services
• Digital object behaviors implemented as linkages
  to other distributed web services
• Service binding metadata (WSDL) stored in special
  Fedora objects.
• Fedora Repository system acts a mediator to these
  services.

23
Fedora Web Services View
24
Fedora Server Design

• 3-Tiered Architecture
• Modular Extensible
• System Diagram

25
Server Design 3 Layers
26
System Diagram
27
Fedora Implementation Technologies

• Fedora Web Services Layer
• Apache Axis for SOAP over HTTP
• Apache Tomcat 4.1
• Core Repository System
• Sun Java J2SDK1.4
• Xerces 2-2.0.2 for XML parsing and validation
• Saxon 6.5 for XSLT transformation
• Schematron 1.5 for validation
• MySQL-2.23.52 and Mckoi relational database
• Deployment Platforms
• Windows 2000, NT, XP
• Solaris
• Linux

28
DEMO

• Local Repository

• www.fedora.info

29
Deployment Partners

• Los Alamos National Laboratory Research Library
• Library of Congress Motion Picture and Recorded
  Sound Division
• Indiana University Digital Library group
• Kings College London Humanities Computing
• NYU Humanities Computing
• Northwestern University Academic Computing
• Oxford Oxford Digital Library and The Refugee
  Studies Center
• Tufts Digital Collections and Archives Department
