Steel Erection

1
Steel Erection

• CE311 Case Study Building

2
Anchor Rods and Plates

• Columns must be anchored to the foundation with
  embedded rods
• These must be accurately set by the concrete
  subcontractor.

3
Anchor Rods and Plates
4
Anchor Rods and Plates
5
Anchor Rods and Plates
6
Anchor Rods and Plates

• The exact locations of anchor bolts must be set
  to within a tolerance of ¼.
• Typically, a theodolite is set up on control
  pins, representing column lines, on the perimeter
  of the building.
• The theodolite will sight along the column line
  and the center of the column bolt-pattern will be
  marked on the concrete formwork

7
Anchor Rods and Plates
8
Cranes

• Steel is lifted with a crane.
• There are several types.

9
Crane Mobile, Rubber-Tired, Hydraulic
10
Crane Mobile, Track-Mounted, Cable
11
Crane Mobilization

• Cranes often must be assembled on-site. This can
  take a day or two.
• Typically, a smaller crane is needed to assemble
  the bigger crane.

12
Crane Mobilization
13
Crane Mobilization
14
Crane Mobilization
15
Crane Mobilization
16
Crane Mobilization
17
Steel Transportation

• Up to about 50000 lbs of steel is stacked on a
  trailer truck (assuming it is done legally)
• Typically, columns are stacked on top because
  they will be erected first
• Beams are stacked on the bottom because their
  erection follows the columns

18
Steel Transportation
Columns
Beams
19
Shakeout
20
Shakeout

• When steel arrives onsite, it is normally spread
  out and organized, a process called shakeout
• In confined places, like Manhattan, this often
  must occur inside the building.

21
Shakeout
22
Shakeout
23
Shakeout
24
Shakeout
25
Shakeout
26
Shakeout
27
Shakeout
28
Erecting the First Columns
Base of Column
Top of Column (note splice plates)
29
Erecting the First Columns
30
Erecting the First Columns
31
Column Base Plate on Foundation
Column
Beam or Girder
Base Plate
32
Erecting Beams
33
Erecting Beams
34
Erecting Beams
35
Erecting Beams
36
Erecting Beams
37
Erecting Beams
38
Erecting Beams
39
Erecting Beams
40
Erecting Beams
41
Erecting Beams
42
Erecting Beams
43
Erecting Beams
44
The Foremans Notes The Foreman Directs the
Order of Erection, Piece-by-Piece
45
Column Erection Next Tier
46
Column Erection Next Tier
47
Column Erection Next Tier
48
Temporary Bracing with Plumbing Cables

• The final bracing for this simple-braced building
  is normally inserted after the building has been
  plumbed up.
• Hence, temporary bracing cables are used to
  stabilize the building during construction
• They serve the additional purpose as plumbing
  cables Ironworkers use turnbuckles on the
  cables to rack the building laterally until a
  surveyor has determined that the building is
  plumb (i.e., vertical)

49
Temporary Bracing with Plumbing Cables
50
Temporary Bracing with Plumbing Cables
51
A Turnbuckle Used to tighten cables in order to
plumb the building
52
Typical Connections Beam-to-Girder
53
Typical Connections Beam-to-Girder
piecemark
54
Typical Connections Open-Web-Joist on Girder
55
Typical Connections Beam-to-Girder (note metal
decking on top)
56
Beams, Joists, Girder, Metal Deck
57
Typical Connections Beam-to-Column (simple)
58
Typical Connections Beam-to-Column (simple)
59
Typical Connections Beam-to-Column (simple)
Column-to-column splice places
60
Typical Connections Column Base Plate
(connection to foundation)
61
Typical Connections Column-to-Column
Smaller Column Above
Splice Plates
Bigger Column Below
62
Typical Connections Column-to-Column
Smaller Column Above
Splice Plates
Bigger Column Below
63
Typical Connections Beam-to-Foundation Wall
64
Bolt-Up Impacting the Bolts
65
Bolt-Up Impacting the Bolts
66
Metal Decking (the concrete floor is poured on
this)
67
Metal Decking (the concrete floor is poured on
this)
68
Welding Metal Decking
69
Welding Metal Decking
70
Metal Decking Holes and Penetrations
71
Almost Complete
72
Completed Building
