Adaptive Agentbased Grid Resource Management

1
Adaptive Agent-basedGrid Resource Management

• Tariq Abdullah

2
Future Computing Application

• Future High-energy physics experiments will
  generate 10 petabytes of data/day.
• The Digital Sky Survey will make many terabytes
  of astronomical photographic data
• Astrophysics (e.g., simulations of a supernova
  explosion or black hole collision)
• Climate modeling (e.g., simulations of a tornado
  or prediction of the earth's climate for the next
  century)
• Economics (e.g., modeling the world economy)
• Modern Meteorological forecasting systems
• Automotive/aerospace industry (e.g., simulations
  of a car crash or a new airplane design)
• Human Genome Folding (30,000 Human Genome
  proteins ) ? require 1,000,000 years of
  computational time on an up-to-date PC.

3
SOLUTION-1 IBM System Blue Gene

• Specification
• 131,000 IBM PowerPC processors
• 1-64 racks
• 1024 nodes/rack
• PowerPC 440 700MHz, two/node
• Peak performance/ rack 5.73TFlops
• Economics
• Starting price 1.5 million
• Development Time Cost 5 years 100 million
  dollars
• Installation
• Department of Energy's / National Nuclear
  Security Administration's Lawrence Livermore
  National Laboratory
• http//www.internetnews.com/ent-news/article.php/3
  432221

4
SOLUTION-2 Sun Grid Compute Utility

• The Network is the Computer (Sun Microsystems
  ltd.)
• Sun Fire dual processor Opteron-based servers
  with 4GB/RAM per CPU
• Solaris 10 (x64)
• Solaris 10 OS
• Sun N1 Grid Engine 6 software
• Grid Network Infrastructure of 1GB switched Data
  Network and 100 MB dedicated management network
• Web-based access portal
• Internet-only access to upload data and
  applications (no physical access to location)
• Storage allocation of up to 10 GB per user
  account.

Price 1/ CPU hour
5
SOLUTION-3 Adaptive Agent-based Grid

• Develop a Grid-based application
• Use Idle Available Resource of the
  underlying network
• Focus will be on Resource Management System
  (RMS) of the Grid
• To make RMS, Adaptive apply Software Agents
• (We will revisit this slide again)

6
Computer Systems Architecture
7
Peer-to-Peer Architectures

• Pure
• A distributed system without any centralized
  control.
• All nodes are equivalent in functionality
  (SERVENT SERVer cliENT)
• Example Gnutella, Freenet, Chord, CAN, Tapesty,
• Hybrid
• There is a central server that maintains
  directories of information about registered users
  to the network.
• The end-to-end interaction (data exchange) is
  between two peer clients.
• Example Napster, Kazaa

Hybrid P2P
8
Hybrid Systems

• Centralized indexing Each peer maintains a
  connection to the central server, through which
  the queries are sent. (Napster)

• Decentralized indexing super-peers maintain
  the central indexes for the information shared by
  local peers connected to them. (Kazaa)

9
Peer-to-Peer Applications

• File Sharing content storage and exchange
• Distributed Computing resource sharing between a
  number of networked computers.
• Collaboration communication (instant messaging,
  online games), and collaboration (collaborative
  editing).
• Platforms infrastructure to support distributed
  applications using P2P mechanisms.

10
Distributed Systems

• Distributed System (DS) is one in which
  components located at networked computers
  communicate and co-ordinate their actions only by
  message passing

11
Challenges Faced in Building DS

• Heterogeneity
• Openness
• Security
• Scalability
• Failure handling
• Concurrency
• Transparency

12
GRID Computing

• A hardware and software infrastructure that
  provides dependable, consistent, pervasive, and
  inexpensive access to high-end computational
  capabilities (Ian Foster)

13
Comparison b/w P2P and Grid
14
Grid Computing Applications

• Distributed supercomputing use grid to solve
  very large problems that can not be solved on a
  single system and need lots of CPU, memory, etc
• High-Throughput Computing use grid to schedule
  large numbers of loosely coupled or independent
  tasks, with the goal of putting unused processor
  cycles
• On-Demand computing use grid capabilities to
  meet short-term requirements for resources that
  cannot be cost-efficiently or conveniently
  located locally
• Data-Intensive Computing use grid for
  synthesizing new information from data that is
  maintained in geographically distributed
  repositories, digital libraries, and databases
• Collaborative Computing use grid to access
  securely a set of distributed services by various
  remote clients

15
Grid Types

• Computational Grid
• Distributed super computing
• High throughput
• Data Grid
• Service Grid
• On Demand
• Collaborative
• Multimedia

16
Grid Toolkits

• Globus
• Condor-G
• Legion
• Nimrod-G
• Ninf-G
• NetSolve
• GridSim

17
Grid Projects

• TeraGrid
• NAREGI
• GRIDS
• grasp
• DATAGRID
• UNICORE Plus
• DATATAG
• Detailed listing can be found at
• http//gridcafe.web.cern.ch/gridcafe/gridproject
  s/projects.html

18
Grid Components

• Portal user interface
• Security
• Broker
• Scheduler
• Data management
• Job Resource Management System (RMS)
• Others (like IPC, Accounting, ...)

19

• GRID Resource Management System

20
Grid RMS Functions

• Standard interface for using remote resources
• Coordinate all Local resource management system
  within multiple or distributed Virtual
  Organizations (VOs)
• Job Submission
• Resource Discovery
• Resource Selection
• Scheduling
• Co-allocation
• Job Monitoring, etc.

21
Challenges in RMS

• Scalability As Grid size increases, it is
  necessary to decentralize their services to avoid
  bottlenecks and ensure scalability.
• Adaptability As the availability of resources
  may fluctuate due to connection/disconnection of
  computing resources, the system needs to adapt
  itself to this changes.
• Reliability The system should be able to
  tolerate failures and recover from them.
• Manageability management includes various
  aspects, such as complexity, resource management,
  fault tolerance, and performance analysis.




22
PROPOSED SOLUTION

• Dynamic, Decentralized
• Self-organizing, Self-adaptive

23
Economic Framework

• Different economic Approaches
• English Auction (First-price, open cry,
  ascending)
• Dutch Auction (Open cry, descending)
• Vickrey Auction (Second-price, sealed bid)
• .
• Reference of Behnazs work

24
Software Agent

• An agent is a computer system that is situated
  in some environment, and that is capable
  autonomous actions in this environment in order
  to meet its design objectives (Wooldridge
  Jennings)

• Agents are normally defined with help of their
  properties
• Autonomy
• Intelligence
• Social Ability
• Reactivity
• Mobility

Relevance to work
25
Adaptive Agent-based Grid RMS

• Develop a Grid-based application
• Use Idle Available Resource of the
  underlying network
• Focus will be on Resource Management System
  (RMS) of the Grid
• To make RMS, Adaptive apply Software Agents

26
Our Focus

• Resource management the process of managing
  available resources and system workloads in
  highly dynamic environment. Resource management
  includes resource discovery, resource selection,
  resource access.
• Self-organization system should be able to
  reconfigure itself in order to provide the
  necessary resources for the tasks are currently
  processed in the system
• Self-adaptation system should be able to adapt
  itself according to changing environment
• Fault tolerance system should be recovered in
  case of node failures. (error detection, error
  isolation and error correction)

27
System Model

• Consumers nodes executing tasks and looking for
  additional resources
• Producers nodes lying idle and looking for
  additional jobs to execute
• Matchmakers mediator between consumers and
  producers allowing tasks to be delegated
• Receives queries-offers
• Matches what can be match
• Reports the result back
• Matchmaker decides on basis of PRICE offered by
  producer and affordable price by a consumer
• Price will be different for different commodities
  (CPU cycles, bandwidth, storage, memory etc)

28
Matchmaking Process
Matchmaker Agent
Advertisement DB
Service request
Capability description
Result of matching
Requester Agent
Provider Agent
Resources
Jobs
29
Dynamic Adaptive Matchmaking Process
30
How to Promote/Demote a node?
Price will be different for different commodities
(CPU cycles, bandwidth, storage, memory etc)
31
Future work

• Design simplest agent structure
• Achieve System Adaptation
• Migration tasks between segments to balance
  workload
• Communication between matchmakers
• Design an architecture for node reconfiguration
• Design of robust mechanism for failure handling
  at a node
• .
• ..
• Testing the mechanism in the most realistic
  distributed environment such as Planet Lab.

32
