Title: PRO Totalizer presentation


1
DENEXLaser CopySensors and solutions for the
Printing Industry
DENEX Systems Technology AB Stockholm,
Sweden www.denex.se www.denexinc.com
2
DENEX PRO LapSensor
The PRO LapSensor is based on the standard DENEX
Laser CopySensor PRO and use its serial
communication link to a PC workstation
3
DENEX PRO LapSensor
  • Measures constantly the distance between each
    copy.
  • Counts the number of copies on each disc.
  • Stores data for each disc
  • One report for each disc

Report
RS-232 Communication
Stop signal
Disc to be rewinded and checked
Clamp signal
Disc to inserter or storage
DENEX LCS PRO Connection Box
PRO Sensor
Encoder with 1 pulse/mm
4
Competitive Analysis
DENEX PRO LapSensor
  • Accuracy of DENEX counter superior to other
    solutions
  • DENEX system is a neat solution with no
    additional hardware required
  • Simple installation using DENEX Connetion Box
  • Higher quality of report presentation
  • Cheap solution

5
DENEX PRO LapSensor
Installation at contract printer
Report
RS-232 Communication
Stop signal
Folder
Clamp signal
Disc to storage
Connection box
PRO Sensor
Encoder wheel 1 pulse/mm
6
Dual winder installation
DENEX PRO LapSensor
Line splitter
Line splitter
Line splitter
A
B
B
A
7
DENEX PRO Lap Sensor
The DENEX Solution to monitor disc quality
Standard PC in cabinet
DENEX PRO Lap Sensor
8
For more information about our products see
our web sitewww.denex.comor contact
DENEXSweden Phone 46 8 556 708 00USA Phone
1 412 369 35 90Spain Phone 34 91 433 73 54
Head Office DENEX Systems Technology AB Box 90
135 S-120 21 Stockholm, Sweden Telephone 46 8
556 708 00 Telefax 46 8 556 708
20 sales_at_denex.se www.denex.com
DENEX INC. Andre Plaza 8035 McKnight
Road Pittsburgh, PA 152 37, USA Telephone 1 412
369 3590 Telefax 1 412 369 3599 gcarrol_at_denexinc.
com
