Reduce MTTR

1
Reduce MTTR

• with Combined Performance Management and Forensic
  Analysis

2
Introduction

• Brian Robertson
• Solutions Marketing Manager
• Netscout Systems, Inc.

Jim Bauer Director of Network Infrastructure
Services
3
Agenda

• Network Performance Management Challenges
• Meeting the Challenge with Performance Management
  Solutions
• Top-Down Troubleshooting Approach
• Case Studies
• Survey Results

4
Balancing Pro-active performance management With
Post-incident investigation and analysis

• Challenge
• Need proactive monitoring and analysis for
  everyday troubleshooting and capacity planning
• Intermittent problems wreak havoc on the
  performance of business-critical and
  revenue-generating applications
• Problem cause is often difficult to discover
• Needs
• Ability to automatically analyze traffic and
  simultaneously retain evidence to recreate a
  complex incident and discover its culprit without
  having to wait for the event to recur

5
Who Finds Performance Problems?
Source NetScout Systems Survey March 2007 N
232
6
Performance Problem Lifecycle
7
The Ultimate Payoff Reduced MTTRFaster time
to resolution/minimized user impact
Service Outage
User Calls Help Desk
End-Users Impacted
Final Verification
End Users Not Impacted!
time
Problem Origin
8
What is needed to Lower MTTR

• A Performance Management System that
• Combines key performance indicator (KPI)
  monitoring and analysis with continuous packet
  capture for post event data mining
• Top down approach to troubleshooting
• Application Fabric Monitoring
• Has an architecture built for high performance
  recording and infrastructure monitoring
• Uses a high capacity, highly available hardware
  platform

9
Unique Approach Three-Tier Data Architecture
for Rapid Top-Down Workflow
Top Down
Data Set
KPIs Retransmits, VoIP QoS Errors, App Resp
Time, etc
Flows CDM - Applications/Services Conversations,
Utilization, Volume, etc
Packets Header and Payload
10
Step 1 DetectionIs there an issue on the
network?

• Trending, alarming and analytical data on key
  performance indicators will provide
• Notification when link or application utilization
  increases
• See when unwanted protocols are on the network
• Measure VoIP links for Jitter, Packet Loss or
  High MOS scores
• This information has to be available in real-time
  and historically
• Collaboration with groups across the organization
  requires quick and easy distribution of reports

11
Understand how your business uses the network
Do you know all the applications running on your
network? Application visibility provides
business justification for IT decisionsAre
there good reasons for an upgrade? Are there
non-business uses of the network?
12
Baseline response time of key business
applications
Looking at several parameters such as MPLS,
VoIP, or QoS classes can provide critical data
in regards to the health of the network.
Response time provides insight into the end-user
experience and should be an integral part of any
performance management audit
13
Top Down Approach for Rapid TroubleshootingPower
Alarms - Micro-Burst Alarming

• Based on traffic rates exceeding a 1 millisecond
  threshold
• Interval can be configured as low as 5
  milliseconds up to 1 second
• An alarm is received when the burst starts and
  one when it ends
• Evidence is launched based on applications,
  hosts, conversations during the alarm interval

14
Step 2 DiagnosisWhat is the root cause of the
issue?

• Look at the flows associated with the KPI
  effected by the issue
• Applications
• Conversations
• Utilization
• Volume
• Historical view of trends for flows show
• When and where an issue commonly occurs
• Upward / downward trends for flows

15
Flow Based Troubleshooting Example
Music downloads from 3 different sites same user
16
Troubleshoot Intermittent or Subtle Problems with
Application Fabric Monitoring

• Efficient on-board analysis
• Sends only the data requested by the client
• Does not require entire data capture files to be
  sent
• Deep forensic analysis
• Logically move from KPI to Flow to Packet
• View data with millisecond granularity
• Record packet level audit trails to view subtle
  and intermittent issues

17
Highly Efficient Architecture
18
Highly Efficient Architecture
On Board Analysis
Client Analysis
Efficient On-board Analysis
Inefficient Client-based Analysis
19
Superior Forensic Analysis

• Expert Analysis
• Expert Zoom and Data Mining interface with
  multiple workspaces
• Broad support of over 1000 protocol decodes
• TCP Session Follow
• Bounce Diagrams
• Intuitive, flexible GUI
• Multi-user, Web-based console
• Eases search process
• Incident Reports for collaborating and
  communicating with others

20
Case in Point Solution Architecture Wins Business

• Bank in North America has assets approaching 300
  Billion
• 2 trading floors Chicago, New York, NJ
  disaster recovery
• Pain Point Needs continuous capture and
  monitoring on trading floors
• Need both flow based monitoring and trending for
  troubleshooting and capacity planning Plus
  recording for in-depth analysis because of the
  value of the financial trades
• Current solution in Chicago not working network
  managers constrained by time delays in viewing
  packet trace files when pulling them over the
  network.

Able to perform top down troubleshooting with
detailed analysis of applications and
conversations. When necessary for in-depth
troubleshooting the actual packets are available
for event reconstruction and forensic data
mining without adding load to the network.
21
High Definition Visibility Deep Forensics
22
Quickly navigate to the needed level of
granularity consistently maintaining context as
you go deeper
What do you do if you need a packet decode, but
the offending traffic occurred two hours ago???
23
Step 3 VerificationHave we resolved the issue?

• Does the KPI meet expectations now that changes
  have been implemented?
• Re-evaluate response time of critical
  applications
• Are key applications being delivered within
  previous response time levels? Have there been
  negative or positive impacts ? Have VoIP QoE
  Metrics changed?
• Determine whether bandwidth utilization meets
  estimates
• If the changes resolve the issue the baseline
  should be reset

24
Case in Point Troubleshooting employee remote
access problem

• New England based insurance company
• Pain Point Remote employees having trouble
  accessing network resources
• LDAP servers source of many problems
• Intermittent issues were elusive
• Application Fabric Monitoring provided continuous
  capture and recording for in-depth
  troubleshooting forensics

Discovered two LDAP servers had their
authentication databases out of sync and were
spending their cycles trying to sync their
databases
25
Step 4 On-Going ManagementHow is your network
growing and changing over time?

• Converged networks need unified performance
  management
• Continuation of the tasks you performed in
  detection and post-deployment impact phases
• Troubleshooting - requiring real-time information
• Planning and traffic engineering - requiring
  longer-term historical information
• Communication to key constituents
• Easy to create, customizable reports

26
Visibility into how the network is usedComplete
Application monitoring and profiling with CDM
Virtualization

• Application identification - Common matrix for
  multimedia voice, video and data
• Well-known, complex, custom, URL-based apps
• VoIP for RTP, SIP, MGCP, H.323, SCCP
• Industry specific i.e. FIX protocol, IP
  Multicast and PACs
• Application discovery for TCP and UDP unknown
• No data reduction all applications
• QoE / Response time analysis
• Proactive Alarms for thresholds, response times,
  time over threshold and microbursts
• Virtual interface analysis for VLANs, VRFs, QoS,
  or sites
• Post-capture filters by variety of metrics, not
  just by IP address, ie CDM port

27
Added Benefits of a Unified Performance
Management System

• Minimize Total Cost of Ownership (TCO) by
  choosing Performance Management Systems that
• Support all applications, conversations and
  diverse network technologies that make up the
  network environment
• Present
• Future
• Uses a common interface for all data sources
• Deep Forensic data
• Probe Flow data
• NetFlow / sFlow

28
Common Data Model More Performance Metrics for
services or applications
VoIP packet loss
Link Usage over Time
Details from drill down on spike
29
Responsiveness Tracking with QoE

• Quality of Experience Tracking (QoE)
• Key Features
• Adds support for Virtual Interfaces
• Granularity down to 1-minute
• Tracks TCP and HTTP Error counters
• Adds support for both passive and active VoIP
  metrics
• Adds support for IP-SLA transactions

TCP Errors
30
Responsiveness Tracking with QoE Visibility with
1 Minute Granularity
Response Time with 1 minute resolution
QoE Virtual Interface Support
31
Application Discovery Visibility into Unknown
Traffic

• Identify Port-to-Port conversations for unknown
  applications
• Can be logged Historically with 1-minute
  resolution

32
Survey Results

• In 2007 NetScout partnered with Ashton, Metzler
  and Associates
• Goal To see what impact performance management
  systems had in diagnosing critical issues
• 138 Participants were asked how long it took to
  diagnose a critical network issue
• Before implementing a Performance Management
  Solution
• After implementing a Performance Management
  Solution

33
Improved MTTR with a Performance Management System
Before Implementing the nGenius Performance
Management System
After Implementing the nGenius Performance
Management System
69 Time Savings 6 Hours Time Savings
Source NetScout Systems Survey March 2007 N
138
34
Ability to Diagnose Issues in the First 3 Hours
Before Implementing the nGenius Performance
Management System
After Implementing the nGenius Performance
Management System
Percentage Increased from 26 to 77
Source NetScout Systems Survey March 2007 N
138
35
Summary Benefits of Proactive Management with
Post-incident analysis

• Reduced MTTR with a Unified Solution
• Must have vision into the network during the
  detection phase through to the on-going
  management phase of the performance problem
  lifecycle
• Must be able to support real-time and historical
  reporting
• Top down approach with context-sensitive data
  mining
• Store packets and report on flows concurrently
• Lower TCO with Architecture Advantages
• Flexible to support todays and tomorrows
  applications and network technologies
• Provide vision into the entire network not just
  certain pieces
• Highly Available Hardware Architecture
• Integrated automatic and ad-hoc reporting
  functionality for collaboration

36
About NetScout

• The most experienced team in the industry
• Founded in 1984
• Growing, profitable
• 102M revenues 2007
• World-wide distribution and support
• Winner of 2004 2006 Omega Northface Award for
  customer satisfaction

37
Case in Point Bates College

• 3000 Users
• Needed to see
• Who was using large amounts of resources
• Who was using the available bandwidth
• Number of flows
• Pain Point Needed to minimize impact of single
  users on resources
• Diagnostics to see service and applications
• Looking for heavily utilized links
• Needed more than layer 2 RMON devices

Please Welcome Jim Bauer Director of Network
Infrastructure Services
Company Confidential
