Chapter 7 Fires Within: Igneous Activity

1
Chapter 7 Fires Within Igneous Activity
2
The Nature of Volcanic Eruptions

• Characteristics of a magma determine the
  violence or explosiveness of an eruption
• Composition
• Temperature
• Dissolved gases
• The above three factors actually control the
  viscosity of a magma

3
The Nature of Volcanic Eruptions

• Viscosity is a measure of a materials
  resistance to flow
• Factors affecting viscosity
• TemperatureHotter magmas are less viscous
• CompositionSilica (SiO2) content
• Higher silica content higher viscosity
• Lower silica content lower viscosity

4
The Nature of Volcanic Eruptions

• Dissolved gases
• Gases expand within a magma as it nears Earths
  surface due to decreasing pressure
• The violence of an eruption is related to how
  easily gases escape
• In summary
• Basaltic lavas mild eruptions
• Rhyolitic or andesitic lavas explosive
  eruptions

5
Materials Extruded from a Volcano

• Lava flows
• Basaltic lavas exhibit fluid behavior
• Types of basaltic flows
• Pahoehoe lava (resembles a twisted or ropey
  texture)
• Aa lava (rough, jagged blocky texture)
• Dissolved gases
• 16 by weight
• Mainly H2O and CO2

6
Aa Lava Flow
Figure 7.5 A
7
Materials Extruded from a Volcano

• Pyroclastic materialsFire fragments
• Types of pyroclastic debris
• Ash and dustFine, glassy fragments
• PumicePorous rock from frothy lava
• CindersPea-sized material
• LapilliWalnut-sized material
• Particles larger than lapilli
• BlocksHardened or cooled lava
• BombsEjected as hot lava

8
A Volcanic Bomb
Figure 7.6 (top)
9
Volcanic Structures

• General features
• Opening at the summit of a volcano
• CraterSummit depression lt1 km diameter
• CalderaSummit depression gt1 km diameter produced
  by collapse following a massive eruption
• VentSurface opening connected to the magma
  chamber
• FumaroleEmit only gases and smoke

10
Volcanic Structures

• Types of volcanoes
• Shield volcano
• Broad, slightly domed shape
• Generally cover large areas
• Produced by mild eruptions of large volumes of
  basaltic lava
• Example Mauna Loa on Hawaii

11
Mauna Loa, a Shield Volcano on Hawaii
Figure 7.9
12
Volcanic Structures

• Cinder cone
• Built from ejected lava (mainly cinder-sized)
  fragments
• Steep slope angle
• Small size
• Frequently occur in groups

13
Cinder Cone Volcano
Figure 7.12
14
Volcanic Structures

• Composite cone (stratovolcano)
• Most are located adjacent to the Pacific Ocean
  (e.g., Fujiyama, Mount St. Helens)
• Large, classic-shaped volcano (1000s of ft. high
  and several miles wide at base)
• Composed of interbedded lava flows and
  pyroclastic debris
• Most violent type of activity (e.g., Mt.
  Vesuvius)

15
Mount St. HelensPrior to the 1980 Eruption
16
Mount St. Helens after the 1980 Eruption
17
Profiles of Volcanic Landforms
Figure 7.10
18
Volcanic Structures

• Nuée ardente
• Nuée ardenteA deadly pyroclastic flow
• Fiery pyroclastic flow made of hot gases infused
  with ash and other debris
• Also known as glowing avalanches
• Move down the slopes of a volcano at speeds up to
  200 km per hour

19
A Nueé Ardente on Mount St. Helens
Figure 7.15
20
Volcanic Structures

• LaharVolcanic mudflow
• Mixture of volcanic debris and water
• Move down stream valleys and volcanic slopes,
  often with destructive results

21
Other Volcanic Landforms

• Caldera
• Steep-walled depressions at the summit
• Generally gt1 km in diameter
• Produced by collapse
• Pyroclastic flow
• Felsic and intermediate magmas
• Consists of ash, pumice, and other debris
• Example Yellowstone Plateau

22
Formation of Crater Lake, Oregon
Figure 7.18
23
Other Volcanic Landforms

• Fissure eruptions and lava plateaus
• Fluid basaltic lava extruded from crustal
  fractures called fissures
• Example Columbia River Plateau
• Lava domes
• Bulbous mass of congealed lava
• Associated with explosive eruptions of gas-rich
  magma

24
Other Volcanic Landforms

• Volcanic pipes and necks
• PipesShort conduits that connect a magma chamber
  to the surface
• Volcanic necks (e.g., Shiprock, New
  Mexico)Resistant vents left standing after
  erosion has removed the volcanic cone

25
Intrusive Igneous Activity

• Most magma is emplaced at depth in the Earth
• Once cooled and solidified, is called a pluton
• Nature of plutons
• ShapeTabular (sheetlike) vs. massive
• Orientation with respect to the host
  (surrounding) rock
• Concordant vs. discordant

26
Intrusive Igneous Activity

• Types of intrusive igneous features
• DikeA tabular, discordant pluton
• SillA tabular, concordant pluton (e.g.,
  Palisades Sill in New York)
• Laccolith
• Similar to a sill
• Lens or mushroom-shaped mass
• Arches overlying strata upward

27
Igneous Structures
Figure 7.22 B
28
A Sill in the Salt River Canyon, Arizona
Figure 7.23
29
Intrusive Igneous Activity

• Intrusive igneous features continued
• Batholith
• Largest intrusive body
• Surface exposure gt100 km2 (smaller bodies are
  termed stocks)
• Frequently form the cores of mountains

30
Plate Tectonics and Igneous Activity

• Global distribution of igneous activity is not
  random
• Most volcanoes are located within or near ocean
  basins
• Basaltic rocks oceanic and continental settings
• Granitic rocks continental settings

31
Distribution of Some of the Worlds Major
Volcanoes
Figure 7.26
32
Plate Tectonics and Igneous Activity

• Igneous activity at plate margins
• Spreading centers
• Greatest volume of volcanic rock is produced
  along the oceanic ridge system
• Mechanism of spreading
• Decompression melting occurs as the lithosphere
  is pulled apart
• Large quantities of basaltic magma are produced

33
Plate Tectonics and Igneous Activity

• Subduction zones
• Occur in conjunction with deep oceanic trenches
• An island arc if in the ocean
• A volcanic arc if on a continental margin
• Associated with the Pacific Ocean Basin
• Region around the margin is known as the Ring of
  Fire
• Majority of worlds explosive volcanoes

34
Plate Tectonics and Igneous Activity

• Intraplate volcanism
• Occurs within a tectonic plate
• Localized volcanic region in the overriding plate
  is called a hot spot
• Produces basaltic magma sources in oceanic crust
  (e.g., Hawaii and Iceland)
• Produces granitic magma sources in continental
  crust (e.g., Yellowstone Park)

35
End of Chapter 7
