Towards Syntactically Constrained Statistical Word Alignment

1
Towards Syntactically Constrained Statistical
Word Alignment

• Greg Hanneman
• 11-734 Advanced Machine Translation Seminar
• April 30, 2008

2
Outline

• The word alignment problem
• Base approaches
• Syntax-based approaches
• Distortion models
• Tree-to-string models
• Tree-to-tree models
• Discussion

3
Word Alignment

• Parallel sentence pair F and E
• Most general map a subset of F to a subset of E

4
Word Alignment

• Very large alignment spaces!
• An n-word parallel sentence has n2 possible links
  and 2n2 possible alignments
• Restrict to one-to-one alignments n! possible
  alignments
• Alignment models try to restrict or learn a
  probability distribution over this space to get
  the best alignment of a sentence

5
Outline

• The word alignment problem
• Base approaches
• Syntax-based approaches
• Distortion models
• Tree-to-string models
• Tree-to-tree models
• Discussion

6
A Generative StoryBrown et al. 1990
7
The Framework

• F words f1 fj fn
• E words e1 ei em
• Compute P(F, A E) for hidden alignment variable
  A a1 aj an
• The major step decomposition, model parameters,
  EM algorithm, etc.
• aj i word fj is aligned to word ei

8
The IBM ModelsBrown et al. 1993 Och and Ney
2003

• Model 1 Bag of words word order doesnt
  affect alignment
• Model 2 Position of words being aligned does
  matter

9
The IBM ModelsBrown et al. 1993 Och and Ney
2003

• Later models use more implicit structural or
  linguistic information, but not really syntax,
  and not really overtly
• Fertility P(f ei) of ei producing f words in F
• Distortion P(t, p E) for a set of F words t in
  a permutation p
• Previous alignments Probs. for positions in F of
  the different words of a fertile ei

10
The HMM ModelVogel et al. 1996 Och and Ney
2003

• Linguistic intuition words, and their
  alignments, tend to clump together in clusters
• aj depends on absolute size of jump between it
  and aj1

11
Discriminative Training

• Consider all possible alignments, score them, and
  pick the best ones under some set of constraints
• Can incorporate arbitrary features generative
  models more fixed
• Generative models EM requires lots of unlabeled
  training data discriminative requires some
  labeled data

12
Discriminative AlignmentTaskar et al. 2005

• Co-occurrence
• Position difference
• Co-occurrence of following words
• Word-frequency rank
• Model 4 prediction

13
Outline

• The word alignment problem
• Base approaches
• Syntax-based approaches
• Distortion models
• Tree-to-string models
• Tree-to-tree models
• Discussion

14
Syntax-Based Approaches

• Constrain alignment space by looking beyond flat
  text stream take higher-level sentence structure
  into account
• Representations
• Constituency structure
• Inversion Transduction Grammar
• Dependency structure

15
An MT Motivation
16
Syntax-Based DistortionDeNero and Klein 2007

• Syntax-based MT should start from syntax-aware
  word alignments
• HMM model target-language parse trees prefer
  alignments that respect tree
• Handled in distortion model jumps should reflect
  tree structure

17
Syntax-Based DistortionDeNero and Klein 2007

• HMM distortion size of jump between aj1 and aj
• Syntactic distortion tree path between aj1 and
  aj

18
Syntax-Based DistortionDeNero and Klein 2007

• Training100,000 parallel FrenchEnglish and
  ChineseEnglish sentences with English parse
  trees
• Both E?F and F ? E combined with different
  unions and intersections, plus thresholds
• Test Hand-aligned Hansards and NIST MT 2002 data

19
Syntax-Based DistortionDeNero and Klein 2007

• HMMs roughly equal, better than GIZA
• Soft union for French hard union for Chinese
  competitive thresholding

20
Tree-to-String Models
21
Tree-to-String Models

• New generative story
• Word-level fertility and distortion replaced with
  node insertion and sibling reordering
• Lexical translation still the same
• Word alignment produced as a side effect from
  lexical translations

22
Tree-to-String AlignmentYamada and Knight 2001

• Discussed in other sessions this semester
• Training 2121 short JapaneseEnglish sentences,
  modified Collins parser output for English
• Test First 50 sentences of training corpus
• Beat IBM Model 5 on human judgements perplexity
  between Model 1 and Model 5

23
Subtree CloningGildea 2003

• Original tree-to-string model is too strict
• Syntactic divergences, reordering
• Soft constraint allow alignments that violate
  tree structure, but at a cost
• Tweak the tree side of the alignment to contain
  things needed for the string side
• Ex. SVO to OSV

24
Subtree CloningGildea 2003
25
Subtree CloningGildea 2003
S
VP
AUX
VP
do
26
Subtree CloningGildea 2003
27
Subtree CloningGildea 2003

• For a node np
• Probability of cloning something as a new child
  of np single EM-learned constant for all np
• Probability of making that clone a node nc
  uniform over all nc
• Surprising that this works

28
Subtree CloningGildea 2003

• Compared with IBM 13, basic tree-to-string,
  basic tree-to-tree models
• Training 4982 KoreanEnglish sentence pairs,
  with manual Korean parse trees
• Test 101 hand-aligned held-out sentences

29
Subtree CloningGildea 2003

• Cloning helps as good or better than IBM
• Tree-to-tree model runs faster

30
Tree-to-Tree Models

• Alignment must conform to tree structure on both
  sides space is more constrained
• Requires more transformation operations to handle
  divergent structures Gildea 2003
• Or we could be more permissive

31
Inversion Transduction GrammarWu 1997

• For bilingual parsing get one-to-one word
  alignment as a side effect
• Parallelbinary-branchingtrees with reordering

32
ITG Operations

• A ? A A
• Produce A1 A2 in source and target streams
• A ? ltA Agt
• Produce A1 A2 in source stream, A2 A1 in
  target stream
• A ? e / f
• Produce e in source stream, f in target stream

33
ITG Operations

• Canonical form ITG produces only one derivation
  for a given alignment
• S ? A B C
• A ? A B B B C B A C B C
  C C
• B ? ltA Agt ltB Agt ltC Agt ltA Cgt ltB Cgt
  ltC Cgt
• C ? e / f

34
Alignment with ITGZhang and Gildea 2004

• Compared IBM 1, IBM 4, ITG, and tree-to-string
  (with and without cloning)
• Training ChineseEnglish (18,773) and
  FrenchEnglish (20,000) sentences less than 25
  words long
• Test Hand-aligned ChineseEnglish (48) and
  FrenchEnglish (447)

35
Alignment with ITGZhang and Gildea 2004

• ITG best, or at least as good as IBM or
  tree-to-string plus cloning
• ITG has no linguistic syntax

36
Dependency Parsing

• Discussed in other sessions this semester
• Notion of violating phrasal cohesion
• Usually bad, but not always

37
Dependencies ITGCherry and Lin 2006

• Find invalid dependency spans assign score of 8
  if used by the ITG parser
• Simple model maximize co-occurrence score with
  penalty for distant words
• ITG reduces AER by 13 relative dependencies
  ITG reduce by 34

38
Dependencies ITGCherry and Lin 2006

• Discriminative training with an SVM
• Feature vector for each ITG rule instance
• Features from Taskar et al. 2005
• Feature marking ITG inversion rules
• Feature (penalty) marking invalid spans based on
  dependency tree

39
Dependencies ITGCherry and Lin 2006

• Compared Taskar et al. to D-ITG with hard and
  soft constraints
• Training 50,000 FrenchEnglish sentence pairs
  for counts and probabilities 100 hand-annotated
  pairs with derived ITG trees for discriminative
  training
• Test 347 hand-annotated sentences from 2003
  parallel text workshop

40
Dependencies ITGCherry and Lin 2006

• Relative improvement smaller in discriminative
  training scenario with stronger objective
  function
• Hard constraint starts to hurt recall

41
Outline

• The word alignment problem
• Base approaches
• Syntax-based approaches
• Distortion models
• Tree-to-string models
• Tree-to-tree models
• Discussion

42
All These Tradeoffs

• Mathematical and statistical correctness vs.
  computability
• Simple model vs. capturing linguistic phenomena
• Not enough syntactic information vs. too much
  syntactic information
• Ruling out bad alignments vs. keeping good
  alignments around

43
Alignment Spaces

• Completely unconstrained every alignment link
  (ei, fj) either on or off
• Permutation space one-to-one alignment with
  reordering Taskar et al. 2005
• ITG space permutation space satisfying binary
  tree constraint Wu 1997
• Dependency space permutation space maintaining
  phrasal cohesion

44
Alignment Spaces

• D-ITG space Dependency n ITG space Cherry and
  Lin 2006
• HD-ITG space D-ITG space where each span must
  contain a head Cherry and Lin 2006a

45
Examining Alignment SpacesCherry and Lin 2006a

• Alignment score
• Learned co-occurrence score
• Gold-standard oracle score

46
Examining Alignment SpacesCherry and Lin 2006a

• Learned co-occurrence score
• More restricted spaces give better results

47
Examining Alignment SpacesCherry and Lin 2006a

• Oracle score subsets of permutation space
• ITG rules out almost nothing correct
• Beam search in dependency space does worst

48
Conclusions

• Base alignment models are mathematical, limited
  notions of sentence structure
• Syntax-aware alignment helpful for syntax-aware
  MT DeNero and Klein 2007
• Using structure as a hard constraint is harmful
  for divergent sentences tweaking trees Gildea
  2003 or using soft constraints Cherry and Lin
  2006 helps fix this

49
Conclusions

• Surprise winner ITG
• Computationally straightforward
• Permissive, simple grammar that mostly only rules
  out bad alignments Cherry and Lin 2006a
• Does a lot, even when its not the best
• Discriminative framework looks promising and
  flexible can incorporate generative models as
  features Taskar et al. 2005

50
Towards the Future

• Easy-to-run GIZA made complicated IBM models
  the norm promising discriminative or
  syntax-based models currently lack such a toolkit
• Syntax-based discriminative techniques
  morphology, POS, semantic information
• Any other ideas?

51
References

• Brown, P., J. Cocke, S. Della Pietra, V. Della
  Pietra, F. Jelinek, J. Lafferty, R. Mercer, and
  P. Roossin, A statistical approach to machine
  translation, Computational Linguistics,
  16(2)79-85, 1990.
• Brown, P., S. Della Pietra, V. Della Pietra, and
  R. Mercer, The mathematics of statistical
  machine translation Parameter estimation,
  Computational Linguistics, 19(2)263-311.
• Cherry, Colin and Dekang Lin, Soft syntactic
  constraints for word alignment through
  discriminative training, Proceedings of the
  COLING/ACL Poster Session, 105-112, 2006.
• Cherry, Colin and Dekang Lin, A comparison of
  syntactically motivated alignment spaces,
  Proceedings of EACL, 145-152, 2006a.
• DeNero, John and Dan Klein, Tailoring word
  alignments to syntactic machine translation,
  Proceedings of ACL, 17-24, 2007.
• Gildea, Daniel, Loosely tree-based alignment for
  machine translation, Proceedings of ACL, 80-87,
  2003.

52
References

• Och, Franz and Hermann Ney, A systematic
  comparison of various statistical alignment
  models, Computational Linguistics, 29(1)19-51,
  2003.
• Taskar, B., S. Lacoste-Julien, and D. Klein, A
  discriminative matching approach to word
  alignment, Proceedings of HLT/EMNLP, 73-80,
  2005.
• Vogel, S., H. Ney, and C. Tillmann, HMM-based
  word alignment in statistical translation,
  Proceedings of COLING, 836-841, 1996.
• Wu, Dekai, Stochastic inversion transduction
  grammars and bilingual parsing of parallel
  corpora, Computational Linguistics,
  23(3)377-403.
• Yamada, Kenji and Kevin Knight, A syntax-based
  statistical translation model, Proceedings of
  ACL, 523-530, 2001.
• Zhang, Hao and Daniel Gildea, Syntax-based
  alignment Supervised or unsupervised?
  Proceedings of COLING, 418-424, 2004.
