Title: Aggregate Imaging System AIMS for Characterizing The Shape Of Fine And Coarse Aggregates


1
Aggregate Imaging System (AIMS) for
Characterizing The Shape Of Fine And Coarse
Aggregates
  • Eyad Masad
  • Assistant Professor
  • Department of Civil Engineering
  • Texas AM University

2
Aggregate Shape Properties
  • Form Flat and Elongated
  • Angularity Fractured Faces
  • Texture Surface Texture

3
Objectives
  • Develop a system to directly analyze aggregate
    shape properties
  • Computer-automated hardware for capturing
    aggregate images of different sizes at different
    resolutions.
  • Software for processing and analyzing images.
  • Investigate the relationship between measured
    shape properties and performance.

4
Implementation
  • Incorporating aggregate shape properties into the
    design procedure of hot mix asphalt, Portland
    cement concrete, and unbound pavement layers.
  • A tool for QC/QA of aggregates. The system will
    offer an automated method for enforcing aggregate
    shape specifications and ensuring consistent
    properties.

5
Why AIMS?
  • Most available systems focus on the form
    (flat-elongation) of coarse aggregates.
  • Fine aggregates have mostly been neglected.
  • Texture is not considered in the available
    systems.
  • There are not enough considerations in the
    available systems to the lighting scheme and
    image resolution.

6
AIMS Features
  • Computer automated hardware.
  • X, Y, and Z motion control.
  • Two and three dimensional analyses.
  • Works for fine and coarse aggregates.
  • User-friendly software for the analysis of form,
    angularity and texture.
  • Control of lighting schemes and image resolution.

7
(No Transcript)
8
AIMS Aggregate Imaging System
9
AIMS Aggregate Imaging System
10
Zoom
Camera
11
X-Axis Motion
Z-Axis motion Auto-Focus
12
Y-Axis Motion
13
Aggregate Table
Bottom Light Box
14
Bottom Lighting for Form and Angularity Analysis
15
Top Lighting for Texture Analysis
16
AIMS Interface
17
AIMS Analysis Program
18
Analysis Program
19
Form Analysis
  • Measure the x and y dimensions using the black
    and white image
  • Use the auto-focus microscope and top lighting to
    measure depth

Auto-focus on the table, z 0
Auto-focus on the particle, z Depth
20
Fine Aggregate-Texture
21
Fine Aggregate-Angularity
22
Coarse Aggregate-Texture
23
Coarse Aggregate-Thickness
24
Coarse Aggregate-Form
25
Summary of Findings
  • Aggregate Imaging System AIMS is developed for
    the analysis of aggregate shape properties.
  • AIMS is capable of analyzing
  • form (three dimensions), angularity, and texture
    of aggregate.
  • coarse and fine aggregates.
  • AIMS is developed with full consideration to
    important experimental issues image resolution,
    lighting, and image type.

26
Summary of Findings
  • Future research will focus on
  • Testing a wide range of aggregates,
  • Statistical analysis of aggregate shape (average
    might not be sufficient),
  • Relationship between aggregate shape and
    performance,
  • Implementation
  • consensus properties in specifications,
  • correlation with performance,
  • QC/QA

27
Questions ???
