CASCON 2006 Model Fusion Workshop An Industry Perspective

1
CASCON 2006Model Fusion WorkshopAn Industry
Perspective
Kim Letkeman Development Lead, Advanced Model
Driven Development Application AnalysisIBM
Rational Software
2
Agenda

• Introduction
• An Industry Perspective
• Challenges when Modeling in a Team Environment
• Summary

3
Agenda

• Introduction
• An Industry Perspective
• Challenges when Modeling in a Team Environment
• Summary

4
What is Model Management?

• From the Model Fusion WEB page
• Models are often constructed and manipulated in
  distributed teams, each modeler working on a
  partial view of the overall system.
• Coordinating this effort, maintaining
  consistency, and merging the various views is a
  major challenge.
• The tools and techniques used to address these
  issues are all a part of Model management.

5
Model Management Key Issues

• Terminology - modelers and tools vary in the
  definition and application of the terms that they
  use.
• Overlap different models may refer to the same
  concepts in the requirements or design of a
  system these overlapping concepts may be
  presented differently in each model the models
  may also contradict one another.
• Ambiguity - modeling languages have ambiguities
  in their semantics, even when well-defined
  meta-models are available. This will cause
  problems if vendors and modelers make different
  assumptions.
• Evolution - Models may evolve through a number of
  different versions, so that model transformations
  may need to be recomputed if the source models
  are updated.

6
Method Flow

• The way we model has a huge influence on the
  problems we choose to solve
• For example, if your only driver is team
  development, then you will work only on a merge
  solution
• But if your drivers expand to include all of the
  processes inherent in MDA, then you have to solve
  a more general fusion issue

7
Ad-hoc Modeling
Projects usually start here

• A team of modelers jumps on the task with fervor,
  and ends up creating several models that must be
  combined to form the enterprise model set going
  forward
• Chief characteristic is ad-hoc development with
  no version control
• High risk of model corruption and confusion, very
  difficult task if done manually

1
fusion
2
4
fusion
fusion
3
Manual fusion steps add risk, prefer assisted
fusion.
8
Team Modeling
Projects might go here

• Any development environment where people
  collaborate and work together to build a software
  system is a team environment
• Chief characteristic is parallel development
• High risk of accidental erasure of artifacts if
  version control is manual and appropriate
  procedures not followed or discipline not
  exercised

1a
1
2
3
1b
No fusion step, v2 is overwritten, all changes
lost!
9
Controlled Modeling Scenario
Projects should go here!

• ClearCase and CVS automatically detect the need
  for a merge!

Fusion step preserves changes in all versions.
10
Model Driven Architecture

• A modeling approach whereby the system is
  specified in a platform independent way, and thus
  is separated from the idiosyncrasies of any
  specific implementation platform.
• Most importantly, a language and vendor neutral
  architecture is created.
• MDA is formally defined by the OMG.

11
MDA Layering and Flow
Model Fusion is needed here.
And here.
And here.
12
Fusion at every transformation

• At every transformation stage, you can iterate.
  Change the source model, and you must transform
  again.
• But the target model may already have custom
  content.
• There is therefore a fusion step at the end of
  each transformation step, which must preserve the
  custom content in the transformation target

Abstract Model
Concrete Model
Concrete Model
Transformation
Fusion
Fusion step should be automatic (silent) if
possible, to allow builders to run the process.
13
Agenda

• Introduction
• An Industry Perspective
• Challenges when Modeling in a Team Environment
• Summary

14
Fundamental Project Drivers

• Its about the bottom line.
• Sales are directly impacted by how users perceive
  our solutions. Costs skyrocket when issues arise
  on customer sites and problems are escalated to
  the development team. So our solution has to work
  every time and in every situation.
• And the customer.
• Although the complexity of fusion is fascinating
  on its own, we must make it possible for users to
  work in parallel on models of any size and to use
  version control systems such as ClearCase and CVS
  to manage their artifacts.
• Thus, we have no choice but to divide our
  attention into several key areas of focus.

15
Key Focus Areas

• Integration
• We need integrations with Eclipse (compare
  with), the various flavors of ClearCase
  (cleartool command line, project explorer,
  version tree, history view, original Eclipse
  plugin (SCM), Eclipse remote client (CCRC), and
  CVS.
• Back-end
• We need fast delta generation and conflict
  analysis
• Front-end
• We need a GUI that will make it possible to
  depict any combination of deltas without flooding
  the user with extreme complexity
• We choose to advance the state of the art with
  visual compare in the UML diagrams themselves

And all of these solutions must be generic so we
can address all meta-models.
16
Other Project Drivers

• TIME!!!
• There is never enough.
• People, Equipment
• Ditto.
• Skills, Experience
• Is there ever enough?

17
Our Approach to Model Management Issues

• Terminology we defined our own.
• Overlap we recommend certain model partitioning
  techniques. We also support the MDA hierarchical
  levels CIM to PIM to PSM to code through our
  transformation technology. Thus, we encourage
  appropriate segregation of concerns.
• Ambiguity we use the UML. We are in a very good
  position to take the most appropriate direction
  with access to the leading experts on the UML
  specification and the open source embodiments of
  same.
• Evolution we support an environment where
  transformation and evolution is a continuous
  process. Each new version of a model can be
  transformed again while preserving the unique
  contents of the transformation target.

18
Terminology

• At the least, any model fusion project must
  create a similar glossary in order for team
  members to be able to communicate.
• The following terms define the way the RSA team
  thinks and are important for understanding RSAs
  fundamental behaviors.

19
Identity

• A unique moniker for an element. An element ID
  must be unique within all models that may
  interact within an organization.
• Example Class1 is created with identity set to
  1. Another Class1 is later created with
  identity set to 2. These look like the same
  class, but they are not because each has a unique
  and separate identity.
• Two copies of an element with different names are
  the same element if they share the same identity.
• Identity is permanent and immutable. An element
  retains the same identity throughout its entire
  life.

20
Name

• The moniker by which an element is generally
  known. Names are not required to be unique within
  a model or even a package.
• Example Class1 is created with identity set to
  1. Another Class1 is later created with
  identity set to 2. These have the same name and
  would be considered to be the same class upon
  casual inspection of the model.
• Names are impermanent and mutable. A rename will
  not change an elements identity, but the user
  will see it as a different element.

21
Qualified Name

• The full path to an element by name. For example,
  a class could have the qualified name
  com.ibm.package1.class1.
• A second class with a different identity could
  have the same qualified name.
• A class with the same name but in a different
  package will have a different qualified name and
  the two can therefore be distinguished from each
  other.
• It is possible to use qualified names as the
  identity. However, a rename or a move (refactor)
  would be seen as delete add, not move.

22
Delta / Difference

• Any change between two elements that have the
  same identity in two different versions of the
  model
• Must be directional, for example left minus
  right, new minus old.
• Add Delta an element was added to the left
  (newer) model.
• Delete Delta an element was removed from the
  left (newer) model.
• Change Delta a structural feature has a
  different value.
• Move Delta an element has a different parent in
  the left (newer) model.
• Reorder Delta special case of move delta an
  element occupies a different position in a list
  (e.g. a parameter change positions in a
  signature.)

23
Compare and Merge

• Comparing or combining two models by identity.
• Two-way merge compares them directly, while
  three-way compares each against a common ancestor
  to generate delta lists and then compares those
  to generate a conflict list.
• Elements that have the same identity on each side
  of a comparison are matched to each other for
  delta generation, regardless of name or content.
• Used to combine generations of the same model.
• Can detect all deltas add, change, delete,
  move, reorder.
• Primary tool for parallel development use cases.

24
Structural Compare and Fuse

• Comparing or combining two models by qualified
  name.
• Two-way comparison only. Looks for structural
  differences.
• Unnamed elements (e.g. notation) are skipped as
  they do not (by definition) participate in
  structure.
• Elements that have the same qualified name on
  each side of a comparison are matched to each
  other for delta generation, regardless of
  identity.
• The matching could be manually overridden to
  realign the model structure based on user input.
• Used to combine models with different identities.
  Primary tool for ad-hoc modeling and
  transformation fusion stage.
• Can detect a subset of deltas add, change,
  delete. Move can be detected with manual match
  override.

25
Rational Software Development Platform

• Shipped 6.0 in December 2004.
• Full ClearCase and CVS parallel development
  support.
• Full Eclipse integration for EMF / UML compare
  and merge.
• Merge by identity only, no fusion by name.
• Open beta for version 7.0 imminent.
• Full model fusion support.
• Our solutions are proprietary and protected by
  patents

26
Agenda

• Introduction
• An Industry Perspective
• Challenges when Modeling in a Team Environment
• Summary

27
There are no perfect solutions

• The following challenges are examples that can be
  addressed, but in many cases the solution brings
  along a new problem
• The key point is to realize that there are no
  perfect solutions, only compromises that lean
  towards your preferred behavior

28
Performance

• What happens when you add a 10mb package into a
  model and a merge results?
• A very long merge! Weve seen 24 hours in the
  distant past
• If you generate nested add deltas this specific
  package generated many thousands of deltas then
  you are asking your delta and conflict engines to
  do a lot more work
• Collapsing containers to a single add delta
  shrinks the delta count, which improves all
  aspects of performance, but there are issues with
  this choice as well
• It is impossible to create a relationship between
  one of the now-hidden add deltas and another
  delta somewhere else
• It is impossible to reference any now-hidden
  addition, as the whole delta is opaque

researchopportunity?
29
Performance

• In delta generation, every element in one model
  must be compared against every element in another
  model. And then conflict analysis compares every
  delta in both lists.
• These are quadratic algorithms if implemented
  with brute force
• Even finding an element by its ID can be
  expensive, cost is linear
• How about indexing, which can help reduce
  quadratic algorithms to linear and linear
  algorithms to logarithmic?
• It works, but there is a memory penalty

30
Scalability

• Customers expect to be able to run very
  sophisticated software on relatively slow and
  under-resourced machines
• Yet we have customers with models that top 100MB
  on disk, which expands to 300-400mb in RAM
• And merging models requires that four models be
  in memory at some point ancestor, remote (last
  one checked into the repository), local (current
  model attempting to check in), and merged (final
  result of merge.)
• Total could be up to 1.6gb for the heap java
  cannot even do that yet!
• The answer is model partitioning. Big user
  education issue!
• http//www-128.ibm.com/developerworks/rational/lib
  rary/05/802_comp3/
• http//www-128.ibm.com/developerworks/rational/lib
  rary/5816.html

researchopportunity?
31
Corruption

• What happens when a user blindly accepts related
  conflict resolutions from different contributors?
  That is, he or she resolves conflict A from local
  and conflict B from remote?
• If these conflicts are created by the same
  gesture, then the result is not going to be
  anything that either user did. I.e. no user
  gesture is represented by the result.
• Worse, it is possible that the tooling is not
  expecting the mix of two gestures and will fail
  to render it, or even to open the model.
• One solution is to treat related conflicts
  atomically. All must resolve to one side or the
  other.
• The penalty is a loss of flexibility eventually
  many deltas are forced in one direction by
  accepting a single delta

32
Data Loss

• Two packages are refactored. Package A becomes
  package Bs parent. Package B becomes package As
  parent in a parallel contributor.
• There is no obvious conflict here, because each
  is getting a new parent.
• But if both deltas are accepted, then they form a
  circle and become detached from the model.
  Bye-bye data.
• This conflict gets more interesting when there
  are other packages in between.
• A conflict strategy that looks for these issues
  comes with a sizeable performance penalty

33
Usability

• How do you display thousands of deltas, each
  potentially relevant to a different diagram,
  without overwhelming the user?
• How do you display conflicts that render in
  different ways? For example, a package deletion
  (rendered in a tree) conflicts with notational
  changes on a contained diagram (rendered in a
  diagram)?
• How do you handle a conflict between two
  multi-line text fields? If you dont allow merges
  at the field level, you force one user to throw
  away the field edits.
• All of these require complex GUIs and that very
  complexity somewhat mitigates its value.

researchopportunity?
34
User Inexperience

• What happens if a modeling team never
  synchronizes their workspaces to the repository?
• Every check-in results in a merge. Every merge
  gets larger as the distance between the common
  ancestor model and every new generation of the
  model grows.
• Seems obvious, yet we have seen it. A huge
  performance issue that is easily fixed by
  synchronizing the workspace with the repository
  now and again. Another user education issue.

35
Parallel Projects

• A set of 100 models that are edited in parallel
  can result in many merges per day.
• So what happens when you have parallel sets of
  models for individual projects?
• ClearCase allows parallel streams to cross-merge
  using the diffmerge tool
• And then what happens when each is independently
  upgraded and the conversion creates enough new
  identities that the model differences rise from a
  dozen to many thousand, all of which are false?
• Not a problem if the requirement for identity is
  removed.

Researchopportunity?
36
Meta-model Mismatch

• By definition, meta-models must be identical to
  be compared.
• Yet, the existence of custom profiles guarantees
  that a model will periodically have its
  meta-model changed. And that model version can
  participate in a merge. In fact, it is possible
  in a volatile environment to have three different
  meta-models as inputs to a merge.
• We always aborted these merges, forcing users to
  go through a lot of pain to upgrade the
  contributors in a temporary space and merge them
  outside the SCM system.
• We now have a partial solution, but it cannot
  handle all use cases. For example, it is
  verydifficult to handle the situation where
  profilesare applied at different levels in the
  hierarchy.

Probablyresearchopportunity.
37
DEMO
38
Agenda

• Introduction
• An Industry Perspective
• Challenges when Modeling in a Team Environment
• Summary

39
Model Merging

• RSA has state of the art model merge capability
  (at least, for a shipping product)
• Fully integrated with Eclipse, CVS and ClearCase
• Supports visual merge of notation
• Can be extended to support domain specific
  meta-models and generic EMF models
• Explicit GMF notation support we have a sample
  logic diagram client
• Version 7 has an API that can be used to support
  merging of any EMF meta-model.

40
Best Practices for Model and Source Management

• Use a Source Code Management (SCM) system
• Version control everything including 3rd party
  binaries that are a part of your build and
  packaging
• Use an SCM system that supports automated merge
  detection
• Much higher productivity when constant need for
  coordination is replaced by automated detection
• Individuals should update to the latest source
  very frequently
• Prevents unnecessary merge sessions
• Practice strong ownership separate
  responsibilities to avoid unnecessary conflicts
• Important for code and for models

41
(No Transcript)
42
(No Transcript)
