Federated Search

1
Federated Search

• April Ens
• Rowena Koh
• Jovy Rosario
• Desy Wahyuni
• Suher Zaher-Mazawi

LIBR 557 November 2007
2
Outline

• Definitions
• Federated vs. Metasearch
• Why Federated Search?
• Issues and Challenges
• Metasearch Initiative
• Examples
• MetaLib (Ex Libris)
• WebFeat
• AGent Search (Auto-Graphic Inc.)
• 360 Search (Serials Solutions)
• Free and Open Source Options
• Conclusion

3
Definitions

• Federated search broadcasts a single search
  query across multiple sources of information and
  aggregates results into a single point of access,
  usually displayed in a common format.
• (Marshall et al. 2006)

4
Definitions

• Federated search is the consolidated retrieval
  of results in response to a query sent to several
  databases hosted by different online information
  systems. Federated searching consists of
  transforming a query and broadcasting it to a
  group of disparate databases with the appropriate
  syntax, merging the results collected from the
  databases, presenting them in a succinct and
  unified format with minimal duplication, and
  allowing the library patron to sort the merged
  result set by various criteria.
• (Jascó 2004)

5
Federated vs Metasearch

• Metasearch, parallel search, federated search,
  broadcast search, cross-database search, search
  portal are a familiar part of the information
  community's vocabulary. They speak to the need
  for search and retrieval to span multiple
  databases, sources, platforms, protocols, and
  vendors at one time.
• (NISO)
• but federated search vendors prefer not to be
  known as metasearch engines

6
Federated vs Metasearch
7
Why federated search?

• Growth in variety of information sources, formats
  and platforms
• Limited budgets
• Web search engines especially

8
Why federated search?

• OCLC study on the Perceptions of Libraries and
  Information Resources
• Open web search engines are viewed as more
  reliable, easy to use, convenient and
  cost-effective
• 87 of respondents say that the web search engine
  would be first choice next time they need a
  source for information
• Patrons stop using resources after becoming
  frustrated by number of dissimilar search
  interfaces they must use to access content

9
Why federated search?

• But library-provided electronic resources are
  still highly rated
• Libraries now have an excellent opportunity to
  provide a simple, yet powerful interface that
  out-Googles Google. (Fryer 2004)

10
Why federated search?
11
Why Federated Search?General Features

• Customized interface design
• Organizes databases by subject
• Start search by selecting subject or desired
  databases
• Boolean and field searching
• One search box
• Most allow customization of basic search fields
• De-duplication of results
• Merging of results
• Can usually be sorted by date, relevancy, or
  title
• May also be able to filter by field
• User interaction functions

12
Why federated search?

• One begins to glimpse here a world where
  information silos are a thing of the past, where
  library provided content truly is presented in a
  unified, integrated fashion, where hypertext
  linking begins to realize its ultimate potential
  and users can customize offerings according to
  their preferences in a true portal environment.
• (Boss and Nelson 2005)

13
Issues and Challenges

• Verification, authentication, certification,
  licensing
• access to multiple, password-protected databases
• access only to licensed users
• Lack of advanced search functions
• Basic Boolean
• No proximity searching
• Multiple-field searching
• Default to keyword

14
Issues and Challenges

• Limited by functions of native database
• De-duplication
• Exact vs. Variable de-duplication
• De-duplicates only first set of results

15
Issues and Challenges

• Relevancy ranking
• Generally based on frequency of search keywords
  in citations
• Full-text and abstracts not generally available
• Slow response time
• Too much information?

16
Metasearch Initiative

• NISO has gathered vendors, content providers, and
  library systems to work on its Metasearch
  Initiative to create standards
• proprietary vendor verification authentication,
  and certification to use certain databases
• search protocol standardization
• common descriptors for data and content tags, as
  well as taxonomies
• how result sets should be sorted, ranked, and
  ordered

17
MetaLib
18
MetaLib Overview

• Developed by Ex Libris Ltd.
• Version 1.0 released in 2001.
• Version 4.0 released in February 8, 2007
• One of the major federated search tool available
• Aimed mainly for academic and research
  institutions
• Widely used internationally

19
MetaLib in Practice

• Canada University of British Columbia
  University of Victoria University of Quebec
• USA West Texas A M University's Cornette
  Library Aeronautics and Space Administration
  (NASA) Johnson Space Center Cleveland Museum of
  Art
• Europe University of Birmingham (UK) Louis
  Pasteur University (Strasbourg I) Groningen
  University (Netherlands) Humboldt University
  (Germany) Consejo Superior de Investigaciones
  Científicas (Spain) National Electronic Library
  of Finland (Finland)
• Asia Korea Advanced Institute of Science and
  Technology (South Korea) Beijing University of
  Technology (China)
• Africa Middle East The American University
  (Cairo, Egypt) Collage of Management (Israel)

20
MetaLib General Features

• Flexible consortia options
• Customizable and meets user needs
• Streamlined authentication and authorization
• Multilingual, accessible, and standards-based
• Works in conjunction with SFX
• Xerxes open-source implementation of Metalib

21
MetaLib Search Features

• Search Levels
• QuickSearch vs. MetaSearch
• Simple search
• Advanced search

22
MetaLib Search Features

• Syntax
• Boolean AND (default), OR, NOT
• Phrase uses quotation marks
• Truncation uses the symbol ?
• Field Searches
• subject, title, author, ISBN, ISSN, year

23
MetaLib QuickSearch Interface
24
MetaLib QuickSearch Interface
25
MetaLib PowerSearch Interface
26
MetaLib Unique Feature

• MetaLib uses Z39.50 or XML gateway protocols,
  thus bypassing the native search interface and
  using its own search to fetch data from native
  databases. (Xiatian, 2006)
• Consequences
• The search results look-and-feel
• Database ranking on the search result page

27
MetaLib Search Process

• While searching

28
MetaLib Search Results
3
1
2
29
MetaLib Search Results
30
MetaLib Search Results
31
MetaLib Strengths

• One clear, familiar user interface
• Customizable flexible infrastructure
• Easy to manage
• Works with any integrated library system
• Provides a layer above the institution's system
• Vendor-hosted or locally hosted

32
MetaLib Weaknesses

• Retrieves first 30 records from each database
  based on relevance rankings
• Not all databases can be configured to work with
  MetaLib's search software
• Does not really offer one-stop shopping
• Searches databases within one subject only
• Slow Speed
• Internal navigation only

33
MetaLib The UBC Library
34
MetaLib The UBC Library
35
MetaLib The UBC Library
36
MetaLib The University of York Library
Archives
37
MetaLib The University of York Library
Archives
38
MetaLib The University of York Library
Archives
39

• the original federated search engine

40
Webfeat Overview

• Three products
• Webfeat Custom API
• Webfeat Express for budget-conscious libraries
• Webfeat Enterprise edition for multi-library
  networks
• Used primarily by large public library systems
  and academic libraries

41
WebFeat _at_ NYPL
42
Selected Databases
43
(No Transcript)
44
WebFeat Search Features
45
WebFeat Search Features
46
WebFeat Search Features
47
WebFeat Search Features
48
WebFeat Syntax
49
WebFeat Advanced Search
50
WebFeat Search Process
51
WebFeat Search Process
52
WebFeat Search Results
53
Clicking the View button leads to the article
citation found on interface of the native database
54
WebFeat Strengths

• Flexible and highly customizable interface

55
Some examples Princetons PULQuickSEARCH
56
VPLs All in One Search
57
University of Pittsburghs Zoom!
58
WebFeat Strengths

• Development and maintenance of translators
  handled by WebFeat
• Translators are tools that allow WebFeat to
  interact with the native database
• Vendor-hosted
• One-stop shopping - ability to combine databases
  in different subject categories

59
WebFeat Strength
60
WebFeat Weaknesses

• Vendor-hosted
• WebFeat IP addresses need to be added to all
  database vendors
• Inconsistent results
• Can only search databases with a search box in
  the front page
• Does not offer de-duplication
• Response time can be slow

61
AGent Search
62
AGent Search Overview

• A product of Auto-Graphics, Inc.
• Previously known as AGent Portal
• Can be integrated into a librarys existing
  applications, or used entirely from a web portal.

63
Who Uses AGent Search?

• 5,000 libraries use AGent Search
• Auto-Graphics, Inc. claims that more libraries
  use AGent Search than any other federated search
  tools
• Users include Public Libraries, Academic
  Libraries, and Library Consortia

64
Library Consortia JerseyClicks
65
Who uses AGent Search locally?

• Coquitlam Public Library
• Port Moody Public Library
• These libraries worked with Auto-graphics Inc. to
  create a shared search between their two
  libraries
• Their case study has been featured in AGent
  literature

66
Coquitlam Port Moody

• Billed as Two Libraries. One Search.
• AGent Search can be accessed by either librarys
  website, using an appropriate library card.
• The search accesses both library catalogues, the
  Outlook provincial catalogue, and a number of
  encyclopedias and databases
• Guest Access is also available, but very few
  databases are accessible.

67
AGent Search Guest Access
68
AGent Search Patron Access (Keyword Search)
69
AGent Search Patron Access (Advanced)
70
AGent Search Syntax

• Wildcards, Phrase Searching, and Basic Boolean
  (AND, OR, NOT) can be used in both keyword and
  advanced search
• When not otherwise specified, AND is assumed when
  multiple words are used in a given search box

71
AGent Search Wildcard Syntax

• ? - Use within a word to represent individual
  characters,
• i.e. p?jama to retrieve pajama or pyjama.
• - Use this to replace multiple characters.

72
AGent Search Search Results
73
AGent Search Results Sorted by Date
74
(No Transcript)
75
AGent Search - Strengths

• Search history, up to 50 searches
• Saved search preferences
• Ability to hide seldom-used resources, or select
  favourite resources to be automatically selected
• Boolean, phrase searching, and wildcards
  available in all search interfaces
• Search results can be grouped by resource, title,
  author, or date. AGent is able to recognize
  identical items
• Full access to results (not just screenscraping)
• Statistical tracking for libraries

76
AGent Strength Search History
77
AGent Strength Saved Search Preferences
78
AGent Search Weaknesses

• Results are delivered in random order.
• Selections offered by Port Moody / Coquitlam are
  limited. A significant number of resources can
  only be searched individually, or in the library
  due to licensing issues.

79
360 Search
80
360 Search Overview

• Vendor Serials Solution/Proquest
• Formerly Central Search

81
Libraries using 360 Search

• James A. Cannavino Library at Marist College
• http//library.marist.edu/
• The University of Arizona Library
• http//www.library.arizona.edu/
• Minneapolis Public Library
• http//www.mpls.lib.mn.us/
• And about 90 other libraries

82
360 Search Features

• Boolean operators
• AND, OR, NOT
• Phrase search using quotation marks
• Truncation
• wildcard symbol

83
360 Search Basic Search
84
360 Search Basic Search
85
360 Search Basic Search
86
360 Search Advanced Search

• Field search

87
360 Search Search Results
88
360 Search Search Results
89
360 Search Strengths

• Hosted application
• no server required on library site
• no maintenance, upgrading, troubleshooting by
  library personnel
• Customizable
• the databases included
• interface
• results
• name of the service

90
360 Search Strengths

• Results clustering
• Aggregates citations based on common terms
• Helps refine searches
• Vivisimo technology

91
360 Search Results Clustering
92
360 Search Results Clustering
93
360 Search Results Clustering
94
360 Search Results Clustering
95
360 Search Weaknesses

• Clustered results can sometimes be weak and/or
  random
• A basic Any search for Civil War in a history
  group of databases resulted in the following
  clusters (with number of hits in each cluster)
  Review (44), History (15), Iraq (8), Memory (7),
  Account (5), Economy (5), Party , Hollande
  (5), President (5), Wars (5), Other (51). Some of
  these clusters work but many do not (indicated by
  brackets here) and, most surprisingly and oddly,
  a cluster for United States does not get
  generated. (Callicott, 2007, p. 7)
• Search ISSN but not journal title

96
Open Source Options
97

• Please refer to Fall 2006 557 presentation for a
  thorough discussion of this search engine
  http//www.slais.ubc.ca/courses/libr557/06-07-wt1/
  presentations.htm

98
Other Open Source Federated Search Engines

• LibraryFind (Oregon State University Libraries)
  http//www.libraryfind.org/
• MasterKey, part of the Keystone Digital Library
  Suite (Index Data) http//www.indexdata.dk/keyston
  e/
• Xerxes (California State University)
  http//xerxes.calstate.edu/

99
Free Federated Search
100

• "a free federated, vertical search portal"

101
The debate

• Loss of controlled vocabularies and specialized
  features of individual databases
• Not all library databases may be available on the
  federated system
• Just another choice on your screen?
• It is dumbing down searching

102
Final Thoughts

• Its time for librarians to accept that library
  users are not interested in being more like us.
• (Luther 2003)

103
Final Thoughts

• Learning about these databases'
  availability is one thing.  Getting to them by
  clicking through the labyrinth on many library
  Web sites is another. Making patrons use them
  while applying the strict semantic and syntax
  rules of Boolean and proximity operators to terms
  looked up from the thesauriis yet another thing.
  It's no surprise that patrons are happy if they
  make it through one database and catch just a few
  small "fish." They don't go to see if another
  database may have more and/or better results.
  Most give up and angrily leave whatever database
  they were using. Then they'll go to Google and
  type the query library anxiety information
  overload help, which will find a few good-enough
  full-text reports, case studies, and articles
  among the first several of the more than 11,400
  free results.  They may never come back to the
  digital library again.
• (Jascó Péter 2004)

104
Resources

• Auto-Graphics, Inc. (2007). AGent Search.
  Retrieved November 12, 2007, from
  http//www4.auto-graphics.com/products/agentsearch
  /agentsearch.htm
• Auto-Graphics, Inc. (2007). AGent Search case
  study Port Moody and Coquitlam
• Public Libraries of British Columbia (BC).
  Retrieved November 12, 2007, from
  http//www4.auto-graphics.com/products/agentsearch
  /cs_port_moody.htm
• Boss, S. C., Nelson, M.L. (2005). Federated
  search tools the next step in the quest for
  one-stop-shopping. Reference Librarian 44,
  139-160.
• Boyd, J., Hampton, M., Morrison, P., Pugh, P.,
  Cervone, F. (2006). The one-box challenge
  Providing a federated search that benefits the
  research process. Serials Review 32(4), 247-254.
• Callicott, B. (2007). 360 Search (formerly
  Central Search). The Charleston Advisor 9(1),
  5-8.
• Chen, X. (2006). MetaLib, WebFeat, and Google
  The strengths and weaknesses of federated search
  engines compared with Google. Online Information
  Review 30(4), 413-427.

105
Resources

• Coquitlam Public Library (2007). Port Moody and
  Coquitlam Public Libraries Two libraries. One
  search. Retrieved November 12, 2007, from
• http//coquitlam-agent.auto-graphics.com/agent/lo
  gin.asp?cidscbclidCOQR
• Curtis, A. M., Dorner, D. G. (2005). Why
  federated search? Knowledge Quest 33 (3), 35-37.
• Dartmouth College Library (2007). About
  Search360. Retrieved November 12, 2007 from
• http//library.dartmouth.edu/search/search360/abo
  ut360.shtml
• ExLibris Ltd. (2007). MetaLib official website.
  Retrieved November 10, 2007 from
• http//www.exlibrisgroup.com/metalib.htm
• Fahey, S. (2007). Fed searchers? The debate
  about federated search engines. Feliciter 52 (2),
  62-63.
• Fryer, D. (2004). Federated search engines.
  Online 28 (2), 16-19.
• Guinn, D. (2006). Federated search symposium
  panelist fact sheet. Retrieved November 10, 2007
  from http//www.thealbertalibrary.ab.ca/viewPostin
  g.asp?postingID182

106
Resources

• Hane, P. J. (2003). The truth about federated
  searching. Information Today 20(9), 24.
• Hollandsworth, B. L., Foy, J. (2007).  Griffin
  search How Westminster College implemented
  WebFeat. Library Hi Tech 25(2), 211-219.
• Jascó, P. (2004). Thoughts about federated
  searching. Information Today 21 (9), 17/20.
• Jacso, P. (2007). Vivisimo, Central Search, TIME
  Magazine, and the Open Directory Project. Online
  31(1), 58-60.
• Marshall, P., Herman, S., Rajan, S. (2006). In
  search of more meaningful search. Serials Review
  12 (3), 172-180.
• Newton, V. W., Silberger, K. (2007).
  Simplifying complexity through a single federated
  search box. Online 31(4), 19-21.
• NISO (2007). Metasearch initiative. Retrieved
  November 8, 2007 from http//www.niso.org/committe
  es/MS_initiative.html

107
Resources

• Port Moody Public Library (2007). Two libraries.
  One search. Retrieved November 12, 2007, from
  http//library.portmoody.ca/Resources/OneSearch/d
  efault.htm
• Rogers, M. (2006). Serials Solutions debuts
  Vivisimo. Library Journal 131(18), 27-28.
• SerialsSolutions (n.d.). 360 Search help.
  Retrieved November 13, 2007 from
• http//va3wn8qp2m.cs.serialssolutions.com/csStati
  c/html/helpPages/clustering.html
• Tenopir, C. (2007). Can Johnny search? Library
  Journal 132(2), 30.
• The UBC Library (2007). How to search MetaLib.
  Retrieved November 10, 2007 from
• http//www.library.ubc.ca/pubs/HowtoSearchMetaLib
  .pdf
• The UBC Library (2007). MetaLib search engine.
  Retrieved November 10, 2007 from
• http//montcalm.util.itservices.ubc.ca8331/V
• Xerxes (n.d.). Top ten reasons to use the Metalib
  X-Server. Retrieved November 10, 2007 from
  http//xerxes.calstate.edu/articles/1
