Title: Graphs and Finding your way in the wilderness


1
Graphs andFinding your way in the wilderness
  • Chapter 14 in DSPS
  • Chapter 9 in DSAA

2
General Problems
  • What is the shortest path from A to B?
  • What is the shortest path from A to all nodes?
  • What is the shortest/cheapest path between any
    two nodes?.
  • Search for Goal node, i.e. a node with specific
    properties, like a win in chess.
  • What is shortest tour? (visit all vertices)
  • no known polynomial algorithm in number of edges
  • What is longest path from A to B

3
Some Applications
  • Route Finding
  • metacrawler, on net, claims to find shortest path
    between two points
  • Game-Playing
  • great increase in chess/checkers end-game play
    occurred when recognized as graph search, not
    tree search
  • Critical Path Analysis
  • multiperson/task job schedule analysis
  • answers what are the key tasks that cant slip
  • Travel arrangement
  • cheapest cost to meet constraints

4
Definitions
  • Graph set of edges E and vertices V.
  • Edge is a pair of vertices (v,w)
  • edge may be directed or undirected
  • edge may have a cost
  • v and w are said to be adjacent
  • Digraph or directed graph directed edges
  • Path sequence of vertices v1,vn where each
    is an edge.
  • Cycle path where v1vn
  • Tour cycle that contains every vertex
  • DAG directed acyclic graph
  • graph with no cycles
  • Tree algorithms usually work with DAGs just fine

5
Adjacency Matrix Representation
  • Matrix A new Boolean(V,V).
  • O(V2) memory costs acceptable only if dense
  • If is an edge, set Aij true, else
    false
  • Special matrix multiple operator
  • rowi _at_ colj rowi1col1j or
    rowi2col2j..
  • In A_at_A, if entry ij is true, what does that
    mean?
  • There is some k so that vi-vk and vk-vj or a
    length 2 path from vi to vk.
  • Similarly, Ak indicates where any two vertices
    are connected by a length k path.
  • Cost O(kn3).

6
Matrix Review
  • If A has n rows and k columns and
  • B has k rows and m columns then AB C
  • Where C has n rows and m columns and (standard)
  • Cij Ai1B1j.AikBkj
  • or i-j entry of C is dot product of row i of A
    and column J of B. Total time cost is O(nkm).
  • Example matrix of size 3-3 represents a linear
    transformation from R3 into R3.
  • Points in R3 represented as a 3 by 1 vector
    (column)
  • Essentially matrices stretch/shrink or rotate
    points.
  • Determinant defines amount of stretch/shrink.
  • Theorem Locally every differentiable function
    can be approximated by a matrix (linear
    transformation).

7
Cost Matrix Representation
  • Now Aij cost of edge from vi to vj.
  • If no edge, either set cost to Infinity or add
    Boolean attribute to indicate no edge.
  • New multiplication operation
  • rowi_at_colj min rowi1col1j,

  • rowi2col2j,

  • rowin colnj
  • Now A2 contains minimum cost path of length 2
    between any 2 vertices.
  • An has complexity O(n4). Not good.
  • If add Aii 0, then Ak records minimum cost
    path of length k. (how to change to allow all
    paths

8
Adjacency List Representation
  • Here each vertex is the head of linked list which
    stores all the adjacent vertices. The cost to a
    node, if appropriate is also stored.
  • The linked lists are usually stored in an array,
    since you probably know how many vertices there
    are.
  • Memory cost O(E) so if E representation.
  • Graph is sparse if E is O(V).
  • To simplify the discussion, we will assume that
    each vertices has a method sons which returns
    all adjacent vertices.
  • Now, will redo same problems with list
    representation.

9
General Graph Search AlgorithmLooking for a node
with a property
  • Set Store equal to the some node
  • while ( Store is non-empty) do
  • choose a node n in Store
  • if n is solution, stop
  • Decisions
  • else add SOME sons of n to store
  • What should store be?
  • How do we choose a node?
  • what does add mean?
  • How do pick which sons to store.
  • Cycles are a problem

10
Problem Is Graph connected? (matrix rep)
  • Note n by n boolean matrix where n is number of
    vertices.
  • Set Aii to true
  • Set Aij to true if there is an edge between i
    and j.
  • Let B A2, using boolean arithmetic
  • Note Bij is true iff there is a k such that
    Bik is true and Bkj is true, i.e if there
    is a 2-path from i to j.
  • Ak represents whether a k-path exists between
    any vertices.
  • Let C boolean sum of Ai where i 1n-1. (why?)
  • Graph connected if C is all ones.
  • Time complexity O(N4)!
  • How about directed graphs? Basically the same
    algorithm.
  • For directed graphs, strongly connected means
    directed path between any two vertices.

11
Is Undirected Graph G Connected? (adjacency
list representation)
  • Suppose G is an undirected graph with N vertices.
  • Let S be any node
  • Do a (depth/breadth) first search of G, counting
    the number of nodes. Be careful not to double
    count.
  • If number of nodes does not equal N,
    disconnected.
  • Searching a Graph is like searching a tree,
    except that nodes may be revisited.
  • Need to keep track of revisits, else infinite
    loop.

12
Depth First Search Pseudo-Code
  • Store Stack
  • Choose pop
  • Initial node any node
  • Add push only new sons (unvisited ones)
  • keep a boolean field visited, initialized to
    false.
  • When a node is popped, mark it as visitied.
  • Graph connected if all nodes visited.
  • Properties
  • Memory cost number of nodes
  • Guarantee to find a solution, if one exists (not
    shortest solution) How could we guarantee that?
  • Time number of nodes (exponential for k-ary
    trees)

13
Breadth First Search
  • G is a undirected Graph
  • As before each node has a boolean visited field.
  • Initial node is arbitrary
  • Store Queue
  • Choose dequeue and mark as visited
  • Add enqueue only those sons that have not been
    visited
  • Properties
  • Time Number of nodes to solution
  • Space Number of nodes
  • Guaranteed to find shortest solution

14
Is Directed Graph Acyclic? (array represntation)
  • Let Aij be true if there is a directed edge
    from i to j.
  • Similar to previous case, if B A2 with boolean
    multiplication, then Bij is true iff there is
    a directed 2-path from i to j.
  • Algorithm
  • For i 1 to n-1 (why?)
  • Compute Ai.
  • If some diagonal element is true, exit
    with true
  • end for
  • Exit with false.

15
Is Directed Graph Acyclic? (adjacency list rep)
  • With care, breadth first search works.
  • Define the indegree of a node v as the number of
    edges of the form (u,v), with u arbitrary.
  • Define the outdegree of a node v as the number of
    edges of the form (v, u) with u arbitrary.
  • A node with indegree 0 is like the root of a
    tree.
  • A node with outdegree 0 is a terminal node.

16
Breadth First Search Pseudo-code
  • Algorithm Idea (has numerous variations/implementa
    tions)
  • Store Queue
  • Compute indegree of all nodes
  • Enqueue all nodes of indegree 0
  • While Queue is not empty
  • Dequeue node n and lower indegrees of nodes of
    form (n,v)
  • Enqueue any node whose indegree is 0.
  • If any node still has positive indegree, then
    cyclic.
  • Why does algorithm terminate?
  • Properties
  • Time Space Number of nodes
  • find node closest to roots.

17
Best-First Search
  • Goal find least cost solution
  • Here edges have a cost (positive)
  • Store priority queue
  • Add enqueue(), which puts in right order
  • Choose dequeue(), chooses element of least cost
  • Properties
  • Find cheapest solution
  • Time and Memory exponential in
  • depth of tree.

18
Best First Pseudo-Code
  • Set distance from S to S to 0
  • Priority Queue PQ
  • while (PQ is not empty)
  • vertex
  • sons
  • for each son in sons
  • PQ.enqueue(son, cost to son)

19
Topological Sort
  • Given a directed acyclic graph
  • Produce a linear ordering of the vertices such
    that if a path exist from v1 to v2, then v1 is
    before v2.
  • If v1 is before v2, is there a path from v1 to
    v2?
  • NO
  • Note there may be multiple correct topological
    sorts
  • Algorithm Idea
  • any vertex with indegree 0 can be first
  • Output and delete that vertex
  • update indegrees of its sons
  • Repeat until empty
  • So we need to compute and keep track of indegrees

20
Algorithm Implementation
  • HashTable of (vertex, indegree, sons)
  • Queue of vertices
  • Step 1 read each edge (v,w) and add 1 to
    indegree of w
  • linear
  • Step 2 Add all vertices with indegree 0 to queue
    Q.
  • Step 3 Process Q by
  • dequeue vertex
  • update indegrees of its sons (constant by
    hashing)
  • enqueue any son whose indegree become 0.
  • Time complexity linear
  • Space linear
  • Proof Does everything get enqueued?

21
UnWeighted Single-Source Shortest path algorihtm
  • Input Directed graph and start node S
  • Output the minimum cost, in terms of number of
    edges traversed, from start node to all other
    nodes.
  • Idea do a level order search (breadth-first
    search)
  • Well use a hashtable to mark elements as seen,
  • i.e. well track vertices that weve visited
  • use hashtable to hold this information by
    marking vertices that have been visited
  • Well use a queue to store the vertices to be
    opened
  • to open a node means to consider its sons
  • Each vertex will have a field for distance to
    start node.

22
Shortest Path Algorithm
  • Set distance from S to S to 0
  • queue
  • while (queue is not empty)
  • vertex
  • mark vertex as visited (enter in
    hashtable)
  • record cost to vertex
  • sons
  • newSons
  • fill in distance measure to newSons
  • queue.enqueue(newSons)
  • Essentially, breadth-first search

23
Discussion
  • Will this terminate?
  • Will we ever revisit a node?
  • Computational cost?
  • O(E)
  • What are the memory requirements?
  • Suppose we dont count graph (virtual graphs)
  • Can we bound queue?
  • Only O(E) and if m-ary tree, this is
    exponential.
  • Did we need the hashtable?
  • This avoids a linear search of the constructed
    graph
  • remove a factor of O(G).

24
Positive-Weighted Single-source Cheapest Path
  • Suppose we have positive costs associated with
    every edge in a directed graph.
  • Problem Find the shortest path(total cost) from
    given vertex S to every vertex.
  • Solution Dijstras algorithm
  • BFS idea still works, with slight modifications
  • Replace Queue by Priority queue.
  • As before, replace newSons by betterSons.
  • As before, replace add entry to update entry
    (which may be add)
  • Note may reopen an old son( if return with
    better path)
  • Dense graphs O(V2), sparse graphs
    O(ElogV)

25
Weighted Shortest Path Pseudo-Code
  • Set distance from S to S to 0 (on node)
  • Priority Queue PQ
  • while (PQ is not empty)
  • vertex
  • mark vertex as visited (enter in
    hashtable)
  • record cost to vertex
  • sons
  • goodSons better costs estimates
  • queue.enqueue(goodSons) enqueue puts in
    proper order.

26
Graphs with negative edge costs
  • Dijsktra doesnt work (since we may have cycles
    which lower the cost)
  • Input Directed graph with arbitrary edge costs
    and vertex v.
  • Output Minimum cost from S to every vertex OR
    graph has a negative cost cycle.
  • Note If no negative cost cycles, then a vertex
    can be visited (expanded) at most V times.
  • Algorithm Add counter to each vertex so each
    time it is visited with lower cost, counter goes
    up. If counter exceeds V, then graph has
    negative cost cycle and we exit. Otherwise queue
    will be empty.

27
Weighted Single-Source shortest-path problems for
Acyclic graphs
  • Easy since no cycles
  • Edge costs may be positive or negative
  • Best-first search works
  • Node may be reentrant
  • Reentrant node require may required updating
    cost.
  • Or apply topological sorting algorithm. (text)

2
4
7
3
6
1
28
Algorithm Display
  • Idea
  • Iterative use of breadth first search
  • addition of edges to effect other choices
  • See Diagrams provided
  • Analysis (requires augmented path be cheapest)
  • Runs in linear time

29
Minimum Spanning Tree
  • Given an undirected connected graph with edge
    costs
  • Output a subtree of graph such that
  • contains all vertices
  • sum of costs of edges is minimum
  • If costs not given, assume 1. What then?
  • Note all spanning trees have same number of edges
  • Application
  • Is undirected Graph with n vertices connected?
  • IFF minimal spanning tree has n-1 edges.

30
Prims Algorithm
  • Let G be given as (V,E) where V has n vertices
  • Let T empty
  • Algorithm Idea grow cheapest tree
  • Choose a random v to start and add to T
  • Repeat (until T has n vertices)
  • select edge of minimum length that does not form
    a cycle and that attaches to current tree (how
    to check?)
  • add edge to T
  • The proof is more difficult than the code.
  • Complexity depends on G and code
  • O(V2) for dense graphs
  • O(Elog(V)) for sparse graphs (use binary heap)

31
Kruskals Algorithm
  • Given graph G (V,E)
  • Sort edges on the basis of cost.
  • Add least cost edge to Forest, as long as no
    cycle is formed.
  • Cost of cycle checking is?
  • If implement as adjacency list, O(E2)
  • If implement as hash table O(1)
  • Proof more difficult.
  • Time complexity O(E log E)

32
Finding the least cost between pairs of points
  • Idea Dynamic programming
  • Let cij be the edge cost between vi and vj.
  • Define Cij as minimum cost for going from vi
    to vj.
  • Finding the subproblems
  • Suppose P is the path from vi to vj which
    realizes the minimum cost and vk is an
    intermediary node.
  • Then the subpaths from i to k and from k to j
    must be optimal, otherwise P would not be
    optimal.
  • Now define Dikj as the minimum cost for
    going from vi to vj using any of v1,v2..,vk as an
    intermediary.
  • Define Dij as the minimum cost for going from
    i to j.
  • Dij min over k of Dikj and cij.

33
All-Pairs (Floyds)Pseudo-Code
  • Initialization
  • Di0j cost(i,j) for all vertices i, j
    O(V2)
  • Dik1j
  • min(Dikj, Dikk1Dk1kj)
  • This last statement is true since any path from
    the shortest path from vi to vj using v1,vk1
    either doesnt use vk1, or the path divides
    into a path from vi to vk1 and one from
    vk1 to vj.
  • The cost of this is O(V3) - i.e. single loop
    over all vertices with V2 per loop.

34
NP vs P
  • Multiple ways to define
  • Define new computational model (Imaginary)
  • add to programming language
  • choose S1, S2,.Sn where Si are statements
  • Semantics algorithm always chooses best Si to
    execute.
  • This is the Non-Deterministic model
  • If problem can be solve in polynomial time with
    non-deterministic it is in the class NP.
  • If problem can be solved in polynomial time on
    standard computer (deterministic) then in class
    P.
  • Unsolved (and possibly unsolvable) does NP P?

35
NP-Completeness
  • A problem is in NP or NP-hard if it can be solved
    in polynomial time on a non-deterministic
    machine.
  • A problem p is NP complete if any problem in NP
    can be polynomial reduced to p.
  • A problem P1 can be polynomial reduced to P2 if
    P1 can be solved in polynomially time assuming
    that P2 can be solved in polynomially time.
  • Alternatively, if P1 can be transformed into P2
    and solutions of P2 mapped back to P1 and all the
    transformations take polynomial time.
  • This is a way of forming a taxonomy of difficulty
    of various problems

36
NP-Complete problems
  • Boolean Satisfiability
  • Traveling Salesmen
  • Bin Packing given packages of size a1an and
    bins of size k, what is the fewest numbers of
    bins needed to store all the packages.
  • Scheduling Given tasks whose time take t1tn
    and k processors, what is minimum completion
    time?
  • Graph Given a graph find the clique of maximum
    size.
  • A clique is a completely connected subgraph.
  • Subset-sum Given a finite set S of n numbers and
    a target number t, does some subset of S sum to
    t.
  • Vertex Cover A vertex cover is a subset of
    vertices which hits every edge. The problem is to
    find a cover with the fewest number of vertices.
About PowerShow.com
