Web Server Architecture
3
C10K Problems?

• http//www.kegel.com/c10k.html (Dan Kegel,
  California Institute of Tech.)
• 3,000 Web server
• 500MHz CPU, 1GB RAM, six 100Mbps Ethernet cards
• 0.3, 50KHz, 100 KB, 60 Kbps per client at 10,000
  clients
• Hardware is no longer the bottleneck
• Sufficient to deliver 4 KB data per second to
  each of 10,000 clients.
• However, current most web servers lt 1,000
  concurrent requests/sec
• How to configure OS and write code to support
  C10K?
• Serve many clients with each server thread, and
  use non-blocking I/O
• Serve one client with each server thread
• Serve many clients with each server thread, and
  use asynchronous I/O
• Build the server code into the kernel
• kernel scalability, limits on open file handles
  and threads

4
Single-Process Event-Driven (SPED)

• Examples Zeus server, Harvest/Squid proxy
• Similar to a state machine
• Non-blocking system calls for asynchronous I/O
  operations
• to avoid context switching and thread
  synchronization overheads
• to overlap CPU, disk and network operations to
  serve many requests
• Good performance for workloads cached in the
  server main memory
• Drawbacks
• Non-blocking reads may actually block for disk
  files
• Select calls waste CPU time when serving a lot of
  concurrent connections.

5
SPED Overhead Measurement usenix98-banga

• Under real workload, SPED has to manage a lot of
  open concurrent connections due to large WAN RTTs
• Traditional UNIX kernel features (select,
  fdalloc) do not scales
• Up to 53 of CPU time sleect() related routines
• Up to 11 of CPU time user process collating
  information from the bitmaps returned by select()

select() costs measured on a Squid proxy server
running on AlphaStation with 400MHz 21164 CPU,
192 MB memory and Digital Unix 4.0B
6
Multi-Process/Multi-Threads (MP/MT)

• Example Apache server
• Assign a process to execute sequential steps to
  serve a client request
• overlap CPU, disk, and network operations by
  context switching
• Drawbacks
• context switching and synchronization overhead
• difficult for optimization on global information
  (e.g, shared URLs cache)

7
Asymmetric Multi-Process Event-Driven(AMPED)

• Example Flash
• The main SPED process handles all processing
  steps
• Non-blocking read, write, and accept system calls
  on sockets and pipes
• Helper processes to perform potentially blocking
  operations
• instructed by the main process via IPC when a
  disk operation is necessary
• mincore system call to check if a file is in main
  memory cache
• mmap system call to access data from the file
  system

8
Performance of Web Server Architectures

• Performance Evaluation usenix99-vivekon a
  333MHz Pen-II server (128 MB, multiple 100Mbps,
  FreeBSD 2.2.6)

Synthetic workload repetitive single file read
test
Real workload
9
Cluster-based Web Servers
10
Changes in Web Server Environmentswith the
Explosive Growth of World Wide Web

• Bursts as well as perpetual increase in client
  requests
• Variation of content
• Small static files -gt graphics or multimedia
  content of various size
• Increase of dynamic content
• due to new Web-based applications such as
  E-commerce
• one or two order of magnitude larger resource
  usage than static file
• HTTP/1.1 protocol is prevalent
• Persistent connections, request pipelining

11
Demand on scalable system

• Distributed or Cluster-based Network Servers
• Clustered Web server is a viable approach
• cost effective and scalable
• Burst requests and variation of content
• may cause skewed utilization among the servers
  within a cluster
• Importance of load distribution
• In order to actually attain scalable high
  performance
• Distribute the requests to the servers best
  suited to respond

12
Request Distribution (Load Balancing) Strategies

• Replication across mirrored servers
• not user-transparent as well as not controllable
• Load-balancing over a distributed Web server
  system
• Client-based approach
• DNS-based approach
• Dispatcher-based approach
• Server-based approach

13
Client-based Approaches

• Examples
• Web-clients based on random select (Netscape
  Navigator)
• Smart clients
• Client-side proxies
• Limited applicability due to
• Porting issues to client(Java applet) or network
  proxy
• Overhead message exchange with servers (load
  state, network delays)

14
DNS-based Approaches

• Cluster DNS
• translate(URL-to-IP) and specify TTL values
• distribution policies constant or adaptive TTL
  algorithms
• more user-transparent than client-based approach
• limited control due to address caching in
  intermediate name servers

15
Dispatcher-based Approaches

• Dispatcher (IP-Sprayer)
• packet single/double-rewriting, packet
  forwarding, HTTP redirect
• Examples
• Magic Router, Cisco LocalDirector/DistributedDirec
  tor, IBM NetDispatcher, Linux Virtual Server
  (LVS)
• user-transparent at IP-SVA level fine-grained
  control
• dispatcher bottleneck packet rewriting overhead

16
Dispatcher-based Approaches L4 Switch

• TCP router mechanism
• Clients know only the IP address of L4 switch
• All client requests reach the front-end
• Packet forwarding

Front-end L4 switch
Back-end servers
TCP router

• Scheduling granularity connection
• content-blind

Client
selects a server

• Scheduling algorithms
• RR, LC,
• WLC, WRR
• schedules the connections in proportion to each
  servers weight
• weight the excess capacity available for new
  connections

17
L4 Switch

• WRR Scheduling Algorithm

/ initially index 0, L (S0,S1,...,Sn-1)
/ While (1) i index if (i 0)
cw-- if (cw lt 0) cw max of
W(Sn) if (cw 0) return NULL if
(W(Si) gt cw) index (i 1) n
return Si else index (i1)
n
18
L4 Switch

• WRR weight estimation

user
Server 1
Collector
Server 2
TCP router
Server n
kernel

• Pros
• high routing throughput
• Cons
• Content-blind scheduling
• Difficult to compute weights accurately
• insufficient load information, load information
  feedback delay overhead
• Dynamic load imbalance across servers

19
Content-aware Routers L5/L7 Switch

• Main idea
• Dispatch a request to the server best suited to
  respond by inspecting URI

Front-end
Back-end servers

• Scheduling granularity connection
• but, content-aware scheduling

dispatcher (httpd)
Handoff
Client
TCP/IP

• Benefits
• Performance improvement of back-end servers
• cache affinity(locality) based scheduling
  asplos98-LARD
• Easy to specialize the back-ends for certain
  types of content or services

20
Content-aware Routers

• Routing Mechanisms

21
Content-aware Routers

• Locality-Aware Request Distribution
  asplos98-vivek

22
Content-aware Routers

• Drawbacks
• Little benefit of LARD on persistent connections
• Scheduling granularity is still per connection
• Routing throughput degradation
• Overhead due to L7 processing front-end
  bottleneck low scalability

Throughput (13 KB file)
23
Content-aware Routers

• Harvard Array of Cluster Computer
  usenixNT99-zhang
• HACC services the requests at the server
  containing the desired contentas long as total
  load does not exceed the server capacity
• If exceeds, it replicates the content into
  another server
• load weight cpu_load(dynamic page generation)
  weight storage_load)

24
Server-based Approaches

• DNS Redirection (HTTP redirection, distributed
  packet rewriting)
• policies based on server capability load state,
  network proximity
• distributed fine-grained control, extensible
  solution (LAN, WAN)
• affected by addr- mapping cache (client,
  intermediate name servers)
• latency(HTTP redirection)
• packet rewriting overhead (distributed packet
  rewriting)

25
Server-based Approaches

• TranSend Proxy within a university or a company
  sosp97-fox
• transformation (distillation, filtering, format
  conversion)
• aggregation (search, collect collate data from
  various sources)
• caching (original or transformed contents)
• customization (maintaining user preference
  database)

26
Web Server Accelerator (1)

• Factors limiting the Web server performance
• Coping the requested data several times across
  layers of software
• Overheads such as OS scheduling and interrupt
  processing
• Main idea
• Servicing frequently requested pages from caches
  in front of a Web site
• static pages, dynamic pages, or both

27
Web Server Accelerator (2)

• IBM WSA (Olympic Winter Games 98 Web site)
• Front-end (embedded OS and TCP/IP stacks
  optimization)
• reduces scheduler and interrupt processing
  overheads and duplicated copy
• maintains persistent TCP connections with
  back-end servers
• caches static as well as dynamic pages
• Routing throughput measured on a PowerPC-200MHz
• TCP-router(15K http requests/sec), Content-router
  (9.8K http requests/sec)

client
TCP router
TCP handoff (for large page)
hit
Cache accel.
Cache accel.
miss
UDP (for small page lt 2KB)
Back-end
Back-end
