Duodenal and Periampullary Neoplasms

1
Duodenal and Periampullary Neoplasms

• Kyo U. Chu, MD, FACS
• Surgical Oncology, Sinai Hospital of Baltimore

2
Duodenal and Periampullary Neoplasms
3
Benign Tumors of Small Bowel
Devita, Hellman and Rosenberg, eds. Cancer
Principles and Practice of Oncology, 5th ed.
Philadelphia Lippincott-Raven, 1997

• Most of leiomyoma is now better defined as GIST
• 10-30 are malignant
• 1/3 of gt3cm adenoma has foci of adenocarcinoma

4
Malignant Tumors of Small Bowel
Devita, Hellman and Rosenberg, eds. Cancer
Principles and Practice of Oncology, 5th ed.
Philadelphia Lippincott-Raven, 1997

• 40 of adenocarcinoma occurs in Duodenum
• 2/3 of duodenal adenoCA are periampullary
• Most of these sarcomas are malignant GIST

5
Surgical Treatment Duodenal Tumors

• Depends on
• Benign or Malignant
• Size
• Location
• Local extension to adjacent structures
• Lymph node involvement
• Distant metastasis
• Known natural history of tumor

6
Types of Surgical treatment

• Simple excision small benign, less than half the
  circumference of duodenum
• Pancreaticoduodenectomy Malignant lesion
  located at 2nd and 3rd portion of
  duodenum
• Antrectomy and/or duodenectomy Small malignant
  tumor located at 1st portion of duodenum or 4th
  portion of duodenum

7
Adenocarcinoma of Duodenum

• K-ras p53 gene similar as in CRC, but much
  less APC mutation
• Risk factors
• Crohns disease
• Villous adenomas
• Polyposis syndromes, FHx of hereditary
  nonpolyposis colorectal cancer (HNPCC)
• Mean age 60, male predominance 2.41
• No proven survival advantage with current
  chemotherapy
• Radiation therapy may be beneficial

8
Duodenal Lymphoma

• Small bowel lymphomas
• Only 5 of all lymphomas
• 15-20 of all small bowel neoplasm
• gt 25 presents with Complications
• Bleeding
• Perforation
• Obstruction
• Best managed with surgery

9
Duodenal Carcinoid

• Rare, only 2 of all SB carcinoid
• 85 of all carcinoid occur at Appendix
• 15 in small bowel (90 in ileum)
• 30 of SB carcinoid have multiple synchronous
  lesions at jejunum and ileum
• Managed similarly to adenocarcinomas
• Chemotherapy 20-30 RR
• Radiation therapy not useful
• Overall 5-year survival 60
• Resected nodal disease 15 years Median survival
  vs. 5 years unresected

10
Duodenal GIST

• 30 in Small bowel
• IHC positive for protooncogene CD117 and CD34
• Malignant potential determined by
• Mitotic frequency (gt2 mitoses/HPF)
• Nuclear atypia
• Cellularity
• Size of tumor
• Central necrosis
• Metastases in 30
• Gleevec tyrosine kinase inhibitor

11
Periampullary Neoplasm

• Carcinomas of ampulla or distal common bile duct
• Exocrine Pancreatic Cancers
• Ductal Adenocarcinoma (90)
• Acinar cell carcinoma (lt5)
• Endocrine Pancreatic Cancers
• Islet cell tumors
• Insulinoma, Glucagonoma, VIPoma etc.

12
Survival Data Localized Pancreatic
Adenocarcinoma after surgical resection
NA, Not available
13
Survival Data Localized Periampullary
(nonpancreatic) adenocarcinoma after surgical
resection
NA, Not available
14
Survival Data Localized, NODE POSITIVE
Periampullary (nonpancreatic) adenocarcinoma
after surgical resection
NA, Not available
15
Median Survival (months)
5-year Survival ()
11-18
20.3
6-12
8
5-7
1.7
Evans DB, et al. Ca of Pancreas in DeVita,
Cancer Principles Practice in Oncology 2001
Source American Cancer Society, 2008
16
Exocrine Pancreatic Cancer

• Almost all eventually die of disease, thus
  incidence rates and mortality rates were nearly
  identical in the past but separating more over
  last few decades.
• American Cancer Society
• Estimates for 2008 in United States
• New cases 37,680 (10th most common)
• Incidence rates stable over last 20-30 years
• Deaths 34,290 (4th leading cause)
• Declining in men since 1970s
• Leveled off in women since 1980s

17
Trends in Five-year Relative Survival Rates
(), 1975-2003
1984-1986
1996-2003

Site
1975-1977

• All sites 50 54 66
• Breast (female) 75 79 89
• Colon 51 59 65
• Lung and bronchus 13 13 16
• Melanoma 82 87 92
• Ovary 37 40 45
• Pancreas 2 3 5
• Prostate 69 76 99
• Rectum 49 57 66

5-year relative survival rates based on follow
up of patients through 2004. Source
Surveillance, Epidemiology, and End Results
Program, 1975-2004, Division of Cancer Control
and Population Sciences, National Cancer
Institute, 2007.
18
Exocrine Pancreatic Cancer

• Although these survival statistics are sobering,
  certain groups of patients do better.
• Clear surgical margins and no lymph node
  metastases 5-year survival is as high as
  25
• Well-differentiated tumors
• 5-year survival is 50
• Unfortunately, only a minority of patients fall
  into these categories.

• Yeo et al. Ann Surg 1995

19
Clinical Presentation

• Most common Weight loss, pain, and malnutrition
• Painless jaundice
• Abdominal Pain
• Low intensity, visceral in origin and poorly
  localized to upper abdomen
• Severe upper back pain is more characteristic of
  advanced disease
• Sudden onset of diabetes mellitus in nonobese
  adults gt40 years warrants an evaluation

20
Clinical Presentation (contd)

• Several large reviews of pancreatic cancer note
  delay in diagnosis of gt 2 months from the onset
  of symptoms in the majority of patients.
• Although many are asymptomatic at early stage,
  subtle signs and symptoms should alert possible
  diagnosis of Pancreatic cancer
• Vague abdominal pain or discomfort
• New onset of diabetes

21
Risk Factors

• Cigarette smoking (2X)
• most strongly (evidence) linked
• Chronic Pancreatitis (2X)
• 1.8 of patients with chronic pancreatitis
  developed pancreatic cancer during
  a mean follow-up of 7.4 years.
• (Fernandez et al . Pancreas 1995 Lowenfels
  et al. NEJM 1993)
• Obesity
• Family History (18-57X) only 5 of patients

22
Diagnostic Studies

• Thin-section helical CT with IV and oral contrast
• CT Resectability (accuracy 80)
• 1. Absence of extra pancreatic disease
• 2. Absence of direct tumor extension to the
  superior mesenteric artery (SMA) and celiac axis
• 3. Patent superior mesenteric-portal vein
  confluence
• Endoscopic retrograde cholangiopancreatography
  (ERCP)
• Endoscopic Ultrasound (EUS)
• Percutaneous CT-guided needle biopsy
• May be useful if initial non-surgical treatments
  are considered
• Tumor Marker CA19-9

23
(No Transcript)
24
(No Transcript)
25
Diagnostic Studies

• Thin-section helical CT with IV and oral contrast
• CT Resectability (accuracy 80)
• 1. Absence of extra pancreatic disease
• 2. Absence of direct tumor extension to the
  superior mesenteric artery (SMA) and celiac axis
• 3. Patent superior mesenteric-portal vein
  confluence
• Endoscopic retrograde cholangiopancreatography
  (ERCP)
• Endoscopic Ultrasound (EUS)
• Percutaneous CT-guided needle biopsy
• May be useful if initial non-surgical treatments
  are considered
• Tumor Marker CA19-9

26
(No Transcript)
27
(No Transcript)
28
Diagnostic Studies

• Thin-section helical CT with IV and oral contrast
• CT Resectability (accuracy 80)
• 1. Absence of extra pancreatic disease
• 2. Absence of direct tumor extension to the
  superior mesenteric artery (SMA) and celiac axis
• 3. Patent superior mesenteric-portal vein
  confluence
• Endoscopic retrograde cholangiopancreatography
  (ERCP)
• Endoscopic Ultrasound (EUS)
• Percutaneous CT-guided needle biopsy
• May be useful if initial non-surgical treatments
  are considered
• Tumor Marker CA19-9

29
ERCP and Pre-operative biliary tract drainage

• Historically was done to lower the bilirubin
• Thought to provide benefit by improving
  immunologic, hepatic and renal function
• Randomized prospective trials have failed to
  demonstrate a reduction in operative morbidity or
  mortality following routine preoperative biliary
  drainage.
• Decompression is recommended only
• For patients with symptomatic jaundice who are to
  be treated with pre-operative radiation or
  chemotherapy.

30
Diagnostic Studies

• Thin-section helical CT with IV and oral contrast
• CT Resectability (accuracy 80)
• 1. Absence of extra pancreatic disease
• 2. Absence of direct tumor extension to the
  superior mesenteric artery (SMA) and celiac axis
• 3. Patent superior mesenteric-portal vein
  confluence
• Endoscopic retrograde cholangiopancreatography
  (ERCP)
• Endoscopic Ultrasound (EUS)
• Percutaneous CT-guided needle biopsy
• May be useful if initial non-surgical treatments
  are considered
• Tumor Marker CA19-9

31
(No Transcript)
32
Tumor Marker CA 19-9

• gt 90 U/mL 85 Accuracy
• gt 200 U/mL 95 Accuracy
• gt 750 U/mL associated with Advanced Disease
• Combination of CT and CA 19-9 (gt100 U/mL) has PPV
  of 99-100

33
Surgical Treatment

• Still remains as only potentially curative
  modality
• No role in the presence of metastatic disease
• Intraoperative Evaluation for resectability
• Liver
• Peritoneum
• Para-aortic lymphatic/root of mesentery
• Primary tumor

34
(No Transcript)
35
Pancreaticoduodenectomy
36
(No Transcript)
37
(No Transcript)
38
Earlier Surgical Results Pancreaticoduodenectomy

• Historically (1960s) Poor Surgical Outcome
• Morbidity gt 50
• Mortality 20
• Lieberman et al., Ann Surg 1995 (New York State,
  1984-1991)
• 75 at hospitals with lt 7cases/year
• Mean hospital stay gt 1 month
• Risk-adjusted perioperative mortality 12-19

39
Recent Surgical Result McPhee et al, Ann Surg
August 2007

• Examined in-hospital mortality after
  pancreatectomy
• Based on large national database, National
  Inpatient Sample (NIS), from 1998-2003
• 7 million nonfederal hospital discharges/year
• 279,445 patients with pancreatic cancer
• 39,463 patients underwent resection (14)

40
Pancreatectomy Mortality

• PD or Whipple (72) - 6.6
• Decrease Trend
• 8.2 in 1998 to 5.5 in 2003
• Men vs. Women 8.2 vs. 4.8
• Age gt70 vs. lt50 9.5 vs. 2.6
• Low/Medium volume vs. High volume center
  (gt18/year)
• 11.1 vs. 2.7

McPhee et al, Ann Surg August 2007
41
Pancreatectomy Mortality

• Distal Pancreatectomy (21) - 3.5
• Men vs. women 4.9 vs. 2.8
• Age gt70 vs. lt50 6.5 vs. 0.3
• Low/medium volume vs. High volume Center
• 5.1 vs. 0.43
• Total Pancreatectomy (3.7) 8.3
• Hospital volume, age, and sex did not influence
  mortality rate

McPhee et al, Ann Surg August 2007
42
5-year survival, Morbidity and Mortality after
Whipple
43
Advance in SurvivalGemcitabine (Gemzar) after
Whipple

• Phase III Randomized prospective multicenter
  trial
• 6 months of Gemcitabine after surgical resection
• Disease-Free Survival
• 13.4 months vs. 6.9 months
• Overall Survival
• 22.8 months vs. 20.2 months

Neuhaus et al., ASCO meeting May-June 2008
44
Surgical Oncology Sinai Hospital (2005-2007)

• Total number of Pancreatectomies - 65
• PD or Whipple - 49
• Distal Pancreatectomy - 16
• Mortality - 0
• Morbidity - 15

45
Improved Surgical Outcome

• Better patient selection for Surgery
• Advances in CT or imaging for accurate staging
• Laparoscopy
• Improved Surgical Procedure
• Regionalization of high risk cases
• Experience of Surgeons
• Advance in operative instruments and equipments
• Improved Peri-operative Management
• Anesthesia
• Critical Care

46
American College of Surgeons National Cancer Data
Base (NCDB) 1995-2004

• Total patients with pancreatic cancer 192,565
• 9559 (5) clinically stage I and potentially
  resectable
• Only 29 had SURGERY
• 96 success 4 unresectable
• Median Survival
• Resected 19months
• No Surgery 8 months
• 5-year survival for resected 19

Bilimoria et al, Ann Surg August 2007
47
American College of Surgeons National Cancer Data
Base (NCDB) 1995-2004

• Of 9559 clinically stage I and potentially
  resectable, 71 had NO SURGERY
• 19 clear reason given
• 9 Age, 4 refused, 6 comorbidities
• 52 no clear reason given
• nihilistic attitudes toward the disease among
  patients, referring physicians and some surgeons

Bilimoria et al, Ann Surg August 2007
48
Summary

• Early detection
• Clinical diagnosis early signs or symptoms
  and risk factors
• Improved Imaging and Diagnostic studies
• All Resectable pancreatic cancer should be
  offered surgical resection
• Improved surgical Outcome
• Restrain Fatalistic attitude

49
Cyberknife
50
Stereotactic Radiosurgery (STRS) or Cyberknife
(CK) in Surgical OncologySinai Experience Feb 3,
2004 Oct 7, 2006
51
CK Contouring Pancreas
52
Sinai CyberKnife Experience Pancreatic
CancerPatient Characteristics

• Total number 45
• Age range 43 84 years, median 64
• Location of tumor
  head 31 (69), body 14 (31)
• Stage T3 T4 45, N1/NX 45, M1 8 (18)
• Prior RT 20 (45)
• Prior surgical resection 9 (20)
• Prior chemo 15 (33)

53
CK Treatment

• GTV (gross tumor volume) median 65 cc (11 -
  189 cc)
• CK dose median 25.2 Gy
• Number of fractions mean 3 (range 1-4)
• Isodose median 0.8 (0.7 0.88)

54
Results

• Pain relief 24/28 (86)
• CA 19-9 response 15/35 (43)
• Local tumor control 91
• Complete Response 4 (9)
• Partial Response 19 (42)
• Stable Disease 18 (40)
• Progressive Disease 4 (9)
• Distant progression 30 (67)

55
Survival Time from CyberKnife Treatment Local
Response
56
Toxicity
57
CK CONCLUSIONS

• CyberKnife is alternative treatment modality for
• Unresectable pancreatic cancer
• Poor surgical candidate
• Acute toxicity was minimal
• GI toxicity (Duodenitis or gastritis) is a major
  side effect
• mainly in patients with tumors gt70cc
• Convenience Delivered in 2-3 sessions without
  hospitalization
• Local tumor control and improves the pain in most
• Shows a trend towards improvement in survival,
  compared to historical controls
• No impact on development of distant metastases

58
(No Transcript)
59
Post-Operative Complications
60
Survival Time from Diagnosis - All Patients
Median 18.4 mos Mean 20.4 mos
Estimated Survival Function
61
Survival Time from CK Treatment - All Patients
Median 8.3 mos Mean 11.3 mos
Estimated Survival Function
62
Correlation of Survival After CK Treatment
63
Survival Time from CK Treatment - Prior RT
64
Survival Time from CK Treatment Distant
Progression
65
Acute Duodenitis
66
Late Duodenal Ulcer
67
CyberKnife Treatment for Pancreatic Cancer
68
Duodenal and Periampullary Neoplasms
